Quantum Scalar i6000 Drive
Replacement
Use this procedure to replace a tape drive in a Scalar i6000 library.
If a drive fails, the library will issue a ticket. From the Details screen, write down
the Repair Link or Error Code number. You’ll need it when you contact
Quantum Service.
WARNING: Before performing any of the steps listed in this document,
contact Quantum Service for help diagnosing the problem.
WARNING: To use this procedure, all drives must be connected to an Ethernet
Expansion Blade (EEB) or an FC I/O blade.
Refer to the following sections and follow the steps in the document to replace
a drive in your Scalar i6000 library:
•Locating a Drive on page 2
•Remove and Replace the Drive on page 4
•Update the Drive Firmware Using Firmware Images on page 8

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
2 Locating a Drive
Locating a Drive
When a drive fails, a ticket is generated by the library that will identify the
malfunctioning drive using a coordinate system. This section will explain the
basics of locating a drive using the coordinate system so when you are replacing
the drive, you will be able to identify the correct drive. Removing a drive
incorrectly can impact data on your library.
The drive coordinate system has six (6) numbers, for example: 1, 2, 1, 7, 1, 1.
The first number identifies the aisle. The Scalar i6000 is a single aisle library only
so this number is always 1.
The second number identifies the module. The module number can be from 1-
16. This applies to both single- and dual-robot libraries. The left parking module
(module 0) is only for dual-robot libraries and cannot contain drives. A high-
density expansion module (HDEM) also cannot contain drives.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
Locating a Drive 3
The third number in the sequence represents the rack. Since drives can only be
contained in rack 1, this number will always be 1.
The fourth number indicates the section. Each module can contain 12 drives so
with drives, this number can range from 1-12. Drives are counted from bottom
to top.
The fifth number in the sequence identifies the column. Since drives can only be
contained in a single column, they will always reside in column 1.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
4 Remove and Replace the Drive
The sixth number denotes the row and will always be 1. Drives have a
connection point at the lower portion of the drive sled that connects to the
library. Therefore, the sled is logically in row 1.
Remove and Replace the Drive
Note: This procedure is used to replace a drive with the same drive model.
Drive upgrades must be performed by Quantum service personnel. If
the failed drive is an EDLM drive, it must be replaced by Quantum
service personnel.
Caution: Before starting this procedure, verify that you have received the
same make and model drive as the drive you are replacing. The
outside of the box will indicate the drive make and model that was
shipped.
Required tool: Phillips screwdriver - use this if the thumbscrews are too tight
1Stop any processes on the host that are communicating with the drive that
is being replaced.
2Log on as the administrator from the library’s touch screen (LMC).
3Locate the drive identified as needing replacement on your call with
Quantum Service:
aSelect View > Physical Library.
bSelect Tools > Drives. The Drives screen displays.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
Remove and Replace the Drive 5
cUsing the coordinates, select the drive to be replaced.
dScroll over to the Firmware Version column.
eWrite down the four digit firmware level.
4Click Cancel to close the Drives screen.
5Double check that there is no tape in the drive you are removing. If there is
a cartridge in the tape drive:
aSelect View > Partition. You will select the partition that contains the
drive you are replacing.
bSelect Operations > Drives > Unload. This will eject the tape from the
drive and return it in its storage slot in the library.
Note: If a tape is in the drive and cannot be ejected, call Quantum
support before proceeding.
6Go back to library view by selecting View > Physical Library.
7Select Tools > Drives. The Drives screen displays.
8Vary off the drive:
aFrom the Drives screen, use the Drive Type drop-down menu to display
the drives by drive type.
bSelect the drive, and then click Vary Off.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
6 Remove and Replace the Drive
cClick Yes.
dGo to the rear of the module containing the drive to be replaced, open
the back door, locate the drive using the coordinates from the ticket and
observe the blue LED on the rear of the drive. When the blue LED stops
blinking and remains constantly lit, you can continue.
Guide Rail
Thumbscrews
Blue LED
Green Port LED 1
Amber LED
Green LED 2
Drive Handle
9Disconnect all cables from the drive. Note which cables go to which
connections for reference during drive replacement.
