RAM 2012 chassis cab 3500 Owner's manual

Page 1
PRODUCT HIGHLIGHTS

Robust 383 hp and 400 lb-ft of torque from the
5.7-liter gas V8 with 6-speed automatic (3500 only)

Electronic Range Select (ERS) — enables the driver to
manually shift the transmission for greater control,
available on 6-speed automatic transmissions

Huge, 15-inch brake rotors (4500/5500)

180-amp alternator: standard with diesel; available
with Snowplow Prep Group gas-powered V8 models

New instrument panel now features a panel-
mounted auxiliary switch bank that includes
four hardwired switches

Electric-over-hydraulic integrated Trailer Brake
Controller — Available

PTO Prep Package has programmable engine RPM
when PTO is engaged, with single-set PTO speed and
torque converter lockup in PTO mode — Available

Cummins® Turbo Diesel will maintain full power when
DEF system fluid is low

New radios include Uconnect® Multimedia, Access,
and Uconnect Navigation — Available

Premium Alpine® sound system with power
amplifier — Available

Dual 220-amp alternators available for diesel-
equipped models

Heated and ventilated seats on Laramie
model — Standard

Heated steering wheel on Laramie model — Standard

B-20 Biodiesel calibration for Cummins — Available
Commercial-grade capability is now redefined. The new 2013 Ram Chassis Cab family brings on new strengths that benchmark
everything that a tough work truck should be — for this is top-of-the-line excellence: best-in-class GCWRs on all models. Best-in-class
Front GAWRs on Ram 4500/5500. A new, available heavy-duty six-speed automatic from AISIN®. Enhanced new PTO capability.
All-new and comprehensive Electronic Stability Control system (ESC) — now standard on every model. Modified frames and
suspensions for greater capability. New interiors, featuring new electronics, including a brilliant new available full-color multiview
display system, depending on model. Even a class-exclusive available Back-Up Camera, packaged with the truck for upfitter installation.
This is where you get it all on one superb package: strength, capability, communications, comfort. The new 2013 Ram Chassis Cabs.
CHRYSLER GROUP FLEET
SAFETY/SECURITY

All-new for 2013: Electronic Stability Control System (ESC) with
ABS, All-Speed Traction Control, Brake Assist, Rain Brake Support,
Trailer Sway Control, Hill Start Assist, Brake-Force Distribution,
and Electronic Roll Mitigation.

Multistage front air bags(5) — Standard

Enhanced Accident Response System (EARS) — Standard

Constant force retractors — Standard

Brake-Park Interlock — Standard with automatic transmission

Four-wheel antilock disc brakes (ABS) — Standard

Massive brake rotors (4500/5500)(4) with authoritative twin
66-mm caliper pistons

Unibelt three-point restraint system — Standard

Height-adjustable driver and front-outboard passenger seat
belt — Standard

Energy-absorbing steering column — Standard
FLEET FEATURES

Ambulance Prep Package — Available

Heavy Duty Snowplow Prep Group — Available

Tradesman Décor Group — Available

Power Accessory Group — Available

Power and Remote Entry Group — Available

New "smart" diesel exhaust brake — Standard with diesel engine only

22-gallon mid-mounted fuel tank — Available with diesel engine

Daytime running lamps — Available

Special low-volume exterior paint colors — Available

Vinyl floor covering — Standard

7- x 11-inch trailer tow mirrors — Standard

Front-Passenger Air Bag Delete — Available

Uconnect Voice Command, Bluetooth(6) — Available
(1)Class 4 and 5 Ram 4500/5500. (2)When properly equipped. (3)Based on Class 3 pickup-based conventional cab
chassis over 10,000-lb GVWR. (4)Based on Class 4–5 pickup-based conventional cab chassis. (5)Always use seat belts.
Remember, a backseat is the safest place for children 12 and under. (6)Requires Bluetooth enabled mobile phone.
2013
RAM 3500/4500/5500
CHASSIS CABS

