Owner’s Manual Please read before using this equipment.
Extra Remote Sensor
to 63-1030
63-1031.fm Page 1 Wednesday, June 28, 2000 10:25 AM

2
ˆ
Contents
Introduction ........................................ 4
Installing Batteries ............................ 5
Mounting the Sensor ........................ 8
Selecting a Location .................... 8
Using the Stand ........................... 9
On a Wall ................................... 10
Operation .......................................... 13
Changing the Display Channel ...... 13
Changing the Degree Format ........ 15
Resetting the Sensor ..................... 15
Care ................................................... 17
Specifications ................................... 18
©2000 RadioShack Corporation. All Rights Reserved.
RadioShack and RadioShack.com are trademarks
used by RadioShack Corporation.
63-1031.fm Page 2 Wednesday, June 28, 2000 10:25 AM

3
FCC INFORMATION
This device complies with Part 15 of the
FCC Rules
. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
This equipment complies with the limits
for a Class B digital device as specified in
Part 15 of
FCC Rules
. These limits pro-
vide reasonable protection against radio
and TV interference in a residential area.
However, your equipment might cause
TV or radio interference even when it is
operating properly. To eliminate interfer-
ence, you can try one or more of the fol-
lowing corrective measures:
63-1031.fm Page 3 Wednesday, June 28, 2000 10:25 AM

4Introduction
• reorient or relocate the receiving
antenna
• increase the distance between the
equipment and the radio or TV
Consult your local RadioShack store if
the problem still exists.
ˆ
Introduction
Your RadioShack Extra Remote Sensor
is designed for use with the RadioShack
Wireless Indoor/Outdoor Thermometer
with Indoor/Outdoor Hygrometer system
(Cat. No. 63-1030). Installation is easy,
with no wires to connect. You can mount
the remote sensor outdoors or in another
room (away from the system’s main unit),
63-1031.fm Page 4 Wednesday, June 28, 2000 10:25 AM

5
Introduction
or use its supplied wire stand for easy
viewing on a table or desktop.
INSTALLING BATTERIES
Your sensor requires two AA batteries
(not supplied) for power. For the best per-
formance and longest life, we recom-
mend RadioShack alkaline batteries.
Cautions:
• Use only fresh batteries of the
required size and recommended
type.
• Do not mix old and new batteries,
different types of batteries (standard,
alkaline, or rechargeable), or
rechargeable batteries of different
capacities.
63-1031.fm Page 5 Wednesday, June 28, 2000 10:25 AM

6Introduction
Note: If you expect to use the remote
sensor in temperatures below –4°F
(–20°C), we recommend you use lithium
batteries.
Follow these steps to install batteries.
1. Use a Phillips screwdriver to remove
the screws in the battery compart-
ment cover, then lift off the cover.
2. Set CHANNEL and °C/°F inside the
compartment to the desired set-
63-1031.fm Page 6 Wednesday, June 28, 2000 10:25 AM

7
Introduction
tings. (See “Changing the Display
Channel” on Page 13 and “Changing
the Degree Format” on Page 15)
3. Place the batteries in the compart-
ment as indicated by the polarity
symbols (+ and –) marked inside.
4. Use a pointed object (such as a
straightened paper clip) to press
RESET and initialize the sensor’s
transmitter.
5. Replace the cover and secure it with
its screws.
When appears (on either the sensor
or under the sensor’s channel number on
the main unit) or the sensor stops operat-
ing properly, replace the batteries.
63-1031.fm Page 7 Wednesday, June 28, 2000 10:25 AM

8Introduction
Warning: Dispose of old batteries
promptly and properly. Do not burn or
bury them.
Caution: If you do not plan to use the
sensor for a week or longer, remove the
batteries. Batteries can leak chemicals
that can destroy electronic parts.
MOUNTING THE SENSOR
You can place the remote sensor on a flat
surface, or mount it on the wall using
screws (not supplied) and the supplied
bracket.
Selecting a Location
Choose a location for the remote sensor
that is within about 328 feet (100 m) of
the main unit. The remote sensor can be
placed either indoors or out.
63-1031.fm Page 8 Wednesday, June 28, 2000 10:25 AM

9
Introduction
The construction of your home or office
might affect the transmission range be-
tween the main unit and the remote sen-
sor. If you have a choice of several
locations, try each to see which provides
the best performance.
Caution: Do not place the remote sensor
where it will be:
• in direct sunlight
• in water (it is weather-resistant, not
water-proof)
• near electrical appliances or heating
or air conditioning vents
Using the Stand
To set the remote sensor on a flat sur-
face, insert the ends of the supplied wire
63-1031.fm Page 9 Wednesday, June 28, 2000 10:25 AM

10 Introduction
stand into the holes on the back of the re-
mote sensor.
On a Wall
1. Drill two holes 13/4inches apart.
Then thread a screw into each hole,
letting the heads extend about 1/4
inch from the mounting surface.
63-1031.fm Page 10 Wednesday, June 28, 2000 10:25 AM

