Quectel LTE-A Series Supplement

EM121R-GL
Hardware Design
LTE-A Module Series
Version: 1.0.0
Date: 2021-04-07
Status: Preliminary

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 1 / 80
Our aim is to provide customers with timely and comprehensive service. For any assistance,
please contact our company headquarters:
Quectel Wireless Solutions Co., Ltd.
Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai
200233, China
Tel: [phone]
Email: [e-mail]
Or our local office. For more information, please visit:
http://www.quectel.com/support/sales.htm.
For technical support, or to report documentation errors, please visit:
http://www.quectel.com/support/technical.htm
Or email to [e-mail].
General Notes
Quectel offers the information as a service to its customers. The information provided is based upon
customers’ requirements. Quectel makes every effort to ensure the quality of the information it makes
available. Quectel does not make any warranty as to the information contained herein, and does not
accept any liability for any injury, loss or damage of any kind incurred by use of or reliance upon the
information. All information supplied herein is subject to change without prior notice.
Disclaimer
While Quectel has made efforts to ensure that the functions and features under development are free
from errors, it is possible that these functions and features could contain errors, inaccuracies and
omissions. Unless otherwise provided by valid agreement, Quectel makes no warranties of any kind,
implied or express, with respect to the use of features and functions under development. To the maximum
extent permitted by law, Quectel excludes all liability for any loss or damage suffered in connection with
the use of the functions and features under development, regardless of whether such loss or damage
may have been foreseeable.
Duty of Confidentiality
The Receiving Party shall keep confidential all documentation and information provided by Quectel,
except when the specific permission has been granted by Quectel. The Receiving Party shall not access
or use Quectel’s documentation and information for any purpose except as expressly provided herein.
Furthermore, the Receiving Party shall not disclose any of the Quectel's documentation and information
to any third party without the prior written consent by Quectel. For any noncompliance to the above
requirements, unauthorized use, or other illegal or malicious use of the documentation and information,
Quectel will reserve the right to take legal action.

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 2 / 80
Copyright
The information contained here is proprietary technical information of Quectel. Transmitting, reproducing,
disseminating and editing this document as well as using the content without permission are forbidden.
Offenders will be held liable for payment of damages. All rights are reserved in the event of a patent grant
or registration of a utility model or design.
Copyright © Quectel Wireless Solutions Co., Ltd. 2021. All rights reserved.

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 3 / 80
Safety Information
The following safety precautions must be observed during all phases of operation, such as usage, service
or repair of any cellular terminal or mobile incorporating the module. Manufacturers of the cellular terminal
should notify users and operating personnel of the following safety information by incorporating these
guidelines into all manuals of the product. Otherwise, Quectel assumes no liability for customers’ failure to
comply with these precautions.
Full attention must be paid to driving at all times in order to reduce the risk of an
accident. Using a mobile while driving (even with a handsfree kit) causes
distraction and can lead to an accident. Please comply with laws and regulations
restricting the use of wireless devices while driving.
Switch off the cellular terminal or mobile before boarding an aircraft. The operation
of wireless appliances in an aircraft is forbidden to prevent interference with
communication systems. If there is an Airplane Mode, it should be enabled prior to
boarding an aircraft. Please consult the airline staff for more restrictions on the use
of wireless devices on an aircraft.
Wireless devices may cause interference on sensitive medical equipment, so
please be aware of the restrictions on the use of wireless devices when in
hospitals, clinics or other healthcare facilities.
Cellular terminals or mobiles operating over radio signal and cellular network
cannot be guaranteed to connect in certain conditions, such as when the mobile bill
is unpaid or the (U)SIM card is invalid. When emergency help is needed in such
conditions, use emergency call if the device supports it. In order to make or receive
a call, the cellular terminal or mobile must be switched on in a service area with
adequate cellular signal strength. In an emergency, the device with emergency call
function cannot be used as the only contact method considering network
connection cannot be guaranteed under all circumstances.
The cellular terminal or mobile contains a transmitter and receiver. When it is ON, it
receives and transmits radio frequency signals. RF interference can occur if it is
used close to TV set, radio, computer or other electric equipment.
In locations with potentially explosive atmospheres, obey all posted signs to turn
off wireless devices such as mobile phone or other cellular terminals. Areas with
potentially explosive atmospheres include fuelling areas, below decks on boats,
fuel or chemical transfer or storage facilities, areas where the air contains
chemicals or particles such as grain, dust or metal powders.

