Raisecom ISCOM6860 User manual

ISCOM6860 (A)
Hardware Description
(Rel_03)
www.raisecom.com

Raisecom Technology Co., Ltd. provides customers with comprehensive technical support and services. For any
assistance, please contact our local office or company headquarters.
Website: http://www.raisecom.com
Tel: [phone]
Fax: [phone]
Email:[e-mail]
Address: Raisecom Building, No. 11, EastArea, No. 10 Block, East Xibeiwang Road, Haidian District, Beijing,
P.R.China
Postal code: 100094
-----------------------------------------------------------------------------------------------------------------------------------------
Notice
Copyright © 2018
Raisecom
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means,
electronic or mechanical, including photocopying and microfilm, without permission in Writing from Raisecom
Technology Co., Ltd.
is the trademark of Raisecom Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
i
Preface
Objectives
This guide mainly describes the ISCOM6860 in terms of chassis, fan, card, cable, optical
module, and electromechanical component, which will help you understand the hardware
feature, components, functions that can be implemented by various components, and
hardware technical specifications.
Versions
The following table lists the product versions related to this document.
Product name
Hardware version
Software version
ISCOM6860
A.03 or later
V2.6 or later
Related manuals
The following table lists manuals and their contents related to the ISCOM6860.
Name
Description
ISCOM6860 Product Description
This document mainly describes features, function,
structure, and technical specifications of the
ISCOM6860, including product overview, system
structure, function and features, networking
applications, management and maintenance,
technical specifications, and appendix.
ISCOM6860 Hardware Description
This guide mainly describes the hardware structure
and card of the ISCOM6860, including product
overview, chassis, fan, cards, cables, pluggable
optical modules, lookup table of LEDs, and lookup
table of weight and power consumption.

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
ii
Name
Description
ISCOM6860 Configuration Guide
This guide mainly describes services supported by
the ISCOM6860, and introduce configuration
methods and procedures of these services in terms
of service overview, default configurations,
configuration methods, and configuration
examples, including basic configurations, EPON
service configurations, multicast service
configurations, VoIP service configurations, CATV
service configurations, TDMoP service
configurations, MAC address table configurations,
VLAN configurations, Spanning Tree
configurations, route configurations, DHCP
configurations, QoS configurations, system
security configurations, link security
configurations, and system management
configurations.
ISCOM6860 Command Reference
This guide mainly describes command formats and
parameters supported by the ISCOM6860,
including system commands, EPON system
commands, MAC address table, multicast, VoIP,
CATV, TDMoP, VLAN, spanning tree, route,
DHCP, QoS, system security, link security, and
system management.
ISCOM6860 Maintenance Guide
This guide mainly describes routine maintenance
methods and common troubleshooting procedures,
including safety introduction, routine maintenance,
troubleshooting procedures, system trouble
shooting, data troubleshooting, voice
troubleshooting, and commonly-used maintenance
commands table.
ISCOM6860 Installation Guide
This guide mainly describes precaution before
installation, installation methods, and verification
after installation, including safety introduction,
installation description, installing the chassis,
installing the fan and the air exhaust plenum,
installing cards, wiring cables, hardware
installation verification, power-on verification,
device initialization, and installation reference.
ISCOM6860 Quick Installation
Guide
This guide mainly describes installation
procedures, including installation tools, precaution,
installation scenario, installation conditions, and
installation steps.

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
iii
Conventions
Symbol conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates a hazard with a medium or low level of risk which, if
not avoided, could result in minor or moderate injury.
Indicates a potentially hazardous situation that, if not avoided,
could cause equipment damage, data loss, and performance
degradation, or unexpected results.
Provides additional information to emphasize or supplement
important points of the main text.
Indicates a tip that may help you solve a problem or save time.
General conventions
Convention
Description
Times New Roman
Normal paragraphs are in Times New Roman.
Arial
Paragraphs in Warning, Caution, Notes, and Tip are in Arial.
Boldface
Names of files, directories, folders, and users are in boldface.
For example, log in as user root.
Italic
Book titles are in italics.
Lucida Console
Terminal display is in Lucida Console.
Book Antiqua
Heading 1, Heading 2, Heading 3, and Block are in Book
Antiqua.
Change history
Updates between document versions are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Issue 03 (2018-06-04)
Third commercial release
Fixed known bugs.

