Red Valve Tideflex Series User manual

IMPORTANT
Please take a moment to review this manual. Before performing any maintenance on the valve be sure the pipeline has been depres-
surized. The improper installation or use of this product may result in personal injury, product failure, or reduced product life. Tideex®
can accept NO liability resulting from the improper use or installation of this product. If you have any questions or problems, please call
the customer service department at [phone]. We appreciate your comments. Thank you for choosing Tideex®.
The revolutionary design of the Series 37G Inline Check Valve provides
superior backow protection. This unique "duckbill" design eliminates
costly backow from oceans, rivers, and other waterbodies and piping
systems.
The Series 37G is available in a wide variety of elastomers and is
designed to meet your exact ow specications.
The cuff of the Series 37G Valve is constructed to have the same outside
diameter as the inside diameter of the mating pipe. This allows the valve
to be inserted into the pipe and held in place by means of an internal
expansion clamp. Tideex®recommends pinning all Series 37G
valves for added security and stability.
The 37G effectively has a zero face-to-face dimension because they
t completely inside of the pipe. No modication of piping is required
provided adequate pipe length exists.
• Simple Design
• Cost Effective
• No Hinges, Levers or Springs
• Minimal Routine Maintenance
Series 37G Inline Check Valve
Installation, Operation and Maintenance Manual
IOM RV09.02-5
February 2023
Red Valve • 750 Holiday Drive, Suite 400, Pittsburgh, PA 15220 • 412-279-0044 • [email protected] • RedValve.com
© 2023 Red Valve Company

INSTALLATION
1. Inspection of Valve
Check inside diameter of pipe section for rough or damaged
areas. Surface should be uniform and relatively smooth. Long
gouges or cracks may allow water to pass and should be lled
prior to installation. The exterior of the Series 37G should
have a rough texture resembling a cloth pattern. This will help
the valve grip the walls of the pipe.
2. Valve Orientation
The valve shall be installed with the bill in the vertical position.
Valves to 18" (nominal) are supplied with a single clamp. The
clamp turnbuckle should be oriented at top dead center.
Valves 24"—48" (nominal) are supplied with two clamps. The
turnbuckles should be oriented 180˚ apart. Valves 60"—72"
(nominal) are supplied with three clamps. Turnbuckles should
be oriented 120˚ apart.
3. Pipe Dimensions
Every Series 37G is designed and built to t into a specic
pipe inside diameter. Different pipe materials such as
concrete, HDPE, steel, and PVC have different. I.D.
dimensions for the same nominal pipe size. Do not attempt
to install a Series 37G into a pipeline for which it was not
intended.
4. Preparation
The Series 37G uses expanding clamp(s) to exert pressure
outwards on the walls of the valve to "wedge" it in place within
the pipe. The walls of the pipe should be clean and free of
debris prior to installation.
5. Securing
The valve should be inserted fully into the pipe so that no
part of the cuff or bill extends outside the pipe. Ensure that
the valve is not "slanted" at an angle, with the bill pointing
upwards or downwards. The valve centerline should be
parallel to the pipe centerline.
Tideex®recommends pinning the Series 37G on all
installations. See below.
Four pre-drilled holes are provided in each expansion clamp.
At least one clamp should be pinned. On exposed pipe, holes
can be drilled through the valve and pipe, and a bolt run
through secured with a nut. For buried pipe, silicon or similar
sealant should be used to seal bolts.
Flow
Flow
NEVER...
Install the Valve at
An Angle
NEVER...
Install the Valve
Backwards
NEVER...
Use Sharp Tools on
Rubber
NEVER...
Exceed Design Back Pres-
sure

INSTALLATION NOTES FOR
SERIES 37G
A. It is important that the Series 37G are installed level within
the pipe. An equal amount of space must exist above and
below the end of the bill. The Series 37G may "gap open" it
installed improperly.
B. The bill of the Series 37G must have room to expand
outwards, while bottom of the bill area rises. The area around
the bill must be kept free of debris to allow the bill to close in
order for the valve to seal properly.
C. The Series 37G effectively reduces the inside diameter of
the pipe in which it is installed, creating a restriction. It may
also create a "ledge" inside the pipe, causing standing water.
D. Back pressure in excess of the maximum line pressure
may invert the sleeve and cause valve failure.
E. Should the conditions that the Series 37G was designed for
change, (line pressure, back pressure, chemical compatibility)
the performance of the valve may suffer.
Nominal Pipe I.D./Valve Size* Maximum Bill Height Maximum Length Maximum Back
(A) (B) (C) Pressure (psi)
6" 5-7⁄8" 11" 75
8" 7-3⁄4" 12-1/4" 75
10" 9-3⁄4" 15-1/4" 65
12" 11-3⁄4" 18-1/4" 65
14" 13-1/2" 21-1/4" 50
16" 15-1/2" 22-3/4" 50
18" 17-1/2" 23-3/4" 25
20" 19-1/2" 31-3/4" 25
24" 22" 37" 25
30" 27" 40-1/2" 15
36" 34" 46-3/4" 15
42" 40" 49" 10
48" 45" 51-1/2" 10
60" 57" 63-7/8" 10
72" 69" 72-1/2" 10
*For pipe I.D.'s other than the nominal pipe I.D.'s shown, consult factory to verify 37G dimensions.
BA
C

MAINTENANCE
1. Inspection
Valves should occasionally be inspected for damage, wear,
and buildup of debris. The frequency of the inspections should
be determined by the severity of the service and the environ-
ment in which it operates.
The clamp should be checked for proper tension, and be
sure that the inside of the valve is free of debris. Soft marine
growth is normal on valves in submerged applications, and
because hard marine growth such as barnacles will not bond
well to the Tideex®they can be easily removed. Also insert
pins to ensure they are tight.
STORAGE
If your Series 37G is to be stored for a period of time prior
to installation, the following storage guidelines will help to
preserve the valve and assure a trouble-free installation.
1. Store in a clean, cool, dry location. Avoid exposure to
light, electric motors, dirt, or chemicals.
2. Store valve vertically on oor or pallet.
3. Store valve to prevent other items from
contacting check sleeve to prevent possible damage.
4. Store this manual with the valve, so that
is readily available at time of installation.
TROUBLESHOOTING GUIDE
SLEEVE INVERTED
• Excessive back pressure, water surge, or water hammer.
LEAKING AROUND PERIMETER OF VALVE
• Tighten Clamp
• Check for cracks and holes in surface of pipe
BACKFLOW
• Debris lodged inside bill
• Debris built up beneath bill
Cuff
Saddle
Bill
Red Valve • 750 Holiday Drive, Suite 400, Pittsburgh, PA 15220 • 412-279-0044 • [email protected] • RedValve.com
© 2023 Red Valve Company