Page 2
POWERTRAINS
Transmissions Transfer Case
Engines Six-Speed
Manual w/PTO
Six-Speed 66RFE
Automatic
Six-Speed AISIN®
Automatic w/PTO
(4x4 only)
BW44-47 BW44-46
3500 only
5.7L gas V8
(383 hp @ 5600 rpm 400 lb-ft of torque @ 4000 rpm) NA SNA S O
3500/4500/5500
6.7L Cummins® Turbo Diesel
(320 hp @ 2,800 rpm 650 lb-ft of torque @ 1,500 rpm) SNA NA S O
6.7L High-Output Cummins Turbo Diesel
(325 hp @ 2,400 rpm 750 lb-ft of torque @ 1,600 rpm) NA NA S S O
S = Standard. O = Optional. NA = Not Available.
DIMENSIONS(1)/SPECIFICATIONS
All Ram Chassis Cab Interiors Regular Cab Crew Cab
Head room (front/rear) 40.3 41.0/39.9
Hip room (front/rear) 62.9 63.2/63.2
Shoulder room (front/rear) 66.0 66.0/65.7
Leg room (front/rear) 41. 0 41.0/40.3
Seating capacity 3 6
(1) All dimensions are in inches unless otherwise noted.
Air Bags(1) — Multistage driver and front-passenger
Alternator — 160-amp, gas V8; 180-amp, diesel
Assist Handles — Driver and passenger-side
Battery — 730-amp (two on diesel)
Brakes — Power-assisted four-wheel antilock disc
Cluster — Instrument, with tachometer and 120-mph speedometer
Engine Cooling — Heavy-duty
Fuel Tank — 52-gallon, rear
Headlamps — Quad-lens halogen
Insulation — Dash liner, floor tunnel
Radio — Uconnect® 3.0 AM/FM radio
Seat Belts — Front, height-adjustable shoulder
Steering — Power, recirculating ball/tilt
Storage — Rear, underseat compartment (Crew Cab models only)
Windshield Wipers — Variable intermittent
(1)Always use seat belts. Remember, a backseat is the safest place for children 12 and under.
STANDARD ON ALL 2013 RAM CHASSIS CABS
Flame Red Maximum Steel Metallic True Blue PearlMineral Gray Metallic Prairie Pearl Western Brown Pearl
Construction
YellowBright RedAgriculture Red Light Cream Midnight Blue Dark Brown Light GreenHolland BlueDetonator YellowAngel Green
(2)Low-volume paint colors are only available with Black/Diesel Gray interior.
National
Safety Yellow Omaha Orange Robin Egg Blue Tree GreenPower Tan
School Bus
Yellow
Timberline
Green Pearl YellowSun Yellow
EXTERIOR COLORS
SPECIAL LOW-VOLUME PAINT COLORS(2)
Deep Cherry Red Crystal PearlCopperhead Pearl(1) Bright WhiteBlack Gold Pearl Bright Silver MetallicBlack

