Rail King R-17 Subway Set User manual

PLEASE READ BEFORE USE AND SAVE
www.railking.com
Operation Manual
R-17 Subway Set
(3V PS2)
Compatibility
This engine will operate on any traditional
O-31 Gauge track system, including
M.T.H.’s RealTrax® or ScaleTrax™ or
traditional tubular track. It is also
compatible with most standard AC
transformers. (See page for a
complete list of compatible transformers
and wiring instructions.)
19

CAUTION: ELECTRICALLY OPERATED PRODUCT:
Not recommended for children under 10 years of age. M.T.H. recommends adult supervision with children ages 10 - 16.
As with all electric products, precautions should be observed during handling and use to reduce the risk of electric shock.
WARNING:Whenusingelectricalproducts,basicsafetyprecautionsshouldbeobserved,includingthefollowing:
Readthismanualthoroughlybeforeusingthisdevice.
lM.T.H. recommends that all users and persons supervising use examine the hobby transformer and other electronic equipment
periodically for conditions that may result in the risk of fire, electric shock, or injury to persons, such as damage to the primary
cord, plug blades, housing, output jacks or other parts. In the event such conditions exist, the train set should not be used until
properlyrepaired.
lDonotoperateyourlayoutunattended. Obstructedaccessoriesorstalledtrainsmayoverheat,resultingindamagetoyourlayout.
lThistrainsetisintendedforindooruse. Donotuseifwaterispresent. Seriousinjuryorfatalitymayresult.
lDonotoperatethehobbytransformerwithdamagedcord,plug,switches,buttonsorcase.
lThe transformer was designed to operate on regular US household current (120 volt, 50-60 Hertz). Do not connect to any other
sourceofpower.
lToavoidtheriskofelectricalshock,donotdisassemblethetransformerunit. Therearenouser-serviceablepartsinside. Iftheunit
isdamagedcontactM.T.H.Serviceforinstructions.
lThe transformer is equipped with an internal circuit protector. If the circuit protector trips, unplug the power cord from the
electrical wall outlet, check your layout for any short circuits. The circuit breaker will reset automatically when the short is
removedfromthecircuit.
lUnplugthetransformerfromtheelectricalwalloutletwhennotinuse.
lDonotusethistransformerforotherthanitsintendedpurpose.
Transformer Ratings:
Input: 120 VAC, 60 Hz Only, Outpu
This product may be protected by one or more of the following patents: 6,019,289; 6,280,278; 6,281,606; 6,291,263; 6,457,681; 6,491,263; 6,604,641;
6,619,594; 6,624,537; 6,655,640.
©2004, M.T.H. Electric Trains, Columbia, MD 21046
t: 14 VAC 80W or 18VAC 100W
2R-17 Subway Set with Proto-Sound® 2.0
Table of Contents
SetUpChecklist................................................3
GettingStarted.................................................4
AssemblingRealTrax.....................................4
ConnectingtheTransformer................................4
LubricatingtheEngine....................................5
CouplingtheEngineandCars ..............................5
CheckingtheBattery......................................5
BasicOperation ................................................6
OperationButtons........................................6
ManualVolumeControl...................................6
Proto-Sound2.0Operation.......................................7
Activating Proto-Sound 2.0 Conventional Mode Features. . . . . . . . . 7
OperatingModes.........................................8
TransitAnnouncementSounds.............................11
®
Proto-Coupler Operation.................................11
SpeedControl..........................................12
LockintoaDirection....................................13
AutomaticSounds.......................................11
Maintenance ..................................................14
Lubrication and Greasing Instructions . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning the Wheels, Tires and Track . . . . . . . . . . . . . . . . . . . . . . . 15
teractiveDVD.......................................20
Troubleshooting................................................21
TransformerCompatibilityChart.................................22
Additional Features with DCS Remote Control System. . . . . . . . . . . . . . . 23
Service and Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
LightBulbReplacement..................................16
Self-ChargingBatteryBack-Up............................18
TractionTireReplacement................................19
RailWare In

