Ravaglioli G3.140R User manual

INSTRUCTION MANUAL
• For any further information please contact your local dealer or call:
For spare parts drawings refer to the section “ LIST OF COMPONENTS” enclosed to this manual.
GB TRANSLATION FROM THE
ORIGINAL INSTRUCTIONS
G3.140R
GP3.140R
G3.140RS
GP3.140RS
1297-M007-1_R
1297-M007-1_R
Technical services: RAVAGLIOLI S.p.A. - Via 1° Maggio, 3 - 40037 Pontecchio Marconi - Bologna Italy
Phone [phone] - Telex 510697 RAV I - Fax [phone] - e-mail: [email protected]
- Rev. n. 1 (02/2015)

GB
Page 2 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
SUMMARY
SYMBOLS USED IN THE MANUAL AND ON
THE MACHINE __________________________ 5
1.0 GENERAL INTRODUCTION _________ 7
1.1 Introduction ___________________________7
2.0 INTENDED USE ____________________ 7
2.1 Staff training __________________________7
3.0 SAFETY DEVICES __________________ 8
3.1 Residual risks _________________________8
4.0 GENERAL SAFETY RULES _________ 8
5.0 PACKING AND MOBILIZATION FOR
TRANSPORT _______________________ 9
6.0 UNPACKING _______________________ 10
7.0 MOBILIZATION____________________ 10
8.0 WORKING ENVIRONMENT
CONDITIONS ______________________ 10
8.1 Working area ________________________ 11
8.2 Lighting _____________________________ 11
9.0 MACHINE ASSEMBLY _____________ 11
9.1 Anchoring system ___________________ 11
9.2 Fixtures contained in the packing ___ 12
9.3 Assembly procedures ________________ 13
9.3.1 Fitting the mandrel on the flange_ 13
9.3.2 Fitting and removal of the
pneumatic mandrel on the
flange ___________________________ 13
9.3.3 Fitting of external data gauge
(standard for G3.140RS -
GP3.140RS versions) (optional for
G3.140R - GP3.140R versions)___ 15
9.3.4 Fitting of professional external
data gauge (optional)____________ 16
9.3.5 Monitor fitting __________________ 17
9.3.6 Fitting the protection guard _____ 18
10.0 ELECTRICAL CONNECTION _______ 18
10.1 Electrical checks ____________________ 19
11.0 AIR CONNECTIONS _______________ 19
12.0 FITTING THE WHEEL ON THE
MANDREL_________________________ 20
12.1 Fitting of the wheel (G3.140R -
G3.140RS)___________________________ 20
12.2 Fitting of the wheel (GP3.140R -
GP3.140RS) _________________________ 21
13.0 CONTROL PANEL _________________ 23
14.0 WHEEL BALANCING ______________ 23
14.1 Switching the machine on and off ___ 23
14.2 Balancing programs setting _________ 24
14.2.1 Programs rapid setting and
measurements through distance-
diameter caliper arm____________ 24
14.2.2 Programs setting through
“Measurement being acquired”
screen page _____________________ 27
14.3 Indicative display of points where to
detect measures/to fit weight________ 28
14.3.1 Weights positioning _____________ 28
14.4 Displaying the active/modifiable
field _________________________________ 28
14.5 Wheel balancing screen page
description __________________________ 29
14.5.1 Balancing mode _________________ 30
14.6 Use of machines with disabled
automatic gauge ____________________ 32
14.6.1 Manual setting of wheel
dimensions ______________________ 32
14.7 Standard balancing programs_______ 32
14.7.1 Static____________________________ 32
14.7.2 Static-1__________________________ 33
14.7.3 Static-2__________________________ 33
14.7.4 Dynamic_________________________ 33
14.7.5 ALU-S ___________________________ 33
14.7.6 ALU-S1 __________________________ 34
14.7.7 ALU-S2 __________________________ 34
14.7.8 ALU-1____________________________ 34
14.7.9 ALU-2____________________________ 34
14.7.10 ALU-3 __________________________ 35
14.7.11 ALU-4 __________________________ 35
14.8 Optional balancing programs _______ 35
14.8.1 ECO-WEIGHT mode______________ 35
14.8.2 SPLIT mode _____________________ 37
14.8.3 Weights hidden behind spokes
mode ____________________________ 39
14.8.4 Matching mode __________________ 40
14.9 Special balancing programs_________ 43
