rav G3.150 Operating and installation instructions

INSTRUCTION MANUAL
• For any further information please contact your local dealer or call:
EN
For spare parts drawings refer to “LIST OF COMPONENTS” section.
TRANSLATION FROM THE
ORIGINAL INSTRUCTIONS
G3.150 - GP3.150
G3.150S - GP3.150S
G3.150WS - GP3.150WS
G3.150WSPLUS - GP3.150WSPLUS
G3.150SA - G3.150WSA
1297-M058-00
1297-M058-00
Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy
Phone [phone] - Telex 510697 RAV I - Fax [phone] - e-mail: [email protected]
- Rev. n. 00 (03/2021)

EN
Page 2 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
SUMMARY
GENERAL DESCRIPTION _________________ 5
SYMBOLS USED IN THE MANUAL ________ 7
INFORMATION PLATE LOCATION
DRAWING ________________________________ 8
1.0 GENERAL INTRODUCTION _________ 10
1.1 Introduction ___________________________10
2.0 INTENDED USE ____________________ 10
2.1 Training of personnel _________________10
3.0 SAFETY DEVICES __________________ 11
3.1 Residual risks _________________________11
4.0 GENERAL SAFETY RULES _________ 12
5.0 PACKING AND MOBILIZATION FOR
TRANSPORT _______________________ 13
6.0 UNPACKING ________________________ 13
7.0 MOBILIZATION_____________________ 14
8.0 WORKING ENVIRONMENT
CONDITIONS _______________________ 14
8.1 Working area __________________________14
8.2 Lighting _______________________________15
9.0 MACHINE ASSEMBLY ______________ 15
9.1 Anchoring system _____________________15
9.2 Assembly procedures _________________16
9.2.1 Fitting the chuck on the flange ____16
9.2.2 Fitting and removal of the
pneumatic chuck on the flange ____16
9.2.3 Monitor fitting _____________________18
9.2.4 Fitting of external data gauge
(standard on some models) ________19
9.2.5 Fitting the protection guard _______20
9.2.6 Protection guard assembly with
automatic width measuring de-
vice (standard on some models) ___21
9.2.7 Protection guard assembly with
laser device "12 o'clock" (optional) _21
9.2.8 Protection guard assembly with
automatic width measuring
device and laser device "12
o'clock" (optional) __________________22
9.2.9 Check correct operation of laser
device "12 o'clock" (optional) _______22
9.2.10 Fitting of ultrasound Run-out (op-
tional)______________________________23
9.2.11 Fitting of ultrasound Run-out
with support (optional) ____________24
9.2.12 Installation of printer kit
(optional) __________________________25
10.0 ELECTRICAL CONNECTIONS_______ 38
10.1 Electrical checks ______________________38
11.0 AIR CONNECTION _________________ 39
12.0 FITTING THE WHEEL ON THE
CHUCK _____________________________ 39
12.1 Wheel assembly _______________________39
12.2 Wheel assembly _______________________41
12.3 Adjustment of ultrasound sensor
support (standard on some models) ___42
12.4 Correct positioning of ultrasound
Run-out detection device (optional)____43
13.0 DISPLAY WITH KEYBOARD ________ 44
14.0 WHEEL BALANCING _______________ 44
14.1 Switching the machine on and off_____44
14.2 Balancing programs setting___________45
14.2.1 Programs rapid setting and
measurements through
distance-diameter caliper arm_____46
14.2.2 Programs setting through
“Measurements acquisition”
screen page ________________________49
14.3 Indicative display of points where to
detect measures/to fit weight__________50
14.3.1 Weights positioning ________________51
14.4 Displaying the active/modifiable field _51
14.5 Wheel balancing screen page
description ____________________________52
14.5.1 Balancing mode____________________54
14.6 Use of machines with disabled
automatic data gauge _________________57
14.6.1 Manual setting of wheel
dimensions ________________________57
14.7 Standard balancing programs ________58
14.7.1 Static ______________________________58
14.7.2 Static-1 ____________________________58
14.7.3 Static-2 ____________________________58
14.7.4 Dynamic ___________________________58
14.7.5 ALU-S ______________________________59
14.7.6 ALU-S1_____________________________59
14.7.7 ALU-S2_____________________________59
14.7.8 ALU-1 ______________________________59
