Owner’s Manual

SAFETY GUIDELINES
Thesymbolsbeloware used throughout this owner's manual and on the power chair to identify warnings and important
information.It is veryimportantforyoutoreadthem and understandthemcompletely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage or malfunction.
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment.
PROHIBITED! These actions should be prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel and/
or damage to equipment.
Copyright© 2005
PrideMobility ProductsCorp.
INFMANU2973/RevC/November2005
www.quantumrehab.com Quantum 1402

Quantum 1402 www.quantumrehab.com 3
I. INTRODUCTION.....................................................................................................................................4
II. SAFETY.....................................................................................................................................................5
III. YOUR POWER CHAIR........................................................................................................................15
IV. ASSEMBLY.............................................................................................................................................20
V. COMFORT ADJUSTMENTS............................................................................................................23
VI. BATTERIES AND CHARGING ........................................................................................................29
VII. OPERATION...........................................................................................................................................33
VIII.CARE AND MAINTENANCE ............................................................................................................41
IX. WARRANTY............................................................................................................................................45
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetherightto make changesastheybecomenecessary.Anychangestoourproducts maycauseslightvariations
betweenthe illustrationsandexplanationsinthismanualand theproductyouhavepurchased.

4 www.quantumrehab.com Quantum 1402
I. INTRODUCTION
SAFETY
WELCOME to Quantum Rehab, a division of Pride Mobility Products Corporation (Pride). The product you have
purchasedcombinesstate of theartcomponents with safety,comfort and stylinginmind.We are confidentthe design
featureswill provide youwith the conveniencesyou expect duringyour daily activities.Understanding how tosafely
operateandcare for this productshould bringyou yearsof troublefree operationsand service.
Readandfollowallinstructions,warningsandnotesinthismanualandallotheraccompanyingliteraturebeforeattemptingto
operatethisproductforthefirsttime.Inaddition,yoursafetydependsuponyou,aswellas yourdealer,carerorhealthcare
professionalinusinggoodjudgement.
Ifthere is any information inthismanualwhichyoudonotunderstand,orif you require additional assistance forsetupor
operation,please contact your QuantumRehabSpecialist. Failure tofollowtheinstructions,warnings andnotes in
thismanualand thoselocatedonyour Prideproductcanresult inpersonalinjuryor productdamageandvoid
Pride’sproductwarranty.
PURCHASER’S AGREEMENT
Byaccepting delivery ofthis product, youpromise that youwill not change,alter or modifythis product orremove or
renderinoperable or unsafeanyguards,shieldsorother safety featuresofthisproduct;fail,refuseor neglect toinstallany
retrofitkitsfrom time to time providedby Prideto enhanceor preservethe safeuse ofthis product.
INFORMATION EXCHANGE
We want to hear your questions, comments and suggestions about this manual. We would also like to hear about the
safetyandreliabilityofyournew Prideproduct,andabout theserviceyoureceived fromyourQuantumRehabSpecialist.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
productsand new optionsthatcan increase yourability to useandenjoy your Prideproduct. Please feelfree tocontact
us at the address below:
PrideMobility Products Ltd.
Unit106, Heyford ParkCamp Road
UpperHeyford,Oxfordshire OX25 5HA
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.
MyQuantum RehabSpecialist is:
Name:_____________________________________________________________________________________
Address:____________________________________________________________________________________
PhoneNumber:_______________________________________________________________________________
PurchaseDate:________________________________________________________________________________

Quantum 1402 www.quantumrehab.com 5
II. SAFETY
Pinch/Crush points created during assembly.
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to reduce
the risk of leakage or explosive conditions.
EMI-RFI! This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight. Refer to specifications table.
Unlocked and in freewheel mode.
Place unit on level ground and stand in front or to one side when changing from drive
mode to freewheel mode or freewheel mode to drive mode.
Locked and in drive mode.
PRODUCT SAFETY SYMBOLS
Thesymbols below are used onthepowerchairtoidentifywarnings,mandatoryactions and prohibited actions. Itisvery
importantfor you to read and understand them completely.