Tools Needed
Cotton Swab or Rag
Scissors
Pliers
Philips Screwdriver RailKing Maintenance Kit or
Light Household Oil and Bearing Grease
Set Up Checklist
®
rAssemble RealTrax
rConnect the transformer
rLubricate the engine
rPlace the engine and cars on the track and couple them together
rCheck to see whether the battery needs to be charged for full sound effects
rApply power to run as described in the Basic Operation section of these
instructions.
3
Battery Charger (Optional)
You can obtain replacement parts and replacement instructions from the M.T.H. Parts
Department
e-mail: [email protected], phone: [phone],
mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532
R-17 Subway Set with Proto-Sound® 2.0
Set Includes
8-Pieces
O-31 Curve RealTrax
DVD/CD-Rom
4-Pieces
Straight RealTrax Transformer and Controller
with wire harness Lighted Lock-On
Two Subway Cars

4
Gently push together RealTrax
Insert lock-on into
knock-out tab
(Lock-on is the interface between
the track and transformer)
Make sure the metal
contacts line up. Align Quick
Connect Plugs
Knock-out must be removed
before remote lock-on can
be installed
Remove knock-out from
outer edge of track by
holding and twisting up
with a pair of pliers
REMOVE TAB
FROM OUTER EDGE
STEP
11STEP 22STEP 33
STEP
44STEP 55STEP 66
R-17 Subway Set with Proto-Sound® 2.0
-750
DIRECTION
BELL
HORN
WHISTLE
POWER
AILING
RK
ByMTHElectricTrains
®
TRANSFORMER CONTROLLER
OFF
FULL
POWER
Also functions as a binding post.
Red Harness
Wire/Plug
Red Harness
Wire/Plug
Black Harness
Wire/Plug Black Harness
Wire/Plug
Getting Started
Assembling RealTrax®
The quick connectors and built-in roadbed allow you to set up RealTrax anywhere,
including carpeted surfaces.
Connecting the Transformer
The transformer included with this set provides an easy-to-use, safe power source for AC-
powered trains and accessories.
To complete the connection between the track and the transformer, simply plug in the color-
coded wire harness that was included in your set and plug the transformer into your wall
outlet.
• Plug the wire from the transformer into the Z-Controller’s center port.
• Connect the Wires from the Z-Controller to the Lighted Lock-On, being
sure that the wires are connected from red-to-red and black-to-black.
• Unplug when not in use.
From Transformer

DO NOT
OVER OIL
DO NOT
OVER OIL
DO NOT
OVER OIL
5
Position
armiture
for proper
operation
Incorrect
Position Place the cars on the
track. Open couplers by
pressing down on plunger.
Push cars together
STEP
11STEP 22STEP 33
R-17 Subway Set with Proto-Sound® 2.0
Lubrication
Lubricate all exposed moving parts before operating, using a multi-
prupose, oil (available with M.T.H.’s Maintenance Kit, sold separately)
or a light household oil. Follow the lubrication points.
Coupling the Powered and Non-Powered Subway Cars
lubricate Pick up Rollers (L) lubricate Pick up Rollers (L)
lubricate Wheel Axles (L)
(On each Truck)
Checking The Battery
You may find, if your locomotive was built several months before you set it up, that the
rechargeable battery has run down and needs to be charged before operating. If you
notice that the sounds are garbled, test and charge the engine as described in the “Self-
Charging Battery Back-up” on page 18.