14.7.9 ALU-2 ______________________________60
14.7.10 ALU-3 _____________________________60
14.7.11 ALU-4 _____________________________60
14.8 Optional balancing programs _________61
14.8.1 ECO-WEIGHT mode (standard on
some models) ______________________61
14.8.2 SPLIT mode________________________63
14.8.3 Weights hidden behind spokes
mode _______________________________65
14.8.4 Matching mode_____________________66
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 3 of 91
14.9 Special balancing programs __________69
14.9.1 Pax_________________________________69
14.10 Recalculation function _______________69
14.11 Wheel balancing in Motorcycle mode
(with distance caliper extension Kit) __70
15.0 USER MENU (OPTIONS AND
CALIBRATION) _____________________ 70
15.1 Options menu _________________________71
15.1.1 Lower weight limit ________________73
15.1.2 Setting adhesive weight dimen-
sions and static threshold
percentage _________________________73
15.1.3 User management__________________74
15.2 Enabling of electronic Run-out
measuring device (optional) ___________75
15.3 Machine calibrations __________________76
15.3.1 Chuck “0” (zero) calibration _______76
15.3.2 Weight measurement sensors
calibration _________________________77
15.3.3 Gauges calibration_________________78
16.0 ERROR SIGNALS ___________________ 83
16.1 Error signals of printer kit (optional) _83
17.0 ROUTINE MAINTENANCE __________ 84
18.0 TECHNICAL DATA__________________ 85
18.1 Technical electrical data ______________85
18.2 Technical mechanical data ____________85
18.3 Dimensions____________________________86
19.0 STORING___________________________ 87
20.0 SCRAPPING ________________________ 87
21.0 REGISTRATION PLATE DATA ______ 87
22.0 FUNCTIONAL DIAGRAMS __________ 87
Drawing A - Electrical connection diagram _88
Drawing B - Pneumaticconnection diagram_90
Drawing C - Electronic board disposition ___91
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 4 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
Model
Feature / Fixtures
G3.150
GP3.150
G3.150S
GP3.150S
G3.150WS
GP3.150WS
G3.150WSPLUS
GP3.150WSPLUS
G3.150SA
G3.150WSA
Threaded chuck      
Pneumatic chuck    
Pedal brake      
Foot pedal / chuck open-close pedal    
Pressure reducer filter unit    
Fixed laser unit + LED light 
External data gauge   
Automatic width measuring device unit     
Car ring nut      
Tyre locking sleeve    
Off-road vehicle cone D.88 - 132 
Wheel protection disc  
Flange with gauge  
“12 o’clock” laser device OPT OPT OPT OPT OPT OPT OPT OPT OPT OPT
Ultrasound Run-out OPT OPT OPT OPT OPT OPT OPT OPT OPT OPT
Printer kit OPT OPT OPT OPT OPT OPT OPT OPT OPT OPT
 = standard
OPT = optional
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 5 of 91
GENERAL DESCRIPTION Fig. 1
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 6 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
KEY (Fig. 1)
1 – Weight holding bridge
2 – Pneumatic chuck
3 – Distance-diameter caliper
4 – Threaded chuck
5 – Protection guard
6 – Pedal brake (for all models)
Chuck open-close pedal (on models with pneu-
matic chuck)
7 – Main switch
8 – External data gauge (standard on some mod-
els)
9 – Monitor
10 – Grippers for weight fitting
11 – Lateral guard
12 – 7-keys keyboard
13 – Pressure ring
14 – Car ring nut (on models with threaded chuck)
15 – Pneumatic locking sleeve (on models with
pneumatic chuck)
16 – Cones + protection cup
17 – Manual caliper
18 – Grippers for weights
19 – Carriages counterweight
20 – Fixed laser unit + LED light (standard on some
models)
21 – Automatic width measuring device unit
(standard on some models)
22 – Off-road vehicle cone D.88 - 132 (standard on
some models)
23 – Wheel protection plate (standard on some
models)
24 – Flange with gauge (standard on some models)
25 – “12 o’clock” laser device (optional)
26 – Ultrasound Run-out (optional)
27 – Ultrasound Run-out with support (optional)
28 – Printer kit (optional)
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 7 of 91
SYMBOLS USED IN THE MANUAL
Symbols Description
Read instruction manual.
