RCA RS2302 - Neo-5 CD Shelf System User manual

EXPORTER
Thomson Inc.
P.O. Box 1976
Indianapolis, IN 46206 -1976
©2003 Thomson Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Marque(s) ® Déposée(s)
55699550 (EN/F/E)
www.rca.com
www.rca.com/LatinAmerica
Printed In China / Impreso en China
IMPORTADOR
Comercializadora Thomson de México, S.A. de C.V.
Miguel de Cervantes Saavedra 57
Col. Ampliación Granada
C.P. 11529 Mexico D.F.
Telefono: (55)25 81 53 20
RFC: CTM-980723-KS5
0151
RS2302 EN 4/2/03 3:41 PM Page 2

RS2302
It is important to read this instruction book prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.
usermanual
ON/
STANDBY
SOURCE TUNE/PRESET
DEMO/DIMMERVOLUME
EQ X-BASS
CLOCK
DISC
1
DISC
2
DISC
3
DISC
4
DISC
5
TIMER SLEEP SHUFFLE REPEAT INTRO CD INFO
BAND
PROG/SET ST/MONO RECORD
CD-R/ RW COMPATIBLE
5
DISC CHANGER
RS2302 EN 4/2/03 3:41 PM Page 3

EN
FCC Information
FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received, includ-
ing interference that may cause undesired operation.
In accordance with FCC requirements, changes or modifi-
cations not expressly approved by Thomson Inc. could
void the user’s authority to operate this product.
This device generates and uses radio frequency (RF)
energy, and if not installed and used properly, this equip-
ment may cause interference to radio and television
reception.
If this equipment does cause interference to radio or tel-
evision reception (which you can determine by unplug-
ging the unit), try to correct the interference by one or
more of the following measures:
• Re-orient the receiving antenna (that is, the antenna
for the radio or television that is "receiving" the interfer-
ence).
• Move the unit away from the equipment that is
receiving interference.
• Plug the unit into a different wall outlet so that the
unit and the equipment receiving interference are on
different branch circuits.
If these measures do not eliminate the interference,
please consult your dealer or an experienced radio/tele-
vision technician for additional suggestions. Also, the
Federal Communications Commission has prepared a
helpful booklet, "How To Identify and Resolve Radio TV
Interference Problems." This booklet is available from
the U.S. Government Printing Office, Washington, DC
20402. Please specify stock number 004-000-00345-4
when ordering copies.
This product complies with DHHS Rules 21 CFR
Subchapter J. Applicable at the date of manufacture.
For Your Safety
The AC power plug is polarized
(one blade is wider than the
other) and only fits into AC power
outlets one way. If the plug won’t
go into the outlet completely,
turn the plug over and try to
insert it the other way. If it still
won’t fit, contact a qualified electrician to change the
outlet, or use a different one. Do not attempt to bypass
this safety feature.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Technical specification
Product: Compact Audio System
Brand: RCA
Model: RS2302
Electrical Consumption:
Power Supply: 120V~ 60 Hz
Power consumption: 110 Watts
IMPORTER
Comercializadora Thomson de México, S.A. de C.V.
Miguel de Cervantes Saavedra 57
Col. Ampliación Granada
C.P. 11529 Mexico D.F.
Telefono: (55)25 81 53 20
RFC: CTM-980723-KS5
For Your Records
In the event that service should be required, you may
need both the model number and the serial number. In
the space below, record the date and place of purchase,
and the serial number:
Model No.
Remote Control No.
Date of Purchase
Place of Purchase
Serial No.
Service Information
This product should be serviced only by those specially
trained in appropriate servicing techniques. For instruc-
tions on how to obtain service, refer to the warranty
included in this Guide.
RECORD
Have a Blast- Just Not in Your
Eardrums
Make sure you turn down the volume
on the unit before you put on head-
phones. Increase the volume to the
desired level only after headphones
are in place.
RS2302 EN 4/2/03 3:41 PM Page 4

