Raymarine RAY430 User guide

Ray430
Loudhailer
Owner’s Handbook

PURPOSE
THIS MANUAL CONTAINS IMPORTANT INFORMATION ON THE INSTALLATION,
OPERATION AND MAINTENANCE OF YOUR EQUIPMENT
Raymarine products are supported by a network of Authorized Service Representatives. For product
information, you may contact the following regional centers:
United States………………………………………. Raymarine, Inc.
21 Manchester Street
Merrimack
New Hampshire
USA 03054-4801
Telephone:[phone]
Fax: [phone]
Europe…………………………………………….. Raymarine plc
Robinson Way,
Anchorage Park
Portsmouth
Hampshire P03 5TD
United Kingdom
Telephone [phone]
Fax [phone]
IMPORTANT NOTICE
THIS DEVICE IS ONLY AN AID TO BOATING SAFETY AND NAVIGATION. ITS
PERFORMANCE CAN BE AFFECTED BY MANY FACTORS INCLUDING EQUIPMENT
FAILURE OR DEFECT, ENVIRONMENTAL CONDITIONS, AND IMPROPER HANDLING OR
USE. IT IS THE USER’S RESPONSIBILITY TO EXERCISE COMMON PRUDENCE AND
NAVIGATIONAL JUDGMENT. THIS DEVICE SHOULD NOT BE RELIED ON AS A
SUBSTITUTE FOR SUCH PRUDENCE AND JUDGMENT.

TABLE OF CONTENTS
SECTION 1 GENERAL
1.1 INTRODUCTION ................................................................................... 1-1
1.2 EQUIPMENT FEATURES..................................................................... 1-1
1.3 SPECIFICATIONS.................................................................................. 1-2
SECTION 2 INSTALLATION
2.1 UNPACKING AND INSPECTION........................................................ 2-1
2.2 EQUIPMENT SUPPLIED....................................................................... 2-1
2.2.1 Optional Accessories ......................................................................... 2-2
2.3 STORAGE............................................................................................... 2-2
2.4 PLANNING THE INSTALLATION...................................................... 2-3
2.4.1 Mounting Options.............................................................................. 2-5
2.5 ELECTRICAL CONNECTION.............................................................. 2-5
2.5.1 DC Power Connections...................................................................... 2-5
2.5.2 Intercom Speaker(s)........................................................................... 2-6
2.5.3 Hailer Horn(s).................................................................................... 2-7
2.5.4 Connection of Burglar Alarm ............................................................ 2-7
2.5.5 Remote Microphone........................................................................... 2-7
2.5.6 Auxiliary lnput................................................................................... 2-8
2.5.7 Connection of an External Speaker.................................................... 2-8
SECTION 3 OPERATION
3.1 INTRODUCTION ................................................................................... 3-1
3.2 CONTROLS AND LCD DISPLAY........................................................ 3-1
3.2.1 Controls.............................................................................................. 3-1
3.2.2 LCD Display...................................................................................... 3-3
3.3 OPERATING PROCEDURES................................................................ 3-5
3.3.1 The Power Switch/Dimmer Control .................................................. 3-5
3.3.2 Volume Control (Hail & Listen)........................................................ 3-5
3.3.3 Hail Mode .......................................................................................... 3-6
3.3.4 Intercom Operation............................................................................ 3-6
i

3.3.5 Fog Horn Mode.................................................................................. 3-8
3.3.6 Aux Mode .......................................................................................... 3-13
SECTION 4 TECHNICAL DESCRIPTION
4.1 BLOCK DIAGRAM................................................................................ 4-1
SECTION 5 MAINTENANCE
5.1 GENERAL............................................................................................... 5-1
5.1.1 Product and Customer Service........................................................... 5-1
5.2 PREVENTATIVE MAINTENANCE..................................................... 5-1
5.3 ADJUSTMENT ....................................................................................... 5-2
5.3.1 Test Equipment.................................................................................. 5-2
5.3.2 Listen Output Adjustment.................................................................. 5-2
5.3.3 Intercom Output Adjustment ............................................................. 5-3
5.3.4 Level Meter Adjustment.................................................................... 5-3
SECTION 6 PARTS LIST & DRAWINGS
6.1 PARTS LIST............................................................................................ 6-1
6.2 ASSEMBLY DRAWING........................................................................ 6-8
6.3 PARTS LIST FOR ASSEMBLY DRAWING........................................ 6-9
6.4 INTERNAL WIRING DIAGRAM.......................................................... 6-11
6.5 LINEAR A SCHEMATIC DIAGRAM................................................... 6-12
6.6 LINEAR B SCHEMATIC DIAGRAM................................................... 6-13
6.7 LINEAR A PCB PARTS LAYOUT........................................................ 6-14
6.8 LINEAR B PCB PARTS LAYOUT........................................................ 6-14
6.9 CPU PCB SCHEMATIC DIAGRAM..................................................... 6-15
6.10 CPU PCB PARTS LAYOUT .................................................................. 6-16
ii