Wear work gloves.
Wear work shoes.
Wear safety goggles.
Mandatory.
Operations or jobs to be per-
formed compulsorily.
Warning.
Be particularly careful (possible
material damages).
Symbols Description
Danger!
Be particularly careful.
Note. Indication and/or useful
information.
Move with fork lift truck or pal-
let truck.
Lift from above.
Attention: never lift the machine
by means of the chuck.
Danger!
Laser presence.
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 8 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
INFORMATION PLATE LOCATION DRAWING
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 9 of 91
Code numbers of plates
99990758 Electric shock danger plate
999912940 Lifting plate
99990114 Arrow plate
999914160 230V 50/60 Hz 1 Ph voltage plate
999910050 Protection device use plate
999912400 Serial number plate
999916311 Rubbish skip plate
999920190 G3 NEW logo plate
999920540 Laser point danger plate (optional on some models)
999922780 Laser opening plate (standard on some models)
999922900 Manufacturer plate
999923160 Prop 65 warning plate (standard on some models)
999923190 Laser classification class 1 plate (standard on some models)
999923200 Laser certification plate (standard on some models)
■QR code plate
IF ONE OR MORE PLATES DISAPPEAR FROM THE MACHINE OR BECOMES DIFFICULT
TO READ. REPLACE IT AND QUOTE ITS/THEIR CODE NUMBER/S WHEN REORDERING.
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 10 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
SOME OF THE PICTURES AND/
OR DISPLAY SCREEN PAGES
PRESENT IN THIS MANUAL HAVE
BEEN OBTAINED FROM PICTURES
OF PROTOTYPES, THEREFORE
THE STANDARD PRODUCTION MA-
CHINES AND ACCESSORIES CAN
BE DIFFERENT IN SOME COMPO-
NENTS/DISPLAY SCREEN PAGES.
1.0 GENERAL INTRODUCTION
This manual is an integral part of the product and
must be retained for the whole operating life of the
machine.
Carefully study the warnings and instructions con-
tained in this manual. It contains important instruc-
tions regarding FUNCTIONING, SAFE USE and
MAINTENANCE.
KEEP THE MANUAL IN A KNOWN,
EASILY ACCESSIBLE PLACE FOR
ALL ACCESSORY OPERATORS
TO CONSULT IT WHENEVER IN
DOUBT.
THE MANUFACTURER DISCLAIMS
ALL RESPONSIBILITY FOR ANY
DAMAGE OCCURRED WHEN THE
INDICATIONS GIVEN IN THIS
MANUAL ARE NOT RESPECTED:
AS A MATTER OF FACT, THE NON-
COMPLIANCE WITH SUCH INDI-
CATIONS MIGHT LEAD TO EVEN
SERIOUS DANGERS.
1.1 Introduction
Thank you for preferring this wheel balancer. We feel
sure you will not regret your decision.
This machine has been designed for use in profes-
sional workshops and stands out for its reliability
and easy, safe and rapid operation. With just a small
degree of maintenance and care, this wheel balancer
will give you many years of trouble-free service and
lots of satisfaction.