Page 3
BFLT13-019
MAX JOB RATING INFORMATION(1)
Ram 3500
Regular Cab 60" CA
(4x2/4x4) SRW
Regular Cab 60" CA
(4x2/4x4) DRW
Regular Cab 84" CA
(4x2/4x4) DRW
Crew Cab 60" CA
(4x2/4x4) SRW
Crew Cab 60" CA
(4x2/4x4) DRW
5.7L HEMI® V8 Auto Trans
Max GVWR NA 12,500 12,500 NA 12,500
Max Payload(1) NA 6,543/6,286 6,489/6,212 NA 6,119/5,833
Max GAWR front NA 5,200 5,200 NA 5,200
Max GAWR rear NA 9,350 9,350 NA 9,350
Max trailer(1) NA 11,850/10,650 11,800/10,400 NA 11,450/10,200
Max GCWR NA 18,000 18,000 NA 18,000
6.7L Cummins® Diesel Man Trans
Max GVWR 10,200 13,000 13,000 10,200 13,000
Max Payload(1) 3,626/3,383 6,080/5,837 5,994/5,711 3,186/2,867 5,602/5,317
Max GAWR front 5,500 5,500 5,500 5,500 5,500
Max GAWR rear 6,200 9,350 9,350 6,200 9,350
Max trailer(1) 19,250/18,050 18,900/18,650 18,800/18,550 18,800/17,500 18,450/18,150
Max GCWR 26,000 26,000 26,000 26,000 26,000
6.7L High Output Cummins Diesel Auto Trans
Max GVWR 10,200 13,000 13,000 10,200 13,000
Max Payload(1) 3,456/3,213 5,910/5,667 5,824/5,541 3,016/2,697 5,432/5,147
Max GAWR front 5,500 5,500 5,500 5,500 5,500
Max GAWR rear 6,200 9,350 9,350 6,200 9,350
Max trailer(1) 19,100/17,850 22,750/22,500 22,650/22,350 18,650/17,350 22,250/21,950
Max GCWR 26,000 30,000 30,000 26,000 30,000
Ram 4500
All weights in lb.
Regular Cab 60" CA
(4x2/4x4)
Regular Cab 84" CA
(4x2/4x4)
Regular Cab 108" CA
(4x2/4x4)
Regular Cab 120" CA
(4x2/4x4)
Crew Cab 60" CA
(4x2/4x4)
Crew Cab 84" CA
(4x2/4x4)
6.7L Cummins Diesel
Manual Transmission
MAX GVWR 16,000 16,500 16,500 16,500 16,000 16,500
MAX Payload 8,391/8,002 8,726/8,350 8,741/8,230 8,711/8,170 7,813/7,460 8,173/7,869
MAX GAWR front 7,250 7,250 7,250 7,250 7,250 7,250
MAX GAWR rear 12,000 12,000 12,000 12,000 12,000 12,000
MAX GCWR 28,000 28,000 28,000 28,000 28,000 28,000
MAX Towing 20,200/19,850 20,050/19,700 20,050/19,550 20,050/19,500 19,650/19,300 19,500/19,200
6.7L High Output Cummins Diesel
Automatic Transmission
MAX GVWR 16,000 16,500 16,500 16,500 16,000 16,500
MAX Payload 8,326/7,937 8,661/8,285 8,571/8,060 8,541/8,000 7,748/7,395 8,108/7,804
MAX GAWR front 7,250 7,250 7,250 7,250 7,250 7,250
MAX GAWR rear 12,000 12,000 12,000 12,000 12,000 12,000
MAX GCWR 32,500 32,500 32,500 32,500 32,500 32,500
MAX Towing 24,650/24,250 24,500/24,100 24,400/23,900 24,350/23,850 24,050/23,700 23,950/23,650
Ram 5500
6.7L Cummins Diesel
Manual Transmission
MAX GVWR 18,750 19,500 19,500 19,500 18,750 19,500
MAX Payload 11,087/10,743 11,711/11,361 11,539/11,217 11,487/11,139 10,580/10,227 11.137/10,807
MAX GAWR front 7,250 7,250 7,250 7,250 7,250 7,250
MAX GAWR rear 13,500 13,500 13,500 13,500 13,500 13,500
MAX GCWR 28,000 28,000 28,000 28,000 28,000 28,000
MAX Towing 20,150/19,800 20,050/19,700 19,850/19,550 19,800/19,450 19,650/19,300 19.450/19,150
6.7L High Output Cummins Diesel
Automatic Transmission
MAX GVWR 18,750 19,500 19,500 19,500 18,750 19,500
MAX Payload 11,022/10,678 11,646/11,296 11,369/11,047 11,317/10,969 10,515/10,162 11.072/10,742
MAX GAWR front 7,250 7,250 7,250 7,250 7,250 7,250
MAX GAWR rear 13,500 13,500 13,500 13,500 13,500 13,500
MAX GCWR 37,500 37,500 37,500 37,500 37,500 37,500
MAX Towing 29,600/29,250 29,450/29,100 29,200/28,850 29,150/28,800 29,100/28,750 28,900/28,550
(1)Maximum job rating numbers are for a properly equipped vehicle and 150-lb allowance for driver. Additional Upfits, options, equipment, passengers, and cargo weight must be subtracted from tow/payload weight.
Please see your dealer for additional information.
Dodge Ram 4500 and 5500 are assembled at the Saltillo, Mexico, plant.
Chrysler, Dodge, Ram, the Ram’s Head logo, HEMI, and Uconnect are registered trademarks of Chrysler Group LLC. Chrysler Group LLC reserves the right to make changes at any time, without notice or obligation. All product
specifications are based on authorized information as of 1/30/13. Photographs are for representational purposes only. Cummins is a registered trademark of Cummins, Inc. Alpine is a registered trademark of Alpine Electronics.
Bluetooth is a registered trademark of Bluetooth SIG, Inc. ©2013 Chrysler Group LLC. All rights reserved.
Weights given in lb. NA = Not Available

