REED R5000 User manual

reedinstruments
www com
Model R5000
Watt Meter
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Instruction Manual
[e-mail] REED-Direct.com

reedinstruments
www com
2
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Table of Contents
Safety ............................................................................................ 3
Features......................................................................................... 3
Specications.............................................................................3-4
Instrument Description.................................................................. 5
Operating Instructions................................................................5-7
Voltage Measurements ............................................................... 5
Current Measurements ............................................................... 6
Watt Measurements.................................................................... 6
Data Hold ................................................................................... 6
Data Record (Max/Min Reading) ................................................. 7
Backlight..................................................................................... 7
Auto Power Off ........................................................................... 7
RS232 PC Serial Interface............................................................. 8
Battery Replacement..................................................................... 9
[e-mail] REED-Direct.com

reedinstruments
www com
3
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Safety
• Do not apply overload voltage or current to the input terminal
• Remove test leads before opening the battery cover
• Only use a dry cloth to clean the plastic case
• Installation Categories III-600V
• Pollution Degree 2
Features
• True RMS Current and Voltage measurements
• Measures Watt (AC), AC A, AC V, and pF
• Large dual display LCD with Backlight
• Full function Auto Range
• Max & Min. Record
• Data Hold
• RS232 Computer Interface
• Low-Battery Indicator
Specifications
Zero: Automatic adjustment
Sampling Time: Approx. 1 second
Operating Temperature: 0 to 50°C (32 to 122°F)
Operating Humidity: Less than 80% RH
Power Supply: 1 x 9V Battery
Weight: 398g (0.88lbs)
Dimensions: 190 x 88 x 40mm (7.5 x 3.5 x 1.6”)
Includes: TL-88-1 test leads and 6AM6X 9V battery
Optional Accessories: FC-300 Fused Test Lead Set and CA-05A Soft
Carrying Case
[e-mail] REED-Direct.com

reedinstruments
www com
4
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Electrical Specifications
Max Input Value: AC Voltage: 600V; AC Current: 10A
Frequency Response: AC V/A is from 40 to 400 Hz
Accuracy is tested under an input signal of a 50/60 Hz Sine Wave.
Watt (True Power) - Auto Range
Range: 6000W
Resolution: 1W
Accuracy: ±(1% + 5W) at 23°C ±5°C
Measuring Signal comes from the front LOAD plug terminals.
AC Voltage and Current (True RMS) - Auto Range
Range: 600V / 10A
Resolution: 0.1V / 0.01A
Accuracy: ±(0.3% + 0.3V) / ±(0.3% + 0.03A) at 23°C ±5°C
PF (Power Factor)
Range: 1.00
Resolution: 0.01
Accuracy: ±(1% + 2d) at 23°C ±5°C
PF (Power Factor) specification tests were taken in an environment with an
RF Field Strength of less than 3 V/M and a Frequency of less than 30 MHz.
For service on this or any other REED product or information on other
REED products, contact REED Instruments at [email protected]
[e-mail] REED-Direct.com

reedinstruments
www com
5
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Instrument Description
1. Display
2. Power/
Backlight Button
3. Function Button
4. Hold Button
5. Record Button
6. Load Terminal
7. Power Source
8. RS232 Output
Terminal
9. AC Adapter
Terminal
10. Battery Cover
11. Stand
Operating Instructions
Press and hold the Power button for to turn the meter on and off.
Voltage Measurements
1. Turn the meter on.
2. Press the Function button to select ACV.
3. Connect the Red Test Lead to the V Input Terminal and Black Test
Lead to the COM Input Terminal.
4. Touch the test leads to the Voltage source.
5. Read the AC Voltage measurement on the display. The value
indicated corresponds to the position selected. If the Display
shows “ ---- ” it indicates an out-of-range measurement.
[e-mail] REED-Direct.com