1
Safety Information
FCC Information
Safety Information
Getting Started . . . . . . .2
Unpacking the system . . . . . . . .2
Back View . . . . . . . . . . . . . . . . . .2
Using the FM and AM
Antennas . . . . . . . . . . . . . . . . . .2
Connecting the Speakers . . . . .2
Installation . . . . . . . . . . . . . . . . .2
General Controls . . . . . .3
Main Unit . . . . . . . . . . . . . . . . . .3
Remote Control . . . . . . . . . . . .4
Display . . . . . . . . . . . . . .5
Settings . . . . . . . . . . . . .6
Showing the Demonstration . .6
Display Clock / Timer . . . . . . . . .6
Setting the Clock . . . . . . . . . .6
Setting the Timer . . . . . . . . .6
Activating the Timer . . . . . . .6
Adjusting the Display
Brightness . . . . . . . . . . . . . . . . . .6
Sleep Mode . . . . . . . . . . . . . .6
Sound Features . . . . . . .7
Volume Control . . . . . . . . . . . . .7
X-Bass . . . . . . . . . . . . . . . . . . . . .7
Muting Audio . . . . . . . . . . . . . .7
Using Preset Equalizer Curves .7
CD Player . . . . . . . . . . . .7
Notes on CD-R/RW Disc . . . . . . .7
Loading Discs . . . . . . . . . . . . . . .7
Play and Pause Discs . . . . . . . . .7
Selecting a Disc . . . . . . . . . . . . .8
Searching Through a CD . . . . . .8
Shuffling the Play Order . . . . . .8
Sampling Tracks . . . . . . . . . . . . .8
Repeat . . . . . . . . . . . . . . . . . . . . .8
Setting Up a CD Program . . . . .8
Playing a Program List . . . . .8
Display Program List . . . . . . .8
Edit Program List . . . . . . . . . .8
Deleting Program List . . . . . .8
Radio . . . . . . . . . . . . . . .9
Selecting Tuner Band . . . . . . . .9
Tuning to a Station . . . . . . . . . .9
Using Presets . . . . . . . . . . . . . . .9
Auto Preset Programming . . .9
Manually Setting Presets . . . . .9
Suppressing Stereo Signal . . . .9
Tape Player . . . . . . . . .10
Selecting Tape Player . . . . . . .10
Playing a Tape . . . . . . . . . . . . .10
Tape Counter . . . . . . . . . . . . . .10
Recording . . . . . . . . . . . . . . . . .10
From Tuner . . . . . . . . . . . . .10
From CD . . . . . . . . . . . . . . . .10
Fron AUX . . . . . . . . . . . . . . .10
Troubleshooting Tips . .11
Maintenance . . . . . . . .12
Cleaning . . . . . . . . . . . . . . . . .12
CD Player . . . . . . . . . . . . . . . . .12
Tape Player . . . . . . . . . . . . . . . .12
Handling CDs . . . . . . . . . . . . . .12
Cleaning CDs . . . . . . . . . . . . . .12
CD Lens Care . . . . . . . . . . . . . .12
Important Information 13
Safety Precautions . . . . . . . . .13
Important Battery
Information . . . . . . . . . . . . . . .13
Headset Safety . . . . . . . . . . . . .13
Don’t Infringe . . . . . . . . . . . . .13
Technical Specification . . . . . .13
Limited Warranty
(U.S.) . . . . . . . . . . . . . .14
Limited Warranty
(Canada) . . . . . . . . . . .16
EN
WARNING:TO PREVENT FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT EXPOSETHIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
Table of Contents
RS2302 EN 4/2/03 3:41 PM Page 5

EN
Getting Started
Unpacking the system:
You should have the following:
•one main unit (with 2 main speakers);
• one remote control;
• one FM antenna;
• one AM loop antenna;
• one user’s guide;
• one safety leaflet.
• Owner and registration Card
Back View
1. FM Antenna Jack
2. AM Loop antenna connector.
3. Main Speaker Jacks
Using the FM and AM Antennas
Before you use your audio system, you’ll want to
make sure both the FM and AM antennas are posi-
tioned properly. Connect the FM antenna to the FM
connector on the back of the unit. Uncoil it, making
sure it is fully extended. (you may even want to tape
it to the wall behind the unit if possible. The higher
the better.)
You’ll also need to connect the AM antenna loop to
the back of the unit if you listen to AM stations.
Rotate the AM loop antenna for better reception.
Connecting the Speakers
Each speaker has a black (negative) and a red
(positive) jack. When connecting the speakers, match
the red wires to the red jacks and the black wires to
the black jacks.
Installation
To ensure sufficient ventilation, keep the spacings
shown below free from other surfaces:
4 inches
4 inches
Front View
4 inches
4 inches
2 inches
Side View
MAIN SPEAKERS 6Ω
FM
ANTENNA AM LOOP
RL
_
+
AC 120V/60Hz
GND
Release tab to lock wire in
the terminal.
NOTE: Make sure the insulation is completely removed from the
ends of the Antenna and speaker wires at all connection
points.
Antenna and Speaker Wire Connection
Push terminal tab down to
insert wire.
2
123
ON/STANDBY SOURCE TUNE/PRESET
DEMO/DIMMERVOLUME
EQ X-BASS
CLOCK
DISC1DISC 2DISC 3DISC 4DISC 5
TIMER SLEEP SHUFFLE REPEAT INTRO CD INFO
BAND
PROG/SET ST/MONO RECORD
CD-R/ RW COMPATIBLE
5DISC CHANGER
RS2302 EN 4/2/03 3:41 PM Page 6