Basic Operation
Throttle Throttle up the power to your track. Advance the throttle until 12 – 16 volts is
applied, then put the subway set into forward motion by either firmly pressing the
Direction button on your transformer or remote once or dropping and advancing the
throttle.
Bell - To sound the bell, quickly press and release the Bell button. If you press the button
for too long, you will trigger the TransitAnnouncement Sounds described later in this
book. To turn the bell off, press and release the Bell button again. The bell will continue to
ring from the time you turn it on until you press and release the button again to turn it off.
Horn/Whistle - To sound the horn, firmly press the Horn/Whistle button. The horn will
sound for as long as you continue to depress the button. It will stop when you release the
button. The horn has four different endings, depending on whether you hold the button for
less than three seconds, three seconds, four seconds, or five seconds or longer.
Direction Your train is programmed to start in neutral. The first direction from neutral
upon start-up is forward. Firmly press and release the Direction button to allow the engine
to move forward. Just as you must stop your automobile between forward and reverse, this
engine will not go directly from forward to reverse; it goes into neutral between directions.
If the train has been moving forward, the first press
of the Direction button will put the train from
forward into neutral, the second press into reverse,
the third press back into neutral, and the fourth back
into forward. To prevent accidental high-speed start-
ups, this engine is programmed to restart in neutral
each time the track voltage is turned off for
approximately 25 seconds or more.
Manual Volume Control
To adjust the volume of all sounds made by this engine, turn the master volume control
knob located under the powered unit (See Figure 2) clockwise to increase the volume and
counter-clockwise to decrease the volume.
Cycle Phases
Neutral
Neutral ForwardReverse
6R-17 Subway Set with Proto-Sound® 2.0
Figure 2: Manual Volume Adjustment
Manual Volume Adjustment

Timing Chart
Total Time Lapse: 1 Seconds½
Press
Horn
Short &
Firm
½ Sec.
Pause ½ Sec. Pause
Press
Bell
Short &
Firm
Press
Bell
Short &
Firm
7
R-17 Subway Set with Proto-Sound® 2.0
Proto-Sound 2.0 Operating Instructions
This manual contains the operating instructions for Proto-Sound 2.0 in conventional mode
only. Instructions for accessing DCS command mode features accompany the DCS Remote
Control System equipment (sold separately.)
Activating Proto-Sound 2.0 Conventional Mode Features
Proto-Sound 2.0 features are activated by sequences of Bell and Horn button pushes
described below. Please read the full descriptions of each feature before using it. To use
these buttons to activate features rather than to blow the horn or ring the bell, you should
press the buttons firmly, but rapidly with a ½-second pause between button presses. You
may need to practice your timing to make this work smoothly.

8R-17 Subway Set with Proto-Sound® 2.0
Operating Modes
1. Manual Mode
Upon initial power application, the engine will start up in manual mode. The chart below
lists the features available to the operator when in Manual Mode. Different features are
available when operating in Learn and Auto Modes, which are described later.
Feature to Be Activated Button Code:
Freight Yard Sounds
Fire the Rear Coupler
Fire the Front Coupler
Speed Control On/Off
Lock into a Direction
Reset to Factory Defaults
1 Bell, 2 Horns
1 Bell, 3 Horns
1 Bell, 4 Horns
1 Horn, 2 Bells (from Neutral only)
1 Horn, 3 Bells
1 Horn, 5 Bells (from Neutral only)
TransitAnnouncement Sounds (TAS)
Your Proto-Sound 2.0 street car is equipped with operator controlledTransit Announcement
Sounds, hereafter known as TAS. This easy-to-use feature plays digitally reproduced transit
announcements and platform action sounds whenever you activate and stop your engine.
No additional wires or modifications are needed on your layout to enjoy these amazing
sound effects. These different sounds are heard each time you give a long bell button press.
The entire TAS sequence is designed to simulate the arrival, disembarking, embarking, and
departure of a transit stop. The sounds include the driver announcing the stop and the
upcoming stop, passenger disembarking and embarking sounds, driver to passenger
requests, door openings and closing and general transit stop sounds. After the station
sounds have finished, the engine will shift back into gear and, if the throttle is set high
enough, will pull away from the station. To activate theTAS, press and hold the bell button
for approximately 2 seconds.

2. Learn Mode
In Learn Mode, the engine may be programmed with either an "Out & Back" route or a
"Loop" route. An "Out & Back" route begins at the 1st station (as programmed by the
operator), stops at intermediate stations, ends at the last station, then reverses its route until
it reaches the 1st station. A "Loop" route begins at the 1st station (as programmed by the
operator), stops at intermediate stations, ends at the last station, and then begins the route
over again at the 1st station.
Example Of An Out-and-Back:
Flatbush
Avenue
Flatbush
Avenue
241st
Street
42nd
Street
Wall
Street
42nd
Street
Wall
Street
Example Of ALoop:
Flatbush
Avenue 42nd
Street
241st
Street
Wall
Street
To program stations:
1. Running in Forward, stop the unit at the desired location for the first stop by pressing
the direction button. Note: if you stop the engine with the throttle control, you must re-
apply power so that the engine goes into neutral and does not shut down.
R-17 Subway Set with Proto-Sound® 2.0