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
iv
Issue 02 (2017-02-23)
Second commercial release
Fixed known bugs.
Upgraded the hardware version to A.03.
Issue 01 (2016-09-23)
Initial commercial release

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
v
Contents
Contents .............................................................................................................................................5
Figures ................................................................................................................................................9
Tables ...............................................................................................................................................11
1 Product overview...........................................................................................................................1
1.1 Appearance.......................................................................................................................................................1
1.2 Structure...........................................................................................................................................................2
1.3 Slot distribution................................................................................................................................................2
1.4 Capacity distribution ........................................................................................................................................3
1.5 Technical specifications ...................................................................................................................................3
2 Fan....................................................................................................................................................5
2.1 Features............................................................................................................................................................5
2.2 Appearance.......................................................................................................................................................5
2.3 LEDs ................................................................................................................................................................6
2.4 Technical specifications ...................................................................................................................................6
3 Cards................................................................................................................................................7
3.1 Overview..........................................................................................................................................................7
3.1.1 Appearance and dimensions....................................................................................................................7
3.1.2 Card types ...............................................................................................................................................8
3.1.3 Hardware information labels...................................................................................................................9
3.2 SMCA card.....................................................................................................................................................10
3.2.1 Features.................................................................................................................................................10
3.2.2 Panel and slots.......................................................................................................................................10
3.2.3 Interfaces............................................................................................................................................... 11
3.2.4 LEDs.....................................................................................................................................................12
3.2.5 Technical specifications ........................................................................................................................12
3.3 EP16 card.......................................................................................................................................................13
3.3.1 Features.................................................................................................................................................13
3.3.2 Panel and slots.......................................................................................................................................13
3.3.3 Interfaces...............................................................................................................................................14
3.3.4 LEDs.....................................................................................................................................................14

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
vi
3.3.5 Technical specifications ........................................................................................................................15
3.4 GP8A card......................................................................................................................................................15
3.4.1 Features.................................................................................................................................................15
3.4.2 Panel and slots.......................................................................................................................................15
3.4.3 Interfaces...............................................................................................................................................16
3.4.4 LEDs.....................................................................................................................................................16
3.4.5 Technical specifications ........................................................................................................................17
3.5 GP16 card.......................................................................................................................................................17
3.5.1 Features.................................................................................................................................................17
3.5.2 Panel and slots.......................................................................................................................................17
3.5.3 Interfaces...............................................................................................................................................18
3.5.4 LEDs.....................................................................................................................................................18
3.5.5 Technical specifications ........................................................................................................................18
3.6 XEP8 card ......................................................................................................................................................19
3.6.1 Features.................................................................................................................................................19
3.6.2 Panel and slots.......................................................................................................................................19
3.6.3 Interfaces...............................................................................................................................................19
3.6.4 LEDs.....................................................................................................................................................20
3.6.5 Technical specifications ........................................................................................................................20
3.7 GE16 card ......................................................................................................................................................21
3.7.1 Features.................................................................................................................................................21
3.7.2 Panel and slots.......................................................................................................................................22
3.7.3 Interfaces...............................................................................................................................................22
3.7.4 LEDs.....................................................................................................................................................22
3.7.5 Technical specifications ........................................................................................................................23
3.8 XP2A card......................................................................................................................................................23
3.8.1 Features.................................................................................................................................................23
3.8.2 Panel and slots.......................................................................................................................................24
3.8.3 Interfaces...............................................................................................................................................24
3.8.4 LEDs.....................................................................................................................................................24
3.8.5 Technical specifications ........................................................................................................................25
3.9 XP4A card......................................................................................................................................................25
3.9.1 Features.................................................................................................................................................25
3.9.2 Panel and slots.......................................................................................................................................25
3.9.3 Interfaces...............................................................................................................................................26
3.9.4 LEDs.....................................................................................................................................................26
3.9.5 Technical specifications ........................................................................................................................27
3.10 XP4L card ....................................................................................................................................................27
3.10.1 Features...............................................................................................................................................27
3.10.2 Panel and slots.....................................................................................................................................27
3.10.3 Interfaces.............................................................................................................................................28