Main Unit
Front Panel
ON/STANDBY —Turns power on or off (STANDBY
mode).
SOURCE - Selects CD player / tuner / tape player/ external
source.
VOLUME - Adjusts volume.
EQ - Selects among different EQ options.
X-BASS - Turns X-Bass on/off.
DEMO/DIMMER - Turns the feature demonstration on or
off; adjusts display contrasts.
TUNE/PRESET - Stops CD track and tape operations,
selects tune or preset mode.
PLAY/PAUSE - Plays or pauses CD and tape opera-
tions.
SKIP FORWARD - In CD mode - Goes to the next CD
track; selects the next program location.
In Tuner mode - Tunes up radio frequency; selects the
next preset station.
In Tape mode - Fast forwards tape.
In Clock or Timer mode - Increases hour and minute digit.
SKIP BACKWARD - In CD mode - Goes to the
previous CD track; selects the previous program location.
In Tuner mode - Tunes down radio frequency; selects the
previous preset station.
In Tape mode - Rewinds tape.
In Clock or Timer mode - Decreases hour and minute
digit.
CLOCK - Enters clock setting mode; shows clock time.
TIMER - Enters timer setting mode; Turns on/ off timer.
SLEEP - Selects sleep duration.
SHUFFLE - Selects random playback in CD mode.
REPEAT - Selects among repeat options in CD mode.
INTRO - Selects intro playback in CD mode.
CD INFO/BAND - In CD mode, Selects display options to
show track elapse time, track remain time or disc remain
time. In Tuner mode - selects radio band.
PROG/SET - Enters program mode for CD and Tuner;
applies new settings for Clock and Timer mode.
ST/MONO - Selects stereo and mono sound in tuner
mode.
RECORD - Starts tape recording.
DISC1 / DISC2 / DISC3 /DISC 4 / DISC 5 - Direct access
to the corresponding disc tray for playback.
OPEN/CLOSE —Opens and closes disc compartment.
PHONES —Jack for connecting headphones.
AUX L/R - Jack for auxiliary connection.
Top Panel
OPEN/CLOSE —Press down on the door to open and
close cassette deck door.
3
General Controls
EN
PHONES AUXLR
ON/STANDBY SOURCE TUNE/PRESET
DEMO/DIMMERVOLUME
EQ X-BASS
CLOCK
DISC 1DISC 2DISC 3DISC 4DISC 5
TIMER SLEEP SHUFFLE REPEAT INTRO CD INFO
BAND
PROG/SET ST/MONO RECORD
CD-R / RW COMPATIBLE
5DISC CHANGER
F
U
L
L
L
O
G
I
C
C
A
S
S
E
T
T
E
D
E
C
K
RS2302 EN 4/2/03 3:41 PM Page 7

Remote Control
ON/STANDBY - Turns power on or off from standby
mode.
EQ - Selects equalizer presets.
X-BASS - Turns on or off Bass Boost.
OPEN/CLOSE - Opens and closes disc compartment.
CD - Selects CD player.
TUNER —Selects radio tuner.
TAPE —Selects tape player.
AUX - Selects external input.
REPEAT - Repeats a track, CD or all CDs in CD mode.
SHUFFLE - Turns on/off random listening in CD
mode.
FM ST • - Selects between stereo and mono sound in
FM tuner mode.
INTRO - Turns intro mode on or off to play the first 10
seconds of each track in CD mode.
MUTE - Mutes audio output.
SLEEP - Press to select the time interval in minutes
before the unit turns off.
PRESET / - Selects next/ previous preset sta-
tion. In Clock or TImer mode - Increases / decreases
the hour or minute digit.
VOL or - Decreases or Increases volume level.
STOP - In CD mode - Stops CD playback; In pro-
gram mode - Clears program; In Tape mode - Stops
tape playback.
PLAY/PAUSE -In CD mode - Plays and pauses
CD; In Tape mode - Plays and pauses tape playback.
SKIP BACKWARD -In CD mode - Goes to the
previous CD track and setting options; searches back-
ward through CD; In Tape mode - Rewinds tape; In
Tuner mode - Tunes down radio frequency.
SKIP FORWARD -In CD mode - Goes to the
next CD track and setting options; searches forward
through CD; In Tape mode - Fast forwards tape; In
Tuner mode - Tunes up radio frequency.
RECORD - Starts tape recording.
DISC SKIP - Skips to the next disc in CD mode.
Installing Batteries
The remote control must be inserted with 2 "AAA" or
"UM-4" or "R03" batteries prior to use. Follow the
steps below to ensure correct installation.
1. Remove the battery compartment door (located at
the back of the remote control) by sliding the com-
partment door in the direction of the arrow and then
lifting the door out and off the cabinet.
2. Before inserting the batteries, observe the polari-
ties (that is, + and -) of the battery, then relate the
polarities to the engraved diagram inside the battery
compartment. Now insert the batteries.
3. After installation of the batteries, replace the bat-
tery compartment door in place by sliding it in the
opposite direction of the arrow (the reverse of step
1).
4
General Controls
EN
VOL
RECORD DISC SKIP
CD
TUNER
TAPE
AUX
REPEAT
FM ST
INTRO
EQ
X-BASS
OPEN/CLOSE
SLEEP
PRESET
ON STANDBY
RS2302 EN 4/2/03 3:41 PM Page 8