10 R-17 Subway Set with Proto-Sound® 2.0
2. Enter Learn Mode by pressing Horn-Bell-Bell-Bell-Bell. The train will then announce
that you have entered Learn Mode.
3. Press and hold the Bell button to scroll through the available stations until you hear the
one that you would like to be your first stop. Release the button quickly as soon as you
have heard the desired stop name.
4. Press and hold the Horn button until a "saved" response confirms that station's location
and name are saved in memory.
5. Proceed to the next stop by pressing the Direction button.
6. Press the Direction button to stop the train again when you have reached the next
desired station location.
7. Using the Bell button, select the name of the station, then save using the Horn button.
8. Repeat steps 5-7 until you are ready to program the last stop in the route.
9. The manner of saving the last station in the route determines whether the route will be
an "Out & Back" or "Loop" route.
"Out & Back"
Follow steps 5-7 to save the last station. After you press the Horn button and
the sound system plays the "Saved" confirmation, press the Horn button again.
Another "Saved" confirmation will play and the car will exit Learn Mode and
enter Manual Mode.
“Loop" Follow steps 5-7 to save the last station. Press the Direction button once to
start the car in forward and stop the car at the location of the first stop by
pressing the Direction button. Press the Bell button as many times as is
necessary to hear the name of the first stop. Press the Horn button until the
"Saved" confirmation is played. The car will then automatically exit Learn
Mode and enter Manual Mode.
Notes:
Always approach a desired station stop location while running in Forward. Learn mode
counts distance traveled, not actual physical locations. However, unlike an automobile's
odometer, Proto-Sound 2.0 Learn Mode does erase distance when traveling in reverse. If
you operate your car past the desired stop location, you may back it up to the desired

11
R-17 Subway Set with Proto-Sound® 2.0
Auto Mode
When you have finished programming your stations in Learn the car will be in Manual
Mode. Running in Forward, stop the car at the location of the first programmed station by
pressing the Direction button. Press Bell-Horn-Horn to put the train into Auto Mode. Press
the Direction button again to begin operation in Auto Mode. BecauseAuto Mode operation
begins at the first stop, the next stop announced will be the second stop.
Function Learn Mode Button Code:
To Enter Learn Mode
To Stop at Each Station
To Scroll through the Station Names
To Save Station
1 Horn, 4 Bells
Direction
Bell (hold to scroll and release as soon
as you hear the desired station name)
Horn (hold for "Saved" response)
Function Auto Mode Button Code:
To Enter Auto Mode from
Manual Mode
To Begin Programmed Run
1 Bell, 2 Horn at the location of the
first programmed station stop
Direction
Function Manual Mode Button Code:
To Enter Manual Mode
from Auto Mode 1 Bell, 2 Whistles
Proto-Coupler® Operation
This locomotive is equipped with one coil-wound Proto-Coupler for remote uncoupling
action. Because Proto-Couplers are controlled through the Proto-Sound 2.0 microprocessor,
they do not require an uncoupling track section or modification to your layout to function.
You can fire a coupler from neutral or while in motion. Use the code shown below (and in
the chart on p. 7) to fire the coupler(s).
Front Coupler:
To fire the front coupler, quickly tap the Bell button once followed by four quick taps of the
Horn button, allowing approximately ½ second to lapse between each quick button press.
The sound of the liftbar and air line depletion will play, and the knuckle will be released.
Horn Horn
Fire
Front
Coupler
=
Horn
Bell
Horn