reedinstruments
www com
6
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Current Measurements
1. Turn the meter on.
2. Press the Function button to select ACA
3. Connect the Red Test Lead to the 10A Input Terminal and the
Black Test Lead to the COM Input Terminal.
4. Touch the test leads to the Current source.
5. Read the AC Current measurement on the display. The value
indicated corresponds to the position selected. If the Display
shows “ ---- ” it indicates an out-of-range measurement.
Watt Measurements
1. Turn the meter on.
2. Verify your voltage of the equipment, either 110V or 220V.
3. Turn off the Power Source.
4. Plug in the Load (equipment) to the V Terminal and COM Terminal.
5. Plug in the power source to the WATT Terminal and 10A Terminal.
6. Push the Function button to change the function for measuring
ACV/ACA.
7. Turn on the Power Source and read out the Work Voltage on the
top part of the LCD.
8. Turn on the equipment power switch. Let it work, and read out the
Power Consumption from the bottom part of the LCD.
9. Push the Function Button to change to WATT/PF measurements.
10. Read the Active Power and Power Factor value on the LCD.
Data Hold
While taking a measurement, press the Hold button. The measured value
will freeze and a HOLD symbol will appear on the LCD. Press the Hold
button again to continue taking measurements.
[e-mail] REED-Direct.com

reedinstruments
www com
7
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Data Record (Max/Min Reading)
1. Press the Record button once to start the Data Record function.
A REC symbol will appear on the LCD.
2. Press the Record button again to display the Max value.
A REC MAX symbol will appear on the LCD.
3. To delete the maximum value, press the Hold button.
The MAX symbol will disappear from the LCD.
4. Press the Record button again to display the Min value.
A REC MIN symbol will appear on the LCD.
5. To delete the minimum value, press the Hold button.
The MIN symbol will disappear from the LCD.
6. To exit the Data Record function, press and hold the Record
button for 2 seconds. The meter will revert back to normal
measurements.
Backlight
While the meter is taking a measurement, press the Backlight button to
turn the LCD backlight on and off.
Auto Power Off
This meter will turn off after 10 min of inactivity. To disable this feature,
press the Record button.
[e-mail] REED-Direct.com

reedinstruments
www com
8
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
RS232 PC Serial Interface
The data output is a 16 digit stream that can be utilized for a user’s
specic application. An RS232 cord is required to link this instruments
to a PC.
The 16 digit data stream will be displayed in the following format:
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Each digit indicates the following:
D0: End Word
D1 to D8: Display reading, D1 = LSD, D8 = MSD.
If the display reading is 1234, then D8 to D1 is: 00001234
D9: Decimal Point (DP), position from right to the left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10: Polarity
0 = Positive 1 = Negative
D11 & D12: Annunciator for Display
ACV = 50, W = 47, A = 52, PF = 54
D13: Upper display data = 1
Lower display data = 2
D14: 4
D15: Start Word
RS232 Format: 9600, N, 8, 1
Baud rate: 9600
Parity: No parity
Data bit no.: 8 Data bits
Stop bit: 1 Stop bit
[e-mail] REED-Direct.com

reedinstruments
www com
9
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Battery Replacement
When the low battery symbol appears on the top left corner of the LCD
you will need to replace the batteries. When the meter has low batteries
the measurements will become less accurate. Make sure there are no
test leads attached to the meter, and that the meter is turned off before
opening the battery compartment.
1. Remove the battery cover with a screwdriver.
2. Replace the 9V battery and close the battery compartment.
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
[e-mail] REED-Direct.com

reedinstruments
www com
10
Pantone 534 Blue
Pantone 123 Yellow
Pantone 485 Red
Pantone 123 Yellow
Pantone 534 Blue
Black Rich Black -
20/20/20/100
Blue - 100/80/30/5
Yellow - 0/27/100/0
Red - 10/100/100/5
Yellow - 0/27/100/0
Blue - 100/80/30/5
Only if you REALLY need them:
Pantone 534 Blue - 100/80/30/5
Pantone 485 Red - 10/100/100/5
Pantone 123 Yellow - 0/27/100/
INSTRUMENTS
Notes _________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
________________________________________________
[e-mail] REED-Direct.com
