Regency F2400M Quick start guide

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-154b
MODELS: F2400M S2400M
FreestandingWoodstove
01/25/05
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
Tested by:
www.regency-fire.com

Regency Freestanding Woodstove
2
Thank-youforpurchasinga
REGENCYFIREPLACEPRODUCT.
Theprideofworkmanshipthatgoesintoeachofourproductswillgiveyouyearsoftrouble-freeenjoyment. Shouldyouhave
anyquestionsaboutyourproductthatarenotcoveredinthismanual,pleasecontacttheREGENCYDEALERinyourarea.
KeepthoseREGENCYFIRESburning.
SAFETYNOTE: Ifthiswoodstoveisnotproperlyinstalled,ahousefiremayresult. Foryoursafety,followtheinstallation
instructions,contactlocalbuilding,fireofficials,orauthorityhavingjurisdictionaboutrestrictionsandinstallationinspection
requirementsinyourarea.
Theauthorityhavingjurisdictionshouldbeconsultedbeforeinstallationtodeterminetheneedtoobtainapermit.
Modular Parts

Regency Freestanding Woodstove 3
TABLE OF CONTENTS
THE REGENCY FREESTANDING WOOD STOVE
Glass Installation .............................................................. 17
Optional Accessories Installation
- Pedestal Ash Drawer Kit .......................................... 17
- Bottom Shield Ashdrawer Kit ................................... 17
- Screen Door ............................................................. 17
- Blower/Fan ............................................................... 18
- Blower/Fan Wiring Diagram .................................... 18
OPERATINGINSTRUCTIONS
Operating Instructions....................................................... 19
Draft Control ...................................................................... 19
First Fire............................................................................. 19
Fan Operation.................................................................... 20
Ash Disposal ..................................................................... 20
- Safety Precautions ................................................... 20
- Ash Drawer Operating Guidelines........................... 20
Safety Guidelines .............................................................. 20
MAINTENANCE
Maintenance ...................................................................... 21
Creosote............................................................................ 21
- Ways to Prevent & Keep Units Free of Creosote..... 21
Maintenance of Gold Doors .............................................. 21
Glass Maintenance ........................................................... 21
Latch Adjustment............................................................... 21
Door Gasket ...................................................................... 21
Wood Storage.................................................................... 21
PARTSLIST
Parts List - F2400M ........................................................... 22
Parts List - S2400M ........................................................... 23
Parts List - Pedestal, Bottom Shield and Legs ................ 24
Parts List - Firebrick .......................................................... 25
WARRANTY
Warranty............................................................................. 27
SAFETYLABEL
Medium Freestanding Stove F2400M ................................. 4
Medium Freestanding Step Stove S2400M ........................ 5
INSTALLATION
Unit Dimensions ................................................................. 6
Residential Installation ....................................................... 7
Modular Installation Options ............................................... 7
Room Air.............................................................................. 8
Minimum Clearance to Combustibles................................ 8
Residential "C" Vent Single Wall......................................... 8
Residential Close Clearance ............................................. 8
Mobile Home Close Clearance .......................................... 8
Minimum Alcove Clearances .............................................. 9
Floor Protection ................................................................... 9
Stove Assembly Prior to Installation ................................. 10
Airmate Assembly ............................................................. 10
Rear Heat Deflector Assembly.......................................... 10
Side Shield Adjustment..................................................... 10
Pedestal Assembly ........................................................... 10
Leg and Bottom Shield Assembly .................................... 11
Chimney & Connector Installation .................................... 11
Masonry Chimney.............................................................. 12
Masonry Fireplace ............................................................. 12
Factory Built Chimney........................................................ 12
Combustible Wall Chimney
Connector Pass-Throughs ........................................ 13
Recommended Height for Woodstove Flue ..................... 14
Flue Height Table .............................................................. 14
Mobile Home Installation .................................................. 15
Methods to Maintain Ventilation ........................................ 15
Listed Components for Mobile Home Installation
- U.S. Installations ...................................................... 16
- Canadian Installations............................................. 16
Flue Baffle & Secondary Air Tube Installation................... 16
Brick Installation ................................................................ 17
Door Handle ...................................................................... 17

Regency Freestanding Woodstove
4
This is a copy of the label that accompanies
each Regency Freestanding Woodstove
(F2400M). We have printed a copy of the
contents here for your review.
