8
Pulp removal................................................................................................................automatic
Material used for cups....................................................................................................TRITAN
Cups volume..............................................................................................................................1 L
Overload protection.................................................................................................... available
Protection mechanism to prevent switching the device if incorrectly
assembled...................................................................................................................................available
Cleaning brush.............................................................................................................. available
Rubberized feet............................................................................................................ available
Max. running time....................................................................................................20 minutes
Switching-on interval.…...........................................................................................5 minutes
List of equipment
Slow juicer .............................................1 pc.
Juice cup.................................................1 pc.
Pulp collecting cup.................................1 pc.
Cleaning brush......................................1 pc.
User manual..........................................1 pc.
Warranty service coupon....................1 pc.
In accordance with the policy of continuous improvement,the manufacturer reserves
Model conguration A1
1. Housing
2. Power indicator
3. Mode switch
4. Pusher
5. Feeding tube
6. Lid equipped with the juicing mecha-
nism
7. Juicer screw
8.
9. Separator bowl
10. Blocking lid to prevent leaking
11. Juice outlet
12. Pulp outlet
13. Silicone stopper plug
14. Juice cup
15. Pulp collecting cup
16. Cleaning brush
17. Power cord
18. Rubberized feet
I. BEFORE USE
Carefullytake the appliance and its parts out of the package box,remove all wrapping
material and stickers.
Take the appliance out of the package box, remove all wrapping material and stick-
automatically disables the user’s right to aftersales service.
Uncoil the power cord.Wipe the housing with a damp cloth.Wash the parts with soapy
water, let them dry at room temperature and natural ventilation before plugging-in.
After transportation or storing the appliance at low temperatures let the device
warm up at room temperature for at least 2 hours before use.
II. OPERATION
See the order of assembling and disassembling the appliance on A2 and A3 dia-
grams.
Helpful tips
• Do not remove thin membranes and skin. Remove only inedible parts, such
as orange,kiwi or cantaloupe peel, uncooked beet parts.Always remove fruit
stones!
• While using the juicer,switch the appliance occasionally to clean and wash the
processing berries (grapes,currants,gooseberries), particular sorts of apples or
apples that are pithy or overripe.
• Drink the juice as soon as you have made it as it quickly starts to lose its nutri-
ents when exposed to air.
• To get as much juice as possible move the pusher slowly. The appliance is not
intended for processing sugar cane and other foods that contain a lot of starch.
Manufacturer’s warning!
To improve the productivity and prolong service life it is recommended:
•
•
• To gradually put the precut vegetables,fruit or berries into the feed chute and
• Not to press the push bar too much to avoid quality degradation of juice and
•
• To preliminarily defrost food.
III.MAINTENANCE
Wipe the housing of the appliance with a damp cloth.
DO NOT immerse the housing and power cord in water or keep in running water.
Wash the detachable parts with soapy water after use.Add some lemon juice to
clean and shine metal parts.
DO NOT use sponges with hard or abrasive surface, abrasive scouring substances
