Quanmax QDSP-1100 Series User manual

QDSP-1100 series User’s Manual
QDSP-1100 Series
0.6-Liter Box PC with Intel®Core i3-3227U Processor
User’s Guide

Content
QDSP-1100 series User’s Manual
Content
Content.......................................................................................................................2
Figures & Tables.........................................................................................................3
Safety Instructions......................................................................................................4
Before You Begin..................................................................................4
When Working Inside a Computer........................................................5
Preventing Electrostatic Discharge.......................................................5
Instructions for Lithium Battery .............................................................6
Voltage Ratings.....................................................................................6
Preface.......................................................................................................................7
How to Use This Guide.........................................................................7
Unpacking.............................................................................................7
Regulatory Compliance Statements......................................................7
Maintaining Your Computer...................................................................8
Chapter 1 Introduction........................................................................................... 11
Overview............................................................................................. 11
Product Specifications ........................................................................12
System tour.........................................................................................13
Mechanical Dimensions......................................................................15
Chapter 2 Getting Started......................................................................................16
Setting up your PC..............................................................................16
Mounting your PC to a monitor...........................................................19
Anti-theft protection with a Kensington Lock.......................................20
Chapter 3 AMI BIOS Setup....................................................................................21
Overview.............................................................................................21
Main Menu..........................................................................................22
Advanced Menu..................................................................................23
Boot Menu ..........................................................................................30
Security Menu.....................................................................................31
Save & Exit Menu...............................................................................31
Chapter 4 Driver Installation..................................................................................33

Figures & Tables
QDSP-1100 series User’s Manual
Figures & Tables
Figure 1 Front Panel..................................................................................13
Figure 2 Rear Panel...................................................................................14
Figure 3 Mechanical Dimensions...............................................................15
Figure 4 DP/ HDMI.....................................................................................16
Figure 5 Connecting USB mouse & keyboard............................................17
Figure 6 RJ45 connector............................................................................17
Figure 7 Turning on the system .................................................................18
Figure 8 VESAmounting............................................................................19
Figure 9 Use a Kensington lock.................................................................20
Table 1 QDSP-1100 Series product specification.......................................12
Table 2 BIOS Main Menu...........................................................................22
Table 3Advanced Menu.............................................................................23
Table 4 Advanced Menu – Display Configuration.......................................24
Table 5 Advanced Menu –Power Management Configuration....................25
Table 6 Advanced Menu –CPU Advanced Configuration...........................26
Table 7Advanced Menu –SATA Configuration...........................................27
Table 8Advanced Menu –Intel (R) Rapid Start Technology .......................27
Table 9Advanced Menu –USB Configuration............................................28
Table 10 Advanced Menu –H/W Monitor....................................................29
Table 11 Boot Menu ...................................................................................30
Table 12 Security Menu .............................................................................31
Table 13 Save & Exit Menu........................................................................31

Safety Instructions
QDSP-1100 series User’s Manual
Safety Instructions
Before You Begin
Before handling the product, read the instructions and safety guidelines on the
following pages to prevent damage to the product and to ensure your own personal
safety. Refer to the “Advisories” section in the Preface for advisory conventions used
in this user’s guide, including the distinction between Warnings, Cautions, Important
Notes, and Notes.
Always use caution when handling/operating a computer. Only qualified,
experienced, authorized electronics service personnel should access the
interior of a computer. The power supplies produce high voltages and
energy hazards, which can cause bodily harm.
Use extreme caution when installing or removing components. Refer to the
installation instructions in this user’s guide for precautions and procedures.
If you have any questions, please contact our Post-Sales Technical
Support.
Access can only be gained by service persons or by users who have
been instructed about the reasons for the restrictions applied to the
location and about any precautions that shall be taken; and access is
through the use of a tool or lock and key, or other means of security,
and is controlled by authority responsible for the location.
WARNING
High voltages are present inside the chassis when the unit’s power cord is plugged into
an electrical outlet. Turn off system power, turn off the power supply, and then
disconnect the power cord from its source before removing the chassis cover. Turning off
the system power switch does not remove power to components.