2.0 INTENDED USE
The machines described in this manual and their
different versions, are wheels balancing machines
for car and light transport, projected to be used
exclusively to cancel out, or at least reduce to ac-
ceptable limits the vibrations of the wheels, by fit-
ting counterweights of suitable size and in specific
positions to the same wheels that are not correctly
balanced.
DANGER: EMPLOYING THESE
MACHINES OUTSIDE THE USE
DESTINATION THEY HAVE BEEN
DESIGNED FOR (AS INDICATED
IN THIS MANUAL) IS INAPPROPRI-
ATE AND DANGEROUS.
THE MANUFACTURER CANNOT
BE HELD RESPONSIBLE FOR ANY
DAMAGE CAUSED BY IMPROPER,
ERRONEOUS, OR UNACCEPTABLE
USE.
2.1 Training of personnel
The machine may be operated only by suitably
trained and authorized personnel.
Given the complexity of the operations necessary to
manage the machine and to carry out the operations
safely and efficiently, the personnel must be trained
in such a way that they learn all the information
necessary to operate the machine as intended by the
manufacturer.
A CAREFUL READING OF THIS
INSTRUCTION MANUAL FOR
USE AND MAINTENANCE AND A
SHORT PERIOD OF TRAINING
WITH SKILLED PERSONNEL CAN
BE AN ENOUGH PREVENTIVE
PREPARATION.
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 11 of 91
3.0 SAFETY DEVICES
PERIODICALLY, AT LEAST MONTH-
LY, CHECK THE INTEGRITY AND
THE FUNCTIONALITY OF THE
SAFETY AND PROTECTION DE-
VICES ON THE MACHINE.
• Main switch positioned on the rear of the machine
Its function is to disconnect machine electric supply.
• Protection guard
Its function is to protect the operator from possible
projections of materials on the wheel during its spin.
Wheel spinning is normally prevented if the wheel
protection guard is raised (open). When the
protection guard is open, this interrupts the cir-
cuit that triggers the motor and automatic start
is prevented, including in the case of an error.
Press stop key to stop wheel rotation in
emergency conditions.
• Laser safety (in case the laser device is present)
This is a Class I/1 (with Class II/2 embedded)
laser product which, during normal operation,
does not permit human access to laser radiation
in excess of Class I/1. This product complies with
21CFR1040.10/.11 and IEC EN60825. The system
is fully interlocked to prevent accidental access to
laser radiation. Any attempt to defeat the safety inter-
lock elements of this product is a violation of Safety
Standards which this product complies with, and the
protection provided by the product may be impaired.
USE OF CONTROLS OR ADJUST-
MENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIA-
TION EXPOSURE.
APERTURE
Side of product nearest port (see
“Plates location drawing”).
CLASSIFICATION
Rear of product (see “Plates location
drawing”).
CERTIFICATION
Rear of product (see “Plates location
drawing”).
3.1 Residual risks
The machine was subjected to a complete analysis of
risks according to reference standard EN ISO 12100.
Risks are as reduced as possible in relation with tech-
nology and product functionality.
Possible residual risks have been emphasized through
pictorial representations and warnings which placing
is indicated in “ PLATE POSITIONING DRAWING” at
page 8.
In case the laser device is present
THIS DEVICE IS EQUIPPED WITH
A LASER, A TOOL THAT USES
LASER BEAMS, PROPERLY INTER-
FACED WITH THE SOFTWARE THE
DEVICE IS EQUIPPED WITH. IT
ENSURES PRECISION MEASURE-
MENTS AND INDICATIONS OF THE
SHAPE AND SIZE OF THE WHEEL
RIM.
THIS DEVICE IS EQUIPPED WITH
A CLASS 1 LASER PRODUCT.
WARNING AND INFORMATION
PLATES HAVE BEEN APPLIED
OUTSIDE THE DEVICE (AS ILLUS-
TRATED BELOW), IN ORDER TO
INDICATE THE PRESENCE AND
EMPLOYMENT OF LASER MEAS-
URING INSTRUMENTS.
