Reebok Paceline RX 5.0 User manual

USERʼS MANUAL
Serial Number
Decal
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. eep this manual
for future reference.
Model No. RBEX14110.2
Serial No.
Write the serial number in the
space above for reference.
www.reebokfitness.com
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-877-994-4999
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.reebokservice.com

2
TABLE OF CONTENTS
WARNINGDECALPLACEMENT ..............................................................2
IMPORTANTPRECAUTIONS ................................................................3
BEFOREYOUBEGIN ......................................................................4
ASSEMBLY ...............................................................................5
HOWTOUSETHEEXERCISEBIE ..........................................................8
PARTLIST ..............................................................................10
EXPLODEDDRAWING.....................................................................11
ORDERINGREPLACEMENTPARTS ..................................................BackCover
LIMITEDWARRANTY ..............................................................BackCover
WARNING DECAL PLACEMENT
This drawing shows the location(s) of the
warning decal(s). If a decal is missing or
illegible, see the front cover of this manual
and request a free replacement decal.
Apply the decal in the location shown.
Note: The decal(s) may not be shown at
actual size.
REEBO and the Vector Logo are registered trademarks and service marks of Reebok. This product is
manufactured and distributed under license from Reebok International.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise bike before using your exercise bike.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the exercise bike only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
4. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
5. eep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
6. Place the exercise bike on a level surface,
with a mat beneath it to protect the floor or
carpet. Make sure that there is at least 2 ft.
(0.6 m) of clearance around the exercise
bike.
7. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. eep children under age 12 and pets away
from the exercise bike at all times.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
10. The exercise bike should not be used by
persons weighing more than 300 lbs.
(136 kg).
11. Always keep your back straight while using
the exercise bike; do not arch your back.
12. The exercise bike does not have a freewheel;
the pedals will continue to move until the fly-
wheel stops. Reduce your pedaling speed in
a controlled way.
13. To stop the flywheel quickly, press the brake
lever downward.
14. When the exercise bike is not in use, tighten
the resistance knob completely to prevent
the flywheel from moving.
15. To avoid damaging the brake pads, do not
lubricate the brake pads.
16. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
IMPORTANT PRECAUTIONS

4
Thank you for selecting the new REEBO ®PACELINE
RX 5.0 exercise bike. Cycling is an effective exercise
for increasing cardiovascular fitness, building
endurance, and toning the body. The PACELINE RX
5.0 exercise bike provides a selection of features
designed to make your workouts at home more effec-
tive and enjoyable.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions
after reading this manual, please see the front cover
of this manual. To help us assist you, note the product
model number and serial number before contacting
us. The model number and the location of the serial
number decal are shown on the front cover of this
manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Resistance nob
Seat
Adjustment nob
Adjustment nob
Pedal/Strap
Water Bottle Holder
Leveling Foot
Leveling Foot
Handlebar
Handle
BEFORE YOU BEGIN
Wheel

5
ASSEMBLY
To hire an authorized service technician to assemble the exercise bike, call 1-800-445-2480.
Assembly requires two persons. Place all parts of the exercise bike in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires an adjustable wrench and a Phillips
screwdriver .
Note: If a part is not in the hardware kit, check to see if it has been preattached.
1. Remove the two screws, the two washers, and
the shipping bracket (not shown) from the rear
of the Frame (1). Discard the screws, washers,
and shipping bracket.
Identify the Rear Stabilizer (58), which does not
have wheels.
Attach the Rear Stabilizer (58) to the Frame (1)
with two M8 x 16mm Screws (55) and two M8 x
16mm Washers (54).
1
55
54
58
1
2. Remove the two screws, the two washers, and
the shipping bracket (not shown) from the front
of the Frame (1). Discard the screws, washers,
and shipping bracket.
Attach the Front Stabilizer (49) to the Frame (1)
with two M8 x 16mm Screws (55) and two M8 x
16mm Washers (54).
2
49
55
54
1

