Regency Fireplace Products City CP60E Series Quick start guide

WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
Installer: Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Certied to/Certié pour: CSA 2.17-2017
ANSI Z21.88-2019
CSA 2.33-2019
Owners &
Installation Manual
STYLE MODEL
Pier CP60E-NG / CP60E-LP
Tested by:
www.regency-re.com
- Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the re department.
- Installation and service must be performed by a qualied installer, service agency or the gas supplier.
City Series®
CP60E DIRECT VENT
920-470d FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 09.15.23

2 | City Series CP60E
This appliance may be installed in an aftermarket, permanently located manufactured home (U.S.A. only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible
for use with other gases unless a certied kit is used.
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The City Series are hand-crafted appliances
and have been designed to provide you with all the warmth and charm of a wood replace at the ick of a switch.
The CP60E City Series have been approved by Intertek for both safety and eciency. As it also bears our own
mark, it promises to provide you with economy, comfort and security for many trouble-free years to follow. Please
take a moment now to acquaint yourself with these instructions and the many features of your Regency® Fireplace.
920-408
4.34.7
Instruction Plate
For a glass-fronted gas appliance where the temperature of the glass
viewing area outside surface exceeds the limits specified in Clause 5.14.4, the following
graphic danger and statements shall be shown on a Class IIIA-2 Permanent Label.
4.34.6
Instruction Plate
Each appliance shall bear a Class IIIB marking with letters on a contrasting background, located
adjacent to the controlling device or in an equally conspicuous position where the instruction can be easily read.
April 22/14: Created draft
Double sided
Material: Synthetic Paper
Size 5.965" W x 5.71" H
Color: As shown in artwork
DANGER
HOT GLASS WILL
CAUSE BURNS
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS
A barrier designed to reduce the risk of burns from the hot viewing glass
is provided with this appliance and must be installed for the protection
of children and other at risk individuals.
!DANGER
!
920-408
CAUTION:
HOT WHILE IN OPERATION. DO NOT TOUCH.
SEVERE BURNS MAY RESULT. KEEP CHILDREN, CLOTHING, FURNITURE,
GASOLINE, AND ANY OTHER LIQUIDS WITH FLAMMABLE VAPOURS AWAY.
KEEP BURNER AND CONTROL COMPARTMENT CLEAN.
SEE INSTALLATION AND OPERATING INSTRUCTIONS ACCOMPANYING
APPLIANCE.
Front Back
LA SURFACE VITRÉE CHAUDE
PEUT CAUSER DES BRÛLURES.
NE TOUCHEZ PAS À LA
SURFACE VITRÉE NON REFROIDIE.
NE LAISSEZ JAMAIS UN
ENFANT TOUCHER LA SURFACE
VITRÉE.
DANGER
!
L’écran pare-étincelles fourni avec ce foyer réduit le risque de brûlure en cas de
contact accidentel avec la vitre chaude et doit être installé pour la protection des
enfants et des personnes à risque.
920-408-fr
ATTENTION
S'assurer que le brûleur et le compartiment des commandes sont propres.
Voir les instructions d’installation et d’utilisation qui accompagnent
l'appareil.
Risque de brûlures graves.
Ne pas toucher l’appareil lorsqu’il fonctionne.
Ne pas laisser les enfants s’approcher de l’appareil. Garder les
vêtements, les meubles et tout gaz ou liquide inflammable (carburant)
à distance de l'appareil.

City Series CP60E | 3
MANUFACTURED MOBILE HOME REQUIREMENTS
INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE
This Regency® product was tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: Vented Gas Fireplace
Heaters ANSI Z21.88-2019 • CSA 2.33-2019 and Gas-red Appliances for Use at High Altitudes CSA 2.17-2017.
This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home
Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes,
follow the current National Fuel Gas Code ANSI Z223.1, the current National Electrical Code ANSI/NFPA 70 in the U.S.A., and the current
CSA B149.1 Gas Installation Code and Canadian Electrical Code CSA C22.1 in Canada.
This Regency® mobile/manufactured home listed appliance comes factory equipped with four 1/4" (6 mm) diameter holes located near each
corner of the base. Fasten the replace in place using screws inserted through these holes.
This appliance comes equipped with a dedicated #8 ground lug for attachment of the ground wire to the steel chassis, as applicable to local
codes. See the "Wiring Diagram" section.
When installed, this appliance must be electrically grounded in accordance with local codes or, in the absence of local codes, the National
Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
This appliance may only be installed in an aftermarket, permanently located manufactured home (U.S.A. only) or mobile home, where not
prohibited by local codes.
This appliance can only be used with the type of gas indicated on the rating plate. It is not convertible for use with other gases unless a
certied kit is used.
Ensure that structural members are not cut or weakened during installation.

4 | City Series CP60E
WARNING
CARBON MONOXIDE POISONING HAZARD
Failure to follow the steps outlined below for each appliance connected to the venting
system being placed into operation could result in carbon monoxide poisoning or death.
The following steps shall be followed for each appliance connected to the venting system
being placed into operation, while all other appliances connected to the venting system are
not in operation:
1. Seal any unused openings in the venting system.
2. Inspect the venting system for proper size and horizontal pitch, as required in the
National Fuel Gas Code, ANSI Z223.1/NFPA 54 or the Natural Gas and Propane
Installation Code, CSA B149.1 and these instructions. Determine that there is no
blockage or restriction, leakage, corrosion and other deficiencies which could cause an
unsafe condition.
3. As far as practical, close all building doors and windows and all doors between the
space in which the appliance(s) connected to the venting system are located and other
spaces of the building.
4. Close fireplace dampers.
5. Turn on clothes dryers and any appliance not connected to the venting system. Turn on
any exhaust fans, such as range hoods and bathroom exhausts, so they are operating at
maximum speed. Do not operate a summer exhaust fan.
6. Follow the lighting instructions. Place the appliance being inspected into operation.
Adjust the thermostat so appliance is operating continuously.
7. Test for spillage from draft hood equipped appliances at the draft hood relief opening
after 5 minutes of main burner operation. Use the flame of a match or candle.
8. If improper venting is observed during any of the above tests, the venting system must
be corrected in accordance with National Fuel Gas Code, ANSI Z223.1/NFPA and/or
Natural Gas and Propane Installation Code, CSA B149.1.
9. After it has been determined that each appliance connected to the venting system
properly vents when tested as outlined above, return doors, windows, exhaust fans,
fireplace damper and any other gas-fired burning appliance to the previous
conditions of use.