DO NOT STARE THE LASER BEAM
DIRECTLY AT CLOSE RANGE
WHILE THE EQUIPMENT IS OP-
ERATING.
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 12 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
4.0 GENERAL SAFETY RULES
• Any tampering with or modification to the machine
not previously authorized by the manufacturer ex-
empts the latter from all responsibility for damage
caused by or derived from said actions.
• Removing of or tampering with the safety devices or
with the warning signals placed on the machine leads
to serious dangers and represents a transgression of
European safety rules.
• Use of the machine is only permitted in places free
from explosion or fire hazard and in dry places
under cover.
• Original spare parts and accessories should be used.
THE MANUFACTURER DENIES
ANY RESPONSIBILITY IN CASE
OF DAMAGES CAUSED BY UNAU-
THORIZED MODIFICATIONS OR
BY THE USE OF NON ORIGINAL
COMPONENTS OR EQUIPMENT.
• The installation must be performed by qualified and
authorized personnel in full compliance with the
instructions given below.
• Ensure that there are no dangerous situations dur-
ing the machine operating manoeuvres. Immediately
stop the machine if it miss-functions and contact the
assistance service of an authorized dealer.
• In emergency situations and before carrying out any
maintenance or repairs, disconnect all supplies to
the machine by using the main switch, placed on the
machine itself, and unplugging the power supply.
• The machine power supply system must be equipped
with an appropriate earthing, to which the yellow-
green machine protection wire must be connected.
• Ensure that the work area around the machine is
free of potentially dangerous objects and that there
is no oil since this could damage the tyre. Oil on the
floor is also a potential danger for the operator.
• UNDER NO CIRCUMSTANCES must the machine be
used to spin anything but vehicle wheels. Bad locking
can cause rotating parts to come loose, with potential
damage to the machine and anything in the vicinity
and injury to the operator.
OPERATORS MUST WEAR SUIT-
ABLE WORK CLOTHES, PROTEC-
TIVE GLASSES AND GLOVES,
AGAINST THE DANGER FROM
THE SPRAYING OF DANGEROUS
DUST, AND POSSIBLY LOWER
BACK SUPPORTS FOR THE LIFT-
ING OF HEAVY PARTS. DANGLING
OBJECTS LIKE BRACELETS MUST
NOT BE WORN, AND LONG HAIR
MUST BE TIED UP. FOOTWEAR
SHOULD BE ADEQUATE FOR THE
TYPE OF OPERATIONS TO BE CAR-
RIED OUT.
• The machine handles and operating grips must be
kept clean and free from oil.
• The workshop must be kept clean and dry. Make
sure that the working premises are properly lit.
The machine can be operated by a single operator.
Unauthorized personnel must remain outside the
working area, as shown in Fig. 3.
Avoid any hazardous situations. Do not use air-
operated or electrical equipment when the shop is
damp or the floor slippery and do not expose such
tools to atmospheric agents.
• When operating and servicing this machine, carefully
follow all applicable safety and accident-prevention
precautions.
The machine must not be operated by untrained
personnel.
WHEN USING THE MODELS WITH
WHEEL PNEUMATIC CLAMPING,
DURING CHUCK OPENING/CLOS-
ING OPERATIONS, BE EXTREMELY
CAREFUL AND KEEP YOUR HANDS
OR OTHER PARTS OF YOUR BODY
AWAY FROM THE MOVING CHUCK.
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 13 of 91
5.0 PACKING AND MOBILIZATION FOR
TRANSPORT
HAVE THE MACHINE HANDLED BY SKILLED
PERSONNEL ONLY.
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE PACKED MACHINE (SEE
PARAGRAPH “TECHNICAL SPECIFICATIONS”).
The machine is packed partially assembled.
Movement must be by pallet-lift or fork-lift trolley.