12 R-17 Subway Set with Proto-Sound® 2.0
Speed Control
M.T.H. engines equipped with Proto-Sound 2.0 have speed control capabilities that allow
the engine to maintain a constant speed up and down grades and around curves, much like
an automobile cruise control. You can add or drop cars on the run, and the engine will
maintain the speed you set.
While the engine is programmed to start with the speed control feature activated, you can
opt to turn it off. This means the engine's speed will fall as it labors up a hill and increase
as it travels downward. It is also affected by the addition or releasing of cars while on the
run. Because the engine will run more slowly at a given throttle voltage when speed control
is on than when it is off, you should adjust the throttle to a lower power level for operation
with speed control off to avoid high-speed derailments. When speed control is off, the
volume will drop to allow for better low voltage operation.
To turn speed control on and off, put the engine in neutral, then quickly tap the
transformer's Horn button one time then quickly tap the Bell button two times, allowing
approximately ½ second to lapse between each quick button press. Two horn blasts will
indicate that the engine has made the change. Repeat the 1 horn, 2 bells code to return it to
the other condition. You will want to do this during the initial neutral upon start-up if you
ever couple this engine to another engine that is not equipped with speed control to avoid
Horn
Place
Engine into
Neutral
Bell Bell
=Speed Control
Two Horn Blasts
(indicates change is made)
Repeat to Return
to Normal Condition

R-17 Subway Set with Proto-Sound® 2.0 13
Locking Locomotive Into ADirection
You can lock your engine into a direction (forward, neutral, or reverse) so that it will not
change directions. To do this, put the engine into the direction you want (or into neutral to
lock it into neutral), run it at a very slow crawl (as slowly as it will move without halting),
and quickly but firmly tap the Horn button once followed by three quick taps of the Bell
button, allowing approximately ½ second to lapse between each quick button press. Two
horn blasts will indicate that the engine has made the change. The engine will not change
direction (including going into neutral) until you repeat the 1 horn, 3 bells code to return
the engine to its normal condition, even if the engine is kept without power for extended
periods of time.
Reset To Factory Default
To override the settings you currently have assigned to the engine and reset it to its factory
defaults, while in Neutral tap the Horn button quickly once, followed by five quick taps of
the Bell button, allowing approximately ½ second to lapse between each quick button press.
Two horn blasts will indicate that the engine has made the change.
Automatic Sound Effects
Certain Proto-Sound 2.0 sound effects automatically play in programmed conventional
mode conditions:
• Squealing Brakes play any time the engine's speed decreases rapidly.
• Platform Action sounds play at random intervals when the engine idles in neutral.
• Engine Start-up and Shut-down sounds play when the engine is initially powered on or is
powered off for five seconds or more.
Reset
Two Horn Blasts
(indicates change is made)
Repeat to Return
to Normal Condition
Horn
Place
Engine in
Neutral =
BellBellBellBellBell
Direction Lock
Two Horn Blasts
(indicates change is made)
Repeat to Return
to Normal Condition
Horn
Place
Engine in
Neutral =
BellBellBell

14 R-17 Subway Set with Proto-Sound® 2.0
Maintenance
Lubricating and Greasing Instructions
The engine should be well oiled and greased in order to run properly.
Regularly lubricate all axles and linkage components and pickup rollers
to prevent squeaking. Use light household oil, such as that found in
M.T.H.'s maintenance kit. Do not over oil. Use only a drop or two on
each pivot point.
The locomotive’s internal gearing was greased at the factory and should not need additional
grease until after 50 hours of operation or one year, whichever comes first. Follow the
greasing instructions below. Note that in some tightly packed engines you may need to
move internal components temporarily in order to access the gears.
1. Remove the four Phillips screws from the chassis, as seen in Figure 3, then lift the body
partially away from the chassis. Unplug three connectors (2 pin type) located at the front of
the car to separate the body completely from the chassis.
2. Remove the four Interior Detail Screws shown in Figure 3 and separate the interior
detail from the chassis.
3. Once the motor mount screw has been removed, pull the motor away from the truck
block and lightly coat the motor worm gear and bronze drive gear (in the truck block) with
grease.
4. Reassemble the truck and motor, being careful not to pinch any wires between the truck
block and motor mount.
Body Mount Screws
DO NOT
OVER OIL
DO NOT
OVER OIL
DO NOT
OVER OIL
Interior Detail Screws
Body Mount Screws
Motor Mounting Screws
Front of Car
Figure 3