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 4 / 80
About the Document
Revision History
Version
Date
Author
Description
-
2021-04-07
Jim HAN/
Kingson ZHANG
Alex WANG
Creation of the document
1.0.0
2021-04-07
Jim HAN/
Kingson ZHANG/
Alex WANG
Preliminary

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 5 / 80
Contents
Safety Information.......................................................................................................................................3
About the Document...................................................................................................................................4
Contents.......................................................................................................................................................5
Table Index...................................................................................................................................................8
Figure Index...............................................................................................................................................10
1Introduction........................................................................................................................................12
1.1. Introduction ...............................................................................................................................12
1.2. Reference Standard..................................................................................................................12
1.3. Special Mark .............................................................................................................................13
2Product Concept................................................................................................................................14
2.1. General Description..................................................................................................................14
2.2. Key Features.............................................................................................................................15
2.3. Functional Diagram...................................................................................................................18
2.4. Pin Assignment.........................................................................................................................19
2.5. Pin Description..........................................................................................................................20
2.6. Evaluation Board.......................................................................................................................24
3Operating Characteristics.................................................................................................................25
3.1. Operating Modes.......................................................................................................................25
3.1.1. Sleep mode....................................................................................................................25
3.1.2. Airplane mode................................................................................................................27
3.2. Communication Interface with the Host....................................................................................27
3.3. Power Supply............................................................................................................................27
3.3.1. Decrease Voltage Drop..................................................................................................28
3.3.2. Reference Design for Power Supply..............................................................................29
3.4. Turn on......................................................................................................................................29
3.5. Turn off......................................................................................................................................31
3.6. Reset.........................................................................................................................................31
4Application Interfaces .......................................................................................................................34
4.1. (U)SIM Interface........................................................................................................................34
4.1.1. Pin definition of (U)SIM..................................................................................................34
4.1.2. (U)SIM Hot-plug.............................................................................................................35
4.1.3. Normally Closed (U)SIM Card Connector......................................................................36
4.1.4. Normally Open (U)SIM Card Connector........................................................................37
4.1.5. (U)SIM Card Connector Without Hot-plug.....................................................................38
4.1.6. (U)SIM2 Card Connector...............................................................................................38
4.1.7. (U)SIM Design Notices...................................................................................................39
4.2. USB Interface............................................................................................................................39

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 6 / 80
4.3. PCIe Interface...........................................................................................................................41
4.3.1. Pin definition of PCIe......................................................................................................41
4.3.2. Reference Design for PCIe............................................................................................42
4.3.3. PCIe Timing....................................................................................................................43
4.3.3.1. PCIe Turn-on Timing...........................................................................................43
4.3.3.2. PCIe Turn-off Timing...........................................................................................44
4.3.3.3. PCIe Reset Timing..............................................................................................45
4.3.3.4. PCIe Modern Standby Timing.............................................................................46
4.4. PCM Interface*..........................................................................................................................47
4.5. Control and Indication Interfaces..............................................................................................49
4.5.1. W_DISABLE1#...............................................................................................................49
4.5.2. W_DISABLE2#...............................................................................................................50
4.5.3. WWAN_LED#.................................................................................................................51
4.5.4. WAKE_ON_WAN#* .......................................................................................................51
4.5.5. DPR................................................................................................................................52
4.5.6. WLAN_PA_EN*..............................................................................................................52
4.6. Cellular/WLAN COEX Interface*...............................................................................................53
4.7. Antenna Tuner Control Interface*.............................................................................................53
4.7.1. Antenna Tuner Control Interface through GPIOs..........................................................53
4.7.2. Antenna Tuner Control Interface through RFFE............................................................54
4.8. Configuration Pins.....................................................................................................................54
5RF Characteristics.............................................................................................................................56
5.1. Cellular Antenna Interfaces.......................................................................................................56
5.1.1. Connector Definition.......................................................................................................56
5.1.2. Operating Frequency .....................................................................................................56
5.1.3. Receiving Sensitivity......................................................................................................58
5.1.4. Output Power .................................................................................................................59
5.2. GNSS Antenna Interface ..........................................................................................................62
5.2.1. General Description .......................................................................................................62
5.2.2. Connector Definition.......................................................................................................63
5.2.3. GNSS Frequency...........................................................................................................63
5.2.4. GNSS Performance .......................................................................................................64
5.3. Antenna Connectors.................................................................................................................64
5.3.1. Antenna Connector Location .........................................................................................64
5.3.2. Antenna Connector Size................................................................................................65
5.3.3. Antenna Connector Installation......................................................................................66
5.4. Antenna Requirements.............................................................................................................68
6Electrical Characteristics and Reliability........................................................................................70
6.1. Power Supply Requirements ....................................................................................................70
6.2. Current Consumption................................................................................................................70
6.2.1. PCIe Only Version..........................................................................................................70
6.2.2. USB Version...................................................................................................................71
6.3. Digital I/O Characteristic...........................................................................................................71