SECTION 1
GENERAL DESCRIPTION
1.1 INTRODUCTION
Congratulations on your purchase of the RAY430 Multifunction Loudhailer.
The RAY430 Loudhailer is a multipurpose device that may be used as a ship-to-shore hailer, ship-to-
ship hailer, foghorn, audio amplifier, intercom, and/or alarm system.
As a loudhailer, the RAY430 amplifies your voice up to a 30 watt level, for hailing through the
hailing horn speaker, and when listening for replies, amplifies the incoming sounds to the desired
listening level. If an additional (optional) horn is added to the system, the loudhailer output can be
switched to either or both of the hailing horn positions by the front panel control.
To verify your ownership and warranty registration, you should take a few minutes and fill out your
warranty registration card found just inside the front cover of this manual. It is very important that
you take the time to fill this card out. The warranty registration card should be returned to the factory
immediately after your purchase in order to receive full warranty benefits.
Section 5 in this manual provides further information on obtaining Customer Service and Product
Support which is available to you as a valued customer.
1.2 EQUIPMENT FEATURES
The RAY430 is designed and manufactured to provide ease of installation and operation with
excellent reliability. Some of the important built-in features of the equipment are listed below.
The loudhailer horns(s) are used as sound dispersal points when the RAY430 is used as a foghorn so
that the full 30 watt output of the unit can be employed.
In the foghorn mode any of six programmed foghorn patterns can be automatically generated. They
are: Underway, Stopped, Sail, Tow, Anchored, and Aground.
INTERCOM — Provides 2-way communication between the display unit and up to 4 connected
remote units, which can also originate a call to the display unit.
AUXILIARY MODE — Allows the selective or simultaneous transmission of an external audio
input to all stations. For entertainment, the external audio can be a cassette deck, radio, or CD player.
For business, it can also be any other instrument having an external audio output, such as the output
from a VHF or SSB radiotelephone.
1-1

EXTERNAL ALARM CONNECTION — For external systems or security alarm sensors.
EASY TO USE — An ideal arrangement, the RAY430 has an illuminated keyboard and LCD which
clearly shows all selected stations and operating modes.
DURABLE, WATERPROOF CONSTRUCTION — With rugged gaskets and our heavy-duty
microphone the RAY430 is built to survive in the toughest marine environments.
SILICONE RUBBER KEYBOARD — Has backlighting for easy night-time viewing and operation.
OPTIONAL FLUSH-MOUNT KIT — For attractive customized mounting into overhead instrument
cabinets or in the console of your bridge.
1.3SPECIFICATIONS
Dimensions: 4 3/4 x 9 3/16 x 4 1/2 inches (121 x 234 x 114 mm)
Height x Width x Depth
Weight Approximately 1.9 Kg (4.3 lbs)
Power supply 13.6 VDC nominal (±20%) 5 amps or less
Audio Output Hail Spkr 30W
Intercom Spkr 4.5W
Ext. Spkr 4.5W
Int. Spkr 2.5W
Output impedances Hail Spkr 8 ohms
Intercom Spkr 8 ohms
Ext. Spkr 8 ohms
Input Impedance Mic. Impedance 600 ohms
Aux Impedance 10K ohms
Input Sensitivity Mic. Sensitivity -40 dB 3dB (at 1KHz)
Aux Sensitivity -10 dB 3dB (at 1KHz)
SP/Mic Sensitivity 6mV RMS ±20%
Frequency Response Hail Mode 100Hz to 8KHz 5dB
Listen Mode 100Hz to 8KHz 5dB
Aux Mode 100Hz to 20KHz 5dB
Distortion Factor Hail Mode 10% or less (at 1KHz 30W)
Listen Mode 10% or less (at 1KHz 5W)
Aux Mode 10% or less (at 1KHz 30W)
Signal to Noise Ratio Hail Mode 60dB or more (at 1KHz)
Listen Mode 60dB or more (at 1KHz)
Aux Mode 60dB or more (at 1KHz)
Horn Frequency 500Hz ± 50Hz
1-2

