In 1979, I founded Regency Fireplace
Products with a mission to produce the
nest replace products available any-
where. As a result, Regency has been
honored with awards for exceptional
aesthetics and performance. It is known
as the premium brand in the industry.
There are so many reasons to choose a
Regency, I would like to share a few with
you.
Save money… Zone heat
Never before have home heating costs
b e e n high e r. Turn your f urna ce way d ow n
and zone heat with beautiful, renewable
wood in the rooms you spend time in.
Not only can you cut your fuel bills in half
but you will be able to enjoy the timeless
joy of a wood re. The glowing embers,
the snap of wood as it catches re, the ca-
sual curl of yellow ames, there is nothing
like a wood re.
Environmentally Friendly
All Regency Wood Stoves, Fireplaces and
Inserts have been certied by the
Environmental Protection Agency (EPA).
Regency engineers have carefully de-
signedthereboxtocreateairowaround
the wood so that it burns completely,
resulting in very little ash and almost no
polluting smoke into our environment.
Burning wood is also carbon neutral.
Regency Quality
The Regency name means quality in ev-
ery way. I am supported by an excep-
tional team, state of the art research and
a world class manufacturing facility. We
have carefully selected a dealer network
that is committed to your satisfaction.
Lifetime Warranty
I am so condent in the quality work-
manship, the nest materials, and du-
rable heavy-duty construction invested
in each and every product, that I oer a
Limited Lifetime Warranty. We know that
you will be as proud of your Regency
Wood Stove, Fireplace or Insert as we are
– I guarantee it.
Robert Little
Founder & CEO
why choose Regency?
2

index
Regency Classic Wood Stoves
F1100, F2400, F3100 6
S2400 8
Rgency Wood Fireplaces
R90 & EX90 10
Regency Classic Wood Inserts
I1200 12
I2400 & I3100 14
Hearth Heater 16
Design Choices 18
Technicalspecs 20
3

renewable aordable beautiful
4

Wood is aordable
Reduce your dependence on high priced, non-renewable
home heating fuels by burning wood. Turn your furnace
down and enjoy comforting warmth in your main living area
with a Regency wood product. Whether you buy your wood
or collect it yourself, you will notice the savings within its rst
year.
Renewable Resource
Wood is a renewable natural resource - well-managed forests
are a renewable, sustainable source of energy that helps us
reduce greenhouse gas emissions and be less dependent on
oil & gas.
Wood is Carbon Neutral
As trees grow they absorb carbon dioxide from the atmo-
sphere. When trees die and are left to decompose in the for-
est or burn in forest res the carbon stored in the trees is re-
leased in the atmosphere as carbon dioxide.
Burning rewood produces the same amount of carbon di-
oxide as it has absorbed during its life cycle - making wood
burning carbon neutral.
All Regency Wood Stoves, Fireplaces and Inserts have been
tested and certied to the strictest clean air standards as set
by the Environmental Protection Agency.
One Regency = One Tree
At Regency, we are committed to protecting our environ-
ment. For every Regency sold, we will plant a tree. Working
withAmericanForests,thetreesplantedacrossNorthAmerica
will oset carbon emissions and take one more step to restore
nature's balance.
burning wood - a green choice
5

6
F2400 with black legs, gold accent door, convector airmate and bottom heat shield.
The timeless styling of the Classic Wood Stove comes in three sizes
producing from 55,000 to 80,000 BTU of toasty warmth for a single
living area or an entire home. Up to 77% eciency means any room
can be heated quickly. It also means your wood stove burns clean-
ly meeting the strictest air quality standards set by DEQ Washington
Phase II Clean Air Standard of 4.5 grams/hr. or less.
Classic Wood Stove
F1100, F2400, F3100