5
Display
DISC 1,2,3,4,5 - The corresponding disc icon lights to
show which disc compartment is loaded. The current
playing disc will flash.
TAPE / CD / AUX / TUNER - indicates which mode the
unit is currently at.
INTRO - In CD mode, intro is activated so the first 10
seconds of each track will be played.
PROG - In program mode.
REPEAT 1 / REPEAT 1 DISC / REPEAT ALL DISC / ALL
DISC - In CD mode, indicates the repeat option that is
activated.
REPEAT 1 - Repeat track.
REPEAT 1 DISC - Repeat current disc.
REPEAT ALL DISC - Repeat all disc.
ALL DISC - Play all discs once.
STEREO - In FM tuner mode, indicates stereo sound is
selected.
- Timer is activated.
REC - In tape mode, indicates tape is recording.
SLEEP - Sleep is activated.
- Random playback is activated in CD mode.
EQ - Preset equalizer is selected.
X-BASS - X bass is activated.
MHz / kHz - Radio frequency unit in tuner mode.
AUTO - Auto reverse is activated in tape mode.
AM / PM - AM/PM time indicator.
EN
RS2302 EN 4/2/03 3:41 PM Page 9

6
EN
Settings
Showing the Demonstration
Press DIMMER/DEMO to turn on/off demonstration
mode. The demonstration scrolls through all display
operations.
Display Clock / Timer
Setting the Clock
1. Press and hold CLOCK to enter clock setting
mode. The hour flashes on the display.
2. Press SKIP BACKWARD or SKIP FORWARD
on the main unit or PRESET or PRESET
on the remote control to set the hour .
Press CLOCK to shift to minute digits.
3. Press SKIP BACKWARD or SKIP FORWARD
on the main unit or PRESET or PRESET
on the remote control to set the minute .
4. Press PROG/SET to save settings.
Press STOP to quit settings.
Note:
• When system is ON, you can press CLOCK to
display the current time for about 2 seconds.
Setting the Timer
1. Press and hold TIMER until the ON and clock
hour flashes on the display ( ON - timer on time ).
2. For setting time, press SKIP BACKWARD or
SKIP FORWARD on the main unit or PRESET
or PRESET on the remote control to set
the hour and then press TIMER to shift to minute
digits.
3. Press SKIP BACKWARD or SKIP FORWARD
on the main unit or PRESET or PRESET
on the remote control to set the minute.
4. Press TIMER to change to OF (timer off time)
with clock time flashing. Repeat steps 2 & 3 for
timer off time setting.
5. Press TIMER to select source. Press SKIP
BACKWARD or SKIP FORWARD on the
main unit or PRESET or PRESET on the
remote control to select between CD / TUNER /
TAPE .
6. Press TIMER to set volume. Rotate the VOLUME
control to select desired volume level.
7. Press PROG/SET to save settings.
Press STOP to quit setting.
The timer is automatically activated once timer
setting is saved.
Activating the Timer
Press and release TIMER to turn on/off the alarm.
The timer is active when the clock icon is lit.
Adjusting the Display Brightness
1. Press and hold DEMO/DIMMER for more than 2
seconds.
2. While the dimmer level is displayed, press and
release DEMO/DIMMER repeatedly to select the
desired level (DIMM 1 - 3).
Sleep Mode
You can select the time interval in minutes before
the unit turn off automatically. Press SLEEP to select
among OFF, 120, 90, 60, 45, 30, 15 and 5 minutes.
RS2302 EN 4/2/03 3:41 PM Page 10

