Quoizel MHE8410K Mounting instructions

Part Description Quantity
A Crossbar 1pc.
2 pcs.
2 pcs.
2 pcs.
B
C
D
E
F
Hex Nut
Lock Washer
Package Contents
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
A
B
C
D
E
Mounting Screw
Assembly Instruction Sheet #IS-MHE8410
For Styles MHE8410K and MHE8410VN
1of6
September2015
Pleasegoto forproductcleaningtips.Gotothe selection.
(3)CandelabraBase60WMaximum
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagrams
belowtobesureallpartsarepresent.Ifanypartsaremissingordamaged,donotattempttoassemble,install,or
operatethefixture.Contactcustomerserviceforreplacementparts.
www.quoizel.com Care+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wirestrippers,electricaltape,safety
glasses.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
G
1pc.
2 pcs.
Lock Ball
Fixture Loop
F
H
I
1pc.
G
H
I
Fixture Body
1pc.
4 pcs.
Panel
Cage
J
J2 pcs.
Lock Screw
Rev.A
K
Alternate Mounting Screw 2 pcs.
K

MHE8410K
1
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
2of6
FINISH: MYSTIC BLACK
GND
2.4mm
13Ga
QUOIZEL R
(3) 60W Candelabra
Base Bulbs
(No Supplied)
10” Sq. 10.5”
22”
10.5”
9.5” Sq.
5”
8”
G3780PA CLEAR SEEDY GLASS PANEL 4
1
MHE8410VN
FINISH: VENETO
Rev.A

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
3of6
STEP 2 Fix the Flat Scroll in place-
A. Rotate the Flat Scroll to the top of the fixture. Pull the
scroll end into the Fixture Loop (F).
Figure 2
STEP 1 -Attach Fixture Loop onto Fixture
Body
A. Thread the Fixture Loop (F) onto the Nipple on the top of
Fixture Body (G). Hand tighten until snug.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
September2015
Flat Scroll
Fixture Loop
STEP 3 Attach panel to Cage-
A. Insert Panels (H) into the Slot in the bottom of the Cage
(I) then fold the Tabs in the top of the Cage (I) to secure
the Panels (H).
Fixture Loop
Figure 1
Fixture Body
Nipple
Figure 4
Cage
Lock Screw
Fixture Hood
Stud
Slot
Hole
Mounting
Hole
Figure 3
Cage
Tab
Panel
Slot
STEP 4 Attach Cage with Panels to Fixture
Body
-
A. Align Slots on the top of Cage (I) with the Studs inside
of Fixture Hood, the Hole on the Fixture Hood with the
Mounting Hole on the Cage, secure by thread Lock
Screw (J) into the Mounting Hole. Tighten until sung.
Note: please make sure have Slot side of Cage over
against the backplate.
Assembly Instruction Sheet #IS-MHE8410
For Styles MHE8410K and MHE8410VN
Rev.A

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
4of6
STEP 6 -Attach Crossbar to Outlet Box
A. Attach the Crossbar (A) to Outlet Box and secure by
threading Outlet Box Screws (not supplied) into the
Mounting Holes on the Outlet Box. Tighten until snug.
Crossbar
Outlet
Box
Outlet Box
Screw
Mounting
Hole
Figure 6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
September2015
Figure 5
Crossbar
Lock Washer
Hex Nut
Backplate
Fixture
Body
Assembly Instruction Sheet #IS-MHE8410
For Styles MHE8410K and MHE8410VN
Rev.A
STEP 5 -Attach Mounting Screws, Lock
Washers and Hex Nuts to
Crossbar
A. Line up a set of holes on the Crossbar (A) and
Holes on the Backplate of the Fixture Body (F).
B. Thread Mounting Screws (B) or alternate short
mounting screws K into the holes on the Crossbar
(A), pass Lock Washers (C) and thread Hex Nut (D)
onto the Mounting Screws (B) or alternate short
mounting screws K . Hand tighten until snug.
Note: Use the Alternate Shorter Mounting Screw (K)
if your installation requires a shorter mounting
screw.
()
()
Mounting Screw
or Alternate Short
Mounting Screw

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
5of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
September2015
STEP 7 Make Wire Connections-
A. Use standard wire connectors to make all wire
connections. (Connectors are not included with fixture.)
Strip and prepare wire ends according to instructions
supplied with connectors.
B. Connect White Supply Wire from the Outlet Box to White
Wire from fixture.
C. Connect Black (or Red) Supply Wire from the Outlet Box
to Black Wire from fixture.
D. Connect Ground Wire from the Outlet Box to Ground
Wire from fixture.
E. Twist connectors until wires are tightly joined together.
F. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Outlet Box.
Figure 8
White wire from supply White wire from fixture
Black wire from supply
(or Red)
Black wire from fixture
Ground wire from supply Ground wire from fixture
Figure 9
Figure 7
Lock Ball
Backplate
Fixture Body
Assembly Instruction Sheet #IS-MHE8410
For Styles MHE8410K and MHE8410VN
Rev.A
STEP 8 -Attach Fixture Body to
Mounting Screw
A. Place the Backplate of the Fixture Body (F)
over the Mounting Screws (B) or Alternate
Short Mounting Screw (K). Place caulk
(not supplied) into threads of Mounting
Balls (E) and thread them onto the
Mounting Screws (B) or Alternate Short
Mounting Screw (K). Hand tighten until
snug.
Mounting Screw
or Alternate Short
Mounting Screw

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc.
6of6
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
STEP 9 Install Bulb-
A. This fixture uses standard bulbs with a standard screw
base. Maximum 60 watts.
B. Insert bulb and screw properly into place.
Figure 10
Bulb
Socket
September2015
Rev.A
STEP 10 Apply Silicone Sealer-
A. Make sure exterior wall surface and fixture backplate
are free of dirt before applying caulk. Using exterior
grade caulk, caulk over top of backplate and down
other side. Do not caulk bottom of fixture backplate to
ensure proper moisture drainage.
Your fixture is now assembled and ready to use.
Enjoy!
Exterior
Grade Caulk
Outdoor Fixture
Backplate
Exterior Wall Surface
Figure 11