14.9.1 Pax ______________________________ 43
14.10 Recalculation Function _____________ 43
14.11 Motorbike Mode wheel balancing ___ 44
15.0 USER MENU (OPTIONS AND
CALIBRATION) ____________________ 45
15.1 Options menu________________________ 45
15.1.1 Lower weight limit ______________ 47
15.1.2 Setting adhesive weight
dimensions and static threshold
percentage ______________________ 47
15.1.3 User management _______________ 48
15.2 Machine calibration _________________ 49
15.2.1 Mandrel “Ø” calibration _________ 49
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 3 of 60
15.2.2 Weight measurement sensors calibra-
tion______________________________ 49
15.2.3 Gauge calibration _______________ 50
16.0 ERROR SIGNALS__________________ 54
17.0 ROUTINE MAINTENANCE _________ 55
18.0 TECHNICAL DATA_________________ 56
18.1 Dimensions __________________________ 57
19.0 STORING__________________________ 58
20.0 SCRAPPING _______________________ 58
21.0 REGISTRATION PLATE DATA _____ 58
22.0 FUNCTIONAL DIAGRAMS _________ 58
Table A - Electrical and pneumatic
connection diagram ____________ 59
23.0 LIST OF COMPONENTS
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 4 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R
KEY
1 – Weight holding bridge
2 – Pneumatic mandrel (only for GP3.140R - GP3.140RS models)
3 – Distance-diameter caliper
4 – Threaded mandrel (only for G3.140R - G3.140RS models)
5 – Protection guard
6 – Foot brake (only for G3.140R - G3.140RS models) / pneumatic mandrel open-close pedal (only for
GP3.140R - GP3.140RS models)
7 – Main switch
8 – External data gauge (standard for G3.140RS - GP3.140RS models ) (optional for G3.140R - GP3.140R
models)
9 – Fixed laser unit + led light (standard for G3.140RS - GP3.140RS models)
10 – Monitor
11 – Pusher ring
12 – Rapid ring nut (only for G3.140R - G3.140RS models)
13 – Locking sleeve (only for GP3.140R - GP3.140RS models)
14 – Cones
15 – Professional external data gauge (optional)
16 – Grippers for weight fitting
17 – Lateral guard
18 – Push-button panel with 7 keys
Fig. 1 - G3.140R - GP3.140R - G3.140RS - GP3.140RS

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 5 of 60
SYMBOLS USED IN THE MANUAL AND ON THE MACHINE
Symbols Description
2167000
Read instruction manual.
FORBIDDEN!
Wear work gloves.
Wear work shoes.
2167000
Wear safety earcaps.
99990758
Shock hazard.
Caution: hanging loads.
Mandatory. Operations or jobs to
be performed compulsorily.
Danger! Be particularly careful.
Symbols Description
Move with fork lift truck or pallet
truck.
Lift from above.
1541000
General danger.
Wear safety goggles.
Technical assistance necessary.
Do not perform any intervention.
Warning. Be particularly careful
(possible material damages).
Note. Indication and/or useful
information.
Attention: never lift the machine
by means of the mandrel.
99990114
Arrow plate.
999912940
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 6 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
99990114
99990758
999912940
999914160
999914170
999910050
•
*
999916310
999920190
999920540
INFORMATION PLATE LOCATION TABLE
IF ONE OR MORE PLATES DISAPPEARS FROM THE MACHINE OR BECOMES DIFFICULT
TO READ, IT MUST BE REPLACED. QUOTE THE CODE NUMBER WHEN REORDERING.
99990114
99990758
999910050
999912940
999914160
999914170
999916310
999920190
999920540
•
*
Arrow plate
Electricity danger plate
Protection device use plate
Lifting plate
Voltage 230V 50/60 Hz 1 Ph plate
Voltage 115V 50/60 Hz 1 Ph plate
Skip label
New G3 logo plate
Laser point danger plate
Serial number plate
Manufacturer trademark nameplate
Code numbers of plates
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 7 of 60
SOME OF THE PICTURES PRE-
SENT IN THIS MANUAL HAVE
BEEN OBTAINED FROM PICTURES
OF PROTOTYPES, THEREFORE
THE STANDARD PRODUCTION
MACHINES AND ACCESSORIES
CAN BE DIFFERENT IN SOME
COMPONENTS.