15
R-17 Subway Set with Proto-Sound® 2.0
5. Repeat the procedure for the other motor
and truck.
6. Reassemble the chassis and body, being
careful that the wires are not caught between
the body and chassis, as this can lead to a
short that may damage the electronics
beyond repair.
7. Before replacing body mount screws, test
the unit on powered track to make sure all
light housings are in place and functioning.
Replace screws and door slider handles.
Periodically check the locomotive wheels and
pickups for dirt and buildup, which can cause
poor electrical contact and traction as well
as prematurely wear out the neoprene
traction tires.
Cleaning the Wheels, Tires and Track
Periodically check the locomotive wheels and
pickups for dirt and buildup, which can cause
poor electrical contact and traction and
prematurely wear out the neoprene traction tires.
Wheels and tires can be cleaned using denatured
(not rubbing) alcohol applied with a cotton
swab.
To clean the track, use a clean rag and RailKing Track Cleaning Fluid or
denatured (not rubbing) alcohol. Unplug the transformer and wipe the rails of
the track, turning the rag frequently to ensure that you are using clean cloth on
the rails. Because the manufacturing process leaves a coat on RealTrax, you
should clean the rails after the first 30 minutes of use (you may smell
something burning during initial use as the coat burns off; this is normal).
Thereafter, keep an eye on the track and clean it when it gets dirty to ensure
good electrical contact and to lengthen the life of the tires.
Lubricate Worm Gear

16 R-17 Subway Set with Proto-Sound® 2.0
Lightbulb Replacement
Instructions
Interior Lights
To replace the interior lights in the
powered unit:
1. Follow the shell removal instructions
found in the “Lubrication and Greasing”
section of this booklet.
2. Pull bulb straight out to remove.
(See figure 5)
To replace the interior lights in the
unpowered units:
1. Remove the four Phillips screws
from the chassis (same as power unit),
then lift the body away from the chassis.
Lift the shell off carefully and turn body
shell over to reveal interior lights. (See
figure 6)
2. Pull light bulbs straight out and push
new bulbs straight in to replace.
(See figure 7)
Gently Pull Bulbs Away From Socket To Remove
Figure 5
Non-Powered Car Chassis & Body
Gently Pull Bulbs Away From Socket To Remove
Figure 6
Figure 7

17
R-17 Subway Set with Proto-Sound® 2.0
Headlights
To replace the headlights and other
end-of-car lights in the powered unit:
1. Remove the shell as described in
the “Lubrication and Greasing”
section of this booklet.
2. Pull out the bulb shown in Figure 8
to replace the Number/Destination
Board bulb.
3. To replace the headlight bulbs,
remove the harness witht the blue 2
pin connector shown in Figure 9.
4. To replace the top marker lights,
remove the harness with the yellow 2
pin connector shown in Figure 9. 5.
To replace the marker lights below the
headlight, remove the harness with the
green 2 pin connector shown in Figure
9.
Replacement bulbs and wire ties are
available directly from the M.T.H.
Parts Department (order online:
www.mth-railking.com, e-mail:
[email protected]; mail: 7020
Columbia Gateway Drive, Columbia
MD 21046-1532, FAX: 410-381-
6122).
Gently Pull Bulbs
Away From Socket
To Remove
Unplug Marker Light Wires
From Socket To Remove
Figure 8
Figure 9

18 R-17 Subway Set with Proto-Sound® 2.0
Self Charging Battery Back-Up
The 2.4v NiCad self-charging battery pack recharges continuously during train operation
and should last for up to five years. It is a battery type that should not leak or cause any
damage to your engine. Depending upon when your engine was built, the battery may need
to be charged right out of the box.
If engine sounds seem distorted or garbled at low voltages or become silent when power
from the transformer is turned off, test the batteries to determine whether the battery should
be recharged or replaced.
Test: Put the engine in neutral and leave the track voltage at 10-12 volts (high enough for
the lights to shine brightly) for 15 minutes.
Recharge: If the sounds are improved at the end of the 15-minute test charge, the batteries
charge has run down and can be recharged. There are a number of ways you can do this:
Leave the engine in neutral with track
voltage at 10-12 volts for 6-7 hours so
the batteries can fully recharge (if your
engine has a smoke unit, be sure it is
turned off).
Use M.T.H.'s battery recharger (sold
separately) that plugs into a wall outlet
and a special port under the engine to
recharge the batteries overnight without
leaving it on the track. (See figure 11)
Replace: If the sounds are not improved
at the end of the 15-minute test charge,
it is time to replace the batteries. Available
through M.T.H. Parts. (See figure 10)
DO NOT substitute alkaline batteries for
these NiCad batteries. Using alkaline
batteries in this system will result in damage
to the PS 2.0 circuit board and/or the batteries.
Unhook Wires, Remove,
and Replace Battery
Figure 10
Battery charging port
under the engine
Figure 11