6 www.quantumrehab.com Quantum 1402
II. SAFETY
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to TT
TT
T with ++
++
+
Connect Black wire to TT
TT
T with ––
––
–
Do not remove anti-tip wheels.
Do not use a cell phone, walkie/talkie, laptop or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt or standing water whenever possible. Maintain and
store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly install an
approved 3-pronged adapter to an electrical outlet having 2-pronged plug access. Failure to
heed could result in personal injury and/or property damage.
Prevent personal injury and equipment damage. Do not connect an extension lead to the
AC/DC converter or the battery charger.

Quantum 1402 www.quantumrehab.com 7
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastateoftheartlife-enhancementdevicedesignedtoincreasemobility.Pride provides an extensive
varietyof productsto best fitthe individualneeds of the power chairuser. Please beaware that the final selectionand
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof making such a decision, and his/her healthcare professional (i.e., medical doctor,physicaltherapist,etc.).
Thecontents of this manual are based on the expectation that a mobility device expert hasproperlyfittedthepowerchair
tothe userandhasassisted theprescribinghealthcareprofessionaland/or theQuantumRehabSpecialistin theinstruction
processfor the useof the product.
Therearecertainsituations,includingsomemedical conditions,wherethe powerchairuser willneedto practiceoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities,youwillprobablyencounter situationsinwhich youwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumanoeuvrethroughdoorways,
onandoff of lifts, upand downramps andover moderateterrain.
Beloware some precautions, tips and other safety considerations that will helptheuserbecomeaccustomedtooperating
thepower chair safely.
Modifications
Pridehasdesignedand engineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderange ofaccessories
isavailablefromyour Quantum Rehab Specialistto furthercustomise yourpower chairto bettersuit your needsand/or
preferences.However,underno circumstances shouldyoumodify,add,removeordisableany feature, partorfunctionof
yourpowerchair.
WARNING! Do not modify your power chair in any way not authorised by Pride. Unauthorised
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Gettoknow the feelof yourpower chairanditscapabilities. Pride recommendsthat youperform asafetycheckbefore
eachuseto make sure yourpower chairoperatessmoothlyand safely.
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkforpropertyreinflation.Maintainbutdonotexceed2.4bar(35psi)ineachtyreifequippedwithpneumatictyres.
!Checkallelectricalconnections. Make sure theyare tight andnot corroded.
!Checkallcontrollerconnections to the electronicstray.Makesure they are secured properly.
!Checkthe brakes. SeeVIII. “Care andMaintenance.”
!Checkbatterycharge.SeeVI. “Batteries and Charging.”
NOTE: If you discover a problem, contact your Quantum Rehab Specialist for assistance.

8 www.quantumrehab.com Quantum 1402
II. SAFETY
Weight Limitations
Yourpowerchair is rated for amaximumweightcapacity. Please refer tothespecificationstableforthislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tyre Inflation
Ifyour powerchairisequippedwith pneumatictyres,youshouldcheck orhavetheairpressure checkedregularly.Proper
inflationpressures will prolong thelifeofyourtyresandhelpensure the smooth operation ofyourpowerchair.
WARNING! It is important that 2.4 bar (35 psi) tyre pressure be maintained in pneumatic tyres at
all times. Do not underinflate or overinflate your tyres. Low pressure may result in loss of control,
and overinflated tyres may burst. Failure to maintain 2.4 bar (35 psi) tyre pressure in pneumatic
tyres at all times may result in tyre and/or wheel failure, causing serious personal injury and/or
damage to your power chair.
WARNING! Inflate your power chair drive tyres from a regulated air source with an available
pressure gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting
in a burst tyre and/or personal injury.
WARNING! When changing a tyre, remove only the centre lug nut, then remove the tyre. If any
further disassembly is required, deflate the tyre completely or it may explode, possibly resulting
in personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designed foreasyandsafeaccess.Someramps
mayhaveturningswitchbacks(180-degreeturns)thatrequireyoutohavegoodcorneringskillsonyourpowerchair.
!Proceedwithextreme caution as youapproach thedowngrade ofa rampor otherincline.
!Takewideswingswithyour powerchair’sfrontwheelsaround anytightcorners.Ifyou dothat,thepower chair’srear
wheelswillfollowawidearc,notcutthe corner short and not bump into orget hung up on any railingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.SeeVII.“Operation.”
!Avoidsudden stops andstarts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.Whendriving down an incline,set yourpower chairto theslowest settingand drivein theforward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestop by releasing the joystick, then push the joystick forward slightly to ensure a safely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.