7
EN
Sound Features
Volume Control
Turn VOLUME on the main unit or press VOL or
on the remote control to adjust volume level.
X-Bass
Press X-BASS to turn on/off boosting the bass
frequency.
Muting Audio
Press MUTE on the remote to cut the sound.
(Remote Only)
Using Preset Equalizer Curves
Press EQ to toggle among FLAT, ROCK, POP, JAZZ,
CLASS and CUSTOM. The display shows the selection
briefly.
Creating a Custom Curve
1. Press EQ to select CUSTOM mode.
2. While CUSTOM is displayed, press SKIP
BACKWARD or SKIP FORWARD on the
main unit or PRESET or PRESET on the
remote control to cycle among displayed bass-
and treble - range levels.
3. While BAS or TRE is displayed, adjust VOLUME
to set the associated gain between -10 - +10.
CD Player
Loading Discs
1. Press SOURCE repeatedly on the main unit or CD
on the remote control to select CD mode.
2. Press OPEN/CLOSE on the front panel of the
main unit or on the remote control to open disc
compartment.
3. Insert up to 5 discs with label face up.
4. Press OPEN/CLOSE on the front panel of the
main unit or on the remote control again to close
disc compartment. The disc that is loaded and
ready to play is the icon that is flashing on the
display.
Play and Pause Discs
• Press PLAY/PAUSE in stop mode to begin
playback.
•PressPLAY/PAUSE during playback to to
pause disc.Press again to resume.
Play and load simultaneously by:
1. Press OPEN/CLOSE on the front panel of the
main unit or on the remote control to open the
tray while a CD is playing.
2. Load/change discs for available trays.
3. Press OPEN/CLOSE on the front panel of the
main unit or on the remote control to close the
tray.
This unit is compatible with
CD-RW/ CD-R discs for play-
back.
Notes on CD-R/RW Disc:
• Do not affix any type of labels to either side
(recordable or labeled side) of a CD-R/RW disc
as this may result in the unit malfunctioning.
• To avoid damages to the CD-R/RW disc, do not
open the disc compartment door while the
disc is being read.
• Do not load an unrecorded CD-R/RW disc into
the unit. This may take a longer time to read
the disc.
• Playback capability for CD-RW discs may
vary due to variations in the quality of
the CD-RW disc and the recorder used to
create the disc.
CD-R / RW
Note: Be sure to remove all discs from the disc
compartment before moving or transporting the
unit!
RS2302 EN 4/2/03 3:41 PM Page 11

8
EN
CD Player
Selecting a Disc
•Press DISC 1, DISC 2, DISC 3, DISC 4, or DISC 5
on the main unit to directly access the
corresponding disc.
•Press DISC SKIP on the remote control to skip
discs.
Searching Through a CD
• Press SKIP BACKWARD / SKIP FORWARD
on the main unit or or on the
remote control to skip to the previous or next
track.
•Press and hold SKIP BACKWARD / SKIP
FORWARD on the main unit or or
on the remote control to search through a CD
while it is playing.
Shuffling the Play Order
Press SHUFFLE to turn on/off the playing of
tracks in random order.
Sampling Tracks
Press INTRO to play the first 10 seconds of each track
on the current disc, all discs in the tray, or turn INTRO
mode off.
Repeat
Press REPEAT to repeat the current track (REPEAT 1),
current disc (REPEAT 1 DISC) , all discs (REPEAT ALL
DISC), or turn repeat mode off (ALL DISC).
Note: You may also press REPEAT to select 1 disc
or all discs before activating SHUFFLE function.
Setting Up a CD Program
You can program the CD player to play up to any 32
tracks on the CDs in the tray.
1. While the CD player is stopped, press PROG/SET
to enter program mode. The system displays the
next available program number 00 PR:01.
2. Press the corresponding disc number on the main
unit or DISC SKIP on the remote control to select
disc.
3. Press SKIP BACKWARD / SKIP FORWARD
on the main unit or TUNING or on
the remote control to select track to enter into
memory.
4. Press PROG/SET to save your settings.
5. Repeat steps 2 to 4 to store more tracks into
program memory.
Playing a Program List
While in PROGRAM mode , press PLAY/PAUSE .
If you are not currently in program mode, press
PROG/SET to enter program mode before pressing
PLAY/PAUSE .
Display Program List
1. While the CD player is stopped, press PROG/SET
to enter PROGRAM mode.
2. Press PROG/SET repeatedly to view each track
assignment in the program list.
Edit Program List
1. Follow “Display Program List” steps until the
location to be edited is displayed.
2. Repeat steps 2 to 4 under “Setting Up a CD
Program “ to edit the track to store into memory.
Deleting Program List
While in PROGRAM mode, press and hold STOP for 3
seconds. They system displays the message CLEAR.
Tips:
• You can create a program of up to 32 tracks.
• Press CD INFO/BAND repeatedly to view
elapsed track time, track number, track remain
time and disc remain time.
Caution: Do not push to force closing of the tray
during CD playback or tray opening.
RS2302 EN 4/2/03 3:41 PM Page 12