1.0 GENERAL INTRODUCTION
This manual is an integral part of the product and
must be retained for the whole operating life of the
machine.
Carefully study the warnings and instructions con-
tained in this manual. It contains important instruc-
tions regarding FUNCTIONING, SAFE USE and
MAINTENANCE.
KEEP THE MANUAL IN A KNOWN,
EASILY ACCESSIBLE PLACE FOR
ALL ACCESSORY OPERATORS
TO CONSULT IT WHENEVER IN
DOUBT.
THE MANUFACTURER DISCLAIMS
ALL RESPONSIBILITY FOR ANY
DAMAGE OCCURRED WHEN THE
INDICATIONS GIVEN IN THIS
MANUAL ARE NOT RESPECTED:
AS A MATTER OF FACT, THE NON-
COMPLIANCE WITH SUCH INDI-
CATIONS MIGHT LEAD TO EVEN
SERIOUS DANGERS.
1.1 Introduction
Thank you for preferring this wheel balancer. We feel
sure you will not regret your decision.
This machine has been designed for use in profes-
sional workshops and stands out for its reliability
and easy, safe and rapid operation. With just a small
degree of maintenance and care, this wheel balancer
will give you many years of trouble-free service and
lots of satisfaction.
2.0 INTENDED USE
The machines models G3.140R - GP3.140R -
G3.140RS - GP3.140RS, and relative versions,
are wheel balancers for car and light transport,
projected to be used exclusively to cancel out, or at
least reduce to acceptable limits the vibrations of the
wheels, by fitting counterweights of suitable size and
in specific positions to the same wheels that are not
correctly balanced.
DANGER: THIS MACHINE MUST
BE USED STRICTLY FOR THE
INTENDED PURPOSE IT WAS DE-
SIGNED FOR (AS INDICATED IN
THIS MANUAL).
THE MANUFACTURER CANNOT
BE HELD RESPONSIBLE FOR ANY
DAMAGE CAUSED BY IMPROPER,
ERRONEOUS, OR UNACCEPTABLE
USE.
AN INTENSIVE USE OF THE EQUIP-
MENT IN INDUSTRIAL ENVIRON-
MENT IS NOT RECOMMENDED.
2.1 Staff training
The machine may be operated only by suitably
trained and authorized personnel.
Given the complexity of the operations necessary to
manage the machine and to carry out the operations
safely and efficiently, the personnel must be trained
in such a way that they learn all the information
necessary to operate the machine as intended by the
manufacturer.
A CAREFUL READING OF THIS
INSTRUCTION MANUAL FOR
USE AND MAINTENANCE AND A
SHORT PERIOD OF TRAINING
WITH SKILLED PERSONNEL CAN
BE AN ENOUGH PREVENTIVE
PREPARATION.
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 8 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
3.0 SAFETY DEVICES
• Master switch positioned on the rear of the ma-
chine
Its function is to disconnect machine electric supply.
• Protection guard
Its function is to protect the operator from possible
projections of materials on the wheel during its spin.
Wheel spinning is normally prevented if the wheel
protection guard is raised (open). When the
protection guard is open, this interrupts the cir-
cuit that triggers the motor and automatic start
is prevented, including in the case of an error.
Press stop key to stop wheel rotation in
emergency conditions.
3.1 Residual risks
The machine was subjected to a complete analysis of
risks according to reference standard EN ISO 12100.
Risks are as reduced as possible in relation with tech-
nology and product functionality.
Possible residual risks have been emphasized through
pictorial representations and warnings which placing is
indicated in “ PLATE POSITIONING TABLE” at page 6.
4.0 GENERAL SAFETY RULES
• Any tampering with or modification to the machine
not previously authorized by the manufacturer ex-
empts the latter from all responsibility for damage
caused by or derived from said actions.
• Removing of or tampering with the safety devices or
with the warning signals placed on the machine leads
to serious dangers and represents a transgression of
European safety rules.
