Quest Engineering V80 User manual

3
QUICK START
for V80 V60
VER:200111S63EN
QUICK START
ITEMS
V80
V60
V80 Control box
✔
V60 Control box
✔
Carbon fiber rod set
✔
O
Aluminum rod set
O
✔
Armrest+Elbow band
✔
✔
Blizzard11 Coil
✔
✔
Blizzard9 Coil
O
O
WireFree WRXB
✔
O
WireFree Pro HE
✔
O
WireFree Vibe
O
✔
USB Charger+Cable
✔
✔
Headphones Adaptor
✔
✔
Underwater Headphones
O
O
WRXB Receiver
VIBE Headphones
Waterproof
Headphones
PRO HE Headphones
CLICK ONCE TO
PINPOINT, CLICK
AGAIN TO RETURN
Maintenance
•Do not twist coil tail or connector to prevent wire damage.
•Store device away from extreme temperatures.
•Use soft object to operate touchpad to avoid damage.
•Avoid chemicals, solvents, and insect repellents that can harm waterproofing,
plastics, and finishes. Tightly secure audio protection cap to prevent damage to
audio port.
NOT POWER ON
Coil is not connected. Power is low, please recharge the
detector.
SPEAKER NO ALARM
Check the volume of speaker, or wireless headphones
VERY NOISY
Perform noise canceling. Please find another place with less
interference. Lower sensitivity
NO SOUND
Make sure the Volume is not set to ZERO level and/or wireless
audio has been activated
FALSING WHEN
SEARCHING IN GRASS
Use Velcro tape to secure cable to rod, prevent tangling, and
protect from hard impacts
OVERLOAD ALARM
Please turn to BEACH MODE if you are detecting on the beach
or high mineralized ground.
* Size not to scale
KEEP
50% OVERLAPPING
HOLD AND PUMP
FOR GROUND
BALANCE
QUEST METAL DETECTORS
[email protected]
6-8 hrs
3
4
5
6
1
2
INSTALLATION
1
Install controler
2
Install armrest
3
Extend rods
4
Connect coil to rod
5
Route coil cable on rods
6
Connect coil to controler
IN THE BOX
RECHARGE
BASIC TECHNICS
2
CLICK TO
SELECT MODE
1
4
HOLD FOR
NOISE CANCELING
CLICK TO
POWER ON
YOU ARE GOOD
TO GO NOW
OK
10 sec
BEACH
GOLD
BLIZZARD9
BLIZZARD11
Carbon-fiber rods
Aluminium rods
Armrest
Controller
Headphones Adaptor
Quick Start Manual
Trouble shooting
Cleaning
•Clean detector after underwater use,let handle dry completely.
•Beware of sand when changing coils on the beach.
•Clean detector with soft,clean, lint-free microfiber cloth.
•If dampening cloth, turn off device and disconnect from power.
•Gently wipe screen with microfiber cloth.
✔: included. O: optional

6
7
1
10
INTERFACE & MENU
SETTINGS
KEY FUNCTION
ALTERNATIVE FUNCTION
IN MENU FUNCTION
1
Power on
Hold 0.5 sec to Power off
Hold 0.5 sec to Power off
2
Change modes
Hold for All-Metal
Confirm, Accept/Reject ID
3
Change frequency
Hold to perform noise
cancelling
Return to higher level MENU
4
MENU Setup
Exit MENU
5
Pinpoint
Hold for Ground Balance
6
Volume up
Hold to + volume quickly
7
Volume down /
Vibration
Hold to - volume quickly
8
Increase sensitivity
Hold to + sensitivity quickly
Scroll up/Increase
9
Decrease sensitivity
Hold to - sensitivity quickly
Scroll down/Increase
10
Backlight adjust
Hold for flashlight
9
8
5
4
2
3
CONTROL BUTTONS
TONE SPACES
CORRECTION INDEX
MINERALIZATION %
SALT WATER %
SENSITIVITY LEVEL
SPEAKER VOLUME
WIRELESS AUDIO STATUS
TARGET ID
CLOCK
BACKLIT
BATTERY STATUS
TARGET ID MASK
SIGNAL STRENTH
FREQUENCY
MODE
FE/NONFE POSSIBILITY
TX POWER
RECOVERY SPEED
GYRO STATUS
IRON AUDIO
Click ⚙to enter MENU.Use▲▼ to navigate. Click upper▪to enter 2nd level. "
Use ▲▼ to navigate in 2nd level menu. Click lower▪to return to 1st level menu.
DETECT MENU
SOUND MENU
GROUND MENU
SET MENU
FUNCTION
DESCRIPTION
Target ID
Masking
Make custom patterns to separate wanted from unwanted
targets. Each target is shown by a number and a spot on the
Discrimination Scale (1-99). By choosing or not choosing,
you can decide if they will be detected or ignored.
Transmitter
Power
Adjust the strength of the electromagnetic field by changing
the TX POWER to different levels. The stronger the TX
POWER, the better the performance and it's a good option
for finding high-conductive targets such as large masses,
treasure, and certain currencies.
Recovery
Speed
Choosing a faster recovery speed helps to quickly analyze
signals in trashy conditions. A slower recovery speed is
better for clear and clean environments for increased depth.
Saved
Programs
Under this menu, press and hold the accept button to save
your current settings. You can also save your favorite settings
as personal programs for different situations, and manage
them here. You can apply, edit, or pin a selected program to
the top for easy access.
Tone
Numbers
The Target Tone Numbers categorizes target sounds into
several spaces. The more tone spaces you have, the more
different sounds you will hear. The changes will showed on
the ID bars at the stand by interface as well.
Tone Space
Under this menu, press the accept button to choose between
different joints, and use the up/down buttons to navigate
back and forth.
Tone Pitch
Tone Pitch lets you customize the sound frequency of target
responses based on target categories from 90 to 1500Hz. It
allows you to customize your desired audio and enhances
your ability to hear desired targets.
Tone volumes
The Tone volume gives you complete control over the audio
volume for detected targets in each Tone space.
FUNCTION
DESCRIPTION
Ferrous
Bias
Iron Bias setting gives the machine permission to
identify ferrous-appearing targets as iron or not. It
helps the detector accurately classify big or intricate
iron targets (such as rusted nails or bottle caps) as
ferrous, making them easier to reject.
Threshold
A threshold tone is a continuous background noise that
assists in distinguishing between desirable and
undesirable targets, as well as detecting soft signals. It
is critical setting in Gold Prospecting.
Gyro Sensor
Instruct the detector to automatically initiate ground
balance without manual button press. Enable the
detector to automatically enter power-saving mode if
there is no motion detected for 5 seconds. Activate
motion detection for the detector to measure swing
speed and angle for improved accuracy.
Manual
Ground
Blance
Manually select the ground effect correction
DIsplay
Setup
Accurately setup backlight brightness, LCD refresh rate
Clock setup
Wireless
Setup
Manage wireless headphone connections, including
searching for new devices, pairing, and unpairing
headphones.
Reset
Reset to factory default setting
