ReelCraft L 70100 123 7 User manual

• Ensure that only a qualified electrician installs/services this
equipment.
•
• Ensure that power supply voltage does not exceed maximum
voltage rating of reel.
•
• Ensure that all electrical power is removed from reel before
servicing.
•
• A high-tension spring assembly is contained within the reel.
Exercise extreme caution.
•
• Check for frayed and/or broken wires before each use. Pull
electrical cord from reel by grasping the electrical cord itself,
not the work device.
•
• If an electrical malfunction should occur, remove power from
reel immediately.
• Ensure that reel, electrical cord, and equipment being serviced
are properly grounded. Use an ohmmeter to check ground
continuity.
•
• If reel ceases to unwind or rewind, remove power immediately.
Do not pull or jerk on electrical cord!
•
• Treat and respect the reel as any other piece of machinery,
observing all common safety practices.
•
• All cord reels with flying leads must be hard wired into the
electrical circuit to ensure proper function.
•
WARNING: Even low voltage can cause irreparable damage or
death! Exercise extreme caution while operating or servicing this
equipment.
SAFETY
Personal injury and/or equipment damage may result if proper safety
precautions are not observed.
Read this manual carefully before installing,
operating or servicing this equipment.
IMPORTANT
Operating Instructions
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: [phone]
Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com
Form# 1287-916 Rev: 4/2017
Dimensions
A20 1/4”
B19 3/4”
C7 7/8”
D3 7/8”
E12 1/2”
Series L 70000 Spring Driven Cord Reels
Model Numbers:
L 70075 123 3 L 70100 123 7 L 70075 123 X
L 70100 123 3 L 70075 123 7A L 70075
L 70075 123 3A L 70100 123 7A L 70100 123 X
L 70100 123 3A L 70075 123 9 L 70100
L 70075 123 3B L 70100 123 9 L 70100 124 X
L 70100 123 3B L 70075 123 9G L 70100 124
L 70075 123 7 L 70100 123 9G




Series L 70000 Spring Driven Cord Reels
Page 2 www.reelcraft.com
Installation Instructions
Mounting
CAUTION:
Unless reel was specified differently when ordering, maximum instal-
lation height is 16 feet. Do not exceed this distance. Ensure that only
a qualified electrician installs/services this equipment. Observe appli-
cable NEC, OSHA, and local codes when installing this equipment.
Installation of GFCI cord reels should be performed by a qualified and
licensed professional in accordance with local building codes and
applicable NEC standards.
1. Unpack and inspect the reel for damage. Turn by hand to check for
smooth operation. Check for completeness.
2. Configure reel for top, side or bottom-wind (bottom-wind for con-
stant tension reels only) electrical cable dispensing by removing
bolts (1) securing guide arm bracket (2).
3. Determine new guide arm bracket location and remove corre-
sponding bolts. Position guide arm bracket to reel and replace
bolts.
4. Position reel on floor, wall or ceiling. Secure into place using four
(customer supplied) screws or bolts (3).
Installing the Input Electrical Cable:
15 and 20 AMP Models
WARNING:
Use only 12/3 or 12/4 SEOOW cable for input wiring. Ensure that appli-
cation does not exceed electrical rating of reel.
1. Feed input cable (1) through elbow (2) and main shaft.
2. Screw elbow (2) onto reel.
3. Connect input wires (3) and collector ring wires (4) together using
wire nuts (5).
4. Take the provided zip tie (not pictured) and zip tie the input cable
wires together closest to the slip ring.
5. Assemble cover (6) to reel.
Installing the Output Electrical Cable:
15 and 20 AMP Models
WARNING:
Select output cable in accordance with power requirement of apparatus
to be supplied. Ensure that application does not exceed electrical rating
of reel. Use extreme caution, reel under tension. Avoid releasing latch
mechanism.
1. Manually turn sheave (1) until spring is tight, back off 2 turns and
latch.
2. Remove access cover (2).
3. Remove 6” of output cable outer jacket (3) and add fork terminals
(4) to ends.
4. Route cable through strain relief (6), then through cut out in spool
(7).
5. Pull enough cable through hole for roughly a 1/2 an inner wrap
shown.
6. Connect output wires to terminal block (8) as shown.
7. Connect ground wire to grounding stud (9) as shown.
8. Using an ohmmeter check for ground faults.
9. Take the provided cable clamp (not pictured) and attach it to the
wire. Then take the cable clamp and screw it down to the right-
most screw on the brush assembly (with the brush assembly fac-
ing upward).
10. Replace cover (2).
11. Replace latch and wind cable onto reel.
12. Install bumper stop (10).
1
2
4
3
6
5
2
1
5
3
9
4
8
7
6
10