19
R-17 Subway Set with Proto-Sound® 2.0
Traction Tire Replacement
Your subway set is equipped with two neoprene rubber traction tires on each
powered truck block. While these tires are extremely durable, you may need to
replace them at some point.
First, remove the truck sides from the
truck block. To do this, turn your
engine upside down and remove the
truckside mounting screws as seen
in (figure 12).
Once the truck sides have
been removed:
1. Make sure the old tire has been
completely removed from the groove
in the drive wheel, using a razor
blade or small flathead screwdriver
to pry away any remains.
2. Slip the new tire onto the wheel. You may find it useful to use two small
flathead screwdrivers to stretch the tire over the wheel.
3. If you twist the tire while stretching it over the wheel, you will need to
remove and reinstall the tire. Otherwise your engine will wobble
while operating.
4. Make sure the tire is fully seated inside the groove. Use a razor blade to trim
away any excess tire that doesn’t seat itself inside the groove properly.
5. Reassemble in reverse order.
One set of replacement tires is packaged with the model. Additional tires are
available directly from the M.T.H. Parts Department (order online: www.mth-
railking.com, e-mail: [email protected]; mail: 7020 Columbia Gateway
Drive, Columbia MD 21046-1532, FAX: [phone]).
Screws to Remove Trucksides
Figure 12

20 R-17 Subway Set with Proto-Sound® 2.0
Quick-Start DVD
The included DVD Quick-Start video demonstrates the start-up and basic operation of
this set as well as other information about model railroading. You may find it helpful to
view the DVD before operating this set.
RailWare Interactive CD ROM
M.T.H. provides a free RailWare CD ROM in each Ready-To-Run set. It is full of helpful
information on M.T.H. product history, track planning software, a dealer finder, and
information and video clips on Loco-Sound and Proto-Sound 2.0. Follow the directions
below to use the CD ROM.
Minimum System Requirements: Pentium 100, 16MB RAM, Windows 95 or later, CD
ROM drive, Sound Card, display properties set to greater than 256 colors. The CD will
®
not work on a Mac OS unless you run VirtualPC .
Running RR-Track Software
You may run the RR-Track software directly off of the CD ROM or you may install the
software to your hard drive.
1. On the Desktop, click on the icon that says My Computer.
2. Find your CD ROM drive.
3. With the M.T.H. CD ROM in the drive, double click on the icon for the CD ROM
drive.
4. Find the folder on the CD ROM entitled INSTALLATION.
5. Choose the folder inside entitled RRTRAXSETUP.
6. Run the file in that folder called SETUP.EXE and follow the directions it provides.
The program may ask you for a registration code. If it does type in "M.T.H." and it will
run.
Additional track libraries can be obtained directly from RR-Track. See their website for
more information www.rrtrack.com.
Installing Adobe Acrobat Software
To read some of the electronic documents included on the CD ROM, you will need to
®
install the Adobe Acrobat Reader if it is not already on your computer. To install the
software:
1. On the Desktop, click on the icon that says My Computer.
2. Find your CD ROM drive.
3. With the MTH CD ROM in the drive, double click on the icon for the CD ROM
drive.
4. Find the folder on the CD ROM entitled INSTALLATION.
5. Choose the folder inside entitled ACROBAT READER.
*If you are running Windows 95, 98 or NT choose the folder 32 BIT. Run the file
AR32E301.EXE and follow the directions it provides.
If you have problems you cannot resolve by using these directions, contact
[email protected] or call 410-381-2580 for further help.
