Raven Scanner Compact User manual

For USB connection, connect
the micro-USB end of the USB
cable into the micro-USB port on
your scanner. Plug
the rectangle end to the USB port
at the rear side of your computer.
For WiFi connection (optional),
proceed with Raven Desktop
installation and follow steps
shown.
(Network Enabled)
Quick Start Guide
1What’s in the box:
2Install the scanner:
3Installing Raven Desktop and Scanner Drivers:
Scanner Power Adapter and Cable Micro USB Cable
2.1 2.3
Remove all protective
tapes and wrapping from the
scanner.
2.2
Plug the small end of the
power adaptor into the power
jack of your scanner. Insert the
other end to an appropriate
power outlet.
Press the Power button on
the front panel and wait for the
LED indicator to stop flashing.
2.4
3.1 Visit Raven.com/Desktop to
download Raven Desktop and drivers to
your Mac or PC.
3.2 Choose the Compact Scanner in the
installation wizard.
3.3 Choose USB connection method to your
scanner, using the USB cable included in the
box, or Wireless to set up WiFi connection to
your scanner.
Getting started with Raven Scanner
Claim Your FREE Product - visit Raven.com/freeproduct
Download the user manual at raven.com/user-manuals
Our support team is available to answer any questions and take your feedback.
Call us at 1-800-713-9009 or email [e-mail]

4Scanning with Raven Desktop:
4.1 Home screen shows available
workflows, scan settings and destinations.
Create custom workflows by clicking the
button.
4.2 Click the button to choose
additional scan settings.
4.3 Set up and manage destinations by
clicking the button. Click the
button to save to folders on your computer.
5Two ways to scan:
6Tips for seamless scanning:
6.1
To avoid occasional multi-feeds or paper jams, please fan your
documents by holding both ends of the documents and fanning
them a few times. Align the top edges in a step-like pattern before
feeding them into the scanner.
6.3
Remove items such as staples, paper clips and sticky notes
before feeding into the scanner to prevent damage.
6.2
Only one sheet of paper is allowed to load in the front paper
tray. The automatic feeder can support up to 20 sheets.
5.1
To use the Automatic Feeder, unfold the document feeder
and its extension and raise the paper guide to hold your
document. Load the stack of document Facing Down with the top
of the pages pointing into the feeder and verify that the paper
guides are aligned with the edges of the stack.
5.2
To scan a single page document or ID card with the front input
tray, open the cover of the front input tray and load your singe-page
document to the front input tray with the top of the page pointing to
the front input tray. Load one-sided document with the text facing
up and center your document with the paper size marks.
ADVANCED
MANAGE
Download the user manual at raven.com/user-manuals
Our support team is available to answer any questions and take your feedback.
Call us at 1-800-713-9009 or email [e-mail]
(Network Enabled)
Quick Start Guide
Getting started with Raven Scanner
Claim Your FREE Product - visit Raven.com/freeproduct
Step-like
Scanning
Direction