Series L 70000 Spring Driven Cord Reels
www.reelcraft.com Page 3
Replacing the Output Cord/Work Device (figure A)
WARNING:
Remove power from reel before performing any of the following proce-
dures. Use extreme caution, reel under tension. Avoid releasing latch
mechanism.
1. Pull output electrical cord from reel until fully extended, then latch.
2. Remove output bumper stop (3).
3. Remove access cover (1).
4. Disconnect output electrical cord/work device (4) at terminal strip
(2).
5. Remove cable clamp.
6. Remove strain relief (5). Remove output electrical cord/work
device.
7. Install replacement electrical cord/work device by reversing steps
2 through 5.
8. Release latch and rewind electrical cord on reel.
9. Replace access cover (1) and bumper stop (3).
Replacing the Input Cord (figure A)
WARNING:
All cord reels with GFCI receptacles must be hard wired into the electri-
cal circuits. Use of 2 or 3 prong plugs may cause a potential
malfunction of the GFCI receptacle.
1. Remove access cover (1).
2. Remove wire nuts (6) securing input electrical cord to collector
assembly (7).
3. Remove zip tie (not pictured), being careful to not damage wires.
4. Remove 90 degree elbow (8).
5. Remove input electrical cord.
6. Remove 11” of outer jacket from replacement input electrical cord
(input electrical cord wires must protrude a minimum of 6” from
center of collector assembly).
7. Install replacement input electrical cord by reversing steps 1
through 4.
8. Replace access cover (1).
Replacing the Brush Holder/Brushes (figure A)
1. At terminal strip (2), remove wires connecting brushes (9) to ter-
minal strip.
2. Remove lock nuts (10) securing brush holder (11) to reel. Relocate
cable clamp temporarily and remove brush holder.
3. Remove brushes (12) from brush holder (11).
4. Install replacement brush holder/brushes by reversing steps 1
through Upon completion of installation, adjust brush-to-ring
alignment by loosening nuts (13) and sliding finger assembly
(14).
1
14
10
12
13
11
3
5
8
2
9
4
7
15
6
Figure A

Series L 70000 Spring Driven Cord Reels
Page 4 www.reelcraft.com
Replacing the Collector Assembly (figure A)
1. Remove access cover (1).
2. Remove wire nuts (6) securing input electrical cord to collector
assembly.
3. Remove zip tie (not pictured), being careful to not damage wires.
4. At terminal strip (2), disconnect wires (9) connecting brushes (12)
to terminal strip.
5. Remove lock nuts (10) securing brush holder (11) to reel. Relocate
cable clamp temporarily and remove brush holder.
6. Remove coupling nut (15).
7. Remove collector assembly.
8. Install replacement collector assembly by reversing steps 1
through 5. Upon completion of installation, adjust brush-to-ring
alignment by loosening nuts (13) and sliding finger assembly
(14).
9. Replace access cover (1).
Troubleshooting Instructions (figure A)
Troubleshooting of the reel consists of isolating a problem to a defec-
tive electrical cord/work device, brush holder/brushes, or collector
assembly. Refer any other discrepancies only to an authorized service
person or directly to Reelcraft.
WARNING:
The following procedure directs the technician to take voltage mea-
surements. Remember, even low voltage is dangerous and can cause
personal injury or death. Exercise extreme caution! Ensure that only a
qualified electrican installs or services this equipment.
1. If work device is either an incandescent or fluorescent light,
replace bulb with a known good bulb. If this does not correct the
problem, proceed to step 2. If work device is an electrical recept-
able, ensure that tool or fixture connected to it is in good working
order. If it is, proceed to step 2.
2. Remove power from reel.
3. Remove access cover (1).
4. Reapply power to reel.
5. Check for correct voltage (120 vac) at a terminal strip (2). If volt-
age reading is correct, replace output electrical device (refer to
page 3). If voltage reading is incorrect, proceed to step 6.
6. Remove power from reel.
7. Using ohmmeter, check continuity of input electrical cord. If cord
checks good, proceed to step 8. If cord is faulty, replace it (refer to
page 3). Remove brush holder/brushes from reel and inspect (refer
to page 3). Replace defective components then proceed to step 9.
8. Reapply power to reel.
9. Check for correct voltage (120 vac) at terminal strip (2).
10. If voltage reading is still incorrect, replace defective collector
assembly (refer to page 4).
11. Replace access cover (1).
Service Instructions
Maintain reel by following the service instructions given in this manual.
Refer all other repairs, other than those listed, only to an authorized
service person or directly to Reelcraft. Failure to do so can result in
personal injury and/or equipment damage and may void the warranty.