Page 1
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
POWERTRAIN
ENGINE TRANSMISSION
5.7L HEMI® V8 with VVT (EZC) (3500 Only) 6-Speed Automatic (DFP) 26A 26G 26H
6.7L Cummins® Turbo Diesel I-6 (ETJ) (320HP/650 lb-ft) 6-Speed Manual (DEG) 2EA 2EG 2EH
6.7L Cummins Turbo Diesel I-6 (ETJ) (325HP/750 lb-ft) AISIN® 6-Speed Automatic AS69RC (DF2) 29A 29G 29H
Mechanical Features
Alternator — 160-amp (BAB) BAB S S S
— 180-amp, available with 5.7L (included on 5.7L with Heavy Duty Snowplow Prep Group;
included with diesel engine) BAD • • •
— 220-amp, available with 6.7L (included on diesel-equipped models with Heavy Duty Snowplow Prep Group;
included with Ambulance Prep Group) BAJ O/P O/P O/P
— 440-amp, optional with 6.7L (dual 220-amp alternators) XF7 O O O
PTO — Available with 6.7L with both the AISIN automatic and the manual transmission LBN O O O
— Alternate left side with 6.7L and AISIN transmission only LBV O O O
Upfitter Interface Module — 55 inputs and outputs XXS O O O
Max Speed Settings — Diesel only (55mph, 60mph, 65mph, 70mph) JJ2, JJ3, JJ4, JJ5 O O O
Engine Shut-Off Timer — Diesel only (5 minutes, 10 minutes, 30 minutes, 60 minutes) XCL O O O
Axles 3500
— Front, 5,500-lb GAWR (included with SRW Group; requires diesel engine) DJB P P P
— Front, 5,500-lb GAWR with hub extension (DRW models only) DJE • • •
— Rear, anti-spin differential DSA • • •
— Rear, 3.42 ratio (diesel models only) DMR O O O
— Rear, 3.73 ratio (diesel models only) DME O O O
— Rear, 4.10 ratio (standard with gas, available with diesel) DMF •/O •/O •/O
— Rear, 11.50-inch (included with SRW Group) DRQ P P P
— Rear, 11.50-inch (DRW models only) DRX • • •
Axles 4500 and 5500
— Front, 10.8-inch, 7,000-lb GAWR DJP • • •
— Rear, anti-spin differential DSA • • •
— Rear, 4.10 ratio (4500 models) (5500 diesel with M/T) DMF • • •
— Rear, 4.44 ratio (on 4500, Standard on 5500 diesel with A/T) DMS O/• O/• O/•
— Rear, 4.88 ratio (5500 diesel with A/T only) DMK O O O
— Rear, Dana® S111 (12,000-lb 4500 GAWR) (13,500-lb 5500 GAWR) DRT • • •
— 7,250-lb Front Axle GAWR — Available on 4500 and 5500 only (includes taller springs) DJT O O O
Battery — 730-amp (one per vehicle with gas, two per vehicle with diesel) BCN • • •
Diesel Engine Five-Minute Shutdown Timer XCL O O O
Diesel Engine Maximum Speed Settings — 55 mph (JJ2), 60 mph (JJ3), 65 mph (JJ4), 70 mph (JJ5) JJ2, JJ3, JJ4, JJ5 O O O
Diesel Exhaust Brake (New Smart Exhaust Brake) — Packaged with 6.7L Cummins engine NEN P P P
Engine Block Heater — Optional with gas, included with Cold Weather Group ADE with diesel NHK O/P O/P O/P
Engine Cooling — Heavy-duty NMC • • •
Fuel Tank — 52-gallon rear NFH • • •
— 22-gallon mid-ship (diesel only) NFA O O O
Shock Absorbers — Front, heavy-duty SFB • • •
— Rear, heavy-duty SGB • • •
Skid Plate — Transfer case (4x4 only; included with Heavy Duty Snow Plow Prep Group) XEF O/P O/P O/P
Stabilizer Bar — Front SHA • • •
Steering — Power, recirculating ball SBE • • •
Tow Hooks — Optional with gas engine, included with diesel engine XEA O/• O/• O/•
Transfer Case — Manual shift, part-time, 4x4 only DK1 • •
— Electric shift, part-time T-case, 4x4 only DK3 O O •
B-20 Biodiesel Compatibility XXJ O O O