Safety Instructions
QDSP-1100 series User’s Manual
When Working Inside a Computer
Before taking covers off a computer, perform the following steps:
1. Turn off the computer and any peripherals.
2. Disconnect the computer and peripherals from their power sources or
subsystems to prevent electric shock or system board damage. This does not
apply when hot swapping parts.
3. Follow the guidelines provided in “Preventing Electrostatic Discharge” on the
following page.
4. Disconnect any telephone or telecommunications lines from the computer.
In addition, take note of these safety guidelines when appropriate:
To help avoid possible damage to system boards, wait five seconds after
turning off the computer before removing a component, removing a system
board, or disconnecting a peripheral device from the computer.
When you disconnect a cable, pull on its connector or on its strain-relief loop,
not on the cable itself. Some cables have a connector with locking tabs. If you
are disconnecting this type of cable, press in on the locking tabs before
disconnecting the cable. As you pull connectors apart, keep them evenly
aligned to avoid bending any connector pins.Also, before connecting a cable,
make sure both connectors are correctly oriented and aligned.
CAUTION
Do not attempt to service the system yourself except as explained in this user’s guide.
Follow installation and troubleshooting instructions closely.
Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation
and follow proper ESD procedure to reduce the risk of damage to components. We
strongly encourage you to follow proper ESD procedure, which can include wrist
straps and smocks, when servicing equipment.
You can also take the following steps to prevent damage from electrostatic
discharge (ESD):
When unpacking a static-sensitive component from its shipping carton, do not

Safety Instructions
QDSP-1100 series User’s Manual
remove the component’s antistatic packing material until you are ready to install
the component in a computer. Just before unwrapping the antistatic packaging,
be sure you are at an ESD workstation or grounded. This will discharge any
static electricity that may have built up in your body.
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components at an ESD workstation. If possible, use
antistatic floor pads and workbench pads.
Handle components and boards with care. Don’t touch the components or
contacts on a board. Hold a board by its edges or by its metal mounting bracket.
Do not handle or store system boards near strong electrostatic, electromagnetic,
magnetic, or radioactive fields.
Instructions for Lithium Battery
WARNING
Danger of explosion when battery is replaced with incorrect type. Only replace
with the same or equivalent type recommended by the manufacturer.
Do not dispose of lithium batteries in domestic waste. Dispose of the battery
according to the local regulations dealing with the disposal of these special
materials (e.g. to the collecting points for disposal of batteries)
Voltage Ratings
The external power adaptor of the QDSP-1100 Series has the following voltage
ratings:
Input: 100-240 VAC, 50-60 Hz
Output: 40W, +19VDC/2.1A output

Preface
QDSP-1100 series User’s Manual
Preface
How to Use This Guide
This guide is designed to be used as step-by-step instructions for installation, and as
a reference for operation, troubleshooting, and upgrades.
Unpacking
When unpacking, follow these steps:
1. After opening the box, save it and the packing material for possible future
shipment.
2. Remove all items from the box. If any items listed on the purchase order
are missing, notify our customer service immediately.
3. Inspect the product for damage. If there is damage, notify our customer
service immediately. Refer to “Warranty Policy” for the return procedure.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class B devices.
FCC Compliance Statement:
This equipment has been tested and found to comply with limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reason able protection against harmful interference in residential installations. This
equipment generates, uses, and can radiate radiofrequency energy, and if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
interference to radio or television equipment reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the

Preface
QDSP-1100 series User’s Manual
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by us could void the user's
authority to operate the equipment.
NOTE
The assembler of a personal computer system may be required to test the system
and/or make necessary modifications if a system is found to cause harmful
interference or to be noncompliant with the appropriate standards for its intended use.
Maintaining Your Computer
Environmental Factors
Temperature
The ambient temperature within an enclosure may be greater than room
ambient temperature. Installation in an enclosure should be such that the
amount of air flow required for safe operation is not compromised.
Consideration should be given to the maximum rated ambient temperature.
Overheating can cause a variety of problems, including premature aging and
failure of chips or mechanical failure of devices.
If the system has been exposed to abnormally cold temperatures, allow a
two-hour warm-up period to bring it up to normal operating temperature before
turning it on. Failure to do so may cause damage to internal components,
particularly the hard disk drive.
Humidity
High-humidity can cause moisture to enter and accumulate in the system. This
moisture can cause corrosion of internal components and degrade such
properties as electrical resistance and thermal conductivity. Extreme moisture
buildup inside the system can result in electrical shorts, which can cause
serious damage to the system.
Buildings in which climate is controlled usually maintain an acceptable level of
humidity for system equipment. However, if a system is located in an unusually
humid location, a dehumidifier can be used to maintain the humidity within an
acceptable range. Refer to the “Specifications” section of this user’s guide for