• Use of the machine is only permitted in places free
from explosion or fire hazard and in dry places
under cover.
• Original spare parts and accessories should be used.
THE MANUFACTURER DENIES
ANY RESPONSIBILITY IN CASE
OF DAMAGES CAUSED BY UNAU-
THORIZED MODIFICATIONS OR
BY THE USE OF NON ORIGINAL
COMPONENTS OR EQUIPMENT.
• Installation must be conducted only by qualified
personnel exactly according to the instructions that
are given below.
• Ensure that there are no dangerous situations dur-
ing the machine operating manoeuvres. Immediately
stop the machine if it miss-functions and contact the
assistance service of an authorized dealer.
• In emergency situations and before carrying out any
maintenance or repairs, disconnect all supplies to
the machine by using the main switch, placed on the
machine itself, and unplugging the power supply.
• The machine electrical supply system must be
equipped with an appropriate earthing, to which
the yellow-green machine protection wire must be
connected.
• Ensure that the work area around the machine is free
of potentially dangerous objects and that there is no
oil since this could damage the tyre. Oil on the floor
is also a potential danger for the operator.
• UNDER NO CIRCUMSTANCES must the machine be
used to spin anything but vehicle wheels. Bad locking
can cause rotating parts to come loose, with potential
damage to the machine and anything in the vicinity
and injury to the operator.
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 9 of 60
Fig. 2
5.0 PACKING AND MOBILIZATION
FOR TRANSPORT
HAVE THE MACHINE HANDLED BY SKILLED
PERSONNEL ONLY.
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE PACKED MACHINE (SEE
PARAGRAPH “TECHNICAL SPECIFICATIONS”).
The machine is packed completely assembled. The
machine is inside a carton box which size is mm
1040x950x1090.
Movement must be by pallet-lift or fork-lift trolley.
The fork lifting points are indicated on the packing.
OPERATORS MUST WEAR SUIT-
ABLE WORK CLOTHES, PROTEC-
TIVE GLASSES AND GLOVES,
AGAINST THE DANGER FROM
THE SPRAYING OF DANGEROUS
DUST, AND POSSIBLY LOWER
BACK SUPPORTS FOR THE LIFT-
ING OF HEAVY PARTS. DANGLING
OBJECTS LIKE BRACELETS MUST
NOT BE WORN, AND LONG HAIR
MUST BE TIED UP. FOOTWEAR
SHOULD BE ADEQUATE FOR THE
TYPE OF OPERATIONS TO BE CAR-
RIED OUT.
• The machine handles and operating grips must be
kept clean and free from oil.
• The workshop must be kept clean and dry. Make sure
that the working premises are properly lit.
The machine can be operated by a single operator.
Unauthorized personnel must remain outside the
working area, as shown in Fig. 3.
Avoid any hazardous situations. Do not use air-
operated or electrical equipment when the shop is
damp or the floor slippery and do not expose such
tools to atmospheric agents.
• When operating and servicing this machine, carefully
follow all applicable safety and accident-prevention
precautions.
The machine must not be operated by professionally
unskilled persons.
WHEN USING THE MODELS WITH
WHEEL PNEUMATIC CLAMPING,
DURING MANDREL OPENING/
CLOSING OPERATIONS, BE EX-
TREMELY CAREFUL AND KEEP
YOUR HANDS OR OTHER PARTS
OF YOUR BODY AWAY FROM THE
MOVING MANDREL.
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 10 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
7.0 MOBILIZATION
THE LIFTING EQUIPMENT MUST WITHSTAND
A MINIMUM RATED LOAD EQUAL TO THE
WEIGHT OF THE MACHINE (SEE PARAGRAPH
TECHNICAL SPECIFICATIONS). DO NOT AL-
LOW THE LIFTED MACHINE TO SWING.
NEVER LIFT THE MACHINE BY MEANS OF THE
MANDREL.
If the machine has to be moved from its normal work
post, the movement must be conducted following the
instructions listed below.
• Protect the exposed corners with suitable material
(Pluribol/cardboard).
• Do not use metallic cables for lifting.
• Make sure the electrical supply (and, for GP3.140R
- GP3.140RS models, the pneumatic supply) of the
machine is not connected.