Quantum 1402 www.quantumrehab.com 9
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Never travel down an incline rearwards. This may result in personal injury.
WARNING! Your power chair may be equipped with a reclining seatback. This feature is intended
for use on a flat, level surface. Do not negotiate inclines with the seat in a reclined position as
this may result in the power chair tipping over and causing personal injury and/or product damage.
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair,
resulting in personal injury and/or damage to your power chair.
Mosthandicappublic access rampsare requiredtohavea maximum slopeof 8.7%(5°).Therefore,Pride recommends
thatthemaximum slope of an incline you attempt to safely ascend or descend on your power chair does not exceed 8.7%
(5°).Seefigure 1.
WARNING! Any attempt to climb or descend a slope steeper than 8.7% (5°) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpowerchairisequippedwithtwopowerfulbrakesystems:
1. Regenerative — uses electricity to rapidly slowthevehiclewhenthejoystickreturnstothecenter/stopposition.
2. DiscParkBrake— activatesmechanicallyafterregenerativebrakingslowsthevehicleto nearstop,orwhenpoweris
removedfromthesystemforanyreason.
Cornering Information
Whileyourpower chair isequipped withcastorwheels and anti-tip wheels,excessivelyhigh cornering speeds canstill
createthepossibility of tipping.Factors whichaffectthepossibility of tippinginclude, butarenotlimited to: cornering
speed,steeringangle(howsharplyyouareturning),uneven road surfaces, inclined road surfaces, ridingfrom an area of
low traction to an area of high traction (such as passing from a grassy area to a paved area – especially at high speed
whileturning)andabruptdirectionalchanges.Highcorneringspeedsarenotrecommended.If you feel that you may tip
over in a corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power
chairfromtipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.

10 www.quantumrehab.com Quantum 1402
II. SAFETY
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete, blacktoportarmac.However,Priderecognisesthatthere willbetimeswhenyou willencounterothersurface
types.Forthisreason,yourpower chairisdesignedto performadmirablyonpacked soil,grassandgravel.Feelfreetouse
yourpowerchair safely on lawnsand inpark areas.
!Reduceyourpowerchair’sspeedwhendrivingonuneventerrainand/orsoft surfaces.
!Avoidtallgrassthatcanentanglethe runninggear.
!Avoidloosely packed gravel and sand.
!Ifyou feel unsure about adrivingsurface,avoidthatsurface.
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmanoeuvrabilitybyatrainedattendant.
Formoreinformationabouthowtoplaceyourpowerchairintoandoutoffreewheelmode,seeIII. “YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Kerbs, etc.)
Proceedwith extreme cautionwhendriving near raisedsurfaces,unprotected ledges and/ordrop-offs(kerbs, porches,
stairs,etc.).Thecorrectmethodfor approaching a kerb is illustratedin figure 2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 10 cm (4 in.) unless you have the assistance of an attendant.
WARNING! If your power chair is equipped with a kerb climber, do not attempt to climb any kerb
in excess of 10 cm (4 in.) in height. Do not approach kerbs at an angle; instead approach any kerb
you intend to ascend or descend in the forward position.
WARNING! Do not attempt to have your power chair proceed rearward down any step, kerb or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Kerb Approach Figure 3. Incorrect Kerb Approach

