Reebok ASTRORIDE SPRINT BIKE User manual

ASTRORIDE
USER MANUAL
SPRINT BIKE

2ASTRORIDE SPRINT BIKE - User Manual
PARTS LIST
Saddle
Adjustment
Knobs
Water Bottle
Holder
Pedal/Strap
Leveling Cap
Handlebar
Resistance Knob
Adjustment
Knob & Quick
Stop
Transport Wheel
WARNING : TO AVOID INJURY, PLEASE ENSURE THE FLYWHEEL
IS STATIONARY BEFORE DISMOUNTING THE BIKE.
HARDWARE PACK
M8 Washer (4) M8 Black Washer (2)
M8 * 16 Screw (2)M 8 *60 Carriage Bolt (4)
M8 Acorn Nut (8)
Spanner (1)
Allen Key with Screwdriver
(1)

www.reebokfitness.info 3
1
2
3
1
2
3
1 2
43
spanner x1
5
M8 acorn nut x2 M8 acorn nut x2
M8 washer x2 M8 washer x2
M8 x 60mm carriage
bolt x2 M8 x 60mm carriage bolt x2
5 5
1 1
2 2
3 3
22
35
8
7
spanner x1 spanner x1

4ASTRORIDE SPRINT BIKE - User Manual
5
7
6
www.reebokfitness.info/product-support
spanner x1
14
12
13
5
allen key with
screwdriver x1
M8 x 16mm screw
x2
M8 black washer
x2 12
13

www.reebokfitness.info 5
1
43
2
allen key with
screwdriver x1
14

6ASTRORIDE SPRINT BIKE - User Manual
SPARE PARTS LIST
23
1
1
1
1
3
36
8
10
12
5
2
2
2
2
4
7
9
11
14
16
18
19
19
13
15
15
15
15
17
17
20
20
21
60
60
23
26
28
30
32
25
22
22
22
24 27
29
29
31
34
59
34
34
36
38
39
33
33
33
33
35
37
40
41
43
43
46
48 50
52
45
42
44
47
49 51
54
56
56
58
58
53
53
55
55
57
57
61
62

www.reebokfitness.info 7
KEY NO. DESCRIPTION QTY.
1 M8 Acorn Nut 4
2 M8 Washer 4
3 M8 x 60mm Carriage Bolt 4
4 Front Stabilizer 1
5 Spanner 1
6 Rear Stabilizer 1
7 Left Pedal 1
8 Right Pedal 1
9 Saddle Post 1
10 Handlebar Post 1
11 Handlebar 1
12 M8 x 16mm Screw 2
13 M8 Black Washer 2
14 Allen key with Screwdriver 1
15 M4 x 10mm Screw 8
16 M5 x 30mm Bolt 2
17 M5 Washer 6
18 M5 Nut 2
19 Leveling Cap 2
20 M6 x 25mm Eyebolt 2
21 Frame 1
22 Adjustment Knob 3
23 Sleeve 2
24 Resistance Knob 1
25 Saddle Carriage 1
26 Saddle 1
27 Carriage Cap 1
28 Flywheel 1
29 Flywheel Cover 2
30 Hub 1
31 Sprocket 1
32 Lock Ring 1
KEY NO. DESCRIPTION QTY.
33 M5 x 12mm Screw 6
34 M4 x 20mm Screw 5
35 Right Crank Arm/Sprocket 1
36 Bottom Bracket 1
37 Inner Chain Guard 1
38 Chain 1
39 Outer Chain Guard 1
40 Guard Cover 1
41 9mm x 12mm x 14mm Spacer 1
42 Square Plate 1
43 Stabilizer Cap 2
44 Upper Brake Cap 1
45 Compression Spring 1
46 Square Nut 1
47 Hex Nut 1
48 M6 Acorn Nut 1
49 Brake Pad Assembly 1
50 Brake Bracket 1
51 Isolator 1
52 Water Bottle Holder 1
53 M6 Locknut 2
54 Left Crank Arm 1
55 Crank Cap 2
56 M8 Flange Nut 2
57 M10 Flange Nut 2
58 M10 Washer 2
59 M5 x 10mm Screw 1
60 Sleeve 2
61 Console 1
62 Console Wire with Speed Sensor 1

