Radio Shack 270-258 User manual

Cat. No. 270-258
Outdoor Connection Box
Preparation for Mounting
1. Slide the cover off the back plate,
then thread a dropcable through thecen-
ter hole and attach it to the splitter’s in-
port. 2.If you have a two- or four-way
splitter, attach the splitter’s in-
port to the bracket marked 2-
WAY or 4-WAY.
If you have a three-way
splitter, attach the splitter’s
in-port to the bracket
marked
3-WAY.
Note: If you have a four-way splitter
with a center-port to center-port clear-
ance of less than 1inch, cut off the left
arm of the bracket marked 3-WAY be-
fore you attach the splitter.
Two-Wa
y
yFour-Wa
y
Three-Wa
y
270-258.fm Page 1 Monday, August 9, 1999 9:25 AM

Mounting the Back Plate and Splitter
1. To mount the back plate,
drive one of the supplied screws
into the mounting location through
the slot at the top of the back
plate.
2. To mount the splitter, drive
the other supplied screws into the
back plate and mounting location
through the screw holes on the
splitter.
3. Attach the remaining cables to
the splitter’s out-ports, then press
the cables into the slots on the
back plate’s shelf.
4. Slide the cover down over
the back plate until it snaps in
place over the locking tab. To se-
cure the cover, you can attach
one of the supplied box-locks
through the locking tab.
Custom Assembled in the USA with Foreign and Domestic
Components for RadioShack, A Division of Tandy Corporation,
Fort Worth, TX 76102
6/96 Printed intheUSA
22
1
U.S.PATENT 4,956,142
Access Control
Lock
U
.
S
.
P
A
T
E
N
T
5
,
0
6
4
,
2
3
1
49
270-258.fm Page 2 Monday, August 9, 1999 9:25 AM