• Place again the machine onto the original pallet with
whom it was delivered.
• Use transpallet or fork-lift for handling.
8.0 WORKING ENVIRONMENT CONDI-
TIONS
The machine must be operated under proper condi-
tions as follows:
• temperature: 0° + 45° C
• relative humidity: 30 - 90% (dew-free)
• atmospheric pressure: 860 - 1060 hPa (mbar).
The use of the machine in ambient conditions other
than those specified above is only allowed after prior
agreement with and approval of the manufacturer.
6.0 UNPACKING
DURING UNPACKING, ALWAYS
WEAR GLOVES TO PREVENT ANY
INJURY CAUSED BY CONTACT
WITH PACKAGING MATERIAL
(NAILS, ETC.).
The cardboard box is supported with plastic strapping.
Cut the strapping with suitable scissors. Use a small
knife to cut along the lateral axis of the box and open
it like a fan.
It is also possible to unnail the cardboard box from
the pallet it is fixed to. After removing the packing, and
in the case of the machine packed fully assembled,
check that the machine is complete and that there is
no visible damage.
If in doubt do not use the machine and refer to pro-
fessionally qualified personnel (to the seller).
The packing (plastic bags, expanded polystyrene, nails,
screws, timber, etc.) should not be left within reach of
children since it is potentially dangerous. These ma-
terials should be deposited in the relevant collection
points if they are pollutants or non biodegradable.
THE BOX CONTAINING THE FIX-
TURES IS CONTAINED IN THE
WRAPPING. DO NOT THROW IT
AWAY WITH THE PACKING.
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 11 of 60
600
600
600
X
ba
1X
X
c
8.1 Working area
Fig. 4
a = 306
b = 580
c = 55
USE THE MACHINE INDOORS OR IN A ROOFED
AREA. PLACE OF INSTALLATION MUST BE
DRY, ADEQUATELY LIT AND IN COMPLIANCE
WITH APPLICABLE SAFETY REGULATIONS.
The location of the machine requires a usable space
as indicated in Fig. 3. The positioning of the machine
must be according to the distances shown. From the
control position the operator is able to observe all the
machine and surrounding area. He must prevent unau-
thorized personnel or objects that could be dangerous
from entering the area.
The machine must be fixed on a flat floor surface,
preferably of cement or tiled. Avoid yielding or irregu-
lar surfaces.
The base floor must be able to support the loads trans-
mitted during operation.
This surface must have a strength of at least 500 kg/m².
The depth of the solid floor must be sufficient to guar-
antee that the anchoring bolts hold.
8.2 Lighting
The machine does not require its own lighting for
normal working operations. However, it must be used
in an adequately lit environment.
In case of poor lighting use lamps having total power
800/1200 Watt.
IF IT IS INSTALLED, EACH TIME
THE ROD OF THE GAUGE IS EX-
TRACTED FROM ITS HOUSING,
THE LED LIGHT (FIG. 1 REF. 9)
TURNS ON MAKING THE INSIDE
OF THE WHEEL WHERE THE OP-
ERATOR MUST WORK BRIGHTER.
9.0 MACHINE ASSEMBLY
After having freed the various components from the
packing check that they are complete, and that there
are no anomalies, then comply with the following in-
structions for the assembly of the components making
use of the attached series of illustrations.
9.1 Anchoring system
The packed machine is fixed to a pallet by support feet.
Such feet also fix the machine to the ground through
anchor small blocks as shown in Fig. 4 ref._1.
IN CASE OF WHEEL WEIGHING
MORE THAN 30 KG, IT IS COM-
PULSORY TO FIX TO THE GROUND
BY MEANS OF SCREW ANCHORS.
The holes in the solid floor must be about 10 cm deep
with a diameter of 8 MA.
The bolts (Fig. 4 ref. 1) must be inserted in the pre-
arranged holes and fully tightened (tightening torque:
about 22 Nm) until reaching the system full seal.
Fig. 3
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 12 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1300A004
999072
129571492
GAR111
GAR101 GAR108
129590710
A
Fig. 5
9.2 Fixtures contained in the packing
The packing case contains also the fixtures box.
Check that all the parts listed below are there (see
Fig. 5).
