Quoizel HC2006IB User manual

Part Description Quantity
A Fixture Body 1pc.
B
C
D
E
F
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
A
B
C
D
E
Assembly Instruction Sheet #IS-HC2006IB
For Style HC2006IB
1of6
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wire
strippers,electricaltape,safetyglasses.
EstimatedAssemblyTime:20-30 minutes
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
F
1pc.
BulbRecommended: edgeBase Maximum(Supplied)(1)12V 18WT5W HalogenBulb,
G
1pc.
G1pc.
1pc.
Tube with Connector
Ground Spike
Tube
T5 Wedge Bulb
2 pcs.
Wire Connector
1pc.
Silicone Caulk
SILICONE CAULK
March2013

HC2006IB
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
2of6
FINISH: IMPERIAL BRONZE
(1)18W 12V T5 Wedge
Base Bulb
(Supplied)
Halogen
SILICONE CAULK
3
12006IBHC
G8209PA
I832SC
1
4
1
1
2
3
5.5” Sq.
6”
8”
23”
2.5”
9”
BASE HC2006IBIMPERIAL BRONZE
BULB 12V 18W ARGON T5 CLEAR
PANEL OPAQUE LINEN 6”H X 4”W

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of6
Assembly Instruction Sheet #IS-HC2006IB
For Style HC2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 1 -Assemble Ground Spike, Tube withe
Connecter, Tube and Fixture Body
together
A. To assemble fixture, thread Tube (E) into the Fixture
Body (A), hand tighten until snug.
B. Thread the Tube with Connecter (F) into the Tube (E),
hand tighten until snug.
C. Thread the bottom of Tube with Connecter (F) into
Ground Spike (G), hand tighten until snug.
STEP 2 Remove Fixture Hood from Shade Cage-
A. Remove the Fixture Hood from the Shade Cage by
unscrewing the Lock Screws.
B. Remove the package papers inside of the Shade Cage.
Figure 2
March2013
Figure 1
Tube
Fixture
Body
Ground Spike
Tube with
Connecter
Fixture
Hood
Lock Screw
Shade
Cage

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
4of6
Assembly Instruction Sheet #IS-HC2006IB
For Style HC2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 3 -Install Bulb
A. This fixture uses 12V . Maximum 8
watts.
B. Insert bulb and push snugly into place.
T5 Wedge Bulb (B) 1 Socket
Bulb Figure 3
March2013
STEP 4 Install Fixture Hood to fixture-
A. Place Fixture Hood back onto the Shade Cage, secure
by threading the Lock Screws into the Lock Hole on the
bottom of Fixture Hood. Hand tighten until snug.
Figure 4
Lock Hole
Fixture
Hood
Lock Screw
Shade
Cage

Transformer
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
5of6
Assembly Instruction Sheet #IS-HC2006IB
For Style HC2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 5 Make Wire Connections-
A. Use standard wire connectors to make all wire connections.
(Connectors are not included with fixture.) Strip and prepare
wire ends according to instructions supplied with connectors.
B. Connect White Supply Wire from the 12V transformer (not
supplied) to ribbed side wire from fixture.
C. Connect Black (or Red) Supply Wire from the 12V transformer
(not supplied) to smooth side wire from fixture.
D. Twist connectors until wires are tightly joined together.
E. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Tube.
Figure 5
White wire from
12V transformer
R
from fixture
ibbed side
wire
Black wire from
(or Red)
12V transformer
Smooth side
wire from fixture
Figure 6
March2013
STEP 6 Apply Silicone Sealer to tube-
A.
Your fixture is now assembled and ready to use. Enjoy!
Using Silicone Caulk (D) provided, inside each
connector (C).
B. Place Ground Spike (G) in predetermined location.
Figure 7
Silicone Caulk
Transformer
SILICONE CAULK
Ground

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
6of6
Assembly Instruction Sheet #IS-HC2006IB
For Style HC2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
CAUTION FOR BULB REPLACING
A. When replace bulb, turn off power and allow lamp to cool. For safety purpose, wear gloves and eye protection.
B. If bulb is scratched or cracked, DO NOT use the lamp to avoid breakage during use or installation.
C. Use only in fixtures rated for lamps wattage and voltage.
D. Lamp operate under high pressure generating intense heat. Prevent contact with liquid and combustible
materials.