11
Introduction
2. Align the keyhole slots on the mount-
ing bracket with the screws and slide
the bracket downward to secure it.
63-1031.fm Page 11 Wednesday, June 28, 2000 10:25 AM

12 Introduction
3. Slide the remote sensor into the
mounting bracket.
63-1031.fm Page 12 Wednesday, June 28, 2000 10:25 AM

13
Operation
ˆ
Operation
Once you install batteries in the remote
sensor, it displays the current tempera-
ture, humidity, and the channel number it
is set to, and starts transmitting signals
(to your Cat. No. 63-1030 system’s main
unit) about every 41 seconds.
CHANGING THE DISPLAY
CHANNEL
The Cat. No. 63-1030 system’s main unit
can display information for up to three dif-
ferent remote sensors.
63-1031.fm Page 13 Wednesday, June 28, 2000 10:25 AM

14 Operation
Set CHANNEL 1/2/3 inside this remote
sensor’s battery compartment to a differ-
ent setting than all other remote sensors
you are using. Then press RESET using a
pointed object (such as a straightened
paper clip).
Note: If you set two or more remote sen-
sors to use the same channel, the main
unit displays temperature and humidity
information for the remote sensor's signal
it received first.
63-1031.fm Page 14 Wednesday, June 28, 2000 10:25 AM

15
Operation
CHANGING THE DEGREE
FORMAT
To change the displayed degree format,
set °C/°F inside the remote sensor’s bat-
tery compartment to the desired setting.
RESETTING THE SENSOR
If the remote sensor stops operating
properly, use a pointed object (such as a
straightened paper clip) to press RESET.
This resets the displayed temperature
63-1031.fm Page 15 Wednesday, June 28, 2000 10:25 AM

16 Operation
and humidity readings and re-initializes
the sensor’s transmitter.
63-1031.fm Page 16 Wednesday, June 28, 2000 10:25 AM

17
Care
ˆ
Care
Keep the sensor dry; if it gets wet, wipe it
dry immediately. Use and store the sen-
sor only in normal temperature environ-
ments. Handle the sensor carefully; do
not drop it. Keep the sensor away from
dust and dirt, and wipe it with a damp
cloth occasionally to keep it looking new.
Modifying or tampering with the sensor’s
internal components can cause a mal-
function and invalidate its warranty. If
your sensor is not performing as it
should, take it to your local RadioShack
store for assistance.
63-1031.fm Page 17 Wednesday, June 28, 2000 10:25 AM

18 Specifications
ˆ
Specifications
Power ......................... 3V with 2 AA Batteries
Temperature Operating Range ... –4° to 140°F
(–20° to 60°C)
Relative Humidity
Operating Range ..................... 25%–90% RH
RF Transmission Frequency ........... 433 MHz
RF Transmission Range ........... 328 ft at sight
(100m at sight)
Resolution ............................................. 0.2°F
(0.1°C)
Approximate Sampling Cycle ...... 41 Seconds
Accuracy ...................... ±1.8° at 32° to 104° F
(0° to 40°C)
±3.6° at –40° to 122° F
(–40° to 50°C)
±5.4° at –58° to 158° F
(–50° to 70° C)
63-1031.fm Page 18 Wednesday, June 28, 2000 10:25 AM

19
Specifications
Weight (without batteries) ..................... 2.8 oz
(80 g)
Dimensions ......................... 41/8×23/4×7/8in
(105 ×70 ×21.5 mm)
Specifications are typical; individual units
might vary. Specifications are subject to
change and improvement without notice.
63-1031.fm Page 19 Wednesday, June 28, 2000 10:25 AM

06A00
63-1031 Printed in China
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and
workmanship under normal use for one (1) year from the date of purchase from Ra-
dioShack company-owned stores and authorized RadioShack franchisees and dealers.
EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES
AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DU-
RATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT
AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBIL-
ITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR
PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING
FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR
PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAM-
AGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclu-
sion or limitation of incidental or consequential damages, so the above limitations or ex-
clusions may not apply toyou.
In the event of a product defect during the warranty period, take the product and the Ra-
dioShack sales receipt as proof of purchase date to any RadioShack store. RadioShack
will, at its option, unless otherwise provided by law: (a) correct the defect by product re-
pair without charge for parts and labor; (b) replace the product with one of the same or
similar design; or (c) refund the purchase price. All replaced parts and products, and
products on which a refund is made, become the property of RadioShack. New or recon-
ditioned parts and products may be used in the performance of warranty service. Re-
paired or replaced parts and products are warranted for the remainder of the original
warranty period. You will be charged for repair or replacement of the product made after
the expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of
God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions,
improper installation or maintenance, alteration, lightning or other incidence of excess
voltage or current; (b) any repairs other than those provided by a RadioShack Authorized
Service Facility; (c) consumables such as fuses or batteries; (d) cosmetic damage; (e)
transportation, shipping or insurance costs; or (f) costs of product removal, installation,
set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
RadioShack Customer Relations, 200 Taylor Street, 6thFloor, Fort Worth, TX 76102
We Service What We Sell
12/99
63-1031.fm Page 20 Wednesday, June 28, 2000 10:25 AM