7
F2400 with gold door, gold legs, convector airmate and bottom heat shield.
F2400 with black door, brushed nickel legs, convector airmate, bottom heat shield,
nickel hinge caps and handles.
F2400 with black door and pedestal.
Standard Features Optional Features
EPA Certifiedw
Mobile home and alcove approvedw
Closest clearances in the industryw
Single rod draft controlw
Brick-lined fireboxw
Airwash systemw
Rear heat deflectorw
Cast iron door in gold, black**, gold accent orw
nickel accent
Nickel hinge caps and handle (for black doorw
upgrade)
Cast iron legs in gold, black or brushed nickelw
Pedestal basew
Bottom heat shield (when using legs)w
Ash drawerw
2-speed blowerw
Convector airmatew
Outside air kitw
Screen doorw
Specifications
F1100 F2400 F3100
Maximum BTU* 55,000 75,000 80,000
Typical Sq. Ft. Heated 600-1200 1000-2200 2000-3500
Optimum Efficiency 73.8% 77% 71%
Maximum Log Size 18" 18" 21"
Burn Time (Typical)* up to 8 hrs up to 8 hrs up to 10 hrs
Emissions (grams/hr) 3.0g 3.4g 4.2g
Firebox Size 1.4 cu. ft. 2.3 cu. ft. 2.9 cu. ft.
Flue Size 6" 6" 6"
* Length of burn time and BTU range depend on type of wood, mois-
ture content, climate conditions and installation.
** Black doors come with gold handles & gold hinge caps
For detailed specications please see pages 18-23.

8
S2400 shown with gold door and pedestal base.
The special design of the Step Top Classic makes it possible for it to
be placed close to a corner of the wall. This makes it ideal for a small
room or for installation in tight alcoves. All Regency wood products
come with an optional two speed blower to help deliver high e-
ciency heat to the far reaches of your home.
Classic S2400
Step Top Wood Stove

9
S2400 with black door and pedestal base. S2400 with gold accent door and pedestal base.
S2400 with nickel accent door and pedestal base.
Standard Features Optional Features
EPA Certifiedw
Mobile home and alcove approvedw
Lowest clearances in the industryw
Single rod draft controlw
Brick-lined fireboxw
Airwash systemw
Cast iron door in gold, black**, gold accent orw
nickel accent
Nickel hinge caps and handle (for black doorw
upgrade)
Cast iron legs in gold, brushed nickel or blackw
Pedestal basew
Ash drawerw
Bottom heat shield (when using legs)w
2-speed blowerw
Outside air kitw
Screen doorw
Specifications
S2400
Maximum BTU* 75,000
Typical Sq. Ft. Heated 1000-2200
Optimum Efficiency 77%
Maximum Log Size 18"
Burn Time (Typical)* up to 8 hrs
Emissions (grams/hr) 3.4g
Firebox Size 2.3 cu. ft.
Flue Size 6"
* Length of burn time and BTU range depend on
type of wood, moisture content, climate condi-
tions and installation.
** Black doors come with gold handles & gold hinge
caps

10
R90 featuring black louvers.
Regency’s high eciency replaces put a designer face on a hard
working heater. Just load up your Regency and tuck in for a cozy
night’s sleep. Delivering up to 70,000 BTU of high eciency heat,
your Regency will burn for up to 8 hours while your rest. Choose a tra-
ditional design (R90) or an arched Excalibur front (EX90) with tasteful
accessory options to create the perfect furnace with a view!
R90 & EX90
Wood Fireplaces

11
R90 featuring black with steel louvers.R90 featuring black louvers and gravity air kit.EX90 shown with Excalibur front in black.
EX90 shown with Excalibur front in antique nickel.
Standard Features Optional Features
EPA Certifiedw
Single rod draft controlw
Airwash systemw
Black cast iron double doorsw
Ceramic safety glassw
Brick-lined fireboxw
Andironsw
Outside air kitw
Black/gold, black/brushed steel or black lou-w
vers (R90)
Excalibur front in black or antique nickelw
Blowerw
Ash drawerw
Finishing trim (R90)w
Gravity air kitw
Masonry retainer kit (R90)w
8" - 7" flue adaptorw
(Canada only)
8" Air cooled chimney adaptors (US only)w
Screen doorw
Specifications
R90 EX90
Maximum BTU* 70,000 70,000
Typical Sq. Ft. Heated 1,000-2,200 1,000-2,200
Optimum Efficiency 74% 74%
Maximum Log Size 20" 20"
Burn Time (Typical)* up to 8 hrs. up to 8 hrs.
Emissions (grams/hr) 3.72g 3.72g
Firebox Size 2.5 cu. ft. 2.5 cu. ft.
Flue Size 8" 8"
* Length of burn time and BTU range depend on type of wood, moisture
content, climate conditions and installation.