Series L 70000 Spring Driven Cord Reels
www.reelcraft.com Page 5




 





























 




Figure B

Series L 70000 Spring Driven Cord Reels
Page 6 www.reelcraft.com
Item # Description # Req'd L 70075 123 3 L 70100 123 3 L 70075 123 3A L 70100 123 3A L 70075 123 3B
1Snap Ring 5 300007 300007 300007 300007 300007
2Lock Nut 2 261650-1 261650-1 261650-1 261650-1 261650-1
3 U-Bolt 1 3-117440 3-117440 3-117440 3-117440 3-117440
4Nyloc Nut 21 S82-15 S82-15 S82-15 S82-15 S82-15
5Latch Pawl Assembly 1 S602694 S602694 S602694 S602694 S602694
6Set Screw 1 S35-84 S35-84 S35-84 S35-84 S35-84
7Inlet Cord Assembly 1 602714 602714 602716 602716 602716
8Strain Relief 1 261082 261082 261082 261082 261082
9Pipe Fitting 90 Deg. Elbow 1 S159-14 S159-14 S159-14 S159-14 S159-14
10 Conduit Box Cover 1 None None None None None
11 Conduit Box 1 None None None None None
12 Lock Nut 4 300107 300107 300107 300107 300107
13 Bumper Stop Assembly 1 1-HR1004 1-HR1004 1-HR1004 1-HR1004 1-HR1004
14 Guide Arm & Roller Assy 1 S602697 S602697 S602697 S602697 S602697
15 Main Shaft 1 262947 262947 262947 262947 262947
16 Containerized Drive Spring 1 602718-80 602718-80 602718-80 602718-80 602718-80
17 Spring Arbor 1 261275 261275 261275 261275 261275
18 Arbor Key 1 261274 261274 261274 261274 261274
19 Strain Relief 1 260697-R 260697-R 260697-R 260697-R 260697-R
20 Spool & Hub Assembly 1 602703 602703 602703 602703 602703
21 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13
22 Collector Ring Assembly 1 S602296 602296 602296 602296 602296
23 Hex Lock Nut 3 S300011 S300011 S300011 S300011 S300011
24 Cable Clamp 1 262371-1 262371-1 262371-1 262371-1 262371-1
25 Grounding Cord Assembly 1 600283 600283 600283 600283 600283
26 Terminal Block Assembly 1 600205 600205 600205 600205 600205
27 Outlet Cord Assembly 1 602709-75 602709-100 602710-75 602710-100 602711-75
28 Slip Ring Bracket & Stud Assy 1 602696-1-35 602696-1-35 602696-1-35 602696-1-35 602696-1-35
29 Split Lock Washer 1 902016 902016 902016 902016 902016
30 Adapter Plate 1 261577 261577 261577 261577 261577
31 Spacing Washer 1 262422 262422 262422 262422 262422