The fork lifting points are indicated on the packing.
Fig. 2
6.0 UNPACKING
DURING UNPACKING, ALWAYS
WEAR GLOVES TO PREVENT ANY
INJURY CAUSED BY CONTACT
WITH PACKAGING MATERIAL
(NAILS, ETC.).
The cardboard box is supported with plastic strapping.
Cut the strapping with suitable scissors. Use a small
knife to cut along the lateral axis of the box and open
it like a fan.
It is also possible to unnail the cardboard box from
the pallet it is fixed to. After removing the packing, and
in the case of the machine packed fully assembled,
check that the machine is complete and that there is
no visible damage.
If in doubt do not use the machine and refer to pro-
fessionally qualified personnel (to the seller).
The packing (plastic bags, expanded polystyrene, nails,
screws, timber, etc.) should not be left within reach of
children since it is potentially dangerous. These ma-
terials should be deposited in the relevant collection
points if they are pollutants or non biodegradable.
THE BOX CONTAINING THE FIX-
TURES IS CONTAINED IN THE
WRAPPING. DO NOT THROW IT
AWAY WITH THE PACKING.
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 14 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
7.0 MOBILIZATION
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE MACHINE (SEE PARAGRAPH
TECHNICAL SPECIFICATIONS). DO NOT AL-
LOW THE LIFTED MACHINE TO SWING.
NEVER LIFT THE MACHINE BY MEANS OF THE
CHUCK.
If the machine has to be moved from its normal work
post, the movement must be conducted following the
instructions listed below.
• Protect the exposed corners with suitable material
(Pluribol/cardboard).
• Do not use metallic cables for lifting.
• Make sure the power and pneumatic supply (on
models with pneumatic chuck) of the machine are
not connected.
• Place again the machine onto the original pallet with
whom it was delivered.
• Use transpallet or fork-lift for handling.
8.0 WORKING ENVIRONMENT CONDI-
TIONS
The machine must be operated under proper condi-
tions as follows:
• temperature: 0° + 45° C
• relative humidity: 30 - 90% (dew-free)
• atmospheric pressure: 860 - 1060 hPa (mbar).
The use of the machine in ambient conditions other
than those specified above is only allowed after prior
agreement with and approval of the manufacturer.
8.1 Working area
Fig. 3
USE THE MACHINE IN A DRY AND AD-
EQUATELY LIT PLACE, POSSIBLY INDOORS
OR ANYWAY IN A ROOFED AREA, THIS PLACE
MUST BE IN COMPLIANCE WITH APPLICABLE
SAFETY REGULATIONS.
The location of the machine requires a usable space
as indicated in Fig. 3. The positioning of the machine
must be according to the distances shown. From the
control position the operator is able to observe all the
machine and surrounding area. He must prevent unau-
thorized personnel or objects that could be dangerous
from entering the area.
The machine must be fixed on a flat floor surface,
preferably of cement or tiled. Avoid yielding or irregu-
lar surfaces.
The base floor must be able to support the loads trans-
mitted during operation.
This surface must have a capacity load of at least 500
kg/m².
The depth of the solid floor must be sufficient to guar-
antee that the anchoring bolts hold.
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 15 of 91
8.2 Lighting
The machine does not require its own lighting for
normal working operations. However, it must be used
in an adequately lit environment.
In case of poor lighting use lamps having total power
of 800/1200 Watt.
IF IT IS INSTALLED, EACH TIME
THE ROD OF THE GAUGE IS EX-
TRACTED FROM ITS HOUSING,
THE LED LIGHT (FIG. 1 REF. 20)
TURNS ON MAKING THE INSIDE
OF THE WHEEL WHERE THE OP-
ERATOR MUST WORK BRIGHTER.
9.0 MACHINE ASSEMBLY
EACH MECHANICAL INTERVEN-
TION MUST BE CARRIED OUT BY
PROFESSIONALLY QUALIFIED
STAFF.