Page 2
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
Exterior Features
Badging — SLT MTD •
— Laramie MTE •
Bumper — Front, black MB1 •
— Front, chrome (included with Chrome Appearance Group) MCT P • •
Fascia — Front, headlamp filler, black (standard on 4500 and 5500 models; included with low-volume paint) MCJ • • •
— Front, headlamp filler in body-color (3500 only) MCM • • •
Fog Lamps — Also packaged with Chrome Appearance Group, which is available on Tradesman LNJ P O •
Grilles — Black insert and surround MFF • • •
— Chrome surround, black insert (packaged with Chrome Appearance Group) MFD P •
— Chrome surround, chrome insert MF1 •
Chrome Body-Side Moldings MJB O O O
Chrome Tubular Side Steps MRT O O O
Headlamps — Automatic LMG • • •
— Halogen — Quad Lens LME • •
— Halogen — Bi-function Projector LMC •
Lamps, Exterior — Cab Clearance LNC • • •
Mirrors, Exterior — Folding trailer tow, manual, black, Regular Cab only GPD •
— Power trailer tow, heated, manual folding, black; includes exterior courtesy lamps and supplemental turn
signal (standard on Crew Cab models, included with Power Accessory or Power and Remote Entry Groups) GPG P/• •
— Power multi-function Trailer Tow, heated, manual folding, chrome; includes position memory, exterior
courtesy lamps, and supplemental turn signal GPC •
Key-Alike Feature — Allows a single key to start multiple trucks GXF O O O
Monotone Paint APA • • •
Front Wheel Flares — 3500 only, in body-color MML O O O
3500 Tires
— LT265/70R17E BSW All-Season (standard with SRW) TT3 P P P
— LT265/70R17E OWL On/Off-Road (available with SRW models only) TT5 O O O
— LT235/80R17E BSW All-Season (DRW models only) TPY • • •
— LT235/80R17E OWL On/Off-Road (4x4 DRW models only) TP9 O O O
— Spare, full-size TBB O O O
4500/5500 Tires
— 225/70R19.5G BSW All-Position (4x2 models only) TUV • • •
— 225/70R19.5G BSW All-Position front, rear traction (standard on 4x4; available on 4x2 models) TUY •/O •/O •/O
— 225/70R19.5G BSW All-Traction (4x4 only) TUZ O O O
— Spare, full-size TBB O O O
3500 Wheels
— 17 x 7.5-inch styled steel, painted Argent (standard with SRW Group) WDA P
— 17 x 8-inch steel, chrome-clad (SRW Group only; packaged with Chrome Appearance Group is new for 13MY) WGS O P
— 17 x 8-inch cast aluminum (SRW Group only) WFK P
— 17 x 6-inch Argent steel (DRW models only) WFU •
— 17 x 6-inch bright wheel skins and center cap (DRW models only; packaged with Chrome Appearance Group) WD4 P •
— 17 x 6-inch aluminum (DRW models only) WF7 O •
4500/5500 Wheels
— 19.5 x 6-inch steel WP3 • •
— 19.5 x 6-inch polished aluminum WP4 O O •
Wheelwell Flares — Black (4500/5500 models only) K50 • • •
— Body-color (3500 models only) MML O O O
Windshield Wipers — Variable-intermittent JHA • • •
PAINT
— Flame Red PR4 O O O
— Deep Cherry Red Crystal Pearl PRP O O O
— Copperhead Pearl PLB O O O