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 7 / 80
6.4. Electrostatic Discharge.............................................................................................................72
6.5. Thermal Dissipation ..................................................................................................................72
6.6. Absolute Maximum Ratings......................................................................................................74
6.7. Operating and Storage Temperatures......................................................................................74
7Mechanical Dimensions and Packaging.......................................................................................75
7.1. Mechanical Dimensions of the Module.....................................................................................75
7.2. Top and Bottom Views of the Module.......................................................................................76
7.3. M.2 Connector...........................................................................................................................76
7.4. Packaging .................................................................................................................................76
8Appendix References........................................................................................................................78

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 8 / 80
Table Index
Table 1: Special Mark.................................................................................................................................13
Table 2: Frequency Bands and GNSS Types of EM121R-GL.................................................................. 14
Table 3: Key Features of EM121R-GL....................................................................................................... 15
Table 4: Definition of I/O Parameters......................................................................................................... 20
Table 5: Pin Description.............................................................................................................................20
Table 6: Overview of Operating Modes.....................................................................................................25
Table 7: Definition of VCC and GND Pins.................................................................................................27
Table 8: Pin Definition of FULL_CARD_POWER_OFF#...........................................................................30
Table 9: Turn-on Timing of the Module...................................................................................................... 30
Table 10: Turn-off Timing of the Module....................................................................................................31
Table 11: Pin Definition of RESET#...........................................................................................................31
Table 12: Reset Timing of the Module....................................................................................................... 33
Table 13: Pin Definition of (U)SIM Interfaces ............................................................................................34
Table 14: Pin Definition of USB Interface..................................................................................................39
Table 15: Pin Definition of PCIe Interface.................................................................................................. 41
Table 16: Power-up Timing of M.2 Specification....................................................................................... 43
Table 16: PCIe Turn-on Timing of the Module........................................................................................... 44
Table 17: PCIe Turn-off Timing through FULL_CARD_POWER_OFF#...................................................45
Table 18: PCIe Reset Timing..................................................................................................................... 46
Table 19: Pin Definition of PCM Interface.................................................................................................. 48
Table 20: Pin Definition of Control and Indication Interfaces..................................................................... 49
Table 21: RF Function Status ....................................................................................................................49
Table 22: GNSS Function Status...............................................................................................................50
Table 23: Network Status Indications of WWAN_LED#............................................................................51
Table 24: State of the WAKE_ON_WAN#................................................................................................. 52
Table 25: Function of the DPR Signal........................................................................................................ 52
Table 27: Pin definition of WLAN_PA_EN for EM121R-GL....................................................................... 53
Table 28: Pin Definition of COEX Interface ............................................................................................... 53
Table 29: Pin Definition of Antenna Tuner Control Interface through GPIOs............................................53
Table 30: Pin Definition of Antenna Tuner Control Interface through RFFE............................................. 54
Table 33: List of EM121R-GL Configuration Pins......................................................................................54
Table 34: Pin Definition of EM121R-GL Configuration Pins......................................................................54
Table 35: EM121R-GL Connector Definition of Antenna Interfaces..........................................................56
Table 37: Operating Frequency of EM121R-GL........................................................................................ 56
Table 38: EM121R-GL Dual-Antenna Conducted Receiving Sensitivity................................................... 58
Table 40: EM121R-GL RF Output Power of PCIe Only Version............................................................... 59
Table 41: EM121R-GL RF Output Power of USB Version........................................................................ 61
Table 35: EM121R-GL Connector Definition of Antenna Interfaces..........................................................63
Table 42: GNSS Frequency....................................................................................................................... 63
Table 43: EM121R-GL GNSS Performance..............................................................................................64
Table 44: Major Specifications of the RF Connector................................................................................. 66