8ASTRORIDE SPRINT BIKE - User Manual
ENGLISH
BUTTON FUNCTION
MODE / RESET
Push down to select functions. Push
down for 2 seconds to reset TIME,
DISTANCE and CALORIES.
AUTO START / STOP
To start exercise at any time begin pedaling. The
TIME, SPEED, DISTANCE and CALORIES will count
up from zero.
If there is no movement detected for
approximately 4 minutes the computer will switch
off. Press any button or begin pedaling to restart.
COMPUTER FUNCTIONS
SCAN
Will scan through the different workout information
such as TIME, SPEED, DISTANCE and CALORIES
every 6 seconds.
TIME
Time will count between 0.00 and 99.59. Will also
count down from inputted selection back to 0.00.
SPEED
Current workout speed will be displayed –
between 0.00 – 99.9 KPH.
DISTANCE
Accumulates the total distance between 0.00 –
99.99 Km.
CALORIES
Records the users calories burnt between 00.00
– 99.99 CAL.
TOTAL DISTANCE
Display the accumulation of distance.
A
A
NOTES
• If the batteries are replaced all values will be reset.
• This computer requires 2 x AA batteries that are located
in the rear.
• If the computer does not respond or seems to have a
fault, remove the batteries for a period of 1 minute and
replace them.
• This reading is a guide only and not to be used for
medical purposes or comparisons.

www.reebokfitness.info 9
FRANÇAIS
FONCTION DES TOUCHES
MODE / RÉINITIALISER
Appuyez vers le bas pour sélectionner
les fonctions. Appuyez sur pendant 2
secondes pour réinitialiser L’HEURE, LA
DISTANCE et LES CALORIES.
DÉMARRAGE AUTOMATIQUE / ARRÊTEZ
Pour commencer l’entraînement à tout moment, il
suffit de pédaler. Les calculs de DURÉE, VITESSE,
DISTANCE et CALORIES commenceront à zéro.
Si aucun mouvement n’est détecté pendant
environ 4 minutes, l’ordinateur s’éteint. Appuyer
sur n’importe quelle touche ou commencer à
pédaler pour redémarrer.
FONCTIONS DE L’ORDINATEUR
BALAYAGE
Passe en revue les différentes données de la
séance d’entraînement comme la DURÉE, la
VITESSE, la DISTANCE et les CALORIES toutes
les 6 secondes (environ).
DURÉE
La durée peut être réglée de 0 à 99,59. Un compte
à rebours peut également être créé à partir d’une
durée choisie.
VITESSE
Affiche la vitesse actuelle de l’appareil, entre 0 et
99,9 Km/h
DISTANCE
Totalise la distance parcourue, entre 0 et 99,9 Km
CALORIES
Enregistre les dépenses caloriques de
l’utilisateur, entre 0 et 99,99 CAL.
DISTANCE TOTALE
Affiche l’accumulation de distance
A
A
NOTE
• Si les piles sont remplacées, toutes les valeurs sont
remises à zéro.
• Cet ordinateur nécessite 2 piles AA situées à l’arrière.
• Si l’ordinateur ne réagit pas ou semble en panne, ôter
les piles pendant 1 minute et les replacer.
• Cette mesure n’est fournie qu’à titre informatif et ne
doit pas être utilisée à des fins médicales ou de
comparaison.

10 ASTRORIDE SPRINT BIKE - User Manual
ITALIANO
FUNZIONE DEI PULSANTI
MODE / RESET
Premere per selezionare le funzioni.
Premere per 2 secondi per resettare
TEMPO, DISTANZA eCALORIE
AUTO START / STOP
Per avviare l’esercizio in qualunque momento
iniziare a pedalare. TEMPO, VELOCITÀ, DISTANZA
e CALORIE verranno calcolati partendo dallo zero.
Se non si rileva alcun movimento per circa 4
minuti il computer si spegnerà. Premere un tasto
qualsiasi o iniziare a pedalare per riavviare.
FUNZIONI COMPUTER
SCANSIONAMENTO
Scansionerà le diverse informazioni sull’esercizio
come TEMPO, VELOCITÀ, DISTANZA e CALORIE
ogni 6 secondi.
TEMPO
Il tempo sarà calcolato nell’intervallo fra 0.00 e
99.59. Si riporterà dalla selezione inserita fino allo
0.00.
VELOCITÀ
L’attuale velocità di esercizio verrà mostrata – fra
0.00 e 99.9 Km/h.
DISTANZA
Viene calcolata la distanza totale cumulativa fra
0.00 e 99.99 Km.
CALORIE
Registra le calorie bruciate dall’utilizzatore fra
00.00 e 99.99 CAL.
DISTANZA TOTALE
Visualizza il totale cumulativo della distanza.
A
A
NOTA
• In caso di sostituzione delle batterie tutti i valori verranno
resettati.
• Questo computer richiede batterie 2 x AA che sono
posizionate sul retro.
• Se il computer non risponde o sembra avere un guasto
togliere le batterie per 1 minuto e sostituirle.
• Queste istruzioni rappresentano soltanto una guida e
non devono essere usate per scopi o raffronti medici.