Page 3
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
PAINT (continued)
— Prairie Pearl PFA O O O
— Western Brown Pearl PEP O O O
— Black Gold Pearl PUG O O O
— True Blue Pearl PBU O O O
— Bright Silver Metallic PS2 O O O
— Mineral Gray Metallic PDM O O O
— Maximum Steel Metallic PAR O O O
— Black PX8 O O O
— Bright White PW7 O O O
INTERIOR FEATURES
Auxiliary Switches — Five switches are now standard (2012 models had four) LHL • • •
Air Conditioning— included with Ambulance Prep Group (required with Crew Cab due to heated mirror function) HAA P •
Air Conditioning — Dual-Zone temperature control HAF •
Assist Handles — Driver and passenger-side (A pillar-mounted handles) CSP • • •
Bezel — Center stack, black JBF •
— Center stack, color-keyed JBY •
— Center stack, woodgrain insert JBB •
Cigar Lighter — Included with Smokers Group JJA P P P
Cluster — Instrument, with tachometer (120 mph on 3500, 87 mph on 4500/5500 models with EVIC display) JAT • •
— Instrument, with 7.4-inch Electroluminescent vehicle information center JA6 P •
Console — Full-size floor center console (included with front bucket seats) P P P
— Overhead with map lights CUN O
— Overhead console with UGDO (packaged with Luxury Group) CV2 O •
Displays
3.5-inch EVIC JAT • •
7-inch TFT EVIC (also packaged in Luxury Group) JA6 P •
Door Locks — Manual, Regular Cab only JE8 •
— Power (included in Power Accessory, and Power and Remote Entry Groups; standard with Crew Cab Tradesman) JPB P/• • •
Floor Covering — Heavy-duty vinyl CKJ • O O
— Carpet CKE O • •
Floor Mats — Front, carpeted (Regular Cab; included with carpet on Tradesman models) CLA P •
— Front and rear, carpeted (Crew Cab; included with carpet on Tradesman models) CLE P • •
Mirrors, interior — Day/night manual GNA • •
— Auto-dimming rearview day/night, with Uconnect® Phone GN5 •
— Auto-dimming rearview day/night, with camera display GN4 P
— Day/night rearview mirror with Uconnect Phone (packaged with RA2, RA3, RA4 radios) GR4 P P P
— Passenger-side visor with mirror GNM • •
— Illuminated visors for passenger and driver (included with Luxury Group) GNC P •
Pedals — Power adjustable (3500, 4500, 5500; requires automatic transmission) XAP O
— Power adjustable with memory (3500, 4500, 5500; requires automatic transmission) XAM O
Pickup Box Delete XBC • • •
Power Accessory Delay JKY • • •
Power Outlet — Two 12-volt auxiliary JJJ • • •
— 115-volt auxiliary (included with*M9,*MJ,*GJ,*VL seats) JKV P •
Seat Belts — Front, shoulder height-adjustable CGD • • •
Seats
— 10-way power driver (included with *M9,*MJ seats) JRT O
— 10-way power driver with memory and 6-way power passenger seat (*GJ,*VL) JRF •
— Heated, driver and front-passenger, includes heated steering wheel CMA O •
— Heated, second-row (included with *GJ bucket seats) JPZ P
— Front Center Seat Delete CJT O O
— Vinyl 40/20/40 split-bench front seat with folding center armrest/business console,
(Crew Cab models include folding rear bench seat trimmed in vinyl) *TX •