For G3.140R model
Code Description N.
GAR101 Rapid ring nut + pusher ring 1
GAR111 Cones + protection cup 1
129571492 Gauge 1
1300A004 Weight pliers 1
999072 Carriages counterweight 1
For GP3.140R model
Code Description N.
GAR108 Rapid ring nut + pusher ring 1
GAR111 Cones + protection cup 1
129571492 Gauge 1
1300A004 Weight pliers 1
999072 Carriages counterweight 1
For G3.140RS model
Code Description N.
GAR101 Rapid ring nut + pusher ring 1
GAR111 Cones + protection cup 1
129571492 Gauge 1
1300A004 Weight pliers 1
999072 Carriages counterweight 1
129590710 External data gauge 1
For GP3.140RS model
Code Description N.
GAR108 Rapid ring nut + pusher ring 1
GAR111 Cones + protection cup 1
129571492 Gauge 1
1300A004 Weight pliers 1
999072 Carriages counterweight 1
129590710 External data gauge 1
THE GRIP-RING (FIG. 5 REF. A)
MUST BE MOUNTED WITH THE
TEETH OR DISCHARGE SIDE
TOWARDS THE RING-NUT OR
SLEEVE (SEE FIG. 5).
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 13 of 60
1
2
Fig. 6
Fig. 7
Fig. 8
9.3 Assembly procedures
9.3.1 Fitting the mandrel on the flange
Only for G3.140R - G3.140RS models
Screw the mandrel with an Allen wrench (Fig. 6 ref. 1)
on the flange (Fig. 6 ref. 2).
9.3.2 Fitting and removal of the pneumatic
mandrel on the flange
Only for GP3.140R - GP3.140RS models
FITTING
1. After making power and air connections switch on
the machine (the pneumatic mandrel always opens
when the machine is switched on). Switch the ma-
chine off. Fit the internal mandrel on the flange
and tighten it with the wrench provided (Fig. 7
and Fig. 8).
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 14 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
2. Press the brake's pedal and, at the same time, tighten
the internal mandrel as far as it will go using the
wrench provided (Fig. 9).
Fig. 9
3. Fit the external mandrel and tighten it manually
(Fig. 10).
Fig. 10
4. Close the pneumatic mandrel by means of the pedal
to access the key socket (Fig.(Fig. 11).
Fig. 11
5. Press the brake pedal and at the same time block
the external mandrel using the wrench supplied
(Fig. 12).
Fig. 12
REMOVAL
• Close the pneumatic mandrel by means of the pedal
to access the key socket (Fig. 11).
• Press the brake pedal and at the same time release
the external mandrel by using the wrench provided
(Fig. 12).
• Remove the external mandrel, open the pneumatic
mandrel by means of the pedal provided and loosen
the internal mandrel using the special wrench
(Fig. 9).
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 15 of 60
12
3
1
2
2
3
4
5
6
1
9.3.3 Fitting of external data gauge (standard
for G3.140RS - GP3.140RS versions)
(optional for G3.140R - GP3.140R ver-
sions)
1. Unscrew the fastening screws of the equalizer's
support (Fig. 13 ref. 1), being very careful about
holding the same support.
2. Unscrew the 3 screws (Fig. 13 ref. 2) to the gauge
bracket (Fig. 13 ref. 3) and in the special inserts
placed on the rear side of the frame.
Lock the gauge arm (Fig. 13 ref. 4) by screwing
the 2 screws provided (Fig. 13 ref. 5). Lock these
screws with the nuts (Fig. 13 ref. 6) so that the
mandrel and the gauge arm are levelled out (see
Fig. 14).
Fig. 13
3. Also make sure the gauge tip (Fig. 14 ref. 1) is
positioned at the centre of the mandrel.
Fig. 14
4. Connect connector (Fig. 15 ref. 1) of the cable com-
ing from inside the machine to connector (Fig. 15
ref. 2) of the cable coming from the gauge arm. Fit
the section of the cable with the connectors inside
the arm (Fig. 15 ref. 3).
5. Fasten the cable with clamps.
6. Enable the external data gauge and carry out the
device's calibration.