After having freed the various components from the
packing check that they are complete, and that there
are no anomalies, then comply with the following in-
structions for the assembly of the components making
use of the attached series of illustrations.
9.1 Anchoring system
The packed machine is fixed to the support pallet
through the holes prearranged on the frame. Such
holes can be used also to fix the machine to the ground,
through floor anchor small blocks (excluded from sup-
ply). Before carrying out the definitive fixing, check that
all the anchor points are laid down flat and correctly
in contact with the fixing surface itself. If not so, insert
shimming profiles between the machine and the fixing
lower surface, as indicated in Fig. 4.
IN CASE OF WHEEL WEIGHING
MORE THAN 30 KG, IT IS COM-
PULSORY TO FIX TO THE GROUND
BY MEANS OF SCREW ANCHORS.
a = 332 mm / 13.07”
b = 580 mm / 22,83”
c = 54 mm / 2,13” Fig. 4
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 16 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
• Execute 4 holes with 10 mm diameter on the floor
by the holes on the bottom floor;
• insert the small blocks (excluded from supply) into
the holes;
• fix the machine to the ground with 4 M8x80 mm
screws (excluded from supply) (Fig. 4 ref. 1) (or
with 4 8x80 mm stud bolts (excluded from supply)).
Tighten the screws with an approximate tightening
torque of 70 Nm.
9.2 Assembly procedures
9.2.1 Fitting the chuck on the flange
For models with threaded chuck
Screw the chuck with an Allen wrench (Fig. 5 ref. 1)
on the flange (Fig. 5 ref. 2).
Fig. 5
9.2.2 Fitting and removal of the pneumatic
chuck on the flange
On models with pneumatic chuck
FITTING
1. After making power and air connections switch on
the machine (the pneumatic chuck always opens
when the machine is switched on).
2. Switch the machine off by using the main switch
(Fig. 27 ref. 1). Couple tyre inner rod (Fig. 6 ref.
1) with flange inner rod (Fig. 6 ref. 2) (see Fig. 6).
Fig. 6
FOR PNEUMATIC SHAFT KIT
FITTING (FIG. 6REF. 1) USE ME-
DIUM RESISTANCE LOCTITE 242
THREADLOCKERS OR EQUIVA-
LENT ONLY ON M10 THREAD AND
TIGHTEN TO 30NM.
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 17 of 91
3. Tighten tyre inner rod (Fig._7 ref. 1) with flange
inner rod (Fig._7 ref. 2) by using the wrench pro-
vided (Fig._7 ref. 3) and a 12 mm wrench (Fig._7
ref. 4). Use also a torque spanner (Fig._7 ref. 5)
(not supplied) on one of the 2 holes on the provided
spanner (Fig._7 ref. 3).
Fig. 7
4. Lock the chuck by pressing the brake and turn the
pneumatic shaft screw (Fig._8 ref. 1) onto the flange
(Fig._8 ref. 2) until it stops.
Fig. 8
5. Tighten with the wrench provided (Fig._8 ref. 3).
REMOVAL
1. Open the pneumatic chuck by means of the pedal
provided and make sure the outer ball (Fig._9 ref.
1) is in the position indicated in Fig._9.
Fig. 9
2. Lock the chuck by pressing the brake and unlock the
pneumatic shaft (Fig._10 ref. 1) using the wrench
provided (Fig._10 ref. 2).
Fig. 10
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 18 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
3. Unscrew pneumatic shaft screw (Fig._11 ref. 1) and
release the two inner rods with the special wrench
provided (Fig._11 ref. 2) and a 12 mm wrench
(Fig._11 ref. 3).
Fig. 11
FIT THE TORQUE SPANNER INTO
THE PROVIDED HOLES (REF. 1)
OF THE SUPPLIED SPANNER AND
TIGHTEN TO 30 NM.