10 Loosen the two thumbscrews on the drive.
11 Grip the drive handle and pull the drive toward you to remove it.
12 Use the guide rails on the replacement drive to slowly slide it in until flush.
13 Tighten the two thumbscrews.
14 Reconnect the cables.
15 Confirm the following status LEDs:
aBlue LED light on the back of the drive is constantly lit
bGreen LED 2 light on the back of the drive is blinking slowly and in
cadence with the LEDs on the other drives
Note: The LEDs should take less than 5 minutes to get to this state.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
Remove and Replace the Drive 7
16 If the LEDs are displaying properly, you can vary on the drive. From the
Drives screen:
aSelect the newly installed drive.
bClick the Vary On button.
cClick Cancel.
17 The library may update the drive sled firmware. Wait a few minutes to see if
a dialog box appears. If this happens, wait until it is complete before
continuing. The drive sled firmware update will take approximately 5
minutes.
18 Go to the rear of the module and observe the drive status LEDs and wait for
the following conditions to occur:
•Green LED 1 - solid green indicating port connectivity to either the
FC I/O blade or the customer FC switch
•Amber LED - off
•Blue LED - blinks one time per 10 seconds
•Green LED 2 - blinks at the same cadence as the other green LEDs on
the other drives in the module
Blue LED
Green Port LED 1
Amber LED
Green LED 2
19 Close the access doors.
20 Close the ticket that was generated for the failed drive.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
8 Update the Drive Firmware Using Firmware Images
Update the Drive Firmware Using Firmware Images
Note: This procedure should only be used if drive auto-leveling is turned off.
Note: If you are viewing a partition, drive firmware update operations affect
drives that are within the partition only.
Note: You can only perform firmware updates for drives of the same product,
such as IBM LTO-4 or HP LTO-5.
Caution: If you load a firmware image onto a drive that is the same version
that is currently running on the drive, the upgrade will fail.
1From the View menu, select the partition that contains the replacement
drive.
2Select Tools > Update Software > Drives. A warning dialog box displays
stating the partition needs to be taken offline.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
Update the Drive Firmware Using Firmware Images 9
3Click Yes.
4From the Update Drive Firmware screen, ensure the option selected in the
Update Method area is set to Firmware Image.
5Click the check box next to the replacement drive.
6Compare the four digit firmware level you wrote down earlier with the four
digit firmware version listed in the Firmware column of the selected drive. If
they match, go to step 12. If not, continue on to step 7.
7From the Select Firmware File drop-down menu, select the firmware image
you want to install.
The drop-down list includes all drive firmware images that are currently
stored on the library, regardless of drive type. Be careful to select a drive
firmware image that is compatible with the type of drive that you want to
update. See the library's Release Notes for compatibility information or
contact Quantum technical support.
For details on downloading drive firmware, see Chapter 15, Maintaining
Your Library - Maintenance Actions in the Scalar i6000 User’s Guide.
8Click Start. A warning dialog box displays stating the operation cannot be
canceled.
9Click Yes. The library automatically logs off other users so they cannot
perform library operations while the drive firmware update is in progress.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
10 Update the Drive Firmware Using Firmware Images
Note: On the back of the drive, the Green LED 2 will flash rapidly while
the firmware update is in progress.
10 The library updates the firmware on the selected drive.
Note: Updating drive firmware could take up to 20 minutes to complete.
11 When finished, the Status column of the drive will state Update Complete
and the LEDs on the back of the drive will display:
•Green LED 1 - solid green indicating port connectivity to either the
FC I/O blade or the customer FC switch
•Amber LED - off
•Blue LED - blinks one time per 10 seconds
•Green LED 2 - blinks at the same cadence as the other green LEDs on
the other drives in the module
12 Click Close.
13 Select View > Views. The Manage Views screen displays.
14 Click the Offline button for the partition that contains the replacement
drive. The Change Library Mode screen displays.
15 In the Mode area on the Change Library Mode screen, select Online and
click OK. The Manage View dialog shows the partition now Online.
16 Click Close.

Quantum Scalar i6000: Drive Replacement
6-67999-01 Rev A
October 2013
Update the Drive Firmware Using Firmware Images 11
17 From your applications, bring the replacement drive online and perform any
necessary tests to ensure it is working properly.
18 Call Quantum Service to confirm that drive replacement was successful and
to perform any further troubleshooting.
Note: When the drive replacement is complete, refer to the documentation
that was included in the drive packaging for how to return the failed
drive to Quantum.