City Series CP60E | 5
table of contents
Venting Arrangement for Vertical Terminations - 5" x 8"
(127 mm x 203 mm) Rigid and Flex Pipe..................................... 56
Vertical Terminations - 5" x 8" (127 mm x 203 mm) Rigid Pipe ...... 57
Vertical Terminations - 5" x 8" - Rigid or Flex Pipe ........................ 58
Vertical Terminations - Vertical Flex Vent Kit (Part #946-772) ......... 59
Vertical Flue Extension Kit (Part # 946-769) .................................. 61
Ceiling Firestop / Firestop Spacer (Part # 946-770)........................ 62
Non Power Vent Wiring Diagram................................................... 63
Wiring the Unit (120 Volt Power Supply) ....................................... 64
Vent Chart for Power Vent Only
Exterior Vent Termination Locations (Power Vent).......................... 66
4"x 6-5/8" Rigid Pipe Cross Reference Chart (Power Vent).............. 67
Venting Introduction.................................................................... 69
Horizontal Terminations - Inline Horizontal Vent Chart.................... 70
Vent Chart for Power Vent Only
Horizontal Terminations - End of Line Horizontal Vent Chart ........... 71
Wiring Diagram - Power Vent Application ...................................... 73
Non Power Vent/Power Vent Switch.............................................. 74
Inner Glass Panel (Firebox Glass) Installation / Removal................. 75
End Inner Firebox Glass Panel Installation/Removal ....................... 77
Glass Barrier Installation & Glass Barrier Adjustment...................... 79
Inner Black Steel/Enamel Panel Install (Part #457-907/457-908) .... 82
Inner Black Glass Panel Installation (Part #457-906)...................... 84
Burner and Firebox Media Options................................................ 86
Optional Log Set Installation ........................................................ 88
WIFI Dongle Installation (optional)............................................... 96
Maintenance Instructions............................................................. 97
Flame Pattern ............................................................................. 97
General Vent Maintenance ........................................................... 97
Log Replacement ........................................................................ 97
Glass Gasket............................................................................... 97
Glass.......................................................................................... 97
Glass Replacement...................................................................... 97
Aeration Adjustment.................................................................... 98
Minimum Air Shutter Opening ...................................................... 98
Bulb Replacement ....................................................................... 99
Valve Replacement .....................................................................100
Gas Maintenance - Recommended Annual Routine........................101
Main Assembly...........................................................................102
Accessories................................................................................104
Bottom Pressure Relief Gasket.....................................................104
Individual Glass Gasket Parts ......................................................104
Upper Glass Clamps....................................................................105
Lower Glass Clamps ...................................................................105
Power Vent - End of Line (Part # 946-535)...................................106
Power Vent - Inline (Part # 666-945)...........................................107
Warranty .............................................................................108
Copy of Safety Decal ..................................................................... 6
Decal Location .............................................................................. 6
Important Message ..................................................................... 8
Before You Start............................................................................ 8
First Fire....................................................................................... 9
Normal Operating Sounds Of Gas Appliances................................... 9
Lighting Procedure ...................................................................... 10
Shutdown Procedure ................................................................... 10
Copy of the Lighting Plate Instructions.......................................... 11
Proame II Remote Control Operating Instructions ........................ 12
Proame II Battery Holder Battery Replacement............................ 16
Maintenance Instructions............................................................. 17
General Vent Maintenance ........................................................... 17
Log Replacement ........................................................................ 17
Glass.......................................................................................... 17
Glass Replacement...................................................................... 17
Replacement Glass Part Numbers ................................................. 17
MA Code - CO Detector.................................................................. 7
Dimensions................................................................................. 18
Gas Connection - Bottom of Unit .................................................. 19
Gas/Electrical Connections - Side of Unit....................................... 19
Gas Connection......................................................................... 19
Electrical Connection ................................................................. 19
General Safety Information .......................................................... 20
Installation Checklist.................................................................... 20
Locating Your Gas Fireplace ......................................................... 21
Unit Assembly Prior to Installation ................................................ 22
Transportation Support Removal................................................... 23
Access Panel Removal.................................................................. 24
Chase Enclosure.......................................................................... 25
Clearances - Flush Installation...................................................... 26
Flush Installation Examples (Ventilation Openings) ........................ 27
Clearances - Bench Installation..................................................... 30
Bench Installation Examples (Ventilation Openings) ....................... 31
Mantel Clearances ....................................................................... 34
Mantel Leg Clearances................................................................. 35
Framing Dimensions.................................................................... 36
Chase Vent Installation (White Front) (Part # 686-991).................. 37
Wall Board/Drywall Installation..................................................... 38
No Screw Zones .......................................................................... 38
Framing and Finishing Inset Installations ...................................... 39
Typical Installations - Flush TV Install ........................................... 40
Typical Installations - Recessed TV Install ..................................... 41
Finishing..................................................................................... 42
Wall Mount On / O Switch and Battery Holder Installation ............ 43
Proame Wall Mount Transmitter.................................................. 44
LP Conversion Instructions........................................................... 45
System Data ............................................................................... 47
High Elevation............................................................................. 47
Gas Line Installation.................................................................... 47
Pilot Adjustment.......................................................................... 47
Gas Pipe Pressure Testing ............................................................ 47
885 S.I.T. Valve Description.......................................................... 47
Exterior Vent Termination Locations.............................................. 48
5” x 8” (127 mm x 203 mm) Rigid Pipe Cross Reference
Chart (Non Power Vent)............................................................... 49
Vent Restrictor Position (Non Power Vent)..................................... 51
Venting Introduction (Non Power Vent)......................................... 52
Venting Arrangement for Horizontal Terminations (Rigid and Flex) .. 52
Horizontal Terminations - Flex Vent 5" x 8" (127mm x 203mm) ...... 53
Horizontal Terminations - Rigid Pipe 5" x 8" (127 mm x 203 mm) ... 54
Horizontal Venting with Two 90o Elbows........................................ 55
Horizontal Venting with Three 90o Elbows ..................................... 55
Installer's information
Installation - General
Installation - Non Power Vent
Installation - Panels, Barriers, Faceplates
Owner's information
Installation - Media
Maintenance
Parts List