6
3
3. Identify the Right Pedal (60), which is marked
with an “R.”
Using an adjustable wrench, firmly tighten the
Right Pedal (60) clockwise into the Right
Crank Arm (42).
Tighten the Left Pedal (35) counterclockwise
into the Left Crank Arm (36).
35
60
36 42
4. Orient the Handlebar Post (21) as shown.
Locate the Adjustment nob (3) on the front of
the Frame (1). Loosen the Adjustment nob
and pull it outward. Then, insert the Handlebar
Post (21) into the Frame.
Move the Handlebar Post (21) upward or down-
ward to the desired position, release the
Adjustment nob (3) into an adjustment hole in
the Handlebar Post, and then tighten the
Adjustment nob. Make sure that the
Adjustment nob is firmly engaged in an
adjustment hole.
4
21
3
1
5. Attach the Handlebar (22) to the Handlebar
Post (21) with a Handle (25) and an M10
Washer (23).
Note: The Handle (25) functions like a ratchet.
Turn the Handle clockwise, pull the Handle out-
ward, turn the Handle counterclockwise, push
the Handle inward, and then turn the Handle
clockwise again. Repeat this process until the
Handle is tight.
5
22
21
23
25

7
6
6. Orient the Seat Post (27) as shown.
Locate the Adjustment nob (3) on the rear of
the Frame (1). Loosen the Adjustment nob
and pull it outward. Then, insert the Seat Post
(27) into the Frame.
Move the Seat Post (27) upward or downward
to the desired position, release the Adjustment
nob (3) into an adjustment hole in the Seat
Post, and then tighten the Adjustment nob.
Make sure that the Adjustment nob is
firmly engaged in an adjustment hole.
3
1
27
7
9
3
6
1
7
24
24
29
7. Orient the Seat (29) and the Seat Carriage (28)
as shown.
Attach the Seat (29) to the Seat Carriage (28)
with two M8 Hex Nuts (24). Make sure that the
nose of the Seat is pointing straight ahead
before you tighten the Hex Nuts.
Locate the Adjustment nob (3) on the Seat
Post (27). Loosen the Adjustment nob and pull
it outward. Then, insert the Seat Carriage (28)
into the Seat Post.
Slide the Seat Carriage (28) to the desired posi-
tion and then release the Adjustment nob (3)
into one of the adjustment holes in the Seat
Carriage. Make sure that the Adjustment
nob is firmly engaged in an adjustment
hole.
9. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise bike to protect the floor.
28
27
8. Attach the Water Bottle Holder (6) to the Frame
(1) with two M5 x 12mm Socket Screws (7).

8
HOW TO USE THE EXERCISE BI E
HOW TO ADJUST THE ANGLE OF THE SEAT
You can adjust the angle of the seat to the position
that is most comfortable. You can also slide your seat
forward or backward to increase your comfort or to
adjust the distance to the handlebar.
To adjust the seat, see the drawing in assembly step 7
on page 7. Loosen the nuts on the seat clamp a few
turns, and then tilt the seat upward or downward or
slide the seat forward or backward to the desired posi-
tion. Then, retighten the nuts.
HOW TO ADJUST THE HORIZONTAL POSITION OF
THE SEAT
To adjust the position
of the seat, first
loosen the adjust-
ment knob and pull it
downward. Then,
move the seat for-
ward or backward,
release the adjust-
ment knob into an
adjustment hole in
the seat carriage,
and firmly tighten the adjustment knob. Make sure
that the adjustment knob is engaged in an adjust-
ment hole.
HOW TO ADJUST THE SEAT POST
For effective exercise, the seat should be at the
proper height. As you pedal, there should be a slight
bend in your knees when the pedals are in the lowest
position.
To adjust the height
of the seat post, first
loosen the adjust-
ment knob and pull it
outward. Then, move
the seat post upward
or downward,
release the adjust-
ment knob into an
adjustment hole in
the seat post, and
firmly tighten the adjustment knob. Make sure that
the adjustment knob is engaged in an adjustment
hole.
HOW TO ADJUST THE HORIZONTAL POSITION OF
THE HANDLEBAR
To adjust the horizon-
tal position of the
handlebar, loosen the
handle, move the
handlebar forward or
backward to the
desired position, and
then tighten the
handle.
Note: The handle functions like a ratchet. To loosen
the handle, turn the handle counterclockwise, pull the
handle outward, turn the handle clockwise, push the
handle inward, and then turn the handle counterclock-
wise again. Reverse this process to tighten the
handle.
HOW TO ADJUST THE HANDLEBAR POST
To adjust the height
of the handlebar
post, first loosen the
adjustment knob and
pull it outward. Then,
move the handlebar
post upward or
downward, release
the adjustment knob
into an adjustment
hole in the handlebar
post, and firmly
tighten the adjustment knob. Make sure that the
adjustment knob is engaged in an adjustment
hole.
Seat
Adjustment
nob
Adjustment
nob
Adjustment
nob
Seat
Post
Handlebar
Post
Handle
Handlebar