SAFETY LABEL
NOTE: Regency units are constantly being
improved.Checkthelabelontheunitandifthere
isadifference,thelabelontheunitisthecorrect
one.
HOT WHILE IN OPERATION DO NOT TOUCH. KEEP CHILDREN,
CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE
SKIN BURNS. READ NAMEPLATE AND INSTRUCTIONS.
DO NOT REMOVE THIS LABEL
244
CERTIFIEDTOCOMPLYWITHJULY1990
PARTICULATEEMISSIONSTANDARDS.
UNITED STATES ENVIRONMENTAL
PROTECTION AGENCY
MADEINCANADA
JAN FEB MAR APR MAY JUN JUL AUG SEPT OCT NOV DEC
CAUTION
DATE OF MANUFACTURE
918-172b
rev. 10/03
LISTEDSPACEHEATER,SOLIDFUELTYPE, ALSO
SUITABLEFORMOBILEHOMEINSTALLATION
MODEL: REGENCY MEDIUM FREESTANDINGSTOVE- F2400M
TESTEDTO: UL1482 / ULC S627 / UL 737 REPORTNO:219-S-02-2
THEF2400MMEETSUL737STANDARDFORFIREPLACESTOVESWHENAFIRESCREENISPROVIDED.
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS
F2400MWITHAIRMATESHIELD F2400M WITHOUTAIRMATESHIELD
RESIDENTIALINSTALLATIONUSING
SINGLE WALL CONNECTOR
MEASURE FLUE
FROM HEATER CENTER-LINE
RESIDENTIALINSTALLATIONUSING
SINGLE WALL CONNECTOR
SIDEWALL A 457 mm / 18 in D 762 mm / 30 in
BACKWALL B 305 mm / 12 in E 470 mm / 18.5 in
CORNER C 165 mm / 6.5 in F 457 mm / 18 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 380 mm / 15 in D 685 mm / 27 in
BACKWALL B 165 mm / 6.5 in E 330 mm / 13 in
CORNER C 152 mm / 6 in F 444 mm / 17.5in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
SIDEWALL A 380 mm / 15in D 685 mm / 27 in
BACKWALL B 165 mm / 6.5in E 330 mm / 13 in
CORNER C 152 mm / 6 in F 444 mm / 17.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL A 406 mm / 16 in D 711 mm / 28 in
BACKWALL B 280 mm / 11 in E 444 mm / 17.5 in
CORNER C 152 mm / 6 in F 444 mm / 17.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 380 mm / 15 in D 685 mm / 27 in
BACKWALL B 140 mm / 5.5 in E 304 mm / 12 in
CORNER C 102 mm / 4 in F 393 mm / 15.5 in
SIDEWALL A 380 mm / 15in D 685 mm / 27 in
BACKWALL B 140 mm / 5.5 in E 304 mm / 12 in
CORNER C 102 mm / 4 in F 393 mm / 15.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL G 380 mm / 15 in I 685 mm / 27 in
BACKWALL H 165 mm / 6.5 in J 330 mm / 13 in
MINIMUM ALCOVE CEILING HEIGHT: 2.15 M / 7 FT MAXIMUM ALCOVE DEPTH 915 MM / 36 IN.
MINIMUM CLEARANCES FOR HORIZONTAL CONNECTOR TO CEILING: 455 MM / 18"
THE SPACE BENEATH THE HEATER MUST NOT BE OBSTRUCTED. OPERATE ONLY WITH FIREBRICKS IN PLACE.
FLOOR
PROTECTION*
F2400MWITHOUT
AIRMATESHIELD
F2400MWITH
AIRMATESHIELD
INSTALLANDUSEONLYINACCORDANCEWITHTHEMANUFACTURER'SINSTALLATIONANDOPERATING
INSTRUCTIONS. CONTACTLOCALBUILDINGORFIREOFFICIALSABOUTRESTRICTIONSANDINSTALLATION
INSPECTION IN YOUR AREA. USE 150 MM (6 IN.) DIAMETER MINIMUM 24 MSG BLACK OR 26 MSG BLUED
STEELCONNECTORWITHLISTEDUL103HTFACTORY-BUILTCHIMNEYSUITABLEFORUSEWITHSOLID
FUELSORMASONRYCHIMNEY.