6 | City Series CP60E
Part #: 920-471
Colour: Black on grey except what is indicated as being printed red.
Size: (File at 100%) 9.11"w x 6.27"h
Material:
Start serial sequence at 570000001
Nov. 8/21: Created draft
No. 18/21: Updated clearances
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
570
570
DOOR SEAL: Please check that the door is properly sealed
JOINT DE PORTE : Veuillez vérifier que la porte est correctement scellée.
FPI Fireplace Products International Ltd. Delta, BC, Canada
Minimum Clearances to Combustibles /
Dégagement minimaux par rapport aux matériaux combustibles
Serial No./ No de série
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.
Listed/Nom: VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
Certified to / Certifi :é ANSI Z21.88-2019 • CSA-2.33-2019
CSA 2.17-2017
Electrical supply / Alimentation électrique 115VAC, 2.5A, 60Hz. o
Part No. 946-535 Power Vent Horizontal Termination City Series may be used. La pièce n 946-535 Horizontal Power Vent Termination City Series peut être utilisée.
o
Part No. 666-945 Inline Power Vent City Series may be used. La pièce n 666-945 Inline Power Vent City Series peut être utilisée.
Made in Canada/ Fabriqué au Canada
Duplicate S/N
GAZ PROPANE : Modèle CP60E-LP
PROPANE GAS: Model: CP60E-LP
Minimum supply pressure
Manifold pressure - High
Manifold pressure - Low
Orifice size
Maximum input
Minimum input
Altitude
GAZ NATUREL : Modèle CP60E-NG
5.0" WC/C.E. (1.25 kPa)
3.8" WC/C.E. (0.94 kPa)
1.1" WC/C.E. (0.27 kPa)
# 32 DMS
39,000 Btu/h (11.42 kW)
21,000 Btu/h (6.15 kW)
0-4500 ft/pi (0-1372 m)
11" WC/C.E. (2.73 kpa)
10.5" WC/C.E. (2.62 kPa)
2.9" WC/C.E. (0.72 kPa)
# 50 DMS
36,000 Btu/h (10.54 kW)
19,500 Btu/h (5.71 kW)
0-4500 ft/pi (0-1372 m)
Minimum supply pressure
Manifold pressure - High
Manifold pressure - Low
Orifice size
Maximum input
Minimum input
Altitude
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in the
United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard.
This appliance is only for use with the type(s) of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by
local codes. See owner's manual for details. This appliance is supplied with a conversion kit.
L'appareil doit être installé conformément aux codes et règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation National Fuel Gas Code ANSI Z223.1, ou CSA-B149.1 Natural Gas and
Propane Installation Code en vigueur.
L'appareil doit être installé conformément à la norme CAN/CSA-Z240, Série MM, Maisons mobiles, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety Standard. Si ces normes ne sont pas
applicables, veuillez vous référer à la norme ANSI/NCSBCS A225.1/NFPA 501A.
Cet appareil doit être utilisé uniquement avec les types de gaz indiqués sur la plaque signalétique et peut être installé dans une maison préfabriquée (É.-U. seulement) ou mobile installée à demeure si les règlements
locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Une trousse de conversion est fournie avec cet appareil.
C # 4001172
For Use Only with Barriers (Part #940-544/P, #940-545/P, #940-546/P) Follow installation instructions.
Utiliser uniquement avec l’écrans CP60E (n° 940-544/P, n° 940-545/P, n° 940-546/P). Suivre les instructions d'installation.
Pression d'alimentation minimale
Pression de sortie (manifold) - Haute
Pression de sortie (manifold) -
Basse
Taille de l’orifice
D bit calorifique maximalé
D bit calorifique minimalé
Altitude
Pression d'alimentation minimale
Pression de sortie (manifold) - Haute
Pression de sortie (manifold) - Basse
Taille de l’orifice
D bit calorifique maximalé
D bit calorifique minimalé
Altitude
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS. CATEGORY I.
NE PAS UTILISER AVEC UN COMBUSTIBLE SOLIDE. CATÉGORIE I.FOYER AU GAZ À ÉVACUATION -
Model/Modèle : CP60E-NG CP60E-LP
FOR USE WITH GLASS DOORS CERTIFIED WITH THE APPLIANCE ONLY DOIT ÊTRE UTILISÉ UNIQUEMENT AVEC LES PORTES VITRÉES CERTIFIÉES
Refer to Intertek's Directory of Building Products for detailed information.
Pour plus de détails , se reporter au Répertoire des produits de construction de Intertek.
This vented gas fireplace heater is not for use with air filters.
Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
920-471
CSA P.4.1 Fireplace Efficiency (FE) /Efficacité énergétique des foyers (EEF) CSA P.4.1
Natural Gas / Gaz nature 60.21%
Propane Gas / Gaz propane 62.48%
CANADIAN ENERGY
PERFORMANCE
VERIFIED
RENDEMENT
ÉNERGÉTIQUE
VÉRIFIÉ
EP5011169
NATURAL GAS: Model: CP60E-NG
(See instruction manual for detailed instructions/Voir manuel pour plus de détails)
Back Wall/Mur du fond 8” (203 mm)
Ceiling/Plafond (from fireplace top opening/d’après l’ouverture
sur le haut du foyer)
52” (1321 mm)
Mantel/Manteau (from fireplace top opening/d’après l’ouverture
sur le haut du foyer)
9” (229 mm)
Mantel Depth (Max.)/Profondeur max. du manteau 12” (305 mm)
Alcove Width/Largeur alcôve 95” (2413 mm)
Alcove Depth/Profondeur alcôve 111” (2819 mm)
Convection Air Outlet (Min.)/Sortie d’air de convection (min.)
180 square inches
Remove the centre access panel on the outer trim.
Data plate will be next to the gas valve, as shown
below.
Decal Location
A
DETAIL A
SCALE 1 : 12
PROCESS :
DWN:
SIGN:
E.C.N.:
DATE:
THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT.
PART :
MAT'L :
UNITS IN INCHES
DIMENSIONS
0.000 =
0.01 CRITICAL
0.000
= SPECIFIED TOLERANCE
0.000 = 0.031
0.000 REF = REFERENCE ONLY
ANGULAR = 1
TOLERANCES UNLESS
OTHERWISE STATED
DO NOT SCALE
DRAWING
3RD ANGLE
PROJECTION
REV: PART NO:
FIREPLACE PRODUCTS
INTERNATIONAL
457-500
-
CP60 MAIN ASSEMBLY
-
SHEAR/ PUNCH/ FORM
11/24/2021
DATE:
SCALE:
1:24
Decal
Remove
This is a copy of the label that accompanies this Direct Vent Gas Fireplace. A copy of the label is posted here for your review. The safety label is located at
the left side of the gas valve on the front, inside the base of the unit. It is visible when the outer front panel is removed.
Copy of Safety Decal
For the State of Massachusetts:
• Installation and repair must be done
by a plumber or gas tter licensed in
the Commonwealth of Massachusetts.
• Flexible connectors shall not exceed 36
inches (914 mm) in length.
• Requires the installation of a carbon
monoxide alarm in accordance with
NFPA 720 and a CO alarm with battery
backup in the same room where the
gas appliance is installed.
• The appliance's individual manual
shuto must be a t-handle type valve.
NOTE
• Regency® units are constantly being improved. Check the label on the unit and if there is a dierence, the label on the unit is the correct one.
NOTE: This replace is rated for both commercial & residential use.