9
EN
Radio
Selecting Tuner Band
1. Press SOURCE on the main unit or TUNER on the
remote control to enter Tuner mode.
2. Press CD INFO/BAND to select between AM or
FM Radio band.
Tip: Your audio system has 32 preset stations.
Tuning to a Station
Press SKIP BACKWARD / SKIP FORWARD
on the main unit or TUNING or on the
remote control to select frequency.
Using Presets
The tuner can be in either TUNE or PRESET mode.
When in preset mode,
• Press TUNE/PRESET on the main system or
PRESET or on the remote control to
access the previous or next preset station.
• The display first shows the preset program
number and after a few seconds, the preset
program and frequency will be displayed.
Auto Preset Programming
Press and hold CD INFO/BAND button for 2 seconds
to scan stations in FM and AM band. The stations will
then be stored as preset channels. A maximum of 32
stations can be stored. Beware of your preset chan-
nels being erased accidentally because the scanning
and storing process is automatic upon pressing the
button. You can stop the automatic scan by pressing
any button, but the erased stations cannot be recov-
ered.
Manually Setting Presets
1. Press SKIP BACKWARD / SKIP
FORWARD to access the desired
frequency.
2. Press the PROG/SET button once.
3. The most recently accessed program location will
flash on the display.
4. If a different program location is preferred, press
SKIP BACKWARD or SKIP FORWARD
on the main unit or PRESET or on the
remote control to move to the desired preset
number (1-32).
5. Press PROG/SET to store the selected frequency
at that preset.
Suppressing Stereo Signal
Press ST/MONO on the main unit or FM ST. on the
remote control to toggle between FM mono and
stereo for stereo FM stations.
PR 01 FM
07 87.90
PROG
MHz
RS2302 EN 4/2/03 3:41 PM Page 13

10
EN
Tape Player
Selecting Tape Player
Press SOURCE on the main unit or TAPE on the
remote control to select tape mode.
Playing a Tape
1. In tape mode, press on the cassette door to open
it.
2. Insert a tape into the door and push the door
closed.
3. Press SKIP BACKWARD / SKIP FORWARD
on the main unit or TUNING or on the
remote control to position the tape to the
desired starting position.
4. Press PLAY to begin playback.
5. Press PAUSE to pause playback.
Tape Counter
You can keep track of tape position with the tape
counter. Press PROG/SET to reset.
Recording
From Tuner
1. Insert a tape into deck.
2. Press SOURCE repeatedly on the main unit or
TUNER on the remote control to select
Tuner .
3. Press BAND to access the desired radio band.
4.. Press SKIP BACKWARD or SKIP
FORWARD on the main unit or TUNING
or the remote control to tune to the station
to be recorded.
5. Press RECORD to enter Record standby. Press
again to begin recording.
6. press STOP to end recording.
From CD
1. Insert a tape into deck .
2. Press SOURCE repeatedly on the main unit to
select CD then press DISC SKIP or DISC1 / DISC2
/ DISC 3 / DISC 4 /DISC 5 to select the disc to be
recorded.
3. Press SKIP BACKWARD or SKIP
FORWARD on the main unit or TUNING
or on the remote control to select the track
to be recorded.
or
Press PROG/SET to enter program mode.
4. Press RECORD to enter Record standby. Press
again to begin recording.
5. press STOP to end recording.
From AUX
1. Insert a tape into tape deck.
2. Check that the auxiliary device has been
connected correctly to the AUX connector on the
front of the system.
3. Start playback on the auxiliary device.
4. Press RECORD to enter Record standby. Press
again to begin recording.
5. Press STOP to end recording.
F
U
L
L
L
O
G
I
C
C
A
S
S
E
T
T
E
D
E
C
K
RS2302 EN 4/2/03 3:41 PM Page 14

11
EN
Troubleshooting Tips
Solution
• Check power cord for a secure
connection.
• Unplug the unit for a moment, and
then plug into power source again.
• Check the outlet by plugging in
another device.
• Increase the volume setting.
• Check connection to speakers.
• Check that you have selected the
appropriate function: CD, TAPE, Tuner.
• Make sure mute is off.
• Make sure headphones are not
plugged in.
• Check antenna connection.
• Move antenna.
• Turn off nearby electrical appliances,
such as hair dryer, vacuum cleaner,
microwave, fluorescent lights.
• Check that CD is in the tray.
• Check that CD label is facing up.
• Check that PAUSE mode is not on.
• Check that CD function is selected.
• Use CD lens cleaner.
• Clean the disc.
• try another disc.
• Clean the disc.
• Check disc for warping, scratches, or
other damage.
• Check if something is causing the
system to vibrate. If so, move the
system.
• Make sure the speakers are at least 3
feet away or on a different surface
from the main unit.
Problem
System will
not turn on
No sound
Poor radio
reception
CD does not
play
CD sound
skips
Problem
CD button
will not
respond, or
does not
change
discs when
you press
DISC SKIP
Distorted or
noisy tape
recordings
Remote
control
does not
work
“ERROR”
message
Solution
• Switch to another function (TAPE,
Tuner) and then back to CD.
• Unplug the unit for a moment and
then plug it back into the power
source.
• Inspect the tape head, clean it if
necessary.
• Check that the batteries are properly
installed.
• Replace weak batteries.
• Check the system is plugged into
power source.
• Point the remote directly at the
system’s front panel.
• Move closer to the system.
• Remove any obstacles between the
remote and the system.
• Unplug the unit
• See if there is anything obstructing
the CD door or preventing it from
closing.
RS2302 EN 4/2/03 3:41 PM Page 15

