Regency F1100S Quick start guide

FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
908-288
MODELS: F1100S F2100M F3100L S2100M S3100L
FreestandingWoodstoves
01/13/03
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
MediumFreestandingStepStove
withPedestalBase.
Medium Freestanding Woodstove
withoptional GoldLegs.
Owners &
Installation Manual

Regency Freestanding Woodstove
2
Thank-youforpurchasinga
REGENCYFIREPLACEPRODUCT.
Theprideofworkmanshipthatgoesintoeachofourproductswillgiveyouyearsoftrouble-freeenjoyment. Shouldyouhave
anyquestionsaboutyourproductthatarenotcoveredinthismanual,pleasecontacttheREGENCYDEALERinyourarea.
KeepthoseREGENCYFIRESburning.
SAFETYNOTE: Ifthiswoodstoveisnotproperlyinstalled,ahousefiremayresult. Foryoursafety,followtheinstallation
instructions,contactlocalbuildingorfireofficialsaboutrestrictionsandinstallationinspectionrequirementsinyourarea.
Modular Parts

Regency Freestanding Woodstove 3
TABLE OF CONTENTS
THE REGENCY FREESTANDING STOVE
Door Handle ...................................................................... 17
Glass Installation .............................................................. 17
Optional Accessories
- Pedestal Ash Drawer Kit .......................................... 17
- Bottom Shield Ashdrawer Kit ................................... 17
- Blower/Fan ............................................................... 18
- Blower/Fan Wiring Diagram .................................... 18
OPERATINGINSTRUCTIONS
Operating Instructions....................................................... 19
Draft Control ...................................................................... 19
First Fire............................................................................. 19
Fan Operation.................................................................... 19
Ash Disposal ..................................................................... 20
- Ash Drawer Operating Guidelines........................... 20
Safety Guidelines .............................................................. 20
MAINTENANCE
Maintenance ...................................................................... 20
Creosote............................................................................ 21
- Ways to Prevent & Keep Units Free of Creosote..... 21
Maintenance of Gold Doors .............................................. 21
Latch Adjustment............................................................... 21
Door Gasket ...................................................................... 21
Glass Maintenance ........................................................... 21
- Glass Replacement................................................. 21
Parts List - F1100, F2100, F3100 ..................................... 22
Parts List - S2100, S3100 ................................................. 23
Parts List - Pedestal, Bottom Shield and Legs ................ 24
Parts List - Firebrick .......................................................... 25
WARRANTY
Warranty............................................................................. 27
SAFETYLABEL
Small Freestanding Stove F1100S ..................................... 4
Medium Freestanding Stove F2100M ................................. 5
Large Freestanding Stove F3100L ..................................... 6
Medium Freestanding Step Stove S2100M ........................ 7
Large Freestanding Step Stove S3100L............................. 8
INSTALLATION
Residential Installation ....................................................... 9
Room Air .............................................................................. 9
Modular Installation Options ............................................... 9
Minimum Clearance to Combustibles.............................. 10
Residential "C" Vent Single Wall....................................... 10
Residential Close Clearance ........................................... 10
Mobile Home Close Clearance ........................................ 10
Minimum Alcove Clearances ............................................ 11
Floor Protection ................................................................. 11
Stove Assembly Prior to Installation ................................. 12
Airmate Assembly ............................................................. 12
Rear Heat Deflector Assembly.......................................... 12
Side Shield Adjustment for the S2100 & S3100 ............... 12
Pedestal Assembly ........................................................... 12
Leg and Bottom Shield Assembly .................................... 13
Chimney & Connector Installation .................................... 13
Flue Height Table .............................................................. 14
Recommended Height for Woodstove Flue ..................... 14
Mobile Home Installation .................................................. 14
Listed Components for Mobile Home Installation
- U.S. Installations ...................................................... 15
- Canadian Installations............................................. 15
Brick Flue Baffle & Secondary Air Tube Installation
- Large Stove F3100L & S3100L................................ 15
- Medium Stove F2100M/S2100 ................................. 16
- Small Stove F1100S ................................................ 16
Brick Installation ................................................................ 17

Regency Freestanding Woodstove
4
HOT WHILE IN OPERATION DO NOT TOUCH. KEEP CHILDREN,
CLOTHINGANDFURNITUREAWAY.CONTACTMAYCAUSE
SKIN BURNS. READ NAMEPLATE AND INSTRUCTIONS.