City Series CP60E | 7
installer's information
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shallobserve that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipmentat the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

8 | City Series CP60E
owner's information
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY ON THE FIREPLACE GLASS,
AND SHOULD STAY AWAY TO AVOID
BURNS OR CLOTHING IGNITION.
INSTALLATION AND REPAIR OF YOUR
APPLIANCE SHOULD BE DONE BY AN
AUTHORIZED SERVICE PERSON. THE
APPLIANCE SHOULD BE INSPECTED
BEFORE USE AND AT LEAST ANNUALLY
BY A PROFESSIONAL SERVICE
PERSON. FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC. IT IS IMPERATIVE
THAT THE APPLIANCE'S CONTROL
COMPARTMENTS, BURNERS, AND
CIRCULATING AIR PASSAGEWAYS
ARE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE
A HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
NEAR THE APPLIANCE. TODDLERS,
YOUNG CHILDREN, AND OTHERS
MAY BE SUSCEPTIBLE TO ACCIDEN-
TAL CONTACT BURNS. A BARRIER
DESIGNED TO REDUCE THE RISK
OF BURNS FROM THE HOT VIEWING
GLASS IS PROVIDED WITH THIS AP-
PLIANCE AND SHALL BE INSTALLED
FOR THE PROTECTION OF CHILDREN
AND OTHER AT-RISK INDIVIDUALS.
Important Message
SAVE THESE INSTRUCTIONS
City Line Direct Vent Fireplaces must be installed
in accordance with these instructions. Consult the
"authority having jurisdiction" to determine the
need for a permit prior to starting the installation.
It is the responsibility of the installer to ensure
that this replace is installed in compliance with
manufacturer's instructions and all applicable codes.
Before You Start
We are required by the Canadian Safety Standards
and ANSI Standards to make you aware of the
following:
ANY SAFETY SCREEN, GUARD, OR
BARRIER REMOVED FOR SERVICING
THE APPLIANCE MUST BE REPLACED
BEFORE OPERATING IT.
IFTHEBARRIERBECOMESDAMAGED,
THE BARRIER MUST BE REPLACED
WITH THE MANUFACTURER'S
BARRIER FOR THIS APPLIANCE.
WE RECOMMEND REMOVING THE
GLASS WITH THE GLASS VACUUM
HOLDERS SUPPLIED BY THE MANU-
FACTURER. REST THE GLASS IN A
SAFE PLACE TO PREVENT DAMAGE TO
THE EDGES. BREAKAGE OR DAMAGE
TO THE EDGE OF THE GLASS DUE
TO CARELESS HANDLING IS NOT
COVERED UNDER WARRANTY.

City Series CP60E | 9
owner's information
Normal Operating Sounds Of
Gas Appliances
It is possible that you will hear some sounds from
your gas appliance. This is normal and is due to
the various gauges and types of steel within your
appliance. Examples are listed below. All are normal
operating sounds and should not be considered
defects in your appliance.
Unit Body/Firebox
The varying thicknesses of steel will expand and
contract at slightly dierent rates which can cause
"ticking" and "cracking" sounds. You should also
be aware that as there are temperature changes
within the unit, these sounds will likely recur.
Burner Tray
The burner tray is positioned directly under the
burner tube(s), media, and logs, and is made of
a dierent gauge material from the rest of the
rebox and body.
Pilot Flame
When on, the pilot ame may make a whispering
sound.
Gas Control Valve
As the gas control valve turns ON and OFF, a dull
clicking sound may be audible. This is normal.
During the rst few res, a white lm may develop
on the glass front as part of the curing process.
The glass should be cleaned after the unit has
cooled down or the lm will bake on and become
very dicult to remove. Use a non-abrasive
cleaner and DO NOT ATTEMPT TO CLEAN THE
GLASS WHILE IT IS HOT.
To ensure that the paint is properly cured, it is
recommended that you burn a re in your replace
for at least four (4) hours the rst time. During the
rst re, the unit will release an odour caused by
the curing of the paint and the burning o of oils
remaining from manufacturing. Smoke detectors
may go o at this time. Open windows to ventilate
the room for a couple of hours.
DO NOT BURN THE UNIT WITHOUT THE
GLASS IN PLACE.
First Fire
NOTE
When the glass is cold and the appliance is
lit, it may cause condensation and fog on
the glass. This condensation is normal and
will disappear in a few minutes as the glass
heats up.

10 | City Series CP60E
owner's information
* Not oered on all models.
Prior to operating this appliance, please read the instructions packaged with
the remote control to understand how to operate the system.
1. Ensure the battery holder switch is in the REMOTE position and / or wall-
mounted battery holder (if equipped) is in the REMOTE position.
2. Press and release the ON/OFF button on the remote hand-held transmitter
(see Diagram 1). A beep should be heard from the receiver. If not using
the remote, turn the appliance on by sliding the battery holder switch to
the ON position.
3. After approximately four seconds for non power vent models or 15 seconds
for power vent models, the spark ignition system will spark for 60 seconds
to light the main burner.
Shutdown Procedure
1. Press the ON/OFF button on the remote.
2. Before service is performed, you must disconnect the power and shut o
gas to the appliance.
Diagram 1
4. The unit will turn on.
5. Reset the system as follows:
a) Turn the system o by pressing the ON/OFF button on the remote .
b) Wait 5 minutes, then repeat the process from step 2.
Lighting Procedure
Continuous Pilot/Intermittent Pilot (CPI/IPI) selection
See remote control instructions for details.
*
*
*
NOTE
• The rst try for ignition will last approximately 60 seconds. If there
is no ame ignition (rectication), the board will stop sparking for ap-
proximately 35 seconds. After wait time, the board will start second
try for ignition by sparking for approximately 60 seconds. If there is
still no positive ignition, the board will go into lock out.
Back lit LCD display On/o key Thermostat key
Up/down arrow key
Mode key
IMPORTANT
•The remote control system supplied has several options
for starting/operating the appliance using the battery
holder and ON/OFF key on the hand-held transmitter.
NOTE
• Power vent models do not have a continuous pilot option.