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
vii
3.10.4 LEDs...................................................................................................................................................28
3.10.5 Technical specifications ......................................................................................................................29
3.11 RPD2151 card ..............................................................................................................................................29
3.11.1 Features...............................................................................................................................................29
3.11.2 Panel and slots.....................................................................................................................................29
3.11.3 Interfaces.............................................................................................................................................30
3.11.4 LEDs ...................................................................................................................................................30
3.11.5 Technical specifications ......................................................................................................................30
4 Cables ............................................................................................................................................32
4.1 Fiber...............................................................................................................................................................32
4.1.1 Introduction...........................................................................................................................................32
4.1.2 Connector..............................................................................................................................................33
4.1.3 Wiring ...................................................................................................................................................34
4.2 Ethernet cable.................................................................................................................................................35
4.2.1 Introduction...........................................................................................................................................35
4.2.2 Appearance............................................................................................................................................35
4.2.3 Technical specifications ........................................................................................................................35
4.3 Configuration cable........................................................................................................................................37
4.3.1 Introduction...........................................................................................................................................37
4.3.2 Appearance............................................................................................................................................38
4.3.3 Wiring ...................................................................................................................................................38
4.3.4 Technical specifications ........................................................................................................................38
4.4 Power cable....................................................................................................................................................39
4.4.1 Introduction...........................................................................................................................................39
4.4.2 Appearance............................................................................................................................................39
4.4.3 Technical specifications ........................................................................................................................39
4.5 Ground cable..................................................................................................................................................40
4.5.1 Introduction...........................................................................................................................................40
4.5.2 Appearance............................................................................................................................................40
4.5.3 Technical specifications ........................................................................................................................41
5 Optical modules ..........................................................................................................................43
5.1 GE SFP module..............................................................................................................................................43
5.1.1 Functions and appearance.....................................................................................................................43
5.1.2 Label .....................................................................................................................................................43
5.1.3 Technical specifications ........................................................................................................................44
5.2 10GE SFP+ module........................................................................................................................................45
5.2.1 Functions and appearance.....................................................................................................................45
5.2.2 Technical specifications ........................................................................................................................45
5.3 PON SFP module ...........................................................................................................................................46
5.3.1 Functions and appearance.....................................................................................................................46

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
viii
5.3.2 Label .....................................................................................................................................................46
5.3.3 Technical specifications ........................................................................................................................47
6 Electromechanical component..................................................................................................48
6.1 Blank panel.....................................................................................................................................................48
6.1.1 Features.................................................................................................................................................48
6.1.2 Appearance............................................................................................................................................48
6.1.3 Slot........................................................................................................................................................49
6.1.4 Techinical specification.........................................................................................................................49
7 Lookup table for LEDs...............................................................................................................51
8 Lookup table for weight and power consumption...............................................................53
9 Appendix ......................................................................................................................................55
9.1 Terms..............................................................................................................................................................55
9.2 Acronyms and abbreviations ..........................................................................................................................57

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
ix
Figures
Figure 1-1 Appearance of ISCOM6860 .................................................................................................................1
Figure 1-2 Chassis structure...................................................................................................................................2
Figure 1-3 Slot distribution of ISCOM6860 ..........................................................................................................3
Figure 1-4 Capacity distribution of ISCOM6860...................................................................................................3
Figure 2-1 FANS381..............................................................................................................................................5
Figure 3-1 Hardware information label of card supported by ISCOM6860...........................................................9
Figure 3-2 SMCA appearance.............................................................................................................................. 11
Figure 3-3 Appearance of EP16 card ...................................................................................................................14
Figure 3-4 Appearance of GP8A card ..................................................................................................................16
Figure 3-5 Appearance of GP16 card...................................................................................................................17
Figure 3-6 Appearance of XEP8 card...................................................................................................................19
Figure 3-7 Appearance of GE16 card...................................................................................................................22
Figure 3-8 Appearance of XP2A card ..................................................................................................................24
Figure 3-9 Appearance of XP4A card ..................................................................................................................26
Figure 3-10 Appearance of XP4L card.................................................................................................................28
Figure 3-11 Appearance of RPD2151 card...........................................................................................................30
Figure 4-1 LC/PC fiber connector........................................................................................................................33
Figure 4-2 SC/PC fiber connector........................................................................................................................34
Figure 4-3 Ethernet cable.....................................................................................................................................35
Figure 4-4 Wiring of straight-through cable.........................................................................................................36
Figure 4-5 Wiring of crossover cable...................................................................................................................37
Figure 4-6 Configuration cable ............................................................................................................................38
Figure 4-7 PIN and wiring ...................................................................................................................................38
Figure 4-8 DC power cable..................................................................................................................................39
Figure 4-9 Ground cable ......................................................................................................................................40
Figure 4-10 OT terminal ......................................................................................................................................40