Fig. 15
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 16 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
4
5
23
6
12
3
1
9.3.4 Fitting of professional external data
gauge (optional)
1. Unscrew the fastening screws of the equalizer's
support (Fig. 16 ref. 1), being very careful about
holding the same support.
2. Unscrew the 3 screws (Fig. 16 ref. 2) to the gauge
bracket (Fig. 16 ref. 3) and in the special inserts
placed on the rear side of the frame.
Lock the gauge arm (Fig. 16 ref. 4) by screwing
the 2 screws provided (Fig. 16 ref. 5). Lock these
screws with the nuts (Fig. 16 ref. 6) so that the
mandrel and the gauge arm are levelled out (see
Fig. 17).
Fig. 16
3. Also make sure the gauge tip (Fig. 17 ref. 1) is
positioned at the centre of the mandrel.
Fig. 17
4. Connect connector (Fig. 18 ref. 1) of the cable com-
ing from inside the machine to connector (Fig. 18
ref. 2) of the cable coming from the gauge arm. Fit
the section of the cable with the connectors inside
the arm (Fig. 18 ref. 3).
Fig. 18
5. Fasten the cable with clamps.
6. Enable the external data gauge and carry out the
device's calibration.
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 17 of 60
1
90°
3
4
5
2
1
2
3
3
4
4
1
23
3
4
4
9.3.5 Monitor fitting
1. Unscrew the nuts (Fig. 19 ref. 1) and the washers
(Fig. 19 ref. 2) from the screws (Fig. 19 ref. 3).
Fit the support tube (Fig. 19 ref. 4) rotated through
90°, paying attention to the monitor and keyboard
cables (Fig. 19 ref. 5) inside it. Then screw the
previously unscrewed nuts and washers again.
Fig. 19
2. Connect the plugs on the power supply sockets and
monitor signal. Connect the wiring of the keyboard.
3. Fix the monitor (Fig. 20 ref. 1) to the support
(Fig. 20 ref. 2) with the screws (Fig. 20 ref. 3)
and the washers (Fig. 20 ref. 4) supplied.
Fig. 20
4. Mount the guard (Fig. 21 ref. 1) to the support
(Fig. 21 ref. 2) with the 6 screws (Fig. 21 ref. 3)
and the washers (Fig. 21 ref. 4) supplied.
Fig. 21
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 18 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
4
Fig. 22
9.3.6 Fitting the protection guard
1. Mount the protection guard (Fig. 22 ref. 1) to the
support (Fig. 22 ref. 2) using the screws (Fig. 22
ref. 3), interposing the Belleville washers (Fig. 22
ref. 4).
2. Tighten the screws (Fig. 22 ref. 3) in order to make
the guard (Fig. 22 ref. 1) lift or lower without
bumping against the limit switch. Carry out the
adjustment so that it's possible to manually guide
the guard both during closing and opening.
DURING GUARD'S ASSEMBLY,
PAY ATTENTION TO THE MICRO
PLACED INSIDE THE MACHINE.
10.0 ELECTRICAL CONNECTION
EVEN THE TINIEST PROCEDURE
OF AN ELECTRICAL NATURE
MUST BE CARRIED OUT BY PRO-
FESSIONALLY QUALIFIED STAFF.
BEFORE CONNECTING THE MA-
CHINE MAKE SURE THAT:
• THE MAIN POWER RATING COR-
RESPONDS TO THE MACHINE
RATING AS SHOWN ON THE
MACHINE PLATE;
• ALL MAIN POWER COMPO-
NENTS ARE IN GOOD CONDI-
TION;
• THE ELECTRICAL SYSTEM
IS PROPERLY GROUNDED
(GROUND WIRE MUST BE THE
SAME CROSS-SECTION AREA
AS THE LARGEST POWER SUP-
PLY CABLES OR GREATER);
• MAKE SURE THAT THE ELEC-
TRICAL SYSTEM FEATURES A
CUTOUT WITH DIFFERENTIAL
PROTECTION SET AT 30 mA.
Connect the machine up to the mains by means of the
3-pole plug provided (230 V single-phase) through the
wall socket.
If the plug provided is not suitable for the wall socket,
fit a plug that complies with local and applicable regu-
lations. This operation must be performed by expert
and professional personnel.