Quantum 1402 www.quantumrehab.com 11
II. SAFETY
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with
extreme caution.
Stairs and Escalators
Powerchairsare not designedtotravelup or downstairsorescalators.Alwaysuse alift.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
Doors
!Determineifthedoor opens toward oraway fromyou.
!Driveyourpowerchairgentlyandslowlyforwardto pushthedooropen. Ordriveyourpower chairgentlyandslowly
rearwardto pull thedoor open.
Lifts
Modernliftshaveadooredgesafety mechanism that, when pushed, reopensthe lift door(s).
!Ifyou are in thedoorwayof a liftwhenthe door(s) begintoclose, push on therubberdoor edge orallowthe rubber
dooredge to contactthe power chairand the doorwill reopen.
!Usecare that handbags,packagesor power chairaccessoriesdo not becomecaughtin lift doors.
Lift/Elevation Products
If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in
transport. Pride recommends that you closely review the instructions, specifications and safety information set forth
by the manufacturer of the lift/elevation product before using that product.
Motor Vehicle Transport
Currently, thereare no standardsapproved for tie-downsystems in amoving vehicle ofany typeto transport aperson
whileseatedinapowerchair.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Positioning Belts
YourQuantum RehabSpecialist, therapist(s) andother healthcare professionalsare responsible fordetermining your
requirementforapositioningbeltinordertooperateyourpowerchairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.

12 www.quantumrehab.com Quantum 1402
Transfers
Transferring onto and off of your power chair requires a
good sense of balance. Always have an attendant or
healthcareprofessional present while learning to properly
transferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youoratrainedattendant perform the following tasks be-
foreattemptingatransfer:
!Turnoffthepowertothecontroller.SeeVII.“Operation.”
!Ensureyourpowerchairis notinfreewheelmode.See
III.“YourPower Chair.”
!Turn both castor wheels toward the transfer destina-
tiontoimprovepowerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed
fromyour power chair.
!Flip up the foot platform or move the leg rests aside;
thiswillhelptokeepyour feet from getting caughton
thefootriggingduringthetransfer.
!Reduce the distance between your power chair and
theobjectyouaretransferringonto.
II. SAFETY
Figure 4.IdealTransfer Position
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Inclement Weather Precautions
Exposureof your power chair to inclement weather conditionsshouldbeavoidedwheneverpossible.Ifsuddenlycaught
up in rain, snow, severe cold or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydry your power chair before storing,chargingor operating your power chair.
WARNING! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.

Quantum 1402 www.quantumrehab.com 13
II. SAFETY
Reaching and Bending
Neverreach,leanorbendwhiledrivingyourpowerchair.If it is absolutely necessary to reach, lean orbend while seated
onyour power chair, it isimportant to maintaina stable centreof gravity andkeep the powerchair from tipping.Pride
recommendsthat the powerchairuser determine his/herpersonallimitations and practicebending and reachinginthe
presenceof aqualifiedhealthcareprofessional.
WARNING! Do not reach, lean or bend for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your centre of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury. Keep your hands away from the tyres when driving. Be aware
that loose fitting clothing can become caught in drive tyres.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout your power chair’sbatteries, seeVI.“Batteries and Charging.”
WARNING! Power chair batteries are heavy. Refer to the specifications table. If you are
unable to lift that much weight, be sure to get help. Lifting beyond your capacity can result
in personal injury.
WARNING! Battery posts, terminals and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Prescription Drugs/Physical Limitations
Usersmustexercisecareand commonsensewhenoperatingapowerchair.Thisincludesawarenessofsafety issueswhen
takingprescribed or over-the-counter drugs orwhentheuserhasspecificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepower chairusermustexercisecare andcommonsensewhenoperating his/herpowerchair.Thisincludes awareness
ofsafetyissueswhile undertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.

14 www.quantumrehab.com Quantum 1402
II. SAFETY
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand RadioFrequency Interference can come fromsources such as cellular phones,mobile two-way
radios(suchaswalkie-talkies),radio stations, TV stations, amateurradio (HAM) transmitters,wireless computer links,
microwavesignals,pagingtransmittersandmedium-rangemobiletransceiversusedbyemergencyvehicles.Insomecases,
thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobilityvehicle
hasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.Thisproduct
hasbeentestedand has passed atan immunity levelof 20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorised by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If unin-
tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact your
Quantum Rehab Specialist to report the incident.

