Tait TB7200 User manual

TB7200 base station
Installation and
Operation Manual
MBA-00005-04
Issue 4
December 2004

2TB7200 InstallationandOperation Manual
© Tait Electronics Limited December 2004
Tait Contact Information
Tait Radio Communications http://www.taitworld.com
Corporate Head Office
New Zealand
Tait Electronics Ltd
P.O. Box 1645
Christchurch
New Zealand
E-mail: [e-mail]
We b s i t e : http://www.taitworld.com
Technical Support:
E-mail: [e-mail]
We b s i t e : http://support.taitworld.com
Tait North America
Regional Head Office - United States of
America
Tait North America Inc.
E-mail: [e-mail]
Canada
Tait North America Inc.
E-mail: [e-mail]
Latin America
Tait Latin America
E-mail: [e-mail]
Tait Europe
Regional Head Office - United Kingdom
Ta i t E u ro p e L t d
E-mail: [e-mail]
Tait North Asia
Regional Head Office - Hong Kong
Tait Mobile Radio (Hong Kong) Ltd
E-mail: [e-mail]
Beijing
Tait Mobile Radio (Hong Kong) Ltd
E-mail: [e-mail]
Tait South Asia
Regional Head Office - Singapore
Tait Electronics (Far East) Pte Ltd
E-mail: [e-mail]
Thailand
Tait Mobile Radio Ltd
E-mail: [e-mail]
Oceania
New Zealand
Tait Communications Ltd
E-mail: headof[email protected]z
Australia
Tait Electronics (Aust) Pty Ltd
E-mail: [email protected]
Note: For the addresses and phone numbers
of the above regional offices refer to the
TaitWorld website.

TB7200 Installation and Operation Manual 3
© Tait Electronics Limited December 2004
Contents
Preface
1 Description
2 Controls
3Configuration
4 Installation
5 Connection
6 Functional Description
7 Circuit Description

4TB7200 InstallationandOperation Manual
© Tait Electronics Limited December 2004
Preface
Scope of Manual
Welcome to the TB7200 base station Installation and Operation Manual.
This manual provides information on installing and operating the TB7200
hardware.
Enquiries and Comments
If you have any enquiries regarding this manual, or any comments,
suggestions and notifications of errors, please contact Technical Support
(refer to “Tait Contact Information” on page 2).
Updates of Manual and Equipment
In the interests of improving the performance, reliability or servicing of the
equipment, Tait Electronics Ltd reserves the right to update the equipment
or this manual or both without prior notice.
Copyright
All information contained in this manual is the property of Tait Electronics
Ltd. All rights are reserved. This manual may not, in whole or in part, be
copied, photocopied, reproduced, translated, stored, or reduced to any
electronic medium or machine-readable form, without prior written
permission from Tait Electronics Ltd. All trade names referenced are the
service mark, trademark or registered trademark of the respective
manufacturers.
Disclaimer
There are no warranties extended or granted by this manual. Tait
Electronics Ltd accepts no responsibility for damage arising from use of the
information contained in the manual or of the equipment and software it
describes. It is the responsibility of the user to ensure that use of such
information, equipment and software complies with the laws, rules and
regulations of the applicable jurisdictions.

TB7200 Installation and Operation Manual Installation 5
© Tait Electronics Limited December 2004
Installation
This chapter describes how toinstall the TB7200 base station in astandard
19 inch rack or cabinet. It also provides some general information on safety
precautions and site requirements. We recommend that you read the entire
chapter before beginning the installation.
1.1 Personal Safety
1.1.1 Explosive Environments
Warning!! Do not operate TB7200 base station equipment
near electrical blasting caps or in an explosive
atmosphere. Operating the equipment in these
environments is a definite safety hazard.
1.1.2 Proximity to RF Transmissions
Do not operate the transmitter when someone is standing within 90cm (3ft)
of the antenna. Do not operate the transmitter unless you have checked that
all RF connectors are secure.
1.2 Equipment Safety
1.2.1 ESD Precautions
Important This equipment contains devices which are susceptible to
damage from static charges. You must handle these devices
carefully and according to the procedures described in the
manufacturers’ data books.
We recommend you purchase an antistatic bench kit from a reputable
manufacturer and install and test it according to the manufacturer’s
instructions. Figure 1.1 shows a typical antistatic bench set-up.
You can obtain further information on antistatic precautions and the dangers
of electrostatic discharge (ESD) from standards such as ANSI/ESD
S20.20-1999 or BS EN 100015-4 1994.