12
EN
Maintenance
Disconnect the audio system from the power source
before performing any maintenance.
Cleaning
Clean the exterior of the system using a soft dust
cloth.
CD Player
CAUTION! This system operates with a laser. It must
be opened by only a qualified technician.
Tape Player
To prevent deterioration of sound quality, periodical-
ly open the door of each deck and clean the magnetic
heads, pinch roller, and capstan with a cotton bud
dipped in alcohol. Also, demagnetize the head by
playing a demagnetizing cassette (available through
an audio equipment store).
To protect recordings on
one or both sides of a tape,
remove the corresponding
tab. If you later want to
record on the tape, affix a
piece of adhesive tape over the hole.
Quit Slacking - A little bit of slack
in your tapes can cause scratches
on the tape, or worse yet, the
tape could break. If you notice
some slack in the tape, use a
pencil to tighten it up before
you insert it.
Handling CDs
• Do not touch the signal surfaces. Hold CDs by the
edges, or by one edge and the hole. Do not affix
labels or adhesive tapes to the label surfaces. Do not
scratch or damage the label. CDs rotate at high
speeds inside the player. Do not use damaged
(cracked or warped) CDs
Cleaning CDs
• Dirty CDs can cause poor sound quality. Always
keep CDs clean by wiping them gently with a soft
cloth from the inner edge toward the outer perime-
ter.
• If a CD becomes dirty, wet a soft cloth in water,
wring it out well, wipe the dirt away gently, and
then remove any water drops with a dry cloth.
• Do not use record cleaning sprays or antistatic
agents on CDs. Also, never clean CDs with benzene,
thinner, or other volatile solvents which may cause
damage to disc surface
CD Lens Care
When your CD lens gets dirty it can also cause the
system to output poor sound quality. To clean the
lens you will need to purchase a CD lens cleaner
which can maintain the output sound quality of
your system. For instructions on cleaning the CD
lens, refer to the ones accompanying the lens
cleaner.
A
Side A Protection
B
Side B Protection
A
RS2302 EN 4/2/03 3:41 PM Page 16

13
EN
Safety Precautions
• Never open the cabinet under any circumstances.
Any repairs or internal adjustments should be made
only by a trained technician.
• Never operate this product with the cabinet
removed.
•Do not use your System immediately after transport-
ing it from a cold place to a warm place, as condensa-
tion may cause the system to malfunction.
• Keep your unit away from humid areas and abnor-
mally hot places.
• Do not touch the player with wet hands. If any liq-
uid enters the player cabinet, take the player to a
trained technician for inspection.
• This compact disc player uses a laser to read the
music on the disc. The laser mechanism corresponds
to the cartridge and stylus of a record player.
Although this product incorporates a laser pick-up
lens, it is completely safe when operated according to
directions.
• Discs rotate at high speed inside the player. Do not
use damaged, warped, or cracked discs.
• Do not touch the pick-up lens which is located
inside the disc compartment. To keep dust from col-
lecting on the pick-up lens, do not leave the compart-
ment door open for an extended period of time. If
the lens becomes dirty, clean it with a soft brush, or
use an air blower brush designed for camera lenses.
• The apparatus shall not be exposed to dripping and
splashing.
Important Battery Information
• Remove the batteries to avoid leakage if you do not
use your remote control for more than one month.
• Discard leaky batteries immediately as leaking bat-
teries may cause skin burns or other personal injuries.
Dispose of batteries in the proper manner, according
to provincial and local regulations.
• Any battery may leak electrolyte under the follow-
ing circumstances:
- if mixed with a different battery type,
- if inserted incorrectly,
- if all batteries are not replaced at the same time,
- if disposed of in fire, or
- if an attempt is made to charge a battery not
intended to be recharged.
Headset Safety
• Do not play your headset at high volume.
Hearing experts warn against extended high-vol-
ume play.
• If you experience ringing in your ears, reduce vol-
ume or discontinue use.
• You should use with extreme caution or temporar-
ily discontinue use in potentially hazardous situa-
tions.
Even if your headset is an open-air designed to let
you to hear outside sounds, do not turn up the vol-
ume so high that you are unable to hear what is
around you.
Don’t Infringe
This product should only be used for the purposes
for which it is sold, that is, entertainment, violating
no copyright law. Any attempts to use this product
for unintended purposes are unlawful and
therefore not condoned by Thomson.
Technical Specification
Power supply: 120V~60Hz
Dimensions ( H x W x D inches):
Unit size - 10.4 x 7.8 x 12
Main Speaker - 13.2 x 9.5 x 8.7
Tape deck: Response curve: 125Hz-8kHz (-5dB)
CD player: Response curve (+/- 2dB): 60Hz to 15 kHz
Rating Plate: Look for it at the back of the set.
The descriptions and characteristics given in this document are given
as a general indication and not as a guarantee. In order to provide
the highest quality product possible, we reserve the right to make any
improvement or modification without prior notice. The English ver-
sion serves as the final reference on all products and operational
details should any discrepancies arise in other languages.
Important Information
RS2302 EN 4/2/03 3:41 PM Page 17