SEELOCALBUILDINGCODEANDMANUFACTURER'SINSTRUCTIONSFOR
PRECAUTIONS REQUIRED FOR PASSING A CHIMNEY THROUGH A
COMBUSTIBLEWALLORCEILING. DONOTPASSCHIMNEYCONNECTOR
THROUGHCOMBUSTIBLEWALLORCEILING. DONOTCONNECTTHISUNIT
TOACHIMNEYFLUESERVINGANOTHERAPPLIANCE.
FRONT
BACK
L
K
M
SIDE
SIDE
K 405 mm / 16 in
L 150 mm / 6 in
M 150 mm / 6 in
FOR USE WITH SOLID WOOD FUEL ONLY. USE OF OTHER FUELS MAY DAMAGE HEATER AND CREATE A HAZARDOUS CONDITION. DO NOT OBSTRUCT COMBUSTION AIR
OPENINGS. OPERATEONLYWITHFIREBRICKSINPLACE. RISKOFSMOKEANDFLAMESPILLAGE,OPERATEONLYWITHDOORSFULLYOPENORFULLYCLOSED.IFINSTALLED
IN A MOBILE HOME OPERATE ONLY WITH DOORS FULLY CLOSED - OPEN FEED DOOR TO FEED FIRE ONLY. WHEN OPERATED WITH DOORS OPEN THE MANUFACTURER
SUPPLIED SCREEN MUST BE USED. DO NOT USE GRATE OR ELEVATE FIRE. BUILD WOOD FIRE DIRECTLY ON HEARTH. DO NOT OVERFIRE - IF HEATER OR CHIMNEY
CONNECTORGLOWSYOUAREOVERFIRING. INSPECTANDCLEANCHIMNEYANDCONNECTORFREQUENTLY. UNDER CERTAINCONDITIONSOFUSECREOSOTEBUILDUP
MAYOCCURRAPIDLY. KEEPFURNISHINGSANDOTHERCOMBUSTIBLEMATERIALAWAYFROMHEATER. REPLACEGLASSONLYWITHNEOCERAMGLASS.COMBUSTIBLE
FLOOR MUST BE PROTECTED BY NON-COMBUSTIBLE MATERIAL EXTENDING BENEATH THE HEATER AND TO THE FRONT AND SIDES AS INDICATED OR TO THE NEAREST
PERMITTEDCOMBUSTIBLEMATERIAL.
OPTIONAL COMPONENT: FAN (846-515), ELECTRICAL RATING: VOLTS 115, 60 HZ, 2 AMPS, SCREEN DOOR (846-101)
DANGER: RISK OF ELECTRIC SHOCK. DISCONNECT POWER BEFORE SERVICING UNIT. DO NOT ROUTE POWER CORD UNDER OR IN FRONT OF APPLIANCE.
COMPONENTS REQUIRED FOR MOBILE HOME INSTALLATION: OUTSIDE AIR KIT AND ONE OF THE FOLLOWING DOUBLE WALL CONNECTOR
INCANADA: LISTEDSECURITYMODELDP,OROLIVERMACLEODPRO-VENTPVDOUBLEWALLEDCONNECTORWITH LISTEDCHIMNEYSYSTEM:SECURITYMODELS2100,
ICC EXCEL 2100, SELKIRK SENTINAL CF.
INUSA: LISTEDDOUBLEWALLCONNECTORSSECURITYMODELDP,SELKIRKMODELDS,OLIVERMACLEODPROVENTPV,SIMPSONDURAVENTMODELDVL,GSWSUPER
PIPE6,METAL-FABDOUBLEWALL. CONNECTEDTOONEOFTHEFOLLOWINGCOMPATIBLECHIMNEYSYSTEMSSECURITYMODELS2100ORMODELASHT,SELKIRKMODEL
SSII,OLIVERMACLEODPROJET3103,SIMPSONDURAPLUS,GSWMODELSCORMETAL-FABTEMP/GUARD,AMERI-TECHS, ICCEXCEL2100. USECHIMNEYCOMPONENTS
AS SPECIFIED IN INSTALLATION INSTRUCTIONS.
MEASURE FLUE
FROM HEATER CENTER-LINE
MANUFACTUREDBY: FPIFIREPLACEPRODUCTSINTERNATIONALLTD.