City Series CP60E | 11
owner's information
Copy of the Lighting Plate Instructions
919-649b
Part #: 919-649b
Colours: Black on Grey, except for parts indicated as being Red.
Punch out .25" hole top right corner where indicated.
Size: 100%
w- 6.52"
h- 11.13"
Apr 05/16: Created decal
Apr. 26/16: Added Fr. Headers/warnings
Sept 27/19 Made changes to text per Matthew Cheng
Oct 14/21: IPI 7 day
June 14/22: Increased font heading / Loven O
DO NOT REMOVE THIS INSTRUCTION PLATE
NE PAS ENLEVER CETTE ÉTIQUETTE D’INSTRUCTIONS
TO TURN OFF GAS TO APPLIANCE / POUR COUPER LE GAZ AU NIVEAU DE L'APPAREIL
CAUTION: Hot while in operation. Do not touch. Severe burns may result. Due to high surface temperatures keep
children, clothing and furniture, gasoline and other liquids having ammable vapors away. Keep burner and control
compartment clean. See installation and operating instructions accompanying appliance.
ATTENTION : Surfaces chaudes lorsque l’appareil est en marche. Ne pas toucher. Risque de brûlures graves. En raison
des températures élevées, les enfants, les vêtements et le mobilier, le carburant et tout autre liquide aux vapeurs
inammables doivent être tenus éloignés de l’appareil. Nettoyer régulièrement le brûleur et le compartiment des
commandes. Voir les consignes d’installation et d’utilisation fournies avec l’appareil.
OPERATING INSTRUCTIONS / CONSIGNES DE FONCTIONNEMENT
FOR YOUR SAFETY READ BEFORE LIGHTING
POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE
WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage,
personal injury or loss of life. Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to the owner’s information manual provided with this appliance. For assistance
or additional information consult a qualified installer, service agency or gas supplier.
AVERTISSEMENT : Quiconque ne respecte pas scrupuleusement les instructions de la présente notice risque de déclencher
un incendie ou une explosion pouvant entraîner des dégâts matériels ou des blessures pouvant être mortelles.
Tout défaut d'installation, de réglage, de modication, de service ou d'entretien peut entraîner des blessures ou des dom-
mages matériels. Reportez-vous au manuel d'utilisation fourni avec cet équipement. Pour obtenir de l'aide ou des infor-
mations complémentaires, consulter un installateur ou un service d'entretien qualié, ou le fournisseur de gaz.
A) This appliance is equipped with an ignition device which automatically lights the pilot.
Do not try to light the pilot by hand.
B) BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the oor
because some gas is heavier than air and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electric switch, do not use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from a neighbours phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the re department.
C) Do not use this appliance if any part has been under water. Immediately call a qualied service
technician to inspect the appliance and to replace any part of the control system and any
gas control which has been underwater.
A) Cet appareil est muni d’un dispositif d’allumage qui allume automatiquement la veilleuse.
Ne tentez pas d’allumer la veilleuse manuellement.
B) AVANT LA MISE EN MARCHE, reniez tout autour de l’appareil pour déceler une odeur de gaz. Reniez au niveau du plancher, car certains gaz
sont plus lourds que l’air et peuvent s’accumuler au niveau du sol.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
• Ne tentez pas d’allumer l’appareil
• Ne touchez à aucun interrupteur; n'utilisez pas le téléphone se trouvant dans le bâtiment.
• Quittez immédiatement le bâtiment.
• Appelez immédiatement votre fournisseur de gaz depuis un téléphone extérieur. Suivez les instructions du fournisseur.
• Si vous ne pouvez pas rejoindre le fournisseur, appelez le service incendie.
C) N’utilisez pas cet appareil s’il a été plongé dans l’eau, même partiellement. Faites inspecter l’appareil par un technicien qualié et remplacez tout
élément du système de contrôle ou de commande qui a été plongé dans l’eau.
1)
STOP! Lisez les instructions de sécurité sur la portion supérieure de cette étiquette.
2) S’assurer que le commutateur principal est en position ON et/ou que le bloc-piles mural (le cas échéant) est en position <REMOTE>.
3) Appuyer sur la touche ON/OFF de la télécommande puis relâcher. Un bip sonore retentira depuis le récepteur. Si vous n'utilisez pas la
télécommande, l'appareil peut également être allumé en faisant glisser le commutateur du bloc-piles sur la position <ON> (le cas éché-
ant).
4) Après environ 4 secondes, le système d'allumage produira une étincelle pendant 60 secondes pour allumer le brûleur principal.
5) L'appareil s’allumera.
Remarque : Au premier allumage, le système tente d’allumer les ammes pendant 60 secondes. Si l’essai est infructueux, le système
fera une pause de 35 secondes. C’est ce qu'on appelle l'étape de rectication. Ce délai écoulé, le système tente à nouveau d'allumer les
ammes en produisant des étincelles pendant 60 secondes. Si les ammes ne s’allument toujours pas, le système se met en mode ver-
rouillage.
Il faut alors le réinitialiser en suivant les étapes ci-dessous (pour le déverrouiller) :
a) Attendre 5 minutes et éteindre l’appareil en appuyant sur la touche ON/OFF de la télécommande.
b) Attendre 2 secondes et appuyer encore une fois sur la touche ON/OFF.
c) L'appareil répètera l'étape 2.
6) Si l'appareil ne fonctionne pas, suivez les instructions "Pour couper le gaz au niveau de l'appareil" et appelez un technicien qualié ou
votre fournisseur de gaz.
Cet appareil est équipé d'une veilleuse sur demande qui s'éteint après sept jours.
1)
STOP! Read the safety information above on this label.
2) Ensure the Main switch is in the ON position and/or the wall mounted battery holder (if equipped) is in the <REMOTE> position.
3) Press and release the ON/OFF button on the remote handheld transmitter. An audible beep should be heard from the receiver. If not
using the remote, the unit can also be turned on by sliding the battery holder switch to the <ON> position (if equipped).
4) After approximately 4 seconds the spark ignition system will spark for 60 seconds to light the main burner.
5) The unit will turn on.
Note: The rst attempt to ignition will last approximately 60 seconds. If there is no ame ignition (rectication) the board will stop spark-
ing for approximately 35 seconds. After this wait time, the board will start a second try for ignition by sparking for approximately 60
seconds. If there is still no positive ignition after the second attempt the board will go into lock out.
The system will need to be reset as follows (after going into lock out mode):
a) Wait 5 minutes - turn the system o󰀨 by pressing the ON/OFF button on the remote.
b) After approximately 2 seconds press the ON/OFF button again.
c) Unit will repeat step 2.
6) If the appliance will not operate, follow the instructions, "To Turn O󰀨 Gas to Appliance" and call your service technician or gas supplier.
This appliance is equipped with an on-demand pilot that shuts o󰀨 after seven days.
1) Press the ON/OFF button on the remote or slide the wall mount switch to the "OFF" position.
2) If service is to be performed–you must disconnect power and shut o󰀨 gas to the unit.
1) Appuyer sur la touche ON/OFF de la télécommande ou faites glisser l'interrupteur mural sur la position "OFF".
2) Lors de l'entretien de l'appareil, vous devez débrancher l'alimentation électrique et couper le gaz alimentant l'appareil.

12 | City Series CP60E
owner's information
Proame II Remote Control Operating Instructions
The Proame 2 Transmitter controls the following hearth appliance
functions:
1. Main burner on/o.
2. Main burner ame modulation (6 levels).
3. Choice of standing or intermittent pilot (CPI/IPI) (non power vent
only).
4. Thermostat and smart thermostat functions.
5. Accent light modulation (6 levels).
6. Split ow valve (not available).
7. On/O relay.
8. Comfort fan speed modulation (6 levels) (not available).
Figure 1: Transmitter LCD Display
TECHNICAL DATA
REMOTE CONTROL
Supply voltage 4.5V (three 1.5V AAA batteries)
Ambient temperature rat-
ings
0 - 50oC (32 - 122oF)
Typical operative distance
in free air
12 m (39 ft)
Radio frequency 315 MHZ (FCC version)
Non-Power Vent Model: Install the 4 AA batteries during power out-
ages to run the main burner. However, the lights will not operate.
Power Vent Model: This appliance will not operate if 120 volt power
is lost within the home.
This appliance requires coding/pairing of the remote control and IFC
(Integrated Fireplace Control). See instructions in this manual.
Figure 3: Battery compartment
Pairing the remote control to remote receiver/
battery
holder (if required)
Power the receiver and press the PRG button located on its top right
corner - see the receiver instruction marked (*). The receiver will beep
three times when ready to synchronize with a transmitter. Install three
AAA batteries in the battery bay, at the base of the transmitter (g. 3).
Press the ON button. The receiver's command is accepted and sets to
the particular code of that transmitter. The system is now initialized.
(*) The receiver may be independent or integral to the IFC hearth appli-
ance control module. The receiver instruction may not be independent
when part of the IFC.
Figure 2: Proame Transmitter
The Proame Transmitter uses a streamlined design with a simple button
layout and informative LCD display (g. 1). A mode key scrolls between
the features and a thermostat key is used to turn on/o or scroll through
thermostat functions (g. 1 & 2). There is also a key lock feature (g. 22).
NOTES
• The Proame Transmitter 2 is an integrated part of the Proame
2 System, which consists of these elements:
»Proame 2 Transmitter, in conjunction with
»Integrated Fireplaces Control (Proame 2 IFC)
WARNING
• The transmitter and IFC are radio frequency devices.
On/o key Thermostat Key
Up/Down Arrow Key
Mode Key
Back lit LCD display
ATTENTION
• Turn OFF the main gas supply of the appliance prior
to installation or maintenance of the IFC, and remov-
ing or reinserting the batteries.
• In case of remote control malfunction, turn o the
IFC device using the ON/OFF main switch.
• For installation / maintenance, switch o the IFC
device removing main power supply plug.