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
x
Figure 5-1 Appearance of GE SFP module ..........................................................................................................43
Figure 5-2 Label of the GE SFP module..............................................................................................................44
Figure 5-3 Appearance of 10GE SFP+ module....................................................................................................45
Figure 5-4 Appearance of PON SFP module........................................................................................................46
Figure 5-5 Label of PON SFP module .................................................................................................................46
Figure 6-1 Appearance of blank panel .................................................................................................................49

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
xi
Tables
Table 1-1 Technical specifications .........................................................................................................................4
Table 2-1 FANS381 LED.......................................................................................................................................6
Table 2-2 Technical specifications of FANS381 ....................................................................................................6
Table 3-1 Types, appearance, and dimensions of ISCOM6860 cards ....................................................................7
Table 3-2 ISCOM6860 card types..........................................................................................................................8
Table 3-3 Hardware information label .................................................................................................................10
Table 3-4 Features of SMCA card........................................................................................................................10
Table 3-5 Interfaces on SMCA card.....................................................................................................................11
Table 3-6 Technical specifications of SNMP interface......................................................................................... 11
Table 3-7 Technical specifications of Console interface ...................................................................................... 11
Table 3-8 LEDs on SMCA card ...........................................................................................................................12
Table 3-9 Technical specifications of SMCA card ...............................................................................................13
Table 3-10 Features of EP16 card ........................................................................................................................13
Table 3-11 Interface of EP16 card........................................................................................................................14
Table 3-12 LEDs on EP16 card............................................................................................................................14
Table 3-13 Technical specifications of EP16 card................................................................................................15
Table 3-14 Features of GP8A card .......................................................................................................................15
Table 3-15 Interface of GP8A card.......................................................................................................................16
Table 3-16 LEDs on GP8A card...........................................................................................................................16
Table 3-17 Technical specifications of GP8A card...............................................................................................17
Table 3-18 Features of GP16 card........................................................................................................................17
Table 3-19 Interface of GP16 card .......................................................................................................................18
Table 3-20 LEDs on GP16 card ...........................................................................................................................18
Table 3-21 Technical specifications of GP16 card ...............................................................................................19
Table 3-22 Features of XEP8 card .......................................................................................................................19
Table 3-23 Interface of XEP8 card.......................................................................................................................20

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
xii
Table 3-24 LEDs on XEP8 card...........................................................................................................................20
Table 3-25 Technical specifications of XEP8 card...............................................................................................21
Table 3-26 Features of GE16 card........................................................................................................................21
Table 3-27 Interface of XEP8 card.......................................................................................................................22
Table 3-28 LEDs on GE16 card ...........................................................................................................................22
Table 3-29 Technical specifications of GE16 card...............................................................................................23
Table 3-30 Features of XP2A card .......................................................................................................................23
Table 3-31 Interface descriptions of XP2A card ..................................................................................................24
Table 3-32 LEDs on XP2A card...........................................................................................................................24
Table 3-33 Technical specifications of XP2A card...............................................................................................25
Table 3-34 Features of XP4A card .......................................................................................................................25
Table 3-35 Interface descriptions of XP4A card ..................................................................................................26
Table 3-36 LEDs on XP4A card...........................................................................................................................26
Table 3-37 Technical specifications of XP4A card...............................................................................................27
Table 3-38 Features of XP4L card........................................................................................................................27
Table 3-39 Interface descriptions of XP4L card...................................................................................................28
Table 3-40 LEDs on XP4L card...........................................................................................................................28
Table 3-41 Technical specifications of XP4L card...............................................................................................29
Table 3-42 Features of RPD2151 card .................................................................................................................29
Table 3-43 Interface descriptions of RPD2151 card ............................................................................................30
Table 3-44 LEDs on RPD2151 card.....................................................................................................................30
Table 3-45 Technical specifications of RPD2151 card.........................................................................................30
Table 4-1 Fiber connectors...................................................................................................................................32
Table 4-2 Shape and color of fiber connector.......................................................................................................33
Table 4-3 Wiring of fiber......................................................................................................................................34
Table 4-4 Wiring of straight-through cable ..........................................................................................................35
Table 4-5 Wiring of crossover cable.....................................................................................................................36
Table 4-6 Technical specifications of Ethernet cables..........................................................................................37
Table 4-7 Technical specifications of configuration cable ...................................................................................38
Table 4-8 Technical specifications of DC power cable ........................................................................................39
Table 4-9 Technical specifications of ground cable .............................................................................................41
Table 4-10 Technical specifications of OT terminal.............................................................................................41
Table 5-1 Label descriptions of GE SFP module .................................................................................................44