DO NOT REMOVE THIS LABEL
FLOOR
PROTECTION*
F1100S WITH
AIRMATE SHIELD
LISTED SPACE HEATER, SOLID FUEL TYPE, ALSO
SUITABLE FOR MOBILE HOME INSTALLATION
MODEL: REGENCY SMALL FREESTANDING STOVE - F1100S
TESTED TO: CSA B366.2 / ULC S627 / UL 1482 REPORT NO.6621 (MAY 1993)
F1100S WITHOUT
AIRMATE SHIELD
INSTALL AND USE ONLY IN ACCORDANCE WITH THE MANUFACTURER'S INSTALLATION AND
OPERATINGINSTRUCTIONS. CONTACTLOCALBUILDINGORFIREOFFICIALSABOUTRESTRICTIONS
AND INSTALLATION INSPECTION IN YOUR AREA. USE 150 MM (6 IN.) DIAMETER MINIMUM 24 MSG
BLACKOR26MSGBLUEDSTEELCONNECTORWITHLISTEDFACTORY-BUILTCHIMNEYSUITABLEFOR
USE WITH SOLID FUELS OR MASONRY CHIMNEY.
SEELOCALBUILDINGCODEAND MANUFACTURER'SINSTRUCTIONS FORPRECAUTIONSREQUIRED
FOR PASSING A CHIMNEY THROUGH A COMBUSTIBLE WALL OR CEILING. DO NOT PASS CHIMNEY
CONNECTOR THROUGH COMBUSTIBLE WALL OR CEILING. DO NOT CONNECT THIS UNIT TO A
CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
FRONT
BACK
L
K
M
SIDE
SIDE
K 405 mm / 16 in
L 150 mm / 6 in
M 150 mm / 6 in
COMPONENTS REQUIRED FOR MOBILE HOME INSTALLATION: OUTSIDE AIR KIT AND ONE OF THE FOLLOWING DOUBLE WALL CONNECTOR
IN CANADA: LISTEDSECURITY MODEL DP,OR OLIVER MACLEODPRO-VENT PV DOUBLEWALLED CONNECTOR WITH LISTED CHIMNEY SYSTEM:
SECURITY MODEL S2100, ICC EXCEL 2100 .
IN USA: LISTED DOUBLE WALL CONNECTORS SECURITY MODEL DP, SELKIRK MODEL DS, OLIVER MACLEOD PRO VENT PV, SIMPSON DURA
VENT MODEL DVL, GSW SUPER PIPE 6, METAL-FAB DOUBLE WALL. CONNECTED TO ONE OF THE FOLLOWING COMPATIBLE CHIMNEY SYSTEMS
SECURITYMODELS2100ORMODELASHT,SELKIRKMODELSSII,OLIVERMACLEODPROJET3103,SIMPSONDURAPLUS,GSWMODELSCORMETAL-
FAB TEMP/GUARD, AMERI-TEC HS, ICC EXCEL 2100 . USE CHIMNEY COMPONENTS AS SPECIFIED IN INSTALLATION INSTRUCTIONS.
CERTIFIED TO COMPLY WITH JULY 1990,
PARTICULATE EMISSION STANDARDS.
UNITED STATES ENVIRONMENTAL
PROTECTION AGENCY
FORUSEWITHSOLIDWOODFUELONLY. USEOFOTHERFUELSMAYDAMAGEHEATERANDCREATEAHAZARDOUSCONDITION. DONOTOBSTRUCT
COMBUSTIONAIROPENINGS. OPERATEONLYWITHFIREBRICKSINPLACE. OPERATEONLYWITHDOORCLOSED-OPENFEEDDOORTOFEEDFIRE
ONLY. DONOTUSEGRATEORELEVATEFIRE. BUILDWOODFIREDIRECTLYONHEARTH. DONOTOVERFIRE-IFHEATERORCHIMNEYCONNECTOR
GLOWSYOUAREOVERFIRING. INSPECTANDCLEANCHIMNEYANDCONNECTORFREQUENTLY. UNDERCERTAINCONDITIONSOFUSECREOSOTE
BUILDUP MAY OCCUR RAPIDLY. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL AWAY FROM HEATER. REPLACE GLASS ONLY WITH
NEOCERAM GLASS. COMBUSTIBLE FLOOR MUST BE PROTECTED BY NON-COMBUSTIBLE MATERIAL EXTENDING BENEATH THE HEATER AND TO
THE FRONT AND SIDES AS INDICATED OR TO THE NEAREST PERMITTED COMBUSTIBLE MATERIAL.
