Redexim Verti-Top 1500-2 User manual

User Manual and
Parts Book of the
Verti-Top®
Model:
Serial number:
Translation of the original operating
instructions
ATTENTION:
IT IS OF THE UTMOST IMPORTANCE TO READ THIS USER MANUAL CAREFULLY
PRIOR TO USING THE VERTI-TOP
®
IN ORDER TO USE THE MACHINE SAFELY AND
TO OBTAIN THE BEST RESULTS.
0948 English 947.120.204

2
FOREWORD
Congratulations on your Verti-Top purchase! For safe and long-lasting operation of this
Verti-Top, it is necessary to read and to understand this user manual. It is impossible to
work safely with this machine without complete knowledge of its content.
The Verti-Top is not a machine that works independently. It is the user’s responsibility to use
the correct tractor. The user must also check the tractor/Verti-Top combination on safety
aspects such as noise level, user instructions and risk analysis.
The following pages deal initially with the general safety instructions. Every user should
know these safety instructions and apply them. At the end of this page, a registration card is
inserted. This registration card should be returned to enable us to deal with potential future
claims.
This user manual lists many instructions that are numbered in sequence. You should follow
this sequence. A is an indication of a safety instruction. A means a tip and/or note.
All information and technical specifications provided at the moment that this document is
published are the most recent ones. Design specifications may be changed without prior
notice.
This document is a translation of the original operating instructions.
Upon request, the original operating instructions are available in Dutch.
WARRANTY CONDITIONS
WITH DELIVERY THIS VERTI-TOP IS GUARANTEED AGAINST MATERIAL DEFECTS.
THIS WARRANTY IS VALID FOR A PERIOD OF 12 MONTHS FROM THE PURCHASE
DATE. VERTI-TOP WARRANTIES ARE SUBJECT TO THE ‘GENERAL CONDITIONS FOR
SUPPLY OF PLANT AND MACHINERY FOR EXPORT, NUMBER 188’ THAT ARE
PUBLISHED UNDER THE AUSPICES OF THE UNITED NATIONS ECONOMIC
COMMISSION FOR EUROPE.
REGISTRATION CARD
For your own information, fill in the table below:
Serial number machine
Dealer name
Date of purchase
Remarks

3
! SAFETY INSTRUCTIONS !
Figure 1
The Verti-Top is designed for safe use. This
can only be achieved if you completely follow
the safety instructions described in this
manual.
Read and understand (Figure 1) the manual
before you start using the Verti-Top.
If the machine is not used as described in this
manual, this can result in injuries and/or
damage to the Verti-Top.
(1) The user must be an expert in using the machine. The machine
should be professionally adjusted for cultivating the subsoil.
The manufacturer will not accept any liability for unprofessional use
and its resulting damage. All risks occurring with this are entirely at
the expense of the user.
Not following the use, maintenance and repair instructions prescribed
by the manufacturer is also considered improper/unprofessional use
of this machine.
Inspect the area to be treated before using the Verti-Top.
Remove loose obstacles and avoid irregularities.
(2) The Verti-Top is manufactured according to the latest technical
understanding and is safe to use.
When careless people use, maintain or repair the machine, danger of
injuries to the user and to third parties can be the result. This must be
avoided!
Always use the Verti-Top in combination with the correct tractor as
described in the technical data.
(3) All persons assigned to operate, maintain and repair the Verti-Top by
the owner must completely read and understand the operation manual
and in particular the chapter of Safety Instructions.
The user is responsible for a safe Tractor/Verti-Top combination.
This entire combination must be tested on noise, safety, risk and
user friendliness. User instructions should also be drafted.
(4) The user is obliged to check the Verti-Top for visible damage and
defects before using the Verti-Top.
Modifications to the Verti-Top (including its operations) that have a
negative impact on safety must be rectified immediately.
For safety reasons it is in principle not permitted to make changes or
adjustments to the Verti-Top (except those approved by the
manufacturer).

4
If modifications to the Verti-Top have been made, then the current
CE marking is cancelled. The person that has made these
modifications has to apply for a new CE marking himself.
Check the Verti-Top for loose bolts, nuts and components before
every operation.
If present, check the hydraulic pipelines regularly and replace these
when the hydraulic pipelines are damaged or appear old. The
replacing pipelines should comply with the technical requirements of
the manufacturer.
If present, you should always make the hydraulic installation
pressure-free before working on this installation.
NEVER use the Verti-Top in the absence of protective guards and
safety stickers.
The inspection hatch MUST be closed when using the Verti-Top. (Figure
2)
Figure 2
Figure 3
BE CAREFUL not to get any parts of your body jammed when
opening the inspection hatch. (Figure 3)
NEVER crawl under the Verti-Top.
If necessary, tilt the Verti-Top.
NEVER step off the tractor while the motor is running.
In case of maintenance, adjusting and repairs, it is necessary to block
the Verti-Top in order to prevent sinking away, driving off and/or
sliding off.
Always switch off the tractor motor, take the tractor’s key out off
the ignition and disconnect the PTO in case of maintenance,
adjusting and repairs. (Figure 4)
Figure 4

5
With regards to the safety of the machine and the user, use only
original Verti-Top parts for maintenance and repairs.
Only authorised technical personnel may carry out repairs to the Verti-
Top.
Keep a record of the repair activities.
(5) The general applicable health & safety (Dutch acronym: ARBO)
regulations must also be followed in addition to the instructions in this
user manual.
Relevant traffic regulations also apply in case of using public roads.
Transporting persons is not permitted!
Do not use the Verti-Top in the dark, in heavy rain/storm or on slopes
with an angle larger than 20 degrees.
(6) All persons that are going to operate the Verti-Top must be familiar
with all the functions and control elements of the Verti-Top before
starting any work activities.
Attach the Verti-Top to the towing vehicle according to the regulations.
(Danger of injuries!)
Check whether you have a clear field of vision – both close by and far
away – before you depart.
Safety stickers with an identical meaning are attached to the
sideboard (Figure 4, 5 and 6) and to the rear cover (Figure 7) of the Verti-Top.
These safety stickers must always be clearly visible and legible and
must be replaced in case they have become damaged.
During operation, NO persons are allowed within the danger zone
of the Verti-Top, because there is danger of physical injuries caused
by flying particles or substances (Figure 5) .
Figure 5
Figure 6
Keep a distance of minimum 4 metres! (Figure 6)