9.2.3 Monitor fitting
1. Unscrew the plate (Fig. 12 ref. 1) from the bridge
(Fig. 12 ref. 2). Place the monitor with its support
in the immediate vicinity of the mounting location.
Support the casing (Fig. 12 ref. 3), as shown in the
figure, and insert the monitor and keyboard cables
(Fig. 12 ref. 4) through the support pipe (Fig. 12
ref. 5).
2. Fit the support (Fig. 12 ref. 5), complete with cas-
ing (Fig. 12 ref. 3), in the provided seat. Block the
support with the dowel (Fig. 12 ref. 6) and the nut
(Fig. 12 ref. 7), supplied.
DURING THIS OPERATION, PAY
PARTICULAR ATTENTION TO
THE POWER SUPPLY CABLE, TO
THE HDMI CABLE AND TO THE
KEYBOARD CABLES (FIG. 12
REF. 4)IN ORDER NOT TO DAM-
AGE THEM.
MAKE SURE THEY HAVE BEEN
INTRODUCED IN THE SUPPORT
PIPE, AS SHOWN IN FIG. 12.
Fig. 12
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00

INSTRUCTION, USE AND
MAINTENANCE MANUAL
EN Page 19 of 91
9.2.4 Fitting of external data gauge (stand-
ard on some models)
1. Unscrew the fastening screws of the equalizer
support (Fig. 15 ref. 1), being very careful about
holding the same support.
2. Screw the 3 screws (Fig. 15 ref. 2) to the gauge
bracket (Fig. 15 ref. 3) and to the equalizer sup-
port (Fig. 15 ref. 1).
Lock the gauge arm (Fig. 2 ref. 4) to the bracket
(Fig. 2 ref. 3) using the 2 appropriate screws
(Fig. 15 ref. 5). Lock these screws with the nuts
(Fig. 15 ref. 6), so that the chuck and the gauge
arm are levelled out (see Fig. 16).
Fig. 15
3. Also make sure the gauge tip (Fig. 16 ref. 1) is
positioned at the centre of the chuck.
Fig. 16
3. Fix the monitor (Fig. 13 ref. 1) to the support
(Fig. 13 ref. 2) with the screws (Fig. 13 ref. 3)
and the washers (Fig. 13 ref. 4) supplied.
4. Connect the plugs on the power supply sockets and
monitor signal. Connect the wiring of the keyboard.
Fig. 13
5. Fix the guard (Fig. 14 ref. 1) to the support
(Fig. 14 ref. 2) with the screws (Fig. 14 ref. 3)
and the washers (Fig. 14 ref. 4) supplied.
6. Reassemble the plate (Fig. 14 ref. 5), previously
unscrewed, with the screws (Fig. 16 ref. 6), sup-
plied.
Fig. 14
1297-M058-00
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.

EN
Page 20 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
4. Connect connector (Fig. 17 ref. 1) of the cable
coming from inside the machine to connector
(Fig. 17 ref. 2) of the cable coming from the gauge
arm. Fit the section of the cable with the connectors
inside the arm (Fig. 17 ref. 3).
5. Fasten the cable with clamps.
6. Enable the external data gauge and carry out the
device calibration.
Fig. 17
9.2.5 Fitting the protection guard
1. Mount the protection guard (Fig. 18 ref. 1) to the
support (Fig. 18 ref. 2) using the screws (Fig. 18
ref. 3), interposing the Belleville washers (Fig. 18
ref. 4) and the tab washers (Fig. 18 ref. 5 - 6).
2. Tighten the screws (Fig. 18 ref. 3) in order to
make the guard (Fig. 18 ref. 1) lift or lower with-
out bumping against the limit switch. Carry out the
adjustment so that it's possible to manually guide
the guard both during closing and opening.
DURING GUARD ASSEMBLY,
PAY ATTENTION TO THE MICRO
PLACED INSIDE THE MACHINE.
Fig. 18
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00