12
Regency I1200, with nickel accent door, regular faceplate and blower.
For that drafty replace that isn’t quite big enough for a standard
insert, or for that area in your house that invites a compact style of
replace, look to the Regency Classic Small Insert. With all the high
eciency, clean burning, quality features of all Regency wood prod-
ucts, this insert adapts to t most prefab replaces.
Classic I1200
Small Wood Insert

13
I1200 with black door, regular faceplate and blower.I1200 with gold door, regular faceplate and blower.
I1200 with gold accent door, regular faceplate and blower.
Standard Features Optional Features
EPA Certifiedw
Single rod draft controlw
Airwash systemw
Brick-lined fireboxw
Cast iron door in gold, black**, gold accentw
or nickel accent
Nickel hinge caps and handle (for black doorw
upgrade)
Regular or oversize faceplate (black trimw
included)
2-speed blowerw
Screen doorw
Brass faceplate trimw
Regency stainless steel flex liner kitw
Bottom 1 piece faceplate & fan supportw
Standard or 4-1/2" offset flue adaptorw
Specifications
I1200
Maximum BTU* 55,000
Typical Sq. Ft. Heated 600-1000
Optimum Efficiency 73.8%
Maximum Log Size 18"
Burn Time (Typical)* up to 8 hrs.
Emissions (grams/hr) 3.0g
Firebox Size 1.4 cu. ft.
Flue Size 6"
Minimum Fireplace Opening
Width 23"
Height 19"
Depth (with standard adaptor) 13-3/4"
* Length of burn time and BTU range depend on type of
wood, moisture content, climate conditions and instal-
lation.
** Black doors come with gold handles & gold hinge caps

14
Regency I2400 with nickel accent door, nickel convection grills, regular faceplate and blower.
Your open masonry replace can allow as much as 90% of your
re’s heat to escape out the chimney. By adding a Regency Classic
Fireplace Insert, you will keep the heat in your home. Regency Inserts
are ready to install and t easily into your existing replace. Increase
the value of your home and decrease your monthly heating bill.
Classic I2400 & I3100
Medium & Large Wood Insert

15
I2400 with gold door, gold convection grills, regular faceplate, brass faceplate trim
and blower.
I2400 with black door, gold convection grills, brass faceplate trim and blower.
I2400 with gold accent door, gold convection grills, brass faceplate trim and blower.
Standard Features Optional Features
EPA Certifiedw
Single rod draft controlw
Airwash systemw
Brick-lined fire boxw
Black convection grillsw
Mobile home approved (I2400 only)w
Cast iron door in gold, black**, gold accent orw
nickel accent
Nickel hinge caps and handle (for black doorw
upgrade)
Gold or nickel convection grillsw
Regular or oversize faceplate (black trimw
included)
Screen doorw
Brass faceplate trimw
Regency stainless steel flex liner kitw
2-speed blowerw
Specifications
I2400 I3100
Maximum BTU* 75,000 80,000
Typical Sq. Ft. Heated 1000-2000 1800-3000
Optimum Efficiency 77% 71%
Maximum Log Size 18" 21"
Burn Time (Typical)* up to 8 hrs up to 10 hrs
Emissions (grams/hr) 3.4g 4.2g
Firebox Size 2.3 cu. ft. 2.9 cu. ft.
Flue Size 6" 6"
Minimum Fireplace Opening
Width 25" 28"
Height 21-1/2" 25"
Depth 17" 17"
* Length of burn time and BTU range depend on type of wood, mois-
ture content, climate conditions and installation.
** Black doors come with gold handles & gold hinge caps

16
Hearth Heater H2100, with black door, regular faceplate and two speed blower.
The Hearth Heater combines the best qualities of the Classic Stove
and Insert series. It eliminates the cold draft of an open replace and,
because it sits out on the hearth, gives you both convective and radi-
ant heat. Build a custom look for your Regency with leg and door op-
tions. Like all Regency products, the Hearth Heater operates during
power outages, providing a convenient cooktop surface as well.
Classic Hearth Heater
HI2100 Wood Insert

17
H2100 with regular faceplate, gold accent door and blower.H2100 with gold door, regular faceplate, brass faceplate trim and blower.
H2100 with regular faceplate, nickel accent door and blower.
Standard Features Optional Features
EPA Certifiedw
Single rod draft controlw
Airwash systemw
Brick-lined fireboxw
Convector airmate (built-in)w
Cast iron door in gold, black**, gold accent orw
nickel accent
Nickel hinge caps and handle (for black doorw
upgrade)
Cast iron legs in gold, black or brushed nickelw
(see diagram on p.22)
Regular or oversize faceplate (black trimw
included)
Brass faceplate trimw
Regency stainless steel flex liner kitw
2-speed blowerw
Specifications
H2100
Maximum BTU* 70,000
Typical Sq. Ft. Heated 800-1500
Optimum Efficiency 72%
Maximum Log Size 18"
Burn Time (Typical)* up to 8 hrs
Emissions (grams/hr) 3.5g
Firebox Size 1.6 cu. ft.
Flue Size 6"
Minimum Fireplace Opening
Width 8"
Height 20"
Depth -
* Length of burn time and BTU range depend on type of wood,
moisture content, climate conditions and installation
** Black doors come with gold handles & gold hinge caps

