Quooker ST-VAQ User manual

Installation guide
Before installing read this guide first

The operation of the Quooker
The Quooker system consists of a small tank under the sink which is connected
to the boiling-water tap. This tank is connected to the water by a so-called inlet
combination. The water is heated electrically to approx. 110° and is kept at
this temperature. When boiling water is drawn off, cold water flows into the
tank at the same time and is automatically heated. Before the water leaves the
tank it is purified by the HiTA ®water filter (High Temperature Activated
arbon). If the entire content is used in one go the heating time is ten to
twenty minutes, depending on the electrical power (see technical specifications).
Different tanks are available: the ST-VAQ (800 W), the PRO3-VAQ (1600 W) and
the PRO7-VAQ (3200 W). All Quooker taps are fitted with a childproof
push-and-turn control knob and are also vertically adjustable and insulated.
Installation, maintenance and warranty
The Quooker can be installed wherever there is a water supply and a socket.
The Quooker comes with a handy installation kit (including the required inlet
combination) for easy fitting, and is maintenance-free. The HiTA ®filter
cartridge has to be replaced about once every three years, when any lime scale
that has built is also removed from the tank. The manufacturer gives a two-year
warranty on the entire system.
Technical specifications
Tanktype ST- PRO3- PRO7-
VAQ VAQ VAQ
Voltage 230 V 230 V 230 V
Wattage 800 W 1600 W 3200 W
apacity 3 litres 3 litres 7 litres
Heating-up time cold tank 20 mins. 10 mins. 10 mins.
Standby power consumption 10 W 10 W 10 W
Tank height 40 cm 40 cm 45 cm
Tank diameter 15 cm 15 cm 20 cm
Tap hole size 32 mm 32 mm 32 mm
Max. working pressure 8 bar 8 bar 8 bar
Safety features •maximum temperature
•pressure relief valve 8 bar
Shut-off valve ceramic
HiTA ®water filter High Temperature Activated arbon,
life expectation approx. 3 years
Introduction

12
3
4
1. Quooker tank
2. Quooker tap
3. Quooker inlet combination
4. Quooker drill bit, fibre rings, PV nipple and drain hose
5. Quooker brochure
6. Installation guide and tips for use
Content of the pack

It is recommended that you install the Quooker in the following order:
A. Drill hole
B. Fit tap
. onnect water
D. onnect drain
E. onnect tank
Overview of Quooker installation
hot water supply
cold water supply

Drilling hole
• The tap should be located in one corner of the basin(s).
• N.B. It must be possible to move the tap outlet freely up and down.
When the outlet is in its lowest position it projects approx.25 cm below the sink.
Bear this in mind when fitting the inlet combination, sockets and the like.
• The radius of the outlet is a good 16 cm from the centre of the tap hole,
which determines how far the outlet extends into the basin.
1
A
1 Drilling hole
Allowing for the basin and the mixer
tap, select a suitable location for the
Quooker tap (see examples). Using the
correct drill bit, drill a hole of 32 35
mm in the sink.
164
±70
Ø50
Maximum thickness 50
Hole Ø32-35
d=50
Basin
Max. 256
Dimensions in mm
Quooker tap
QMMixer tap

standard position
'left' position
1 Tap through
sink
Slacken the brass sink nut. Clinch the
loop in the hose and remove the sink
nut and the loose metal ring. Push the
tap through the hole in the sink.
Fit the rubber ring between the tap
and the sink.
2 Tightening
screws
Set the tap to the desired position
and tighten the screws in the sink nut.
Only if necessary!
A hex head bolt (key width 2 mm)
enables the tap to be twisted if neces-
sary. Slacken the hex head bolt. Viewed
from above turn it clockwise as far as
the stop. Then turn back a few degrees
so that the tap outlet is able to move
freely up and down. Then retighten the
hex head bolt.
1 2
Fitting tap
• N.B. The total length of the boiling water hose is only 50 cm. The tank must
therefore be fitted close to the tap. An extension hose is available but is not
normally required.
B

Connecting water
• N.B. The Quooker operates under water supply pressure and must always be
fitted with the inlet combination (supplied).
• The Quooker boiling-water tap must be connected according to the locally
applicable regulations.
• Position the inlet combination at such a height that the difference in height
between it and the drain is the maximum possible to allow the expansion
water to run off (see D4).
1 utting through
cold water pipe
Cut through the cold water pipe at a
suitable point.
2 Making space
for T-piece
3 onnecting
T-piece
Position the T piece between the pipe
sections and tighten the clamping nuts.
4 Fitting the inlet
combination
Connect the inlet combination to the
T piece with a copper tube (15 mm).
Screw the transparent funnel in the
hole in the inlet combination provided
for this purpose.
12
3 4
C

as high as possible
Connecting drain
The Quooker tank releases expansion water via the inlet combination during
heating, this water being fed into the transparent funnel. The funnel can easily
be connected to the drain by means of the drain hose supplied. The drilling kit
also supplied can be used to make a connection to the drain pipe.
Try to keep the difference in height between the inlet combination and the
connection to the drain as large as possible as the drain water can flow back.
1 2
3 4
1 Drilling hole
Using the drill bit supplied, drill and
tap in one operation a threaded hole
in the grey PVC drain pipe. Drill slowly
so that the PVC does not melt.
Turn back anticlockwise to preserve
the thread.
2 Screwing in
nipple
First try to screw the nipple in the
hole before fitting permanently with
PVC glue.
3 Hose to drain
Slide the drain hose over the PVC
nipple.
4 Hose on inlet
combination
Connect the other side of the hose
with a suspended bend to the funnel
of the inlet combination. This will
create a water lock to prevent smells
from the drain pipe.
D

Serialnumber
Connecting tank
• N.B. Do not switch on the Quooker until the tank is filled with water.
• The Quooker tank is supplied with a 3-core mains cord with earthed plug.
All that is required is an earthed socket close to the appliance.
• The Quooker tap is fitted with an indicator lamp which indicates whether or
not the heating element is heating.
1 2
3 4
1 onnecting
tank
Place the Quooker in position and
connect it to the inlet combination
with the fibre ring supplied.
2 onnecting tap
Connect the other short hose to
the tap in the same way with the fibre
ring supplied.
3 Flushing tank
Open the Quooker tap. Now open
the main tap and the tap of the inlet
combination. Check for leaks.
Flush the Quooker through for a few
minutes until the water is clear.
Black water will flow out first. This is
Norite carbon from the filter and is,
incidentally, completely harmless.
4 Electrical
connection
To connect the indicator lamp you
insert the bush in the hole provided.
Connect the tank to the earthed
socket and do not switch the lamp on
until the tank is filled with water.
After the Quooker has heated up the
entire content of boiling water must
be flushed through once before use.
E
1