14
EN
Limited Warranty (U.S.)
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year from date of purchase for labor and parts
• Warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental
firm, whichever comes first.
What we will do:
• Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
• Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts
required to repair your unit.
How you get service:
• Take your unit to any Authorized RCA Audio Service Center. To identify your nearest Authorized RCA Audio
Service Center, ask your dealer, look in the Yellow Pages, or call 1-800-336-1900.
• Show the Authorized Service Center Representative your evidence of purchase date or first rental.
• Pick up your unit when repairs are completed.
• Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within
the warranty period must be presented to obtain warranty service. For rental firms, proof of first rental is also
required.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your dealer.)
• Installation and related adjustments.
• Signal reception problems not caused by your unit.
• Damage from misuse or neglect.
• Cleaning of audio heads.
• Batteries.
• A unit that has been modified or incorporated into other products or is used for institutional or other com-
mercial purposes.
• A unit purchased or serviced outside the U.S.A.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your product. It will make it easier to
contact you should it ever be necessary. The return of the card is not required for warranty coverage.
RS2302 EN 4/2/03 3:41 PM Page 18

15
EN
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMA-
TION GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY
WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY
ARE GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How State Law relates to warranty:
• Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other rights that vary from state to state.
If you purchased your unit outside the United States:
• This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not covered by this war-
ranty. Costs of such service calls are the sole responsibility of the purchaser.
Limited Warranty (U.S.)
RS2302 EN 4/2/03 3:41 PM Page 19

16
EN
Limited Warranty (Canada)
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year from date of purchase for labor and parts
• The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental
firm, whichever comes first.
What we will do:
• Pay any Authorized RCA Audio Service Center the labor charges to repair your unit.
• Pay any Authorized RCA Audio Service Center for the new or, at our option, refurbished replacement parts
required to repair your unit.
How you get service:
• Take your unit to any Authorized RCA Audio Service Center. To identify your nearest Authorized RCA Audio
Service Center, ask your dealer, look in the Yellow Pages, or call 1-800-336-1900.
• Show the Authorized Service Center Representative your evidence of purchase date or first rental.
• Pick up your unit when repairs are completed.
• Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within
the warranty period must be presented to obtain warranty service. For rental firms, proof of first rental is also
required.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your dealer.)
• Installation and related adjustments.
• Signal reception problems not caused by your unit.
• Damage from misuse or neglect.
• Cleaning of audio heads.
• Batteries.
• A unit that has been modified or incorporated into other products or is used for institutional or other com-
mercial purposes.
• A unit purchased or serviced outside Canada.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your product. It will make it easier to
contact you should it ever be necessary. The return of the card is not required for warranty coverage.
RS2302 EN 4/2/03 3:41 PM Page 20

17
EN
Limited Warranty (Canada)
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO VERBAL
OR WRITTEN INFORMATION GIVEN BY THOMSON MULTIMEDIA LTD., ITS AGENTS OR EMPLOYEES SHALL
CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. THOMSON MULTIMEDIA LTD. SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE PROVINCIAL LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET
FORTH ABOVE.
How Provincial Laws relates to warranty:
• This warranty gives you specific legal rights which are in addition to statutory warranties that may vary from
Province to Province.
If you purchased your unit outside Canada:
• This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not covered by this war-
ranty. Costs of such service calls are the sole responsibility of the purchaser.
RS2302 EN 4/2/03 3:41 PM Page 21