OPTIONAL COMPONENT: FAN, ELECTRICAL RATING: VOLTS 115, 60 HZ, 2 AMPS
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS
F1100S WITH AIRMATE SHIELD F1100S WITHOUT AIRMATE SHIELD
RESIDENTIALINSTALLATION USING
SINGLE WALL CONNECTOR
MEASURE FLUE
FROM HEATER CENTER-LINE
RESIDENTIALINSTALLATION USING
SINGLE WALL CONNECTOR
SIDEWALL A 380 mm /15 in D 685 mm / 27 in
BACKWALL B 265 mm / 10.5in E 430 mm / 17 in
CORNER C 280 mm / 11 in F 585 mm / 23 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 330 mm / 13 in D 635 mm / 25 in
BACKWALL B 125 mm / 5 in E 290 mm / 11.5in
CORNER C 230 mm / 9 in F 535 mm / 21 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
SIDEWALL A 345 mm / 13.5in D 650 mm / 25.5in
BACKWALL B 125 mm / 5 in E 290 mm / 11.5in
CORNER C 125 mm / 5 in F 430 mm / 17 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL A 330 mm / 13 in D 635 mm / 25 in
BACKWALL B 280 mm / 11 in E 445 mm / 17.5in
CORNER C 205 mm / 8 in F 510 mm / 20 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 280 mm / 11 in D 585 mm / 23 in
BACKWALL B 150 mm / 6 in E 320 mm / 12.5in
CORNER C 150 mm / 6 in F 460 mm / 18 in
SIDEWALL A 230 mm / 9 in D 535 mm / 21 in
BACKWALL B 125 mm / 5 in E 290 mm / 11.5in
CORNER C 75 mm / 3 in F 380 mm / 15 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
SIDEWALL G 280 mm / 11 in I 585 mm / 23 in
BACKWALL H 180 mm / 7 in J 345 mm / 13.5in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL G 330 mm / 13 in I 635 mm / 25 in
BACKWALL H 125 mm / 5 in J 290 mm / 11.5in
MINIMUM ALCOVE CEILING HEIGHT: 2.15 M / 7 FT MAXIMUM ALCOVE DEPTH 915 MM / 36 IN.
MINIMUM CLEARANCES FOR HORIZONTAL CONNECTOR TO CEILING: 455 MM / 18"
THE SPACE BENEATH THE HEATER MUST NOT BE OBSTRUCTED. OPERATE ONLY WITH FIREBRICKS IN PLACE.
MEASURE FLUE
FROM HEATER CENTER-LINE
MADE IN CANADA
JAN FEB MAR APR MAY JUN JUL AUG SEPT OCT NOV DEC
A
D
BACKWALL
SIDEWALL
BE
GG
I
BACKWALL
SIDEWALL
SIDEWALL
HJ
F
ADJACENT WALL
SIDEWALL
C
CAUTION
DATE OF MANUFACTURE
2001 2003
2002
WD
908-281 01/03
MANUFACTURED BY: FIREPLACE PRODUCTS INTERNATIONAL LTD.
6988 VENTURE ST.
DELTA, BC V4G 1H4
100
100
* In Canada, floor protection must
extend 18" to the front and 8" to
each side of the stove.
This is a copy of the label that accompanies
each Regency Small Freestanding Woodstove
(F1100S). It is located in the upper right corner
ofthebackofthestove.Wehaveprintedacopy
of the contents here for your review.
SAFETY LABEL
NOTE: Regency units are constantly being
improved.Checkthelabelontheunitandifthere
isadifference,thelabelontheunitisthecorrect
one.