Convector Airmate
Directs convection heat
into your room. Allows
closer clearances.
Firebox
Airtight and lined with firebrick
to ensure wood is burned
completely to deliver clean
efficient heat.
Side Shields
Insulates stove to prevent heat
loss and allows convective air to
be warmed against side of stove.
Single Rod Draft Control
Simple and easy to control
heat output and size of fire.
Heavy Gauge Steel
Used throughout the stove to ensure
long term durability and increase radi-
ant heat.
Stainless Steel Air Tubes
Injects secondary air into firebox
to create reburn. Provides cleaner,
more complete combustion.
Heavy Duty Cam Latch
Ensures airtight seal for controlled
airflow.
Heavy Duty Hinge Pins
To ensure long term durability.
Ceramic Safety Glass
Tested and certified to withstand very
high temperatures. Allows heat to
radiate through the glass.
Airwash System
Engineered to keep your glass clean
automatically by creating airflow across
inside of glass. Stove must burn at
maximum for 30 minutes for Airwash to
occur.
Heat Reflective Baffle
Designed to reflect heat
back into the firebox to
enhance reburn. Improves
temperature distribution and
efficiency of the firebox.
Removable Ash Drawer
For safe and easy clean up.
Fits seamlessly into design
of stove.
Exhaust
Non-catalytic Technology
Regency uses non-catalytic technology which
means that the airflow in the firebox is directed
in such a way that smoke is reburned. This cre-
ates greater efficiency, a spectacular fire and
results in cleaner emissions.
By combining non-catalytic technology with
durable construction, Regency builds wood
fireplaces that are guaranteed to last. These
stove and insert diagrams illustrate the airflow
and durable components that make Regency
your heating solution.
Limited Lifetime Warranty
All Regency products are warrantied
for a lifetime of great looks, ease of
useandsuperbperformance.Ask
your Regency dealer for details.
Inside your Regency Wood Stove
18

Powerful Blower
The blower can dramatically increase the circulation
of heat in your home. It includes dual speed set-
tings and an automatic heat sensor which turns
the blower on and o at predetermined tempera-
tures.
1. Open door 2. Pull out drawer 3. Slide cover on top 4. Carry away Leg Ash Drawer
A compact ash drawer
system is also featured
on the leg version.
Convenient Ash Removal System
24 Karat Gold Plated Cast Iron Legs Brushed Nickel Cast Iron Legs Black Cast Iron Legs Black Pedestal
Base Options
Cast Iron Doors
Black Cast Iron Door Gold Cast Iron Door Gold Accent Cast Iron Door Nickel Accent Cast Iron Door
Convector Airmate
The convector airmate scoops super heated air
from the back and top of the stove and directs it
to the living area in front. This heat dispersion re-
duces temperatures behind the unit and allows it
to be installed even closer to the wall.
Screen Doors
For wood stoves and inserts. For R90 & EX90 wood fireplaces
Options
19