City Series CP60E | 13
owner's information
Figure 4: Remote Control
Display in Fahrenheit.
Temperature Indication Display
With the system o, press the THERMOSTAT key and the MODE key at
the same time. Look on the transmitter's LCD screen for a C or F to the
right of the room temperature display (gures 4 & 5).
Figure 5: Remote Control
Display in Celsius.
Turn on the Appliance
With the system o, press the ON/OFF
key on the transmitter. Some icons will
be active on the transmitter display;
nonetheless, the IFC will activate the
appliance. A single “beep” from the IFC
conrms reception of the command.
Figure 6: Remote Control
display
Remote-Flame Control
The Proame has six (6) ame levels. With the system on and ame level
at maximum, the DOWN ARROW key will reduce the ame height by one
step each time it is pressed, until the ame is o.
The UP ARROW key will increase the ame height each time it is pressed.
If the UP ARROW key is pressed while the system is on but the ame is
o, the ame will come on in the high position. (g. 7 & 8) A single “beep”
conrms reception of the command.
Fig. 7
Fig. 8
Room Thermostat (Transmitter Operation)
The remote control can operate as a room thermostat which can be set
to a desired temperature. To activate this function, press the THERMO-
STAT key (g. 1). The LCD display on the transmitter will show that the
room thermostat is on, and the set temperature is displayed (g. 9). To
adjust the set temperature, press the UP or DOWN ARROW keys until
the desired temperature is displayed on the transmitter's LCD screen.
Figure 9 Figure 10
Turn o the Appliance
With the system ON, press the ON/OFF key on the transmitter. The
transmitter LCD display will only show the room temperature (g. 6).
At the same time, the IFC will turn o the appliance. A single “beep”
from the IFC conrms reception of the command.

14 | City Series CP60E
owner's information
Smart Thermostat (Transmitter Operation)
The smart thermostat function adjusts the ame height based on the
dierence between the set point and the actual room temperatures. As
the room temperature gets closer to the set point, the smart function
will turn the ame down.
To activate this function, press the THERMOSTAT key (g. 1) until the word
"SMART" appears to the right of the temperature bulb graphic (g. 11).
To adjust the set temperature, press the UP or DOWN ARROW keys
until the desired temperature is displayed on the transmitter's LCD
screen (g. 12).
Figure 12Figure 11: Smart Flame Function
Fan Speed Control**
If the appliance is equipped with a hot air circulating fan, its speed can
be controlled by the Proame system. To activate this function, use the
MODE key (g.1) to scroll to the fan control icon (g. 13). Use the UP/
DOWN ARROW keys (g.1) to turn on, o, or adjust to one of the fan's
six speeds (g. 14). A single “beep” conrms reception of the command.
Figure 13 Figure 14
Remote Dimmer Control (Light)**
The auxiliary function controls the AUX power outlet by the dimmable
light control. To activate this function, use the MODE key (g. 1) to scroll
to the AUX icon (g. 15 & 16).
The intensity of the output can be adjusted through six (6) levels. Use
the UP/DOWN ARROW keys (g.1) to adjust the output level (g. 16). A
single “beep” conrms reception of the command.
Figure 15 Figure 16
Split Flow control**
The secondary burner is controlled by the split ow. To activate this
function, use the MODE key (g. 1) to scroll to the SPLIT FLOW mode
icon (g. 17 & 18).
Pressing the UP ARROW key will activate the secondary burner. Pressing
the DOWN ARROW key will turn the secondary burner o. A single “beep”
conrms the reception of the command.
Figure 17 Figure 18
NOTE
• This function is available only with the IFC Control Module.
NOTE
• When smart thermostat is activated, manual ame height adjust-
ment is disabled.
On Demand Pilot Light (seven-day safety timer) (Non Power Vent Model Only)
Important information if using the appliance in CPI (continuous pilot mode) only
This appliance is a ProFlame 2 system tted with the “On Demand” Pilot, a safety feature which will shut down the gas valve completely by extinguishing
the pilot light in the event of a continuous full seven days of inactivity.
This only applies if the CPI (continuous pilot) switch is in the “on” position in your remote control transmitter.
Each time the main burner shuts down, manually or through the call from the thermostat, the seven-day timer starts again.
The seven-day inactivity timer is controlled within the circuit board. Therefore, if in CPI mode and when the pilot light is extinguished after seven straight
days of inactivity, the CPI setting on the remote control transmitter will remain in the “CPI” (continuous pilot) position. Therefore, all that is required to
relight the pilot would be to press the on/o button on the remote control transmitter from “on” to “o” and back to “on”. Once the pilot has re-established
operation will resume as normal. There is no requirement to do anything with the IPI/CPI mode on the remote control transmitter.
If the unit never goes as long as seven full days without a call for heat, the pilot will remain lit until it is manually shuto.
If the unit is being operated in IPI (intermittent pilot) mode, neither the above instructions nor the seven-day timer will apply.
See the instructions in this manual and on the Lighting Instructions plate on the appliance to light or relight the pilot.