Quantum 1402 www.quantumrehab.com 15
III. YOUR POWER CHAIR
THE QUANTUM 1402
YourQuantum1402hastwomainassemblies:theseatandthepowerbase.Seefigure5.Typically, the seating assembly
includesthearmrests,seatbackandcontroller.Thepowerbaseassemblyincludestwodrivewheels,twoanti-tipwheels,
tworear castor wheels,a power seatconnector (optional), harnessconnectors and abody shroud. Seefigures5 and6.
Figure 5.The Quantum 1402
SEATBACK
CONTROLLER
ARMRESTS
BODY SHROUD
ANTI-TIP WHEELS
DRIVEWHEEL
REARCASTORWHEEL
POWERBASEASSEMBLY
SEAT ASSEMBLY
(OPTIONAL SEAT SHOWN)
FOOTRIGGING

16 www.quantumrehab.com Quantum 1402
III. YOUR POWER CHAIR
*Depending on user weight, battery amp hour rating (AH) and terrain.
Specifications
Suspension: Active-Trac system and rearsuspension
DriveWheels: 35.5cm(14in.),pneumatic,center-mounted (solid tyres are optional)
CastorWheels: 20 cm (8 in.), solid, reararticulating
Anti-tipWheels: 15 cm (6 in.), solid,front-mounted
OverallSize: Length:103cm(40.5in.)
Width: 64.5 cm (25.4 in.)
TurningRadius: 53 cm (21 in.)
GroundClearance: 8 cm (3.25 in.)
MaximumObstacleClimbingAbility: 10 cm
MaximumSafeSlope: 8.7% (5°)
MaximumClimbingAbility: 8.7% (5°)
MaximumSpeed: Upto7.24km/h(4.5mph) withhigh-torquemotors (standard)
Upto9.6km/h(6.0 mph) withhighspeedmotors (optional)
SeatingOptions: Medium-back Seat (standard) SolidSeat Pan
High-backSeat PowerElevating Seat
EuroSeat
SpecialtySeat
SynergySeat
TRU-BalancePowerPositioningSystems
Electronics: 70-ampPGRemotePlusController
70-ampMicrodrive Controller
Drivetrain: Two-motor, mid-wheel
Brakes: “IntelligentBraking,”electronic,regenerativediscbrakes
Batteries: Two12-volt,Group24batteries(AGMorGel-Celltyperecommended)
(NF-22batterieswithpowerelevating seat option)
Range: Up to 40 km (25 miles)*
BatteryCharger: 5-amp, onboard
Off-board(optional)
WeightCapacity: 181 kg(400lbs/29stone) with high-torque motors(standard)
147kg(325lbs/23 stone) with high-speedmotors (optional)
Component Weights Base: 58.5 kg (136 lbs)
Standard Seat: 16.5 kg (36.5 lbs)
Batteries:24 kg (53.5lbs)each

Quantum 1402 www.quantumrehab.com 17
III. YOUR POWER CHAIR
Electronics Tray
Theelectronicstrayislocated on the rear of yourpower chair.Theelectronicstrayis located underneath the rear sliding
door and consists of the ammeter, the charger power lead receptacle, the main circuit breaker, accessory connector
(optionalequipment) andthecontrollerconnector(s).
Ammeter:The ammeter displays the charger’s currentoutput in amps.For more information, seeVI. “Batteriesand
Charging” inthismanual.See figure6.
ChargerPowerLeadReceptacle: Thisreceptacle isused whenever your batteryneedsrecharging. See figure 6.
MainCircuitBreaker:Themaincircuitbreakerisasafetyfeaturebuiltintoyour powerchair.Whenthebatteries andthe
motorsareheavilystrained(e.g., fromexcessiveloads),themaincircuitbreaker tripstopreventdamagetothemotorsand
theelectronics.Ifthecircuittrips, allowyourpowerchairto “rest”forapproximatelyone minute.Next,pushinthe circuit
breakerbutton,turnonthecontrollerand continue normal operation. If the maincircuit breaker continues to triprepeat-
edly,contactyourQuantumRehabSpecialist.Seefigure6.
AccessoryConnector(Optional):This is where optionalpower harnessesconnect tothe controller.
ControllerConnector(s):This is where thecontroller connectsto the motors,batteries andcharger.
PowerElevatingSeatConnector(Optional):This is for the optionalpower elevating seatswitch. Seefigure 6.
Figure 6.ElectronicsTray
AMMETER
CONTROLLER CONNECTOR
CHARGERPOWERLEADRECEPTACLE
(SHOWNCOVERED)
MAINCIRCUITBREAKER