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 9 / 80
Table 45: Antenna Requirements of EM121R-GL..................................................................................... 68
Table 47: Power Supply Requirements .....................................................................................................70
Table 48: EM121R-GL Current Consumption (PCIe Only Version, 3.3 V Power Supply)........................70
Table 49: EM121R-GL Current Consumption (USB Only Version, 3.7 V Power Supply)......................... 71
Table 50: Logic Levels of Digital I/O (1.8 V).............................................................................................. 71
Table 51: (U)SIM 1.8 V I/O Requirements.................................................................................................71
Table 52: (U)SIM 3.0 V I/O Requirements.................................................................................................71
Table 53: Electrostatic Discharge Characteristics (Temperature: 25 ºC, Humidity: 40 %).......................72
Table 54: Absolute Maximum Ratings....................................................................................................... 74
Table 55: Operating and Storage Temperatures....................................................................................... 74
Table 56: Related Documents....................................................................................................................78
Table 57: Terms and Abbreviations........................................................................................................... 78

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 10 / 80
Figure Index
Figure 1: Functional Diagram..................................................................................................................... 18
Figure 2: Pin Assignment...........................................................................................................................19
Figure 3: DRX Run Time and Current Consumption in Sleep Mode......................................................... 26
Figure 4: Sleep Mode Application with USB Remote Wakeup..................................................................26
Figure 5: Power Supply Limits during Radio Transmission.......................................................................28
Figure 6: Reference Circuit for the VCC....................................................................................................28
Figure 7: Reference Circuit for the Power Supply ..................................................................................... 29
Figure 8: Turn on the Module with a Host GPIO........................................................................................30
Figure 9: Turn-on Timing of the Module.....................................................................................................30
Figure 10: Turn-off Timing through FULL_CARD_POWER_OFF#........................................................... 31
Figure 11: Reference Circuit for the RESET# with NPN Driver Circuit ..................................................... 32
Figure 12: Reference Circuit for the RESET# with a Button......................................................................32
Figure 13: Reset Timing of the Module...................................................................................................... 33
Figure 14: Reference Circuit for Normally Closed (U)SIM Card Connector..............................................37
Figure 15: Reference Circuit for Normally Open (U)SIM Card Connector................................................ 37
Figure 16: Reference Circuit for a 6-Pin (U)SIM Card Connector............................................................. 38
Figure 17: Recommended Compatible Design for (U)SIM2 Interface.......................................................38
Figure 18: Reference Circuit for the USB 3.0 & 2.0 Interface....................................................................40
Figure 19: PCIe Interface Reference Circuit.............................................................................................. 42
Figure 20: PCIe Power-on Timing Requirements of M.2 Specification.....................................................43
Figure 20: PCIe Turn-on Timing of the Module..................................................................................... 44
Figure 21: PCIe Turn-off Timing through FULL_CARD_POWER_OFF#.................................................. 45
Figure 22: PCIe Reset Timing.................................................................................................................... 45
Figure 23: PCIe D3 Hot State Timing ........................................................................................................46
Figure 24: PCIe D3 Cold Timing................................................................................................................47
Figure 25: Primary Mode Timing................................................................................................................ 48
Figure 26: Auxiliary Mode Timing ..............................................................................................................48
Figure 27: W_DISABLE1# and W_DISABLE2# Reference Circuit........................................................... 50
Figure 28: WWAN_LED# Reference Circuit..............................................................................................51
Figure 29: WAKE_ON_WAN# Signal Reference Circuit........................................................................... 52
Figure 31: Recommended Circuit of EM121R-GL Configuration Pins...................................................... 55
Figure 30: Internal circuit for Active Antenna DC Bias ..............................................................................63
Figure 33: Antenna Connectors on the EM121R-GL Module.................................................................... 65
Figure 34: EM121R-GL RF Connector Dimensions (Unit: mm)................................................................ 66
Figure 35: EM121R-GL RF Connector Dimensions (Unit: mm)................................................................66
Figure 36: Specifications of Mating Plugs Using Ø 0.81 mm Coaxial Cables........................................... 67
Figure 37: Connection between RF Connector and Mating Plug Using Ø 0.81 mm Coaxial Cable......... 67
Figure 38: Connection between RF Connector and Mating Plug Using Ø 1.13 mm Coaxial Cable......... 68
Figure 39: Thermal Dissipation Area on Bottom Side of Module ..............................................................73
Figure 40: Mechanical Dimensions of the Module (Unit: mm)................................................................... 75
Figure 41: EM121R-GL Top View and Bottom View .................................................................................76