Preface
QDSP-1100 series User’s Manual
the operating and storage humidity specifications.
Altitude
Operating a system at a high altitude (low pressure) reduces the efficiency of
the cooling fans to cool the system. This can cause electrical problems related
to arcing and corona effects. This condition can also cause sealed components
with internal pressure, such as electrolytic capacitors, to fail or perform at
reduced efficiency.
Power Protection
The greatest threats to a system’s supply of power are power loss, power spikes,
and power surges caused by electrical storms, which interrupt system operation
and/or damage system components. To protect your system, always properly
ground power cables and one of the following devices.
Surge Protector
Surge protectors are available in a variety of types and usually provide a level
of protection proportional with the cost of the device. Surge protectors prevent
voltage spikes from entering a system through theAC power cord. Surge
protectors, however, do not offer protection against brownouts, which occur
when the voltage drops more than 20 percent below the normal AC line voltage
level.
Line Conditioner
Line conditioners go beyond the overvoltage protection of surge protectors.
Line conditioners keep a system’sAC power source voltage at a fairly constant
level and, therefore, can handle brownouts. Because of this added protection,
line conditioners cost more than surge protectors. However, line conditioners
cannot protect against a complete loss of power.
Uninterruptible Power Supply
Uninterruptible power supply (UPS) systems offer the most complete protection
against variations on power because they use battery power to keep the server
running when AC power is lost. The battery is charged by theAC power while it
is available, so when AC power is lost, the battery can provide power to the
system for a limited amount of time, depending on the UPS system.
UPS systems range in price from a few hundred dollars to several thousand
dollars, with the more expensive unit s allowing you to run larger systems for a

Preface
QDSP-1100 series User’s Manual
longer period of time when AC power is lost. UPS systems that provide only 5
minutes of battery power let you conduct an orderly shutdown of the system,
but are not intended to provide continued operation. Surge protectors should be
used with all UPS systems, and the UPS system should be Underwriters
Laboratories (UL) safety approved.

Chapter 1
QDSP-1100 series User’s Manual
Chapter 1
Introduction
Overview
The QDSP-1100 Series is a Box PC with a volume of just 0.6-liter that is ideal for
space critical applications. This embedded hardware platform is designed with
Intel® Core i3-3227U processor which provides with excellent performance. System
is supported with Intel® HM76 Express chipset, and DDR3 SO-DIMM up to 8 GB.
Featured are 1x 2.5” SATA HDD /SSD, 2x GbE, 2x USB 2.0, 4x USB 3.0, HDMI, 2x
DP, and S/PDIF..
Checklist
QDSP-1100 Series
Power Adapter
Power Cord
Driver CD
Quick installation Guide
VESA Mounting Kit (optional)
Wireless LAN, 3G (optional)
Features
Intel®Core i3-3227U Processor
Intel®HM76 Express Chipset
Support DDR3 1333 / 1600 MHz SO-DIMM up to 8 GB
Support 1xHDMI, 2xDP, 2xGbE and S/PDIF, 2x USB2.0, 4x USB3.0
Support 1x 2.5” SATA HDD / SSD
Support up to triple-independent displays

Chapter 1
QDSP-1100 series User’s Manual
Product Specifications
Construction Aluminum
CPU/ Chipset Intel
®
Core i3-3227U Processor
Intel®HM76 Express Chipset
Memory DDR3 1333/ 1600 SO-DIMM up to 8GB
I/O Panel
■
Front I/O panel
1x Push button (w/LED) for power on/off
1x WiFi LED
1x HDD LED
2x USB2.0
4x USB3.0
1x S/PDIF
■Rear I/O panel
1x DC JACK
2x RJ-45, GbE ports
2x DP
1x HDMI
1x WiFi / 3G Antenna ( Optional )
1x Clear CMOS
1x Kensington Lock
Storage
QDSP-1100 - 1x 500GB 2.5” SATA HDD
QDSP-1101 - 1x 320GB 2.5” SATA HDD
QDSP-1102 - 1x 32GB SSD
Expansion 3G or WiFi
Power Supply Input: 100-240 VAC, 50-60 Hz
Output: 40W, +19VDC / 2.1A output
Cooling System Fan
OS Support Windows 7 / Windows 8 / Linux
Temperature /
Humidity Operating: 0°C to 50°C, 0%-90%, non-condensing
Storage: -20°C to 80°C, 0%-90%, non-condensing
Dimensions 130 x 35 x 111 mm (WxHxD)
Weight
440 g
Mounting
VESA mount ( Optional)
Certifications
CE, FCC Class A
Table 1 QDSP-1100 Series product specification