Page 4
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
INTERIOR FEATURES Seats (continued)
— Cloth-trimmed 40/20/40 split-bench front seat with folding center armrest/business console
(Crew Cab models include folding rear bench seat trimmed in cloth) *V9 O •
— Premium cloth-trimmed 40/20/40 split-bench front seat, power 10-way driver seat, power lumbar adjuster,
folding center armrest/business console with center seat cushion storage, 115-volt auxiliary power outlet
(Crew Cab models include 60/40 split-folding rear bench seat trimmed in cloth) *M9 O
— Premium cloth-trimmed low-back bucket seats, power 10-way driver seat, power lumbar adjuster, fixed
center console, 115-volt auxiliary power outlet (Crew Cab models include 60/40 split-folding rear bench
seat trimmed in cloth) *MJ O
— Leather-trimmed 40/20/40 split-bench heated front seats with power 10-way/memory for driver and power
6-way passenger seat, power lumbar adjuster, front center seat cushion storage and folding center
armrest/business console, 115-volt auxiliary power outlet (Crew Cab models include 60/40 split-folding
rear bench seat trimmed in vinyl) *VL •
— Leather-trimmed low-back, ventilated and heated bucket seats, includes power 10-way driver and power 6-way
passenger, power lumbar adjuster, fixed center console, 115-volt auxiliary power outlet, heated 2nd-row seats
on Crew Cab models (Crew Cab models include 60/40 split-folding rear bench seat trimmed in vinyl) *GJ O
Speed Control NHM • • •
Steering — Tilt column SUA • • •
— 4-spoke, urethane SCF • •
— Leather-wrapped with remote audio control buttons (packaged with Luxury Group ADA and
Comfort Group AGF) SCV P •
— Heated (included with heated seats) NHS P •
Storage — Front-seat center cushion (included with *M9) CVH P •
— Front, behind seat (Regular Cab only) CU3 • •
Three-Blink — Turn signal lane-change feature • • •
Tip Start — Included with automatic transmissions P P P
Visors — Front passenger, with mirror GNM • •
— Driver and front passenger, with illuminated vanity mirrors (included with Luxury Group) GNC P •
Windows — Manual (Regular Cab only) JF8 •
— Power, front with driver’s one-touch down (Regular Cab only; included with Power Accessories and
Power Remote Entry Groups) JPY P •
— Power, front and rear with driver’s one-touch-down and -up (Crew Cab models only) JP3 • • •
— Rear backlight, fixed GJD • •
— Rear backlight, sliding (Regular Cab) GFD O
— Rear backlight, power sliding (Crew Cab models only) GFE • •
— Rear defrost (available with power sliding rear window only) GFA O O
Displays
3.5-inch EVIC JAT • •
7-inch TFT EVIC (also packaged in Luxury Group) JA6 P •
Interior colors — Black/Diesel Gray -X8 O O
— Canyon Brown/Light Frost Beige -U1 O O O
— Black -X9 O
UCONNECT® MULTIMEDIA
Auxiliary Outlets — One battery and one ignition-feed JJJ • • •
Uconnect 3.0 Radio — AM/FM with media hub (USB, aux) RA1 • •
Uconnect 5.0 Radio — AM/FM/5.0-inch touch-screen display, media hub (USB, aux), global positioning system,
Uconnect with Bluetooth,
® SiriusXM Satellite Radio(2) RA2 O O
Uconnect 8.4A Radio — AM/FM/8.4-inch touch-screen display, media hub (SD, USB, aux), global positioning
system, Uconnect with Bluetooth, SiriusXM Satellite Radio, Rcall/Ecall RA3 O •
Uconnect 8.4AN Radio — AM/FM/8.4-inch touch-screen display, media hub (SD, USB, aux), GPS Navigation,
Uconnect with Bluetooth, SiriusXM Satellite Radio,
(2) Rcall/Ecall, HD radio, premium speakers RA4 O O
Radio Controls — Steering wheel-mounted audio controls (included with leather-wrapped steering wheel and
Luxury Group) RDZ P •
SiriusXM Satellite Radio(2) RSD O O •
— 2.5-amp charging USB port (included with Uconnect 5.0 radio or higher, or *M9, or *MJ seats) RS3 P P •