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 11 / 80
Figure 43: Tray Size (Unit: mm)................................................................................................................. 77
Figure 44: Tray Packaging Procedure....................................................................................................... 77

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 12 / 80
1Introduction
1.1. Introduction
The hardware design defines EM121R-GL and describes the air and hardware interfaces which are
connected with customers’ applications.
This document helps you quickly understand the interface specifications, electrical and mechanical
details, as well as other related information of EM121R-GL. To facilitate its application in different fields,
reference design is also provided for reference. Associated with application notes and user guides, you
can use the module to design and set up mobile applications easily.
This document is applicable to the EM121R-GL module.
1.2. Reference Standard
The module complies with the following standards:
⚫PCI Express M.2 Specification Revision 2.0,Version 1.2
⚫PCI Express Base Specification Revision 2.0
⚫Universal Serial Bus Specification, Revision 3.0
⚫ISO/IEC 7816-3
⚫MIPI Alliance Specification for RF Front-End Control Interface version 2.0
⚫3GPP TS 27.007 and 3GPP 27.005
⚫3GPP TS 34.121-1
⚫3GPP TS 36.521-1

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 13 / 80
1.3. Special Mark
Table 1: Special Mark
Mark
Definition
*
When an asterisk (*) is used after a function, feature, interface, pin name, AT command, or
argument, it indicates that the function, feature, interface, pin name, AT command, or
argument is under development and currently not supported, unless otherwise specified.
[…]
Brackets ([…]) used after a pin enclosing a range of numbers indicate all pin of the same
type. For example, ANTCTL [0:3] refers to all four ANTCTL pins, ANTCTL0, ANTCTL1,
ANTCTL2, and ANTCTL3.

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 14 / 80
2Product Concept
2.1. General Description
EM121R-GL is a LTE-A/UMTS/HSPA+ wireless communication module with receive diversity. It provides
data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA networks.
They are standard WWAN M.2 Key-B modules. For more details, see PCI Express M.2 Specification
Revision 2.0, Version 1.2.
EM121R-GL is an industrial-grade module for industrial and commercial applications only.
It supports embedded operating systems such as Windows, Linux and Android, and also provide GNSS 1)
and voice functionality 2) to meet specific application demands.
The following table shows the frequency bands and GNSS types of the module.
Table 2: Frequency Bands and GNSS Types of EM121R-GL
Mode
Frequency Bands
LTE-FDD
(with Rx-diversity)
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/ /B18/B19/B20/B25/B26/
B28/B29 4)/B30/B32 4)/B66
LTE-TDD
(with Rx-diversity)
B38/B39/B40/B41/ B46 4)/B48
WCDMA (with Rx-diversity)
B1/B2/B3/B4/B5/B6/B8/B19
GNSS 1)
GPS L1;
GPS L5;
GLONASS;
BeiDou/COMPASS;
Galileo
1. 1) GNSS function is optional.
2. 2) EM121R-GL contains Telematics version and Data-only version. Telematics version supports
NOTES