City Series CP60E | 15
owner's information
NOTE
For information about glass or glass barriers, see "Panels, Barriers,
Faceplates" in the "Installation - General" section of this manual. For
information on light bulb replacement, refer to the "Maintenance"
section.
NOTE
Power vent models do not have a continuous pilot (CPI) option.
IMPORTANT
This unit must remain in intermittent pilot (IPI) mode
when used as a power vent model. If the unit is acciden-
tally placed in CPI mode, the pilot and the external power
vent fan will work constantly, causing unnecessary wear.
NOTE
• The fan (if installed) or CPI/IPI mode should not be programmed
out on the remote.
Continuous Pilot/Intermittent Pilot (CPI/IPI)
selection
Key Lock
This function will lock the keys to avoid unsupervised operation.
To activate or deactivate this function, press the MODE and UP keys
at the same time (g. 21).
Figure 21
Low Battery Power Detection Transmitter
The life span of the remote control batteries depends on various factors:
• Quality of the batteries used.
• The number of ignitions of the appliance.
• The number of changes to the room thermostat set point, etc.
When the remote control's batteries are low, a battery icon will appear
on its display (Fig. 22) before power is lost. When the batteries are
replaced, the battery icon will disappear.
Figure 22
CPI/IPI Switch (Non Power Vent Only)
This appliance comes equipped with a CPI/IPI switch. The functions of
the CPI/IPI switch are listed below.
Continuous Pilot (CPI) - A pilot that remains continuously ignited
until it is manually interrupted.
Intermittent Pilot (IPI) - A pilot that is automatically ignited when
an appliance is called on to operate and remains continuously ignited
during each period of main burner operation. The pilot is automatically
extinguished when each main burner operating cycle is completed.
The mode of the replace is easily changed from an intermittent pilot
ignition system (IPI) to a continuous pilot ignition system (CPI) using
the remote control as noted above.
The benets of CPI mode are as follows:
- Keeps venting primed for a trouble-free startup under colder weather
conditions or inversions.
- Keeps the unit glass warm, which decreases the amount of condensa-
tion on startup.
- Provides owners with exibility to choose a traditional continuous pilot.
The primary benet of having the IPI function is a signicant saving
on fuel as the pilot will only run when there is a call for heat.
Thermostat Icon: If the thermostat icon is not present on the remote
transmitter, follow the instructions noted below:
1. Remove one battery from the remote.
2. Press and hold the THERMOSTAT button on the remote while rein-
stalling the battery.
4. If you see "Set" on the remote,the thermostat option is enabled.
If you see "Clr", the thermostat option is disabled.
5. Repeat the procedure to change the "Set" or "Clr" option.
Enable all other functions if not present on the remote transmitter, fol-
lowing the instructions noted below.
1. Remove one battery from remote.
2. Press and hold the ON/OFF and MODE buttons simultaneously.
3. Reinstall the battery removed in step 1 while holding both buttons,
then release the MODE button only.
4. The screen will show either "Clr" or "Set".
5. "Clr" will remove a mode—use the up or down arrow while holding
the ON/OFF and MODE keys (mode icon will disappear once removed).
6. Use the MODE key to move to the next function.
7. "Set" will add a mode —use the up or down arrow while holding
ON/OFF and MODE keys (mode icon will appear when added).
8. Use the MODE key to move to the next function.
With the system in o position, press the MODE key (g. 1) to scroll to
the CPI mode icon (g. 19 & 20).
Pressing the UP ARROW key will activate the continuous pilot ignition
mode (CPI). Pressing the DOWN ARROW key will return to IPI. A single
“beep” conrms the reception of the command.
Figure 19 Figure 20

16 | City Series CP60E
owner's information
1 | 1
Battery Holder Battery Replacement & Battery Back up if 120 volt power is lost
witihin home
How to replace/add the batteries on battery holder (Proflame 2).
Note : If a wall switch cover plate is installed, first remove cover plate by removing 2 small phillips head screws
STEP 1
STEP 2
STEP 3
STEP 4 Reinstall wall cover plate with 2 Phillips head screws.
Replace 4 x AA batteries and insert the battery
compartment back into remote receiver/battery holder
Move both the left/right slides
as shown below.
The battery compartment
will be pushed out slightly,
to allow to easily extract it
Extract the battery
compartment from the remote
receiver/battery holder
Close the right slide
Keeping the battery compartment
pressed in, close the left slide
Proame II Battery Holder Battery Replacement & Battery Back Up if 120 Volt Power is lost
IMPORTANT
Non-Power Vent Model: Install the 4 AA batteries during power outages to run the main burner. However, the lights will not operate
Power Vent Model: This appliance will not operate if 120 volt power is lost within the home. This will not operate with 4 AA batteries due to the power
vent blower motor requiring AC power to operate.

City Series CP60E | 17
owner's information
NOTE
Improper positioning of logs may create
carbon buildup and will alter the appliance's
performance. The resulting damage is not
covered under warranty.
WARNING
• Do not clean the glass when it
is hot.
• The use of substitute glass will
void all product warranties.
• Do not strike the glass.
• Do not operate this replace with
a cracked, broken, or missing
glass front.
• Wear gloves and safety glasses
when removing damaged or bro-
ken glass.
• Replacement of glass panels
should be done by a licensed or
qualied service person.
4. Inspect joints to verify that no pipe sections
or ttings were disturbed or loosened. Also
check mechanical supports such as wall straps
or plumbers' tape for rigidity.
Log Replacement
The appliance should never be used with broken
logs. Turn o the gas valve and allow the unit to cool
before opening the door and removing the logs. If
a log needs replacement, you must use the proper
replacement log. The position of these logs must
be as shown in the diagrams under log installation.
Glass
Maintenance Instructions
1. Always turn o the gas valve before cleaning.
For relighting, refer to lighting instructions. Keep
the burner and control compartment clean by
brushing and vacuuming it at least once a year.
When cleaning the logs, use a soft, clean paint
brush as the logs are fragile and easily damaged.
2. Clean appliance and door with a damp cloth
(never when the unit is hot). Never use an
abrasive cleaner. The glass should be cleaned
with a gas replace glass cleaner. The glass
should be cleaned when it starts
looking cloudy.
3. The replace is nished in a heat-resistant paint
and should only be renished with heat-resistant
paint. Regency® uses StoveBright Paint - Metallic
Black #6309.
4. Periodically check the burner for proper
positioning and condition. Visually check the
ame of the burner periodically, making sure
the ames are steady, not lifting or oating.
If there is a problem, call a qualied service
person.
5. The appliance and venting system must be
inspected before use and at least annually by
a qualied eld service person, to ensure that
the ow of combustion and ventilation air is not
obstructed.
6. Do not use this appliance if any part has been
under water. Immediately call a qualied service
technician to inspect the appliance and replace
any part of the control system and gas control
which has been under water.
7. In the event this appliance has been
serviced, check that the vent-air system was
resealed & reinstalled in accordance with the
manufacturer's instructions.
8. Verify operation after servicing.
General Vent Maintenance
Conduct an inspection of the venting system
semiannually. Recommended inspection areas are
listed below.
1. Check the venting system for corrosion in areas
that are exposed to the elements. These will
appear as rust spots or streaks, and in extreme
cases, holes. These components should be
replaced immediately.
2. Remove the cap and shine a ashlight down the
vent. Remove any bird nests or other foreign
material.
3. Check for evidence of excessive condensation,
such as water droplets forming in the inner
liner and dripping out the joints. Continuous
condensation can cause corrosion of caps,
pipes, and ttings. It may be caused by having
excessive lateral runs, too many elbows, and
exterior portions of the system exposed to cold
weather.
In the event that you break your glass by impact,
purchase your replacement from an authorized
Regency dealer only. Replacement glass is shipped
already installed into the door frame. Reinstall
as per the instructions in the "Glass Installation"
section.
Replacement Glass Part
Numbers
Outer Safety Glass Side - Tempered
(Part# 940-545/P Side B, 940-546/P Side A)
Outer Safety Glass End - Tempered
(Part# 940-544/P)
Inner Glass Side (Part# 940-542/P)
Inner Glass End (Part# 940-543/P)
Your Regency® replace is supplied with high
temperature 5mm tempered outer glass & 5mm
ceramic inner glass. If your glass requires cleaning,
we recommend using an approved glass cleaner
sold by an authorized dealer. Do not use abrasive
materials or ammonia-based cleaners.
Glass Replacement