6988VENTUREST.
DELTA,BC V4G1H4
SIDEWALL G 380 mm / 15 in I 685 mm / 27 in
BACKWALL H 140 mm / 5.5in J 304 mm / 12 in
2003 20052004
* In Canada, floor protection must
extend 18" (450mm) to the front
and 8" (200mm) to each side and
back of the stove.

Regency Freestanding Woodstove 5
SAFETY LABEL
This is a copy of the label that accompanies
eachRegencyMediumFreestandingStepStove
(S2400M). We have printed a copy of the
contents here for your review.
NOTE: Regency units are constantly being
improved.Checkthelabelontheunitandifthere
isadifference,thelabelontheunitisthecorrect
one.
HOT WHILE IN OPERATION DO NOT TOUCH. KEEP CHILDREN,
CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE
SKIN BURNS. READ NAMEPLATE AND INSTRUCTIONS.
DO NOT REMOVE THIS LABEL
245
CERTIFIEDTOCOMPLYWITHJULY1990
PARTICULATEEMISSIONSTANDARDS.
UNITED STATES ENVIRONMENTAL
PROTECTION AGENCY
MADEINCANADA
JAN FEB MAR APR MAY JUN JUL AUG SEPT OCT NOV DEC
CAUTION
DATE OF MANUFACTURE
918-203b
rev. 10/03
LISTEDSPACE HEATER,SOLIDFUEL TYPE, ALSO
SUITABLEFORMOBILEHOMEINSTALLATION
MODEL: REGENCY MEDIUM FREESTANDINGSTEP STOVE- S2400M
TESTED TO: UL1482 / ULC S627 / UL 737 REPORTNO:219-S-02-2
THES2400MMEETSUL737STANDARDFORFIREPLACESTOVESWHENAFIRESCREENISPROVIDED.
S2400MMINIMUMCLEARANCES
TOCOMBUSTIBLEMATERIALS
RESIDENTIALINSTALLATIONUSING
SINGLE WALL CONNECTOR
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL A 406 mm / 16 in D 711 mm / 28 in
BACKWALL B 280 mm / 11 in E 444 mm / 17.5 in
CORNER C 152 mm / 6 in F 444 mm / 17.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 380 mm / 15 in D 685 mm / 27 in
BACKWALL B 140 mm / 5.5 in E 304 mm / 12 in
CORNER C 102 mm / 4 in F 393 mm / 15.5 in
SIDEWALL A 380 mm / 15 in D 685 mm / 27 in
BACKWALL B 140 mm / 5.5 in E 304 mm / 12 in
CORNER C 102 mm / 4 in F 393 mm / 15.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
MINIMUM ALCOVE CEILING HEIGHT: 2.15 M / 7 FT MAXIMUM ALCOVE DEPTH 915 MM / 36 IN.
MINIMUM CLEARANCES FOR HORIZONTAL CONNECTOR TO CEILING: 455 MM / 18"
THE SPACE BENEATH THE HEATER MUST NOT BE OBSTRUCTED. OPERATE ONLY WITH FIREBRICKS IN PLACE.
FLOOR
PROTECTION*
S2400M
INSTALLANDUSEONLYINACCORDANCEWITHTHEMANUFACTURER'SINSTALLATIONANDOPERATINGINSTRUCTIONS.
CONTACTLOCALBUILDINGORFIREOFFICIALSABOUTRESTRICTIONSANDINSTALLATIONINSPECTIONINYOURAREA.
USE 150 MM (6 IN.) DIAMETER MINIMUM 24 MSG BLACK OR 26 MSG BLUED STEEL CONNECTOR WITH LISTED UL103 HT
FACTORY-BUILTCHIMNEYSUITABLEFORUSEWITH SOLID FUELSORMASONRYCHIMNEY.
SEELOCALBUILDINGCODEANDMANUFACTURER'SINSTRUCTIONSFORPRECAUTIONSREQUIREDFORPASSINGACHIMNEY
THROUGHACOMBUSTIBLEWALLORCEILING. DONOTPASSCHIMNEYCONNECTORTHROUGHCOMBUSTIBLEWALLOR
CEILING. DONOTCONNECTTHIS UNIT TO A CHIMNEYFLUESERVINGANOTHERAPPLIANCE.