Regency Freestanding Woodstove 5
This is a copy of the label that accompanies
each Regency Medium Freestanding Wood-
stove (F2100M). It is located in the upper right
SAFETY LABEL
NOTE: Regency units are constantly being
improved.Checkthelabelontheunitandifthere
isadifference,thelabelontheunitisthecorrect
one.
HOT WHILE IN OPERATION DO NOT TOUCH. KEEP CHILDREN,
CLOTHINGANDFURNITUREAWAY.CONTACTMAYCAUSE
SKIN BURNS. READ NAMEPLATE AND INSTRUCTIONS.
DO NOT REMOVE THIS LABEL
101
CERTIFIED TO COMPLY WITH JULY 1990,
PARTICULATE EMISSION STANDARDS.
UNITED STATES ENVIRONMENTAL
PROTECTION AGENCY
MADE IN CANADA
JAN FEB MAR APR MAY JUN JUL AUG SEPT OCT NOV DEC
CAUTION
DATE OF MANUFACTURE
WD
908-282
rev. 01/03
LISTED SPACE HEATER, SOLID FUEL TYPE, ALSO
SUITABLE FOR MOBILE HOME INSTALLATION
MODEL: REGENCY MEDIUM FREESTANDING STOVE - F2100M
TESTED TO: CSA B366.2 / ULC S627 / UL 1482 REPORT NO.6622 (FEB.1993)
MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS
F2100M WITH AIRMATE SHIELD F2100M WITHOUT AIRMATE SHIELD
RESIDENTIALINSTALLATION USING
SINGLE WALL CONNECTOR
MEASURE FLUE
FROM HEATER CENTER-LINE
RESIDENTIALINSTALLATION USING
SINGLE WALL CONNECTOR
SIDEWALL A 430 mm / 17 in D 735mm / 29in
BACKWALL B 280 mm / 11 in E 445mm / 17.5in
CORNER C 230 mm / 9 in F 535 mm / 21 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 460 mm / 18 in D 775 mm / 30.5 in
BACKWALL B 215 mm / 8.5in E 395 mm / 15.5in
CORNER C 215 mm / 8.5in F 535 mm / 21 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
SIDEWALL A 355 mm / 14 in D 675 mm / 26.5in
BACKWALL B 180 mm / 7 in E 355 mm / 14 in
CORNER C 215 mm / 8.5in F 535 mm / 21 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL A 355 mm / 14 in D 660 mm / 26 in
BACKWALL B 255 mm / 10 in E 420 mm / 16.5 in
CORNER C 190 mm / 7.5 in F 510 mm / 20 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - MOBILE HOME
SIDEWALL A 405 mm / 16 in D 725 mm / 28.5in
BACKWALL B 215 mm / 8.5in E 395 mm / 15.5in
CORNER C 190 mm / 7.5in F 510 mm / 20 in
SIDEWALL A 255 mm / 10 in D 550 mm / 22.5 in
BACKWALL B 115 mm / 4.5 in E 290 mm / 11.5 in
CORNER C 150 mm / 6 in F 445 mm / 17.5 in
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - RESIDENTIAL CLOSE CLEARANCE
INSTALLATION USING LISTED DOUBLE WALL
CONNECTOR - ALCOVE
SIDEWALL G 355 mm / 14 in I 675 mm / 26.5in
BACKWALL H 180 mm / 7 in J 355 mm / 14 in
MINIMUM ALCOVE CEILING HEIGHT: 2.15 M / 7 FT MAXIMUM ALCOVE DEPTH 915 MM / 36 IN.
MINIMUM CLEARANCES FOR HORIZONTAL CONNECTOR TO CEILING: 455 MM / 18"
THE SPACE BENEATH THE HEATER MUST NOT BE OBSTRUCTED. OPERATE ONLY WITH FIREBRICKS IN PLACE.
FLOOR
PROTECTION*
F2100M WITHOUT
AIRMATE SHIELD
F2100M WITH
AIRMATE SHIELD
INSTALLANDUSEONLYINACCORDANCEWITHTHEMANUFACTURER'SINSTALLATIONANDOPERATING
INSTRUCTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION IN YOUR AREA. USE 150 MM (6 IN.) DIAMETER MINIMUM 24 MSG BLACK OR
26 MSG BLUED STEEL CONNECTOR WITH LISTED FACTORY-BUILT CHIMNEY SUITABLE FOR USE WITH
SOLID FUELS OR MASONRY CHIMNEY.