Page 5
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
UCONNECT® MULTIMEDIA (continued)
— Media Hub (included with Uconnect 3.0 and 5.0 radios) • •
— 1.5-amp fully functional USB port RSX
— Auxiliary jack for mobile devices RSU
— Media Hub (included with Uconnect 8.4A or 8.4AN Radio) RSF O •/O
— 1.5-amp fully functional USB port
— Auxiliary jack for mobile devices
— SD card slot
Single-Disc Remote CD Player — Available with Uconnect 3.0, 5.0, 8.4A, and 8.4AN radios RH1 O O O
Speaker System — 2 standard RCB •
— 6 standard RCG • •
— Premium I speakers (included with Uconnect 8.4AN radio) RCK P
Uconnect Voice Command — Hands-free calling with Address Sync,
(1) Bluetooth, ®
(Packaged with Uconnect 5.0, 8.4A, and 8.4AN radios) RSP P P •
Uconnect Web — Internet connection/Wi-Fi HotSpot O O O
SAFETY AND SECURITY
Air Bags — Advanced Multistage Front(4) CG3 • • •
— Drivers air bag only(4) CGT O O
Back-Up Camera — shipped loose in cab (displays in rearview mirror with RA1, all other radios will include the
camera display) XAC O O O
Brakes — Power-assisted 4-wheel disc antilock BRT • • •
DOT-certified Roadside Safety Kit — Includes DOT fire extinguisher, three reflecting triangles, spare fuses, and
DOT first aid kit ACL O O O
Electronic Stability Control (ESC) BNB • • •
Red Seat Belts (Regular Cab only) CGQ O O
Rcall/Ecall — Packaged with RA3 and RA4 radios RSR P P P
Remote Keyless Entry — Controls for power door locks, illuminated entry system, panic alarm, includes two
transmitters (included with Power and Remote Entry Group) GXM P/O • •
Remote Start System — Requires automatic transmission XBM O •
Security Alarm LSA O •
Sentry Key® Theft Deterrent — Engine immobilizer GXX • • •
Trailer brake control — Fully integrated electronic XHC O O O
PACKAGE GROUPS
Ambulance Prep Group — Includes 220-amp alternator, voltage monitoring, auto idle-up system, and A/C
(on Tradesman trim level) AH2 O O O
Cold Weather Group — Includes engine block heater and winter front grille cover (requires diesel engine) ADE O O O
Heavy Duty Snowplow Prep Group — Includes 180-amp alternator (with gas engine; 220-amp alternator with
diesel engine) and transfer case skid plate (3500 models require 4x4) AHD O O O
Max Tow Package — Delivers best-in-class GCWRs for all chassis cab models AHQ O O O
Luxury Group — Includes sun visors with illuminated vanity mirrors, glove-box lamp, underhood lamp, rear dome lamp
with on/off switch, 7.4-inch EVIC, leather-wrapped steering wheel with audio controls (formerly called Light Group) ADA O
Comfort Group — Includes heated cloth front seats and heated leather-wrapped steering wheel AGF O
Convenience Group — Includes Auto High-Beam Headlamp Control, rain-sensing wipers, remote proximity
keyless entry, Keyless Enter ’n Go ADC O
Power Accessory Group — (Regular Cab only) Includes power windows, power door locks, and power trailer
folding exterior mirrors AJW O
Power and Remote Entry Group — (Regular Cab only) Includes power windows, power door locks, power trailer
folding exterior mirrors, and remote keyless entry AJH O
Rollback Carrier Group — Includes voltage monitoring, auto idle-up system (5500 Regular Cab models only) AH1 O O
Single Rear Wheel Group — 3500 models only AR9 O O O
Smokers Group — Includes ashtray and cigar lighter AWS O O O
Chrome Appearance Group — Includes chrome front bumper and grille surround (and Chrome Wheels on 3500) AMP O
15K GVWR Package — Includes 15,000-lb GVW Rating (4500 84CA, 108CA, 120CA only) 4x2 (Z4B), 4x4 (Z9B) Z4B, Z9B O O O
16K GVWR Package — Includes 16,000-lb GVW Rating (4500 84CA, 108CA, 120CA only) 4x2 (Z4C), 4x4 (Z9C) Z4C, Z9C O O O

Page 6
RAM 3500/4500/5500 CHASSIS CABS CHRYSLER GROUP FLEET
Tradesman
Reg/Crew
SLT
Reg/Crew
Laramie
Crew
Features Sales Code A G H
• = Included. P = Available with package noted in parentheses. O = Optional.
(1) Requires Bluetooth® enabled mobile phone.
(2) Sirius services require subscriptions, sold separately after 12-month trial included with vehicle purchase/lease. Subscriptions governed by SiriusXM Customer Agreement at siriusxm.com.
If you decide to continue your SiriusXM service at the end of your complimentary trial, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at
1-866-635-2349 to cancel. SiriusXM U.S. Satellite service available only to those at least 18 years of age in the 48 contiguous United States, D.C., with Sirius also available in PR. Go to
www.siriusxm.com/traffic for available coverage. © 2013 SiriusXM Radio Inc.
(3) Always sit properly in the seat with the seat belt fastened. Children 12 and under should always be in a backseat correctly using an infant or child restraint system or with the seat belt
positioned correctly for the child’s age and weight.
(4) Always drive carefully, consistent with conditions. Always use your seat belt.
NOTE: Some features and/or applications may be late availability.
Chrysler, Dodge, Ram, the Ram’s Head logo, Mopar, Sentry Key, Tradesman, and Uconnect are registered trademarks of Chrysler Group LLC. Chrysler Group LLC reserves the right to make
changes at any time, without notice or obligation. All product specifications are based on authorized information as of 1/30/13. Cummins is a registered trademark of Cummins, Inc.
Sirius, XM, and all related marks are trademarks of SiriusXM Radio Inc. and its subsidiaries. Bluetooth is a registered trademark of Bluetooth SIG, Inc. Dana is a registered trademark of
Dana Limited. Alpine is a registered trademark of Alpine Electronics. ©2013 Chrysler Group LLC. All rights reserved.