FRONT
BACK
L
K
M
SIDE
SIDE
K 405 mm / 16 in
L 150 mm / 6 in
M 150 mm / 6 in
FORUSEWITHSOLIDWOODFUELONLY. USEOFOTHERFUELS MAY DAMAGE HEATER AND CREATE A HAZARDOUSCONDITION. DONOTOBSTRUCTCOMBUSTIONAIR
OPENINGS. OPERATE ONLY WITH FIREBRICKS IN PLACE. RISK OF SMOKE AND FLAME SPILLAGE, OPERATE ONLY WITH DOORS FULLY OPEN OR FULLY CLOSED. IF
INSTALLED IN A MOBILE HOME OPERATE ONLY WITH DOORS FULLY CLOSED - OPEN FEED DOOR TO FEED FIRE ONLY. WHEN OPERATED WITH DOORS OPEN THE
MANUFACTURERSUPPLIEDSCREENMUSTBEUSED. DO NOT USE GRATEORELEVATEFIRE. BUILDWOODFIRE DIRECTLY ON HEARTH. DONOTOVERFIRE-IFHEATER
OR CHIMNEY CONNECTOR GLOWS YOU ARE OVERFIRING. INSPECT AND CLEAN CHIMNEY AND CONNECTOR FREQUENTLY. UNDER CERTAIN CONDITIONS OF USE
CREOSOTEBUILDUPMAY OCCURRAPIDLY. KEEPFURNISHINGSANDOTHERCOMBUSTIBLEMATERIAL AWAYFROMHEATER. REPLACEGLASSONLYWITHNEOCERAM
GLASS.COMBUSTIBLEFLOORMUSTBEPROTECTEDBYNON-COMBUSTIBLEMATERIALEXTENDINGBENEATHTHEHEATERANDTOTHEFRONTANDSIDESASINDICATED
ORTO THENEAREST PERMITTEDCOMBUSTIBLE MATERIAL.
OPTIONAL COMPONENT: FAN (846-515), ELECTRICAL RATING: VOLTS 115, 60 HZ, 2 AMPS, SCREEN DOOR (846-101)
DANGER: RISK OF ELECTRIC SHOCK. DISCONNECT POWER BEFORE SERVICING UNIT.
DO NOT ROUTE POWER CORD UNDER OR IN FRONT OF APPLIANCE.
COMPONENTS REQUIRED FOR MOBILE HOME INSTALLATION: OUTSIDE AIR KIT AND ONE OF THE FOLLOWING DOUBLE WALL CONNECTOR
INCANADA: LISTED SECURITY MODEL DP, OR OLIVER MACLEOD PRO-VENT PV DOUBLE WALLED CONNECTOR WITH LISTED CHIMNEY SYSTEM: SECURITY MODEL
S2100, ICC EXCEL 2100, SELKIRK SENTINAL CF.
IN USA: LISTED DOUBLE WALL CONNECTORS SECURITY MODEL DP, SELKIRK MODEL DS, OLIVER MACLEOD PRO VENT PV, SIMPSON DURA VENT MODEL DVL, GSW
SUPERPIPE6,METAL-FABDOUBLEWALL. CONNECTEDTOONEOFTHEFOLLOWINGCOMPATIBLECHIMNEYSYSTEMSSECURITYMODELS2100ORMODELASHT,SELKIRK
MODEL SSII, OLIVER MACLEOD PRO JET 3103, SIMPSON DURA PLUS, GSW MODEL SC OR METAL-FAB TEMP/GUARD, AMERI-TEC HS, ICC EXCEL 2100 . USE CHIMNEY
COMPONENTS AS SPECIFIED IN INSTALLATION INSTRUCTIONS.
MEASURE FLUE
FROM HEATER CENTER-LINE
MANUFACTUREDBY: FPIFIREPLACEPRODUCTSINTERNATIONALLTD.
6988VENTUREST.
DELTA,BC V4G1H4
SIDEWALL G 380 mm / 15 in I 685 mm / 27 in
BACKWALL H 140 mm / 5.5in J 304 mm / 12 in
2003 20052004
*In Canada, floor protection must extend
18" (450mm) to the front and 8" (200mm)
to each side and back of the stove.