SEE LOCAL BUILDING CODE AND MANUFACTURER'S INSTRUCTIONS FOR PRECAUTIONS REQUIRED
FOR PASSING A CHIMNEY THROUGH A COMBUSTIBLE WALL OR CEILING. DO NOT PASS CHIMNEY
CONNECTORTHROUGHCOMBUSTIBLEWALLORCEILING. DO NOTCONNECTTHISUNITTOACHIMNEY
FLUE SERVING ANOTHER APPLIANCE.
FRONT
BACK L
K
M
SIDE
SIDE
K 405 mm / 16 in
L 150 mm / 6in
M 150 mm / 6in
FORUSEWITHSOLIDWOODFUELONLY. USEOFOTHERFUELSMAYDAMAGEHEATERANDCREATEAHAZARDOUSCONDITION. DONOTOBSTRUCT
COMBUSTIONAIROPENINGS. OPERATEONLYWITHFIREBRICKSINPLACE. OPERATEONLYWITHDOORCLOSED-OPENFEEDDOORTOFEEDFIRE
ONLY. DONOTUSEGRATEORELEVATEFIRE. BUILDWOODFIREDIRECTLYONHEARTH. DONOTOVERFIRE-IFHEATERORCHIMNEYCONNECTOR
GLOWSYOUAREOVERFIRING. INSPECTANDCLEANCHIMNEYANDCONNECTORFREQUENTLY. UNDERCERTAINCONDITIONSOFUSECREOSOTE
BUILDUP MAY OCCUR RAPIDLY. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL AWAY FROM HEATER. REPLACE GLASS ONLY WITH
NEOCERAM GLASS. COMBUSTIBLE FLOOR MUST BE PROTECTED BY NON-COMBUSTIBLE MATERIAL EXTENDING BENEATH THE HEATER AND TO
THE FRONT AND SIDES AS INDICATED OR TO THE NEAREST PERMITTED COMBUSTIBLE MATERIAL.
OPTIONAL COMPONENT: FAN, ELECTRICAL RATING: VOLTS 115, 60 HZ, 2 AMPS
COMPONENTS REQUIRED FOR MOBILE HOME INSTALLATION: OUTSIDE AIR KIT AND ONE OF THE FOLLOWING DOUBLE WALL CONNECTOR
IN CANADA: LISTED SECURITY MODEL DP, OR OLIVER MACLEOD PRO-VENT PV DOUBLE WALLED CONNECTOR WITH LISTED CHIMNEY SYSTEM:
SECURITY MODEL S2100, ICC EXCEL 2100.
IN USA: LISTED DOUBLE WALL CONNECTORS SECURITY MODEL DP, SELKIRK MODEL DS, OLIVER MACLEOD PRO VENT PV, SIMPSON DURA
VENT MODEL DVL, GSW SUPER PIPE 6, METAL-FAB DOUBLE WALL. CONNECTED TO ONE OF THE FOLLOWING COMPATIBLE CHIMNEY SYSTEMS
SECURITYMODELS2100ORMODELASHT,SELKIRKMODELSSII,OLIVERMACLEODPROJET3103,SIMPSONDURAPLUS,GSWMODELSCORMETAL-
FAB TEMP/GUARD, AMERI-TEC HS, ICC EXCEL 2100 . USE CHIMNEY COMPONENTS AS SPECIFIED IN INSTALLATION INSTRUCTIONS.
MEASURE FLUE
FROM HEATER CENTER-LINE
A
D
BACKWALL
SIDEWALL
BE
GG
I
BACKWALL
SIDEWALL
SIDEWALL
HJ
F
ADJACENT WALL
SIDEWALL
C
MANUFACTURED BY: FIREPLACE PRODUCTS INTERNATIONAL LTD.
6988 VENTURE ST.
DELTA, BC V4G 1H4
SIDEWALL G 255 mm / 10 in I 570 mm / 22.5in
BACKWALL H 115 mm / 4.5in J 290 mm / 11.5in
2001 20032002
* In Canada, floor protection must
extend 18" to the front and 8" to
each side of the stove.
cornerofthebackofthestove.Wehaveprinted
a copy of the contents here for your review.