Chapter 1
QDSP-1100 series User’s Manual
System tour
Refer to the diagrams below to identify the components of the system.
Front Panel
Figure 1 Front Panel
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral
acting as additional plug-in sites or hubs.
WiFi LED
The WiFi LED will light when the WiFi is on.
HDD LED
The hard disk LED blinks when data is being written into or read from the HDD.
S/PDIF
S/PDIF output for carrying digital audio signals out to the device.
Power Switch
The power switch allows powering ON and OFF the system.

Chapter 1
QDSP-1100 series User’s Manual
Rear Panel
Figure 2 Rear Panel
Ethernet
The eight-pin RJ-45 LAN port supports a standard Ethernet cable for
connection to a local network.
DC Jack
The supplied power adapter convertsAC power to DC for use with this jack.
Power supplied through this jack supplies power to the PC. To prevent damage
to the PC, always use the supplied power adapter.
DP
DP is a display interface used to connect a video source to a display device such as
a computer monitor or a television set.
HDMI
HDMI connector for display output
Wireless / 3G
1x reserved holes for wireless/ 3G antenna connection.
Clear CMOS
1x reset button for clear CMOS.
Kensington Lock Slot
The slot is used for attaching a lock-and-cable apparatus. Locks are generally
secured in place with a key or combination lock attached to a rubberized metal
cable.

Chapter 1
QDSP-1100 series User’s Manual
Mechanical Dimensions
130 x 35 x 111 mm (WxHxD)
Figure 3 Mechanical Dimensions

Chapter 2
QDSP-1100 series User’s Manual
DP
HDMI
Chapter 2
Getting Started
Setting up your PC
Connecting the monitor
Connect the DP/ HDMI cable from your display to the DP/ HDMI port.
Figure 4 DP/ HDMI

Chapter 2
QDSP-1100 series User’s Manual
Connecting USB mouse & keyboard
Your QDSP-1100 Series does not come with a keyboard and mouse, but you can use
any USB keyboard or mouse with your computer.
Figure 5 Connecting USB mouse & keyboard
NOTE
Using a third-party USB mouse or keyboard may require software drivers.
Check the manufacturer’s website for the latest software drivers.
Connecting to a network device
Connect one end of a network cable to the LAN port on the system rear panel and
the other end to a hub or switch.
Figure 6 RJ45 connector
USB 3.0
RJ45
USB 2.0

Chapter 2
QDSP-1100 series User’s Manual
DC Jack
Turning on the system
1. Connect the power adapter cable to the DC jack (DC IN) of
the QDSP-1100 Series
2. Connect the power cable to the power adapter
3. Connect the power cable to a power outlet
4. Press the power switch on the front panel to turn on the system
Figure 7 Turning on the system
On/Off

Chapter 2
QDSP-1100 series User’s Manual
Mounting your PC to a monitor
1. Secure the VESAmounting kit to your monitor with four screws.
NOTE
To fasten the metal shelf, your monitor must comply with VESA75 or
VESA100 standard. The VESA mounting kit is optional.
2. Place the QDSP-1100 Series on the VESA mounting bracket and make sure
the bracket is hooked with the fins of the system housing.
3. Secure the screw with the VESA mounting bracket and make sure the
QDSP-1100 Series is solidly secured to the display.
Figure 8 VESA mounting
NOTE
When mounting the unit on the wall with a display. The total weight of the
unit and display won’t exceed 7 Kg.

Chapter 2
QDSP-1100 series User’s Manual
Anti-theft protection with a Kensington Lock
The QDSP-1100 Series has a Kensington lock slot for the Kensington MicroSaver.
With the Kensington MicroSaver, a sturdy steel cable, you can attach your
QDSP-1100 Series to a stationary object and protect your PC from theft.
Figure 9 Use a Kensington lock
K Lock