Raisecom
ISCOM6860 (A) Hardware Description
Preface
Raisecom Technology Co., Ltd.
xiii
Table 5-2 Technical specifications of 1000BASE-X SFP optical interface..........................................................44
Table 5-3 Technical specifications of 10GE SFP+ module..................................................................................45
Table 5-4 Label of PON SFP module...................................................................................................................46
Table 5-5 Technical specifications of PON SFP module......................................................................................47
Table 6-1 Slots for blank panels...........................................................................................................................49
Table 6-2 Technical specifications of blank panel................................................................................................49
Table 7-1 Lookup table for LEDs on the ISCOM6860 ........................................................................................51
Table 8-1 Lookup table for weight and power consumption of the ISCOM6860 ................................................53

Raisecom
ISCOM6860 (A) Hardware Description
1 Product overview
Raisecom Technology Co., Ltd.
1
1 Product overview
This chapter describes the ISCOM6860, including the following sections:
Appearance
Structure
Slot distribution
Capacity distribution
Technical specifications
1.1 Appearance
The ISCOM6860 is an xPON integrated Optical Line Terminal (OLT) device. It provides data,
voice, and video service access of large capacity, high speed, and high bandwidth, which fully
meets carriers' requirements on establishing xPON networks with large capacity and few
offices.
Figure 1-1 shows the appearance of the ISCOM6860.
Figure 1-1 Appearance of ISCOM6860

Raisecom
ISCOM6860 (A) Hardware Description
1 Product overview
Raisecom Technology Co., Ltd.
2
1.2 Structure
The ISCOM6860 adopts a chassis+card modular design, which helps users select the number
and type of uplink/downlink cards freely according to the network scale. In addition, the
ISCOM6860 supports network expansion based on redundant slots and service expansion
based on new service cards.
The chassis provides a high-speed digital backplane bus, 13 slots, and auxiliary parts, such as
the brackets and anti-static jack.
Figure 1-2 shows the chassis structure.
Figure 1-2 Chassis structure
1.3 Slot distribution
Figure 1-3 shows slot distribution of the ISCOM6860.

Raisecom
ISCOM6860 (A) Hardware Description
1 Product overview
Raisecom Technology Co., Ltd.
3
Figure 1-3 Slot distribution of ISCOM6860
1.4 Capacity distribution
Figure 1-4 shows capacity distribution of the ISCOM6860.
Figure 1-4 Capacity distribution of ISCOM6860
1.5 Technical specifications
Table 1-1 lists technical specifications of the ISCOM6860.

Raisecom
ISCOM6860 (A) Hardware Description
1 Product overview
Raisecom Technology Co., Ltd.
4
Table 1-1 Technical specifications
Hardware feature
Description
Dimensions
443 mm (Width) ×237 mm (Depth) ×266 mm (Height) (6U)
Components such as panel, screws, and brackets are not
counted in the dimensions.
Backplane and slot
A backplane has been installed. There are 13 slots in total.
Backplane bandwidth
2.88 Tbit/s
Switching capacity
1.28 Tbit/s bidirectional

Raisecom
ISCOM6860 (A) Hardware Description
2 Fan
Raisecom Technology Co., Ltd.
5
2 Fan
This chapter introduces the fan of the ISCOM6860, including the following sections:
Features
Appearance
LEDs
Technical specifications
2.1 Features
The FANS381 is a fan module of the ISCOM6860 and its main features are as below:
Provide 6 embedded fans, offering better heat dissipation for cards in the chassis.
Provide an alarm LED and an operating status LED on the front panel. These two LEDs
monitor fan status in real time.
Separate the fan box from the chassis. Therefore, operating services are not affected
when fans are being changed.
Support intelligent speed adjustment based on temperature.
Support manually adjusting rotational speed of fans. Support 8 grades of rotational
speeds.
Support rotational speed feedback.
Support hot swapping. Adopt dual-soft start program.
2.2 Appearance
The FANS381 is placed on the left of the ISCOM6860. Figure 2-1 shows the appearance of
the FANS381.
Figure 2-1 FANS381