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 15 / 80
EM121R-GL can be applied in the following fields:
⚫Tablet PC and Laptop
⚫Remote Monitor System
⚫Wireless POS System
⚫Smart Metering System
⚫Wireless Router and Switch
⚫Other Wireless Terminal Devices
2.2. Key Features
Table 3: Key Features of EM121R-GL
voice and data functions, while Data-only version only supports data function.
3. 4) LTE-FDD B29/B32 and LTE-TDD B46 support Rx only and are only for secondary component
carrier.
4. For details about CA combinations, see document [1].
Feature
Details
Function Interface
PCI Express M.2 Interface
Power Supply
⚫Supply voltage: 3.135–4.4 V
⚫Typical supply voltage: 3.7 V
(U)SIM Interface
⚫Compliant with ISO/IEC 7816-3
⚫Support (U)SIM card: 1.8/3.0 V
⚫Support Dual SIM Single Standby
USB Interface
⚫Compliant with USB 3.0 and 2.0 specifications, with maximum transmission
rates up to 5 Gbps on USB 3.0 and 480 Mbps on USB 2.0
⚫Used for AT command communication, data transmission, firmware
upgrade, software debugging, GNSS NMEA sentence output, and voice
over USB*
⚫Support USB serial drivers for: Windows 7/8/8.1/10, Linux 2.6–5.10,
Android 4.x/5.x/6.x/7.x/8.x/9.x/10.x
PCIe Interface
⚫Complaint with PCIe Gen 2
⚫PCIe ×1, supporting 5 Gbps per lane
⚫Used for AT command communication, data transmission, firmware
upgrade, software debugging, GNSS NMEA sentence output
PCM Interface*
⚫Used for audio function with external codec
⚫Support 16-bit linear data format
⚫Support long and short frame synchronization

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 16 / 80
⚫Support master and slave modes, but must be the master in long frame
synchronization
Rx-diversity
⚫LTE/WCDMA
Antenna Interfaces
EM121R-GL
⚫Main, Rx-diversity and GNSS antenna connectors
⚫50 Ω impedance
Transmitting Power
PCIe Interface
⚫WCDMA Bands: Class 3 (24 dBm +1/-3 dB)
⚫LTE-FDD:
- B30: Class 3 (20 dBm ±2 dB)
- Other Bands: Class 3 (23 dBm ±2 dB)
⚫LTE-TDD:
- B41 HPUE: Class 2 (25.5 dBm +1/-2 dB)
- B48: Class 3 (19 dBm ±2 dB)
- Other Bands: Class 3 (23 dBm ±2 dB)
USB Interface
⚫WCDMA Bands: Class 3 (24 dBm +1/-3 dB)
⚫LTE-FDD Bands: Class 3 (23 dBm ±2 dB)
⚫LTE-TDD:
- B41 HPUE: Class 2 (25.5 dBm +1/-2 dB)
- Other Bands: Class 3 (23 dBm ±2 dB)
LTE Features
EM121R-GL
⚫Up to LTE Cat 12
⚫1.4–60 MHz (3CA) RF bandwidth
⚫Support 2 ×2 MIMO in DL direction
⚫Support uplink QPSK, 16QAM and 64QAM modulation
⚫Support downlink QPSK, 16QAM and 64QAM and 256QAM modulation
⚫Data rate: up to 600 Mbps (DL)/150 Mbps (UL)
UMTS Features
⚫3GPP R9 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA
⚫Support QPSK, 16QAM and 64QAM modulation
⚫Data rate:
- DC-HSDPA: max. 42 Mbps (DL)
- HSUPA: max. 5.76 Mbps (UL)
- WCDMA: max. 384 kbps (DL)/384 kbps (UL)
GNSS Features
⚫Support GPS, GLONASS, BeiDou/COMPASS and Galileo
⚫Protocol: NMEA 0183
⚫Data update rate: 1 Hz
AT Commands
⚫Compliant with 3GPP TS 27.007 and 3GPP TS 27.005
⚫Quectel enhanced AT commands
Internet Protocol
Features
QMI/MBIM/NITZ/PING/HTTP/HTTPS protocols
Firmware Upgrade
USB 2.0 interface, PCIe interface and DFOTA