32 Collector Ring Cover 1 262938 262938 262938 262938 262938
Voltage 125 125 125 125 125
AMPS 15 15 20 20 20
Item # Description # Req'd L 70100 123 3B L 70075 123 7 L 70100 123 7 L 70075 123 7A L 70100 123 7A
1Snap Ring 5 300007 300007 300007 300007 300007
2Lock Nut 2 261650-1 261650-1 261650-1 261650-1 261650-1
3 U-Bolt 1 3-117440 3-117440 3-117440 3-117440 3-117440
4Nyloc Nut 21 S82-15 S82-15 S82-15 S82-15 S82-15
5Latch Pawl Assembly 1 S602694 S602694 S602694 S602694 S602694
6Set Screw 1 S35-84 S35-84 S35-84 S35-84 S35-84
7Inlet Cord Assembly 1 602716 602715 602715 602716 602716
8Strain Relief 1 261082 261082 261082 261082 261082
9Pipe Fitting 90 Deg. Elbow 1 S159-14 S159-14 S159-14 S159-14 S159-14
10 Conduit Box Cover 1 None None None None None
11 Conduit Box 1 None None None None None
12 Lock Nut 4 300107 300107 300107 300107 300107
13 Bumper Stop Assembly 1 1-HR1004 1-HR1004 1-HR1004 1-HR1004 1-HR1004
14 Guide Arm & Roller Assy 1 S602697 S602697 S602697 S602697 S602697
15 Main Shaft 1 262947 262947 262947 262947 262947
16 Containerized Drive Spring 1 602718-80 602718-80 602718-80 602718-80 602718-80
17 Spring Arbor 1 261275 261275 261275 261275 261275
18 Arbor Key 1 261274 261274 261274 261274 261274
19 Strain Relief 1 260697-R 260697-R 260697-R 260697-R 260697-R
20 Spool & Hub Assembly 1 602703 602703 602703 602703 602703
21 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13
22 Collector Ring Assembly 1 602296 602296 602296 602296 602296
23 Hex Lock Nut 3 S300011 S300011 S300011 S300011 S300011
24 Cable Clamp 1 262371-1 262371-1 262371-1 262371-1 262371-1
25 Grounding Cord Assembly 1 600283 600283 600283 600283 600283
26 Terminal Block Assembly 1 600205 600205 600205 600205 600205
27 Outlet Cord Assembly 1 602711-100 602332-75 602332-100 602333-75 602333-100
28 Slip Ring Bracket & Stud Assy 1 602696-1-35 602696-1-35 602696-1-35 602696-1-35 602696-1-35
29 Split Lock Washer 1 902016 902016 902016 902016 902016
30 Adapter Plate 1 261577 261577 261577 261577 261577
31 Spacing Washer 1 262422 262422 262422 262422 262422
32 Collector Ring Cover 1 262938 262938 262938 262938 262938
Voltage 125 125 125 125 125
AMPS 20 15 15 20 20