18 | City Series CP60E
installer's information
NOTES
• Height dimension is taken with levelling legs fully inserted and may vary depending on the height of the levelling legs when unscrewed or extended.
• All pictures/diagrams shown throughout this manual are for illustration purposes only. Actual product may vary due to enhancements.
• Dimensions will appear as (inches)" / (metric) mm throughout this manual. The inches are rounded to the nearest 1/16" when converted.
M
D
K
E
F
J
L
G H I
N
O
B
C
A
Side A
Side B
Side A Side B
PROCESS :
DWN:
SIGN:
E.C.N.:
DATE:
THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT.
PART :
MAT'L :
UNITS IN INCHES
DIMENSIONS
0.000 =
0.01 CRITICAL
0.000
= SPECIFIED TOLERANCE
0.000 = 0.031
0.000 REF = REFERENCE ONLY
ANGULAR = 1
TOLERANCES UNLESS
OTHERWISE STATED
DO NOT SCALE
DRAWING
3RD ANGLE
PROJECTION
REV: PART NO:
FIREPLACE PRODUCTS
INTERNATIONAL
457-500
MEDRALIN
-
CP60 MAIN ASSEMBLY
-
SHEAR/ PUNCH/ FORM
7/9/2021
DATE:
SCALE:
1:24
M
D
K
E
F
J
L
G H I
N
O
B
C
A
Side A
Side B
Side A Side B
PROCESS :
DWN:
SIGN:
E.C.N.:
DATE:
THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT.
PART :
MAT'L :
UNITS IN INCHES
DIMENSIONS
0.000 =
0.01 CRITICAL
0.000
= SPECIFIED TOLERANCE
0.000 = 0.031
0.000 REF = REFERENCE ONLY
ANGULAR = 1
TOLERANCES UNLESS
OTHERWISE STATED
DO NOT SCALE
DRAWING
3RD ANGLE
PROJECTION
REV: PART NO:
FIREPLACE PRODUCTS
INTERNATIONAL
457-500
MEDRALIN
-
CP60 MAIN ASSEMBLY
-
SHEAR/ PUNCH/ FORM
7/9/2021
DATE:
SCALE:
1:24
QP
Dimensions
Item Description Measurement
AExhaust center to stand-o 11-11/16" (298 mm)
BUnit body depth 22-1/4" (565 mm)
C Width (lip to lip) 23-5/16" (593 mm)
D Nailing strip 79-1/8" (2009 mm)
EGlass center to stando 35-7/8" (911 mm)
FGlass center to stando 39-3/16" (995 mm)
G Gas connection N/A
H Aeration adjustment N/A
Item Description Measurement
I Electrical N/A
J Viewing opening width 64-1/2" (1638 mm)
KUnit body width 73-9/16" (1868 mm)
L Viewing opening height 18-1/2" (469 mm)
M Unit height 41-1/2" (1054 mm)
NUnit body height 36-9/16" (928 mm)
OUnit base to bottom opening 10-1/8" (257 mm)
P Inner Flue Pipe 5" (127 mm)
Q Outer Flue Pipe 8" (203 mm)
Side A
Side A Side B
Side A
Side B

City Series CP60E | 19
installation - general
05/18/21
1
REGENCY GAS INSTALLATION CHECKLIST
Customer: Date Installed:
Install Address: Location of Fireplace:
Serial No: Installer:
Model No:
Site Requirements YES NO
If applicable, are the insulation, vapour barrier, and drywall present if installed on an outside wall or chase?
Does the area have a solid continuous base to support the unit?
Will the area accommodate the size of the applliance and all clearances?
Are the gas and electrical roughed into the area where the unit is being installed?
In City & Grandview series cool wall applications, is the chase enclosure sealed to prevent heat from escaping? All hot air
from the unit must exit via the mandatory ventilation openings.
In City & Grandview applications, Is the chase enclosure vented with the mandatory heat ventilation openings? See manual
for details.
If applicable, is the masonry/factory built freplace in its original condition with no modifications?
If applicable, have the hearth requirements been met?
Unit Setup YES NO
If applicable, are the standoffs and top nailing flange extensions installed and at the correct depth to accommodate finishing
material? See manual for details.
If applicable, is the fireplace level and secured, meeting framing clearances? See manual for details.
If applicable, is the unit converted to top or rear vent per manual instructions, and the insulation discarded?
Venting YES NO
Are the venting components approved for the unit installed?
Does the venting configuration comply with venting diagrams?
Is venting installed and secured, and are clearances for the vent pipe and termination cap maintained?
If applicable, was a 1/4" rise maintained for every foot of horizontal run?
Was the termination installed and sealed?
Is the direct vent termination at the highest point in the vent assembly?
If applicable, are both chimney liners continuous from flue collars to termination?
Electrical and Wiring YES NO
Is the appliance connected to the household's 110/120v per local codes? Check local codes for receptacle placement.
Were the connections in the fireplace tested with a circuit tester?
Is the appliance properly grounded?
If applicable, is the supplied electrical/gang box affixed to the wall to facilitate the mounting of the receiver/battery box ?
Gas YES NO
Does the supply pressure meet the requirements shown on the rating plate?
Was a conversion performed?
Was a leak check performed and manifold pressures verified?
Is the shut-off valve installed and easily accessible to the customer?
This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your
Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority.
Gas Installation Checklist

20 | City Series CP60E
installation - general
05/18/21
2
REGENCY GAS INSTALLATION CHECKLIST
Finishing YES NO
If applicable, is only noncombustible material installed in the noncombustible areas?
Do clearances meet installation and manual requirements?
Do the mantels and/or projections comply with the installation manual?
If applicable, was the solid fuel fireplace warning plate installed?
Appliance Media Setup YES NO
Do commands from the remote or wall switch light the pilot and main burner?
Are the burner media/log set, glass door, and screen installed per instructions in the manual?
Was the air shutter on the proper setting after running the unit for 20 minutes?
If applicable, were the surround and trims installed according to the manual?
Was the operation of the fan, lights (if installed), and flame modulation checked?
Customer Tutorial and Presentation YES NO
Is the customer confident operating the new gas appliance and aware of all the features on the remote?
Confirm that the rating and lighting plates are attached to the appliance. Do not remove.
Was the customer informed of the location of the rating and lighting plates?
Was accessing unit controls in a power outage explained to the customer?
Are the model and serial numbers and the date of installation of the unit written in the manual and on the checklist?
Were the warranty and unit registration reviewed with the customer?
Comments:
