RCT LEVELview.BASIC.LPG User manual

RCT. Simplify monitoring.
Remote Control Technology
LEVELview.BASIC.LPG
Radio transmitter unit (868 MHz)
for ll level monitoring of liquid gas tanks
 Contactlesslllevelmeasurementusing
Halleffectsensors(magneticeld)
Operating Instructions

www.rct-monitor.com
3
RCT. Simplify monitoring.
Welcome
ARTICLE INFORMATION
RCT Article-No. 1000079
Name LEVELview.BASIC.LPG
Included • Transmitter
• External antenna with
magnetic base
• Instruction Manual
•
Documentation of conformity
ACCESSORIES
Depending
on selection
Hall effect sensor
1000516 (Standard) External antenna with
magnetic base 1,2 m
1000528 Standard battery
100112 1 Longlife battery
1000924 DATALOGGER
1000384 RF Receiver, internal antenna,
LCD display
LPG
Please read carefully
before use!
Welcome
ThankyoufordecidingforthisRCTqualityproduct-
andthetrustthatimplies.Agoodchoice,because
ourdedicatedteamatRCTdevelopsandproduces
smart,modularremotemonitoringsystemsfora
widerangeofapplications,MADEINGERMANY.
Ourpromise:WithRCT. Simplify monitoring. remote
monitoringhasbecomesmart,safe,fastandin
combinationwithstrongservice,verysimpleforour
customers.
Ifyouhaveanyquestionsaboutassembly,installa-
tionoroperationorwouldlikefurtherinformation
aboutourproducts,pleasecontactyourspecialist
dealerorcontactthemanufacturerRCTdirectly
(seeaddressonlastpage).
CONTENTS
Included Hardware 2
Welcome 3
Fill level measurement liquid gas 4
Step 1: Sensor and zero adjustment 5
Step 2: Installation of the sensor 6
Step 3: Activate transmitter unit 7
Step 4: Install transmitter unit 8
Step 5: Install antenna 9
Step 6: Putting radio receiver into operation 10

www.rct-monitor.com
5
RCT. Simplify monitoring.
Operation
Liquid gas ll level measurement
ThelevelmeasurementontheLPGtankiscarried
outpreciselyandcontactlessusingaHalleffect
sensor.Thetransmissionofthellinglevelsis
realizedwirelesslyviaradiotransmitteronthe
tank.Withinarangeof1.500mthetankcontentcan
bereadoffinpercentorlitersontheleveldisplay
(RFreceiver).
LEVELview.BASICisprotectedandapprovedfor
useinATEXZone1and0.Theunitmaybeinstalled
inthemanholechamberofundergroundtanks,
undertheprotectivehoodofabove-groundtanks
orfurtheroutsideinATEXZone1.
Caution! Opening the tank is not neces-
sarythankstothecontactlessmeasuring
methodandstrictlyforbiddentounau-
thorizedpersons!
Thesystemcanbeinstalledonthetankquicklyand
withoutcomplexwiring.
(Fi g. 1)
!
Step 1: Sensor and zero adjustment
Notethecurrentlllevelandremovetheexisting
dialbyremovingthetwoPhillipsscrews.
(Fig. 2)
Caution! Onlyremovethetwoscrewsof
thedial.Neverloosenthefourhexagonal
screwsontheangeforfasteningthe
oat!Thereisariskofgasleakageand
explosion!
PlacethenewRCTdialintheholderandcompare
thenewlllevelwiththeoldone.Adeviationofup
to 2 % is within the tolerance.
Iftherearedeviationsofaround15%betweenthe
originalandtheRCTdial,anadapterofthetype
SRG705isrequired.IftheRCTdialissignicantly
smaller,contactRCTandaskfortherightadapter.
Fig. 2+3 | Removing original dial and installing RCT sensor
Radio
868
MHz
Float in LPG Tank
Antenna
Battery
Transmitter
Hall sensor
Fig. 1 | Fill level measurement using a Hall eect sensor
!
Only remove these two screws!

1.
2.
3.
Activation
Startup phase
(Duration: approx. 3 minutes)
Normal operation mode
Battery
Transmitter
Receiver
www.rct-monitor.com
7
RCT. Simplify monitoring.
Step 2: Installing the sensor
Ifthell-leveldisplayedmatches,fastentheRCT
electronicdialwiththeenclosedscrews.
(Fig . 3)
Step 3: Activating the transmitter
Activatethetransmitterbypluggingitintothe
batterypack.
(Fig. 4a)
Thetransmitterstartsimmediatelyandautomat i-
callywiththemeasurementandleveltransmission.
Inthestartphase(Fig. 4b) it transmits at short
intervalsfortestingpurposes,after3minutesit
switches to normal operation (Fig. 4c).
Caution! Thepluggingandunpluggingof
thetransmitterandbatterypackduring
set-upandlaterbatterychangesshould
becarriedoutoutsideofATEXZone1.
Caution! Toforceanotherstartmessage,
separatethetransmitterandthebattery
pack.Thenwaitaround5minutes.
Changing the battery:Periodicalbatterychanges
canbecarriedoutwithoutwaitingtime.
Cyclical notications:Thedatatransferiscarried
outevery20minutes.Amessagecontainsthe
currentlllevelandthebatterylevel.
!
!
Operation
Fig. 4a | Connect transmitter with battery
Fig. 4b | Transmit, test signal at receiver location
and place the receiver
Fig. 4c | Transmitting and receiving
“Signal” in LCD
display ashes
Signal every
5 seconds
Signal every
20 minutes

www.rct-monitor.com
9
RCT. Simplify monitoring.
Step 4: Mounting the transmitter
Nowproceedwiththeinstallationofthetransmitter
andantenna.
Protect from water:Thetransmitterunitmustbe
installedinsothatitisprotectedfromwater.For
outdoorsystems,placetheunituprighttoprevent
waterfromenteringthebatterycontacts.
Mounting: Attachthetransmittertothetankorthe
wallofthemanholechamberusingthemagnets
integratedinthebatterypack(seearrowsbelow)
(Fig. 5),orwiththeoptionalbracket.
Caution! InExzone1,thecabletothe
sensormustbelaidcarefullytoavoid
damage.Makesurethatthecableisnot
kinkedorpinchedanddamagedwhenthe
manholecoverisclosed.
Thereshouldbeadistanceofatleast20cmbetween
thedeviceandthesignalgenerator.Otherwise
thereisariskthatthemagneticeldofthesensor
systemwillbeaffectedbythefasteningmagnets
andthemeasurementresultwillbedistorted.(Fig. 5)
!
Step 5: Mounting the antenna
Attachtheexternalantennatoametalsurface
usingthemagneticbase(Fig. 6).Asageneralrule,
thelargerthemetalsurface,thebetterthetrans-
mission power.
Inordertoachievegoodtransmissionpower,the
antennashouldbemountedvertically(upright).
Makesurethattheconnectionbetweentheantenna
baseandthemetalsurfaceisclean.
Inthecaseofabove-groundtanks,forexample,
attachtheexternaltransmissionantennadirectly
to the container.
Inthecaseofundergroundtanks,theantenna
shouldbeattachedoutsidethemanholechamber
e.g.attachedtothemanholecoverorsafely
embeddedintothegroundusingtheoptionaldrive-
overantenna.Insidethechamber,thesignalcanbe
signicantlyrestrictedbythemetalsurroundings,
thusreducingthetransmissionrange.
Operation
Richtig
fastening magnets
Fig. 5 | Attaching the transmitter
min. 20 cm
Fig. 6 | Attaching the antenna
Richtig
Transmitter
Signal
generator

www.rct-monitor.com
11
RCT. Simplify monitoring.
Fig. 8+9 | Indications on LCD display
Operation
Fig. 7 | LCD Display Receiver with power supply and wall bracket
mountingpositionofthereceiversothatareliable
receptionoftheradiosignalispermanentlyguar-
anteed.Duringtherst3minutesafteractivationof
thetransmitter(startphase),thesignalistransmitted
approx.every5seconds,theninnormaloperation
onlyevery20minutes.Usethe“startphase”totest
thereliablesignalreceptionatthemountingposition
ofthereceiverortomakefurtheradjustments.You
cantriggerthe“startphase”asoftenasyoulike
bydisconnectingthetransmitterfromthebattery,
waiting5minutesandactivateitagain. (Fig. 4, page 6)
Mounting: Mountthereceiverwiththeincluded
wallbracketusingsuitablemountingmaterial
(screws/plugsdependingonthesurface).
Warning symbols: TheredLEDnexttothedisplay,
warningtriangleandbatterysymbolwarnwhen
theminimumlllevelisbelow20percent,the
transmitterbatteryisemptyortheradioconnection
isinterrupted(seeinstructions).(Fig. 9)
Note:Furtherinformationcanbefoundinthede-
tailedoperatinginstructionsofthecorresponding
radioreceiver.
Step 6: Putting radio receiver into operation
Assoonasthetransmitterhasbeenactivated
(step3),itstartsmeasuringanddatatransmission.
Thecodedradiosignal(868MHz)canbereceived
byvariousradioreceivers(LCDdisplay,Interface
4-20mA,WiFi,Datalogger).Whendeliveredasa
set,thereceiverisprogrammedtoautomatically
receivethesignalofthesuppliedtransmitter.
Example: RF receiver LCD display (Fig. 7)
WithLCDdisplaythetanklevelcanbeeasilyread
inthelivingareaorofce.
Itisrecommendedthatthereceiverisrstputinto
operationnearthetransmitterfortesting.Insert
theplugofthepowercableintothesocketonthe
bottomsideofthedevice.Thenconnectthepower
supplyunittoasocket(230V).Thedeviceisim-
mediatelyreadyforuse.Whenthesignalofthe
transmitterisreceived,theword“Signal”ashes
inthedisplay(Fig. 8).Assoonasthetransmitter
hasnishedasuccessfulmeasurement,thetank
contentisdisplayedasapercentagevalue.The
levelcanbedisplayedeitherinpercentorliters.
Forfurtherinformationonsettingtheliterdisplay,
receivingotherradiotransmitters,solvingproblems
andresettingthedevice,pleaserefertotheradio
receivermanual.
Sending and receiving: Astableradioconnection
isessentialfortrouble-freeoperation.Selectthe
26 %
Signal
26 %
!

RCT. Simplify monitoring.
Remote Control Technology
Remote Control Technology GmbH
Plockeweg5
D-35080BadEndbach
T+49(0)27769214330
F+49(0)27769214331
[e-mail]
www.rct-monitor.com
Design: www.ArtFactory.de
Photos:RCT,AndyAlexander&Shutterstock
©RCTOct.2020|Subjecttomodication!