A
F
F
C
C
BE
6"
6"
6"
6"
16"
16"
D
G
K
HJ
I
Residential Installation “C” Vent (Single Wall) FROM UNIT FROM CORNER FROM FLUE CENTER-LINE
A B C D E F
Small F1100 with AirMate 13" 11" 8" 25" 17.5" 20"
with Rear Deflector 15" 10.5" 11" 27" 17" 23"
Medium S2400 with Step Top 16" 11" 6" 28" 17.5" 17.5"
Medium F2400 with AirMate 16" 11" 6" 28" 17.5" 17.5"
with Rear Deflector 18" 12" 6.5" 30" 18.5" 19.5"
Large F3100 with AirMate 18" 12" 8.5" 32" 18.5" 22"
with Rear Deflector 20" 14" 10.5" 34" 20.5" 24"
These clearances are certified clearances for the stove, however, the clearance to the combustibles and the single wall stove pipe must also be
maintained. You can reduce the stove pipe clearance with a stove pipe heat shield.
Minimum Clearance to Combustible Materials
Please read the section below carefully as clearances depend on
whether the optional airmate convector or the rear heat deflector
is installed on the stove. Measurements “From Unit” are from the
top plate of the stove to a side wall or to a corner, and from the
rear heat shield to a back wall.
Residential Close Clearance (To be installed with required pipe components)
When the stove is installed as a close clearance residential unit, a listed double wall connector is
required from the stove collar to the ceiling level.
Residential Close Clearance FROM UNIT FROM CORNER FROM FLUE CENTER-LINE
(To be installed with required pipe components) A B C D E F
Small F1100 with AirMate 9" 5" 3" 21" 11.5" 15"
with Rear Deflector 13.5" 5" 5" 25.5" 11.5" 17"
Medium S2400 with Step Top 15" 5.5" 4" 27" 12" 15.5"
Medium F2400 with AirMate 15" 5.5" 4" 27" 12" 15.5
with Rear Deflector 15" 6.5" 6" 27" 13" 17.5"
Large F3100 with AirMate 16" 9.5" 8.5" 30" 16" 22"
with Rear Deflector 20" 12" 8.5" 34" 18.5" 22"
Mobile Home Close Clearance (To be installed with required pipe components)
“C” Vent single wall pipe is not approved for mobile home installations. (Refer to mobile home instruc-
tions)
Mobile Home Close Clearance FROM UNIT FROM CORNER FROM FLUE CENTER-LINE
(To be installed with required pipe components) A B C D E F
Small F1100 with AirMate 11" 6" 6" 23" 12.5" 18"
with Rear Deflector 13" 5" 9" 25" 11.5" 21"
Medium S2400 with Step Top 15" 5.5" 4" 27" 12" 15.5"
Medium F2400 with AirMate 15" 5.5" 4" 27" 12" 15.5"
with Rear Deflector 15" 6.5" 6" 27" 13" 17.5"
Large F3100 with AirMate 18" 9.5" 10" 32" 16" 23.5"
with Rear Deflector 20" 12" 10" 34" 18.5" 23.5"
Minimum Alcove Clearance to Combustible Materials
The Regency®Freestanding models have been alcove approved and must be installed with a
listed double wall connector to the ceiling level.
Note: Minimum alcove ceiling height - 84 in. / Maximum depth of alcove - 36 in.
Minimum Alcove Clearance FROM UNIT FROM FLUE CENTER-LINE MIN. WIDTH
G H I J K
Small F1100 with AirMate 11" 7" 23" 13.5" 46"
with Rear Deflector 13" 5" 25" 11.5" 50"
Medium S2400 with Step Top 15" 5.5" 27" 12" 54"
Medium F2400 with AirMate 15" 5.5" 27" 12" 54"
with Rear Deflector 15" 6.5" 27" 13" 54"
Large F3100 with AirMate 16" 9.5" 30" 16" 60"
with Rear Deflector not approved for Alcove
FRONT WITH
PEDESTAL
B
A
DC
B
E
Dimensions A** BC*** DE**
Small F1100 30-1/4" 24" 20" 6" 31-3/4"
Medium F2400 32-1/16" 24" 27-3/8" 6" 33-1/2"
Large F3100 33-5/16" 28" 25-1/4" 6" 34-3/4"
Medium S2400 34-3/8" 24" 27-3/8" 6" 35-7/8"
**Measured to top of flue collar for height
***Including Ash Lip
B
A
DC
B
E
B
A
DC
B
E
FRONT WITH LEGS
TOP
Classic Stoves
Flat Top Step Top
F1100 F2400 F3100 S2400
Small Stove Medium Stove Large Stove Medium Stove
Maximum BTU* 55,000 75,000 80,000 75,000
Typical Sq. Ft. Heated 600-1200 1000-2200 2000-3500 1000-2200
Optimum Efficiency 73.8% 77% 71% 77%
Maximum Log Size 18" 18" 21" 18"
Burn Time (Typical)* up to 8 hrs up to 8 hrs up to 10 hrs up to 8 hrs
Emissions (grams/hr) 3.0g 3.4g 4.2g 3.4g
Firebox Size 1.4 cu. ft. 2.3 cu. ft. 2.9 cu. ft. 2.3 cu. ft.
Flue Size 6" 6" 6" 6"
* Length of burn time and BTU range depend on type of wood, climate conditions and installation.
Specications - Wood Stoves