SECTION 2
INSTALLATION
2.1 UNPACKING AND INSPECTION
Use care when unpacking your new RAY430 from the shipping carton to prevent damage to the
contents. It is also a good practice to save the carton and the interior packing material. The original
packing material should be used in the unlikely event that it becomes necessary in the future to return
the unit for service.
2.2 EQUIPMENT SUPPLIED
The following is a list of the standard equipment included with your RAY430 Loudhailer.
Equipment Name Part No.
RAY430 Loudhailer Unit M95997
Hailer Horn M95435
Microphone G263596-2
Microphone Mounting Bracket G263596-3
Mounting Yoke G263596-4
Bridge Card G263647-4
Instruction Manual G263647-5
2-1

2.2.1 Optional Accessories
Item # Description Part No.
1 Console Mounting Kit (Flush Mount) M95990
2 Console Mounting Kit (Trim Ring Style) M95995
3 Power Supply, 115/220 VAC to 1 2 VDC M59733
4 Sun Cover G263696- 1
5 Intercom Speaker M95998
6 Hailer Horn M95435
2.3 STORAGE
After all of the components have been unpacked and inspected, they should be replaced in their
shipping containers and stored in a dry place until they are to be installed. The storage area should be
dry, well-ventilated and not subjected to temperature extremes below -20°C or above +55 °C.
2-2

2.4 PLANNING THE INSTALLATION
When planning the location for your RAY430 to be installed, the following conditions should be
considered to insure dependable and trouble-free operation.
1) The mounting location should be easily accessible to allow easy operation of the front panel
and provide the best viewing angle of the display.
2) There should be adequate ventilation.
3) A sufficient space should be secured behind the unit to allow all cable connections to the rear
panel terminal strip.
4) The mounting place should be located as near to the power source as possible.
5) The selected location should be isolated away from devices that may cause offending noise or
interference, such as motors, steering cables and generators.
6) Generally speaking, the Loudhailer should be protected from prolonged direct exposure to
rain and salt spray. It is a good practice to protect this valuable equipment as much as pos-
sible.
The unit can be conveniently mounted on a chart table, bulkhead, overhead or any other desired
place. (Refer to Figure 2- 1 for typical locations and mounting configurations.)
(table top mount) (bulkhead mount) (overhead mount)
Figure 2-1 Examples of installation
2-3

Figure 2-2 Outline and Mounting Dimensions
2-4

2.4.1 Mounting Options
Flush-mounting your RAY430 can be performed using one of the methods shown below.
Console Mounting Kit (Trim Ring Style-M95995) Console Mounting Kit (M95990)
Figure 2-3
2.5 ELECTRICAL CONNECTION
Figure 2-4 RAY430 Rear Panel
CAUTION
DO NOT INSTALL THIS RADIO ON VESSELS WITH POSITIVE
GROUND BATTERY SYSTEMS.
2.5.1 DC Power Connections
The RAY430 is intended for use on vessels with 12 VDC power systems and can operate as long as
the DC supply is regulated between 10.8 and 16 VDC.
The input power connections are made at the terminal strip on the rear of the RAY430 unit at the
terminals labeled "13.6V" "+" and "–". See Figure 2-8 on page 2-9 for the exact locations.
2-5