FIT A TYPE-APPROVED (AS RE-
PORTED BEFORE) PLUG TO THE
MACHINE CABLE (THE GROUND
WIRE IS YELLOW/GREEN AND
MUST NEVER BE CONNECTED TO
THE PHASE LEADS). MAKE SURE
THAT THE ELECTRICAL SYSTEM
IS COMPATIBLE WITH THE RATED
POWER ABSORPTION SPECIFIED
IN THIS MANUAL AND APT TO
ENSURE THAT VOLTAGE DROP
UNDER FULL LOAD WILL NOT
EXCEED 4% OF RATED VOLTAGE
(10% UPON START-UP).
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R

INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB Page 19 of 60
1
Fig. 24
FAILURE TO OBSERVE THE ABOVE
INSTRUCTIONS WILL IMMEDIATE-
LY INVALIDATE THE WARRANTY.
10.1 Electrical checks
BEFORE STARTING UP THE
WHEEL-BALANCER, BE SURE TO
BECOME FAMILIAR WITH THE LO-
CATION AND OPERATION OF ALL
CONTROLS AND CHECK THEIR
PROPER OPERATION (SEE PAR.
“CONTROLS”).
CARRY OUT A DAILY CHECK OF
MAINTAINED-TYPE CONTROLS
CORRECT FUNCTIONING, BEFORE
STARTING MACHINE OPERATION.
Once the plug/socket connection has been made, turn
on the machine using the master switch (Fig. 23
ref. 1).
11.0 AIR CONNECTIONS
Only for GP3.140R - GP3.140RS models
IN CASE OF A CHANCE SUP-
PLY FAILURE, AND/OR BEFORE
ANY PNEUMATIC CONNECTIONS,
MOVE THE CONTROLS TO THE
NEUTRAL POSITION.
Connect the wheel balancer to the centralised com-
pressed-air system by means of the connection on the
back of the machine (see Fig. 24).
The air system supplying the machine must be able
to supply filtered and de-humidified air at a pressure
between 8 and 10 bar. It must feature an on-off valve
upstream of the machine.
Fig. 23
1297-M007-1_R
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.

GB
Page 20 of 60
INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
12
1
2
3
4. Fit the protection cap (Fig. 26 ref. 1) in the locknut
(Fig. 26 ref. 2) and fasten against the wheel.
Fig. 25
Fig. 26
Fig. 27
Some aluminium wheels, with very high centring, must
be fitted with the cone outside the wheel.
5. Clean the mandrel (Fig. 27 ref. 1) before fitting
the wheel.
6. Fit the wheel (Fig. 27 ref. 3) with the inside of the
rim towards the wheel balancer, until the wheel is
up against the support flange (Fig. 27 ref. 2).
12.0 FITTING THE WHEEL ON THE
MANDREL
To achieve perfect balancing, the wheel must be care-
fully and properly fitted on the mandrel. Imperfect
centring will inevitably cause unbalances.
MOST IMPORTANT IS THAT ORIGI-
NAL CONES AND ACCESSORIES
ARE USED MADE SPECIFICALLY
FOR USE ON THE WHEEL BAL-
ANCER.
Wheel fitting using the cones provided is illustrated be-
low. For alternative fittings, using optional accessories,
refer to the special instructions provided separately.
12.1 Fitting of the wheel (G3.140R - G3.140RS)
1. Remove any type of foreign body from the wheel
(Fig. 25 ref. 3): pre-existing weights, stones and
mud, and make sure the mandrel (Fig. 25 ref. 1)
and the rim centring area are clean before fitting
the wheel on the mandrel.
2. Carefully choose the cone (Fig. 25 ref. 2) most suit-
able for the wheel to be balanced. These accessories
must be selected according to the shape of the rim.
Position the wheel (Fig. 25 ref. 3), fitting the cone
(Fig. 25 ref. 2) on the mandrel (Fig. 25 ref. 1): be
careful (otherwise this could seize) until this rests
against the support flange (Fig. 25 ref. 4).
3. Fit the wheel with the inner side of the rim towards
the wheel balancer and against the cone.
G3.140R - GP3.140R - G3.140RS - GP3.140RS
RAVAGLIOLI S.p.A.
1297-M007-1_R
