Redarc SBI12KIT User manual

12 V Dual Battery
Isolator & Wiring Kit
SBI12KIT

2 |
PRODUCT FUNCTION
The Smart Start Dual Battery Isolator and Wiring Kit (SBI12KIT)
comes with everything required to install your Smart Start Dual
Battery Isolator, including the Smart Start itself. Perfectly suited
to the Do-It-Yourself installer, the SBI12KIT requires no crimping
or soldering, its just plug and play. The SBI12KIT features
high quality MTA 60 Amp fuses and fuse holders with the
corresponding ring terminals already attached to the wires.
KIT CONTENTS
Part Description Quantity
1. SBI12 Battery Isolator 1
2. 200 mm (7.9") Battery Positive Cable (red) 2
3. 1800 mm (70.9") Battery Positive Cable (red) 2
4. 60 A Fuses 2
5. Fuse Holders (including mounting nuts) 2
6. Battery Terminals 2
7. Isolator Terminal Protectors 2
8. Battery Terminal Protector for Auxiliary Battery Positive Terminal 1
9. 750 mm (29.5") Auxiliary Battery Ground Cable (black) 1
1
9
8
5
3
2
4
7
6
WIRING INSTRUCTIONS
1. REMOVE Main Battery Earth.
2. Place fuses in fuse holders and attach the red cables as
shown in diagram 1.
3. Connect a short red cable to one of the supplied battery
terminals by stripping back the wire and inserting it into the
battery terminal (as shown in diagrams 2and 3). This terminal
will attach to your auxiliary battery positive (+) terminal.
123

| 3
4. Remove the start battery positive (+) terminal from your start
battery. Connect the other battery positive cable into the
existing battery terminal from your start battery. Reconnect
the existing battery terminal to your start battery positive (+)
terminal.
5. Insert the crimped ends of the battery positive cables into
the isolator terminal protectors provided as per diagrams 4,
5and 6.
4 56
6. Mount the SBI Unit (7)
Mount in a convenient location, as shown in diagram 7.
REDARC recommends connecting the SBI as close as
possible to the start battery.
NOTE: Nuts, bolts and mounting plate not provided.
Refer to the SBI manual for further mounting instructions.
7. Attach the Earth Wire (8)
Connect the SBI ground wire to the chassis earth (8). Ensure
a good connection is made and any paint has been removed
from the mounting location.
8
7
8. Connect the ground terminal of the
auxiliary battery to chassis earth, using
the auxiliary battery ground cable and
the other battery terminal provided as per
diagrams 9and 10.
910
9. Wire the SBI12 as shown in diagrams 11, 12 and 13. Ensure
that all connections are tight and that the provided spring
washers are used.
10.Reconnect Main Battery Earth.
11 12 13