The power leads should normally be routed to the ship’s DC power distribution panel on larger
boats. The RAY430 is fused at 10 amps so connection to a 10 amp or (maximum of) 15 amp circuit
breaker is recommended. On smaller vessels the power leads may be connected directly to the main
battery, isolation switch, or circuit breaker. For best noise isolation from other shipboard electronics
avoid grouping the loudhailer power connections with radar, radio, or echo sounder power leads
together on the same circuit breaker.
Although the RAY430’s power consumption is only 65 watts (maximum), if you find that the power
cable leads need to be extended more than 10 feet, the wire size of the leads should be in-creased
accordingly to minimize line losses. For runs of 20-35 feet #12 AWG is recommended, remember to
always solder all connections on all your power cord additions.
Observe proper polarity! The wire connected to the positive (+) terminal must be connected to the
positive point of the DC power source; The wire connected to the Negative (—) terminal of the
terminal strip must be connected to the negative point of the DC power source. If the power leads are
accidentally reversed, the 10 Amp fuse will blow. If this happens, recheck the polarity of the
connections with a voltmeter (VOM) and, if necessary, reverse the leads for proper connection. Then
replace the 10 amp fuse in the power cord.
2.5.2 Intercom Speaker
Up to four intercom station speakers (optional) can be connected to the intercom speaker terminals
labeled IC1-IC4 on the terminal block. The optional intercom speakers M95998 are 8 ohms and in-
dude “CALL” buttons. Stations 1, 2, 3 and 4, should be connected to the terminal block accordingly
so that they will correspond to the desired Intercom station selections.
Connect one of the speaker lines to terminal 2, the other line to the GND terminal (on the right side
of the terminal block). The “call” line should be connected to the terminal 1.
Figure 2-5
2-6

2.5.3 Hailer Horn(s)
The outside hailer horns should be mounted facing away from the display unit to prevent feedback
problems using the universal swivel mount provided. High gain audio amplifier circuits “hailers” are
susceptible to high frequency audio oscillations (a.k.a. feedback). It is highly recommended that be-
fore permanently mounting the hailing horn, that the HAIL feature is tested with the horn in the
desired location. This should be done to ensure optimum performance. Generally speaking the horn
should be mounted as far away as possible and facing away from the RAY430 base unit. It should be
pointed in the opposite direction of the RAY430 microphone as you are speaking into it.
Connection to the horn(s) should be made with No. 1 8 or larger, stranded, twisted pair copper wire.
The two-conductor cable chosen should be suitable for external all-weather use.
Electrical connections from the deck horn(s) are made on the rear panel terminal strip at either the
FWD or AFT terminal point, depending on the location of the speaker you are connecting.
For connection to FWD, connect the deck horn to terminals “FWD” 1 and 2. For connection to AFT,
connect the deck horn to terminals “AFT’ 1 and 2.
2.5.4 Connection of Burglar Alarm
By connecting an external alarm sensor using a normally open type of switch (not supplied) to the
ALM terminals, this unit can be used as a burglar alarm in the Fog ALM mode (burglar alarm).
When the sensor connected at terminals 1 and 2 (AUX) of this terminal block become shorted
(closed), the alarm function becomes activated and the yelp signal will sound at the maximum
volume through the forward deck hailer horn speaker.
Figure 2-6
2.5.5 Remote Microphone
An external microphone connection is located on the rear panel terminal strip. This may be used if
you desire to operate hailing functions from a secondary station.
2-7

Figure 2-7
2.5.6 Auxiliary Input
Your RAY430 has been designed to allow you to amplify the audio from your VHF radiotelephone
or any other external audio output (i.e. AM/FM radio, CD player) through your intercom or deck
speaker stations. This external audio input can be connected at the auxiliary input terminals 1 and 2.
2.5.7 Connection of an External Speaker
In situations where the main unit is distant from the operator and the noise level is very high, it may
be difficult to hear your RAY430 clearly. By connecting an external (8 ohms, 5 watts or more)
speaker, the sound level can be increased for improved listening capability. When an external
speaker is connected at the external speaker jack, the internal speaker is automatically disconnected.
The connector, a mini phone plug, for the external speaker is supplied with your RAY430 for your
convenience.
2-8

Figure 2-8 RAY430 Electrical Connections
2-9

2-10

SECTION 3
OPERATION
3.1 INTRODUCTION
While the operation of the RAY430 is easy and straight forward, the operator who is familiar with
the functions and understands the layout of the front panel controls will be able to obtain the best
performance from their equipment.
Following is a description of the front panel controls of the RAY430 loudhailer.
3.2 CONTROLS AND LCD DISPLAY
Refer to Figure 3-1 for familiarization with the following controls:
Figure 3-1 RAY430 Front Panel
3.2.1 Controls
1) On/Off & Dimmer Control Knob:
This control turns the RAY430 On and Off, and rotating the control clockwise
increases the backlighting level of the LCD display.
3-1