9
HOW TO ADJUST THE PEDAL STRAPS
To tighten the pedal straps (see the drawing on page
4), simply pull the ends of the pedal straps. To loosen
the pedal straps, press and hold the tabs on the buck-
les, adjust the pedal straps to the desired position,
and then release the tabs.
HOW TO ADJUST THE PEDALING RESISTANCE
To increase the
resistance of the
pedals, turn the
resistance knob
clockwise; to
decrease the resis-
tance, turn the
resistance knob
counterclockwise.
To stop the flywheel, push the resistance knob
downward. The flywheel should quickly come to a
complete stop.
IMPORTANT: When the exercise bike is not in use,
tighten the resistance knob completely.
HOW TO LEVEL THE EXERCISE BI E
If the exercise bike rocks slightly on your floor during
use, turn one or both of the leveling feet on the front
or rear stabilizer (see the drawing on page 4) until the
rocking motion is eliminated.
HOW TO MAINTAIN THE EXERCISE BI E
Inspect and tighten all parts of the exercise bike regu-
larly. Replace any worn parts immediately.
To clean the exercise bike, use a damp cloth and a
small amount of mild detergent. IMPORTANT: To
avoid damage to the console, keep liquids away
from the console and keep the console out of
direct sunlight.
Resistance
nob

10
1 1 Frame
23Sleeve
33Adjustment nob
42M8 x 40mm Socket Bolt
52M8 Nut
61Water Bottle Holder
72M5 x 12mm Socket Screw
81Resistance nob
91Spring
10 1 3/8" Square Nut
11 1 3/8" Acorn Nut
12 1 Brake Shoe
13 1 Black Acorn Nut
14 2 Flange Nut
15 1 Spacer
16 1 Brake Bracket
17 2 M5 x 20mm Socket Screw
18 2 M5 x 30mm Button Bolt
19 6 M5 x 14mm Washer
20 2 M5 Locknut
21 1 Handlebar Post
22 1 Handlebar
23 1 M10 Washer
24 2 M8 Hex Nut
25 1 Handle
26 3 Carriage Cap
27 1 Seat Post
28 1 Seat Carriage
29 1 Seat
30 1 Hub Set
31 1 Ring
32 1 Small Pulley
33 1 Flywheel
34 2 Crank Cap
35 1 Left Pedal/Strap
36 1 Left Crank Arm
37 1 Large Pulley
38 1 Outer Shield
39 1 Drive Belt
40 1 Inner Shield
41 1 Front Shield
42 1 Right Crank Arm
43 6 M8 Locknut
44 6 Split Washer
45 6 M8 x 20mm Hex Bolt
46 2 M8 x 10mm Hex Bolt
47 9 M4 x 12mm Self-tapping Screw
48 2 M5 x 12mm Screw
49 1 Front Stabilizer
50 4 Leveling Foot
51 4 3/8" Hex Nut
52 4 Stabilizer Cap
53 2 M8 x 45mm Socket Bolt
54 8 M8 x 16mm Washer
55 4 M8 x 16mm Screw
56 2 Wheel
57 2 M8 Locknut
58 1 Rear Stabilizer
59 2 Crank Screw
60 1 Right Pedal/Strap
61 1 Crank Hub
*–Assembly Tool
*–Userʼs Manual
ey No. Qty. Description ey No. Qty. Description
PART LIST Model No. RBEX14110.2R1110A
Note: Specifications are subject to change without notice. For information about ordering replacement parts, see
the back cover of this manual. *These parts are not illustrated.