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 17 / 80
1. 1) To meet this operating temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module can meet 3GPP specifications.
2. 2) To meet this extended temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module remains the ability to establish and maintain functions such as voice, SMS, emergency
call, etc., without any unrecoverable malfunction. Radio spectrum and radio network are not
influenced, while one or more specifications, such as Pout, may undergo a reduction in value,
exceeding the specified tolerances of 3GPP. When the temperature returns to the normal operating
temperature level, the module will meet 3GPP specifications again.
SMS
⚫Text and PDU modes
⚫Point-to-point MO and MT
⚫SMS cell broadcast
⚫SMS storage: ME by default
Physical
Characteristics
⚫M.2 Key-B
⚫Size: (30.0 ±0.15) mm ×(42.0 ±0.15) mm ×(2.3 ±0.2) mm
⚫Weight: approx. 6.8 g
Temperature Range
⚫Operating temperature range: -25 to +75 °C 1)
⚫Extended temperature range: -40 to +85 °C 2)
⚫Storage temperature range: -40 to +90 °C
RoHS
All hardware components are fully compliant with EU RoHS directive
NOTES

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 18 / 80
2.3. Functional Diagram
The following figure shows a functional diagram of EM121R-GL.
⚫Power management
⚫Baseband
⚫LPDDR4X SDRAM + NAND Flash
⚫Radio frequency
⚫M.2 Key-B interface
(U)SIM2
(U)SIM1
USB 2.0 & USB 3.0
PCIe 2.0 ×1
ANT_GNSS
ANT_MAIN
38.4MHz XO
Qlink
Control
Tx
PRx
DRx
PCI Express M.2 Key-B Interface
FULL_CARD_POWER_OFF#
W_DISABLE2#
WWAN_LED#
WAKE_ON_WAN#
RFFE
W_DISABLE1#
GPIOs
ANT_DIV
GND
RESET#
VCC
SPMI
BB_CLK 19.2MHz RF_CLK 38.4MHz
EBI1
EBI2
PMIC
4Gb 8 bit NAND Flash
2Gb 16 bit LPDDR4X SDRAM
Baseband
Transceiver
Tx/Rx Blocks ET
GNSS
Figure 1: Functional Diagram

LTE-A Module Series
EM121R-GL Hardware Design
EM121R-GL Hardware Design 19 / 80
2.4. Pin Assignment
The following figure shows the pin assignment of the module. The top side contains module and antenna
connectors.
PIN2
PIN74
BOT
PIN1
PIN75
TOP
Pin Name No.
CONFIG_2 75
GND 73
GND 71
CONFIG_1 69
RESET# 67
ANTCTL3 65
ANTCTL2 63
ANTCTL1 61
ANTCTL0 59
GND 57
PCIE_REFCLK_P 55
PCIE_REFCLK_M 53
GND 51
PCIE_RX_P 49
PCIE_RX_M 47
GND 45
PCIE_TX_P 43
PCIE_TX_M 41
GND 39
USB_SS_RX_P 37
USB_SS_RX_M 35
GND 33
USB_SS_TX_P 31
USB_SS_TX_M 29
GND 27
DPR 25
WAKE_ON_WAN# 23
CONFIG_0 21
Notch
Notch
Notch
Notch
GND 11
USB_DM 9
USB_DP 7
GND 5
GND 3
CONFIG_3 1
PIN11
PIN10
No. Pin Name
74 VCC
72 VCC
70 VCC
68 ANT_CONFIG
66 USIM1_DET
64 COEX_TXD
62 COEX_RXD
60 WLAN_PA_EN
58 RFFE_DATA
56 RFFE_CLK
54 PCIE_WAKE_N
52 PCIE_CLKREQ_N
50 PCIE_RST_N
48 USIM2_VDD
46 USIM2_RST
44 USIM2_CLK
42 USIM2_DATA
40 USIM2_DET
38 NC
36 USIM1_VDD
34 USIM1_DATA
32 USIM1_CLK
30 USIM1_RST
28 PCM_SYNC
26 W_DISABLE2#
24 PCM_DOUT
22 PCM_DIN
20 PCM_CLK
Notch
Notch
Notch
Notch
10 WWAN_LED#
8 W_DISABLE1#
6
FULL_CARD_POWER_OFF#
4 VCC
2 VCC
Figure 2: Pin Assignment