2) Hail Output Control:
Rotating this control clockwise will increase the volume going to the Hailer Horns or
Inter-com Speaker(s) and rotating this control counterclockwise will decrease the
volume.
3) Listen Control:
Rotating this control clockwise will increase the listening volume at the internal
speaker and rotating this control counterclockwise will decrease the volume.
4) Hail Key:
Pressing the [HAIL] key puts the RAY430 into the hailer mode and HAILER is
displayed on the LCD.
5) FOG (Foghorn) Key:
Pressing the [FOG] key sequentially selects one of the 9 different horn or automatic
fog signals for use.
6) AUX (Auxiliary) Key:
Audio signals connected to the AUX input from radiotelephone, tape player, etc. are
amplified and heard at the selected external speaker location(s).
7) IC (Intercom) Key:
Pressing this key puts the RAY430 into the Intercom mode.
8) IC 1/2 Key:
Selects between Intercom Station 1 or 2 for connection to the input/output circuitry in
the Intercom Mode. Pressing the [IC 1/2] key, selects IC- 1 , IC-2, in sequence,
alternately.
9) IC 3/4 Key:
Selects between Intercom Station 3 or 4 for connection to the input/output circuitry in
the Intercom Mode. Pressing the [IC 3/4] key selects IC-3, IC-4, in sequence,
alternately.
10) FWD (Forward) Key:
Selects the Hailer horn which is normally mounted on the forward part of the vessel
for use as a foghorn, hailer or public address system.
11) AFT (After) Key:
Selects the Hailer horn which is normally mounted at the rear of the vessel for use as
a fog-horn, hailer or public address system.
12) BOTH Key:
Selects both Hailer horns which are mounted on the forward and rear part of the
vessel for simultaneous use as foghorns, hailing or for public address.
3-2

13)ALL Key:
Connects the input/output circuitry to all speaker stations for use simultaneously
during fog-horn, hailer or public address operations.
14)Microphone PTT (Push-To-Talk) Switch
The PTT switch located on the side of the RAY430 microphone is used to activate the
microphone, etc.
3.2.2 LCD Display
The custom LCD display on the RAY430 is used to show the operation status of the loudhailer in
bright bold characters. The display is illuminated in a blue-green color with adjustable intensity for
best viewing in twilight or nighttime use. The lighting can also be turned off by use of the On/Off &
Dimmer control knob.
The Ray430 has 4 operating modes. The selected mode is indicated by the message on the left side of
the display. The modes messages are:
HAILER — for Hailing or public address mode
INTERCOM — for Intercom operation on up to 4 different stations
SEE TABLE — for Fog horn Signal mode. The RAY430 generates any one of 9 automatic or
manual fog horn signals.
AUX — for Auxiliary audio inputs.
Figure 3-2 LCD Display
3-3

When the FOG mode is selected, the message area will display the selected type of signal to
be emitted as follows:
TYPE
Auto/Manual PURPOSE
1. MANUAL Manual Use as horn signal for passing, etc.
2. UNDRWY Automatic Fog signal for Power Boat underway.
3. STOP Automatic Fog signal for vessel that is stationary.
(STOPPED)
4. SAIL Automatic Fog signal for sailboat, fishboat, towboat.
5. TOW Automatic Fog signal for vessels under tow.
6. ANCHOR Automatic Fog signal for any vessel at anchor.
7. AGROUND Automatic Fog signal for any vessel aground.
8. YELP Manual Yelp type siren for police, Fish & Game, US
Coast Guard.
9. ALARM Automatic Burglar alarm signal when activated.
The speaker station display normally indicates the location of the speakers selected for use with each
operating function. Located on the top right side of the display these messages use up to four
characters. The speaker stations are: FWD, AFT, BOTH, or ALL.
In the FOG mode, the speaker station message area will temporally indicate which FOG mode # has
been selected for use when the [FOG] key is pushed. One second later the normal speaker station
selection message will re-appear.
When the microphone push-to-talk [PTT] key is pressed in the Hail or Intercom modes, the message
“TALK” appears in the speaker station window, confirming that transmission of your voice is now
possible by speaking into the microphone.
Further information on the operating modes can be found in the sections that follow.
3-4