18 www.quantumrehab.com Quantum 1402
III. YOUR POWER CHAIR
Dual Manual Freewheel Levers
Foryour convenience,yourpower chairis equipped withdual manual freewheellevers. The leversare located onthe
insideof the anti-tipwheels.Theleversallowyouto disengage thedrivemotorsandmanoeuvrethe chair manually.
WARNING! In freewheel mode, the braking system is disengaged. Only engage the freewheel
mode when on a level surface.
WARNING! Prevent personal injury and/or equipment damage. Do not use the freewheel lever
handles as tie-down points to secure this product. Failure to comply could result in personal
injury and/or equipment damage.
Tooperate thedual manual freewheellevers:
1. Pull up both manualfreewheelleversforfreewheelmode(drivemotor disengaged). See figure7.
2. Push down both manual freewheel levers for drive mode (drive motor engaged). See figure 8.
NOTE: If a lever is difficult to move in either direction, rock your power chair back and forth slightly. The
lever should then move to the desired position.
Figure 8. Drive Mode (left side shown)Figure 7. Freewheel Mode (left side shown)
Active-Trac Suspension
Yourpower chair isequippedwith Active-TracSuspension (ATS).ATSis a suspension systemdesignedto make your
powerchairtraversedifferenttypesof terrainandobstacleswhilemaintainingsmoothoperation.WithATS,thefrontanti-
tipwheels work in conjunction with the motor suspension tohelpyoumanoeuvreoverobstacles.
Asthefront anti-tip wheels comein contactwithanobstacle, the front anti-tipwheel assemblyis drawnupward.Atthe
sametime,themotors are forced downward.This allowsthe motorsto pushthe powerchair over anobstacle andlimits
thepossibility of your powerchairgettingcaughtontheobstacle.
ATSalsohelpsin day-to-day operating conditions. For instance, when you release thejoystick, your power chair begins
toslow down.As the chairslows down, thefront anti-tipwheels will automaticallydrop toward theground.This will
reducethe forwardtipthatistypicallyencounteredwith mid-wheeldrivechairs.

Quantum 1402 www.quantumrehab.com 19
Rear Suspension
Your power chair is equipped with rear suspension. See
figure9.Thissuspensionsystemworksinconjunctionwith
ATSandisdesignedtomaintainasmoothridewhendriv-
ingoverroughterrainand upanddownkerbs.Thissystem
works by allowing the castor forks to respond to weight
transfers and uneven terrain. The rear castor wheelswill
pivotasyoudriveoverobstacles.Thissystemalsoenhances
performancewhenthefrontanti-tipwheelsaresetlowerto
thesurface.
Figure 9. Rear Suspension System
REARCASTERWHEEL REAR
CASTER
FORK
REAR
CASTER
FORK
III. YOUR POWER CHAIR

20 www.quantumrehab.com Quantum 1402
IV. ASSEMBLY
INITIAL ASSEMBLY
Yourpowerchairmayrequiresomeassemblyeitherbeforeinitialuseoraftertransportation.Itmayalsorequiredisassembly
tomakesomecomfortadjustments.Figure10detailsthosepartsofthepowerchairthataredesignedtobedisassembledand
assembledbyanenduserorbyaqualifiedcarerbeforeusingtheproductormakingcomfortadjustments.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local hardware stores
or through your Quantum Rehab Specialist.
Figure 10.Quantum 1402 AssemblyView
ARMREST WIDTH
ADJUSTMENT
ARMRESTANGLEADJUSTMENT
SEAT INSTALLATION
CONTROLLER POSITION
SEATHEIGHT/ANGLEADJUSTMENT
ANTI-TIP WHEEL ADJUSTMENT FOOT PLATFORM ADJUSTMENT