Series L 70000 Spring Driven Cord Reels
www.reelcraft.com Page 7
Item # Description # Req'd L 70075 123 9 L 70100 123 9 L 70075 123 9G L 70100 123 9G L 70075 123 X
1Snap Ring 5 300007 300007 300007 300007 300007
2Lock Nut 2 261650-1 261650-1 261650-1 261650-1 261650-1
3 U-Bolt 1 3-117440 3-117440 3-117440 3-117440 3-117440
4Nyloc Nut 21 S82-15 S82-15 S82-15 S82-15 S82-15
5Latch Pawl Assembly 1 S602694 S602694 S602694 S602694 S602694
6Set Screw 1 S35-84 S35-84 S35-84 S35-84 S35-84
7Inlet Cord Assembly 1 602714 602714 602714 602714 262958
8Strain Relief 1 261082 261082 261082 261082 261082
9Pipe Fitting 90 Deg. Elbow 1 S159-14 S159-14 S159-14 S159-14 None
10 Conduit Box Cover 1 None None None None 262294
11 Conduit Box 1 None None None None 262293
12 Lock Nut 4 300107 300107 300107 300107 300107
13 Bumper Stop Assembly 1 1-HR1004 1-HR1004 1-HR1004 1-HR1004 1-HR1004
14 Guide Arm & Roller Assy 1 S602697 S602697 S602697 S602697 S602697
15 Main Shaft 1 262947 262947 262947 262947 262947
16 Containerized Drive Spring 1 602718-80 602718-80 602718-80 602718-80 602718-80
17 Spring Arbor 1 261275 261275 261275 261275 261275
18 Arbor Key 1 261274 261274 261274 261274 261274
19 Strain Relief 1 260697-R 260697-R 260697-R 260697-R 260697-R
20 Spool & Hub Assembly 1 602703 602703 602703 602703 602703
21 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13
22 Collector Ring Assembly 1 602296 602296 602296 602296 602296
23 Hex Lock Nut 3 S300011 S300011 S300011 S300011 S300011
24 Cable Clamp 1 262371-1 262371-1 262371-1 262371-1 262371-1
25 Grounding Cord Assembly 1 600283 600283 600283 600283 600283
26 Terminal Block Assembly 1 600205 600205 600205 600205 600205
27 Outlet Cord Assembly 1 602712-75 602712-100 602713-75 602713-100 602707-75
28 Slip Ring Bracket & Stud Assy 1 602696-1-35 602696-1-35 602696-1-35 602696-1-35 602696-1-35
29 Split Lock Washer 1 902016 902016 902016 902016 902016
30 Adapter Plate 1 261577 261577 261577 261577 261577
31 Spacing Washer 1 262422 262422 262422 262422 262422
32 Collector Ring Cover 1 262938 262938 262938 262938 262938
Voltage 125 125 125 125 125
AMPS 15 15 15 15 20
Item # Description # Req'd L 70075 L 70100 123 X L 70100 L 70100 124 X L 70100 124
1Snap Ring 5 300007 300007 300007 300007 300007
2Lock Nut 2 261650-1 261650-1 261650-1 261650-1 261650-1
3 U-Bolt 1 3-117440 3-117440 3-117440 3-117440 3-117440
4Nyloc Nut 21 S82-15 S82-15 S82-15 S82-15 S82-15
5Latch Pawl Assembly 1 S602694 S602694 S602694 S602694 S602694
6Set Screw 1 S35-84 S35-84 S35-84 S35-84 S35-84
7Inlet Cord Assembly 1 262958 262958 262958 262966 262966
8Strain Relief 1 261082 261082 261082 261082 261082
9Pipe Fitting 90 Deg. Elbow 1 None None None None None
10 Conduit Box Cover 1 262294 262294 262294 262294 262294
11 Conduit Box 1 262293 262293 262293 262293 262293
12 Lock Nut 4 300107 300107 300107 300107 300107
13 Bumper Stop Assembly 1 1-HR1004 1-HR1004 1-HR1004 1-HR1004 1-HR1004
14 Guide Arm & Roller Assy 1 S602697 S602697 S602697 S602697 S602697
15 Main Shaft 1 262947 262947 262947 262947 262947
16 Containerized Drive Spring 1 602718-80 602718-80 602718-80 602718-80 602718-80
17 Spring Arbor 1 261275 261275 261275 261275 261275
18 Arbor Key 1 261274 261274 261274 261274 261274
19 Strain Relief 1 260697-R 260697-R 260697-R 260697-R 260697-R
20 Spool & Hub Assembly 1 602703 602703 602703 602703 602703
21 Snap Ring 1 S140-13 S140-13 S140-13 S140-13 S140-13
22 Collector Ring Assembly 1 602296 602296 602296 602297 602297
23 Hex Lock Nut 3 S300011 S300011 S300011 S300011 S300011
24 Cable Clamp 1 262371-1 262371-1 262371-1 262371-1 262371-1
25 Grounding Cord Assembly 1 600283 600283 600283 600283 600283
26 Terminal Block Assembly 1 600205 600205 600205 600280 600280
27 Outlet Cord Assembly 1 None 602707-100 None 602475-100 None
28 Slip Ring Bracket & Stud Assy 1 602696-1-35 602696-1-35 602696-1-35 602696-2-35 602696-2-35
29 Split Lock Washer 1 902016 902016 902016 902016 902016
30 Adapter Plate 1 261577 261577 261577 261577 261577
31 Spacing Washer 1 262422 262422 262422 262422 262422
32 Collector Ring Cover 1 262938 262938 262938 262938 262938
Voltage 125 125 125 600 600
AMPS 20 20 20 16 16
