Mobilizer Norbert
Instructions for use
Instructions for use
Mobilizer Norbert
Table of contents Information
on the instructions for use
Manufacturer
Reha & Medi Hoffmann GmbH
Debyestraße 5
04329 Lei zig
Germany
Tel. +49 341 / 39284960
SRN: DE-MF-000007034
www.rehamedi.de
Version: 5
Date of issue: 02.05.2023
Language: English
Validity range: Mobilizer Norbert
Article number: 5020409
1. Preface and general information .....................3
1.1 Co yright.........................................................4
1.2 Disclaimer........................................................4
1.3 Denition of grou s of ersons .......................5
2. Descri tion and ur ose.................................6
2.1 Indication.........................................................7
2.2 Contraindication ..............................................7
3. Permissible o erating conditions/ lace of use8
4. Dimensions......................................................8
5. Safety instructions...........................................9
5.1 Ex lanation of symbols and notes ..................9
5.2 Basic safety information..................................9
5.4 Products mechanical adjustment..................12
5.5 Products with battery ....................................12
6. Height adjustment .........................................12
6.1 Hydromechanical height adjustment.............12
6.2 Electromotive height adjustment...................13
7. Backrest adjustment .....................................13
8. Hand control* ................................................13
9. Main switch* ..................................................13
10. Transfer..........................................................14
10.1 Horizontal transfer.........................................14
10.2 Sitting transfer ...............................................14
11. Armrests ........................................................15
Locking the armrests.....................................15
12. Footste ........................................................15
12.1 with electric footrest adjustment ..................15
12.2 with manual footrest adjustment...................16
13. Driving and braking .......................................16
14. Battery change*.............................................17
15. Equi ment o tions ........................................18
15.1 Headrest, xing .............................................18
15.2 Table with u holstery.....................................18
15.3 Locking the armrests in lace ........................18
15.4 Side bar ..........................................................18
15.5 Stra s............................................................19
15.6 Infusion stand................................................19
15.7 Battery...........................................................19
16. Warranty ........................................................20
17. Dis osal.........................................................20
18. Product life ....................................................20
19. Technical data ...............................................20
19.1 IP rotection classes & tem erature ranges 21
19.2 The ty e late................................................22
3
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
1. Preface and general information
Dear customer,
Thank you for choosing a roduct from Reha & Medi Hoffmann GmbH. These instructions
for use rovide you with all the im ortant information and notes on the Mobilizer Norbert.
Furthermore, it is intended to make it easier for you to get to know the Mobilizer Norbert
and to give you instructions for its ro er use and safe o eration.
Please read these instructions carefully and completely before starting up and using
your Mobilizer Norbert. Keep them handy for future reference.
All directions are indicated looking from the back of the roduct in the direction of travel, as
shown in Fig. 1.
If, des ite careful study, further information is required, lease do not hesitate to contact us.
You will nd our contact details at the beginning of these instructions for use.
You can find all documents in digital form online at www.rehamedi.de.
Fig. 1: Basis for direction/page references
LEFT RIGHT
DIRECTION OF TRAVEL
Instructions for use Mobilizer Norbert
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
1.1 Copyright
These o erating instructions, including all their arts and illustrations, are rotected by co-
yright. The rights to translation, re rinting, extraction of ictorial re resentations as well as
re roduction and storage in data rocessing systems are reserved, even if only excer ts are
used. The use in lectures or ublication in media, in articular in ublications, also in ex-
tracts, requires the rior written consent of Reha & Medi Hoffmann GmbH.
1.2 Disclaimer
Understanding, observing and com lying with these instructions for use is absolutely es-
sential for atient safety and the safety of users as well as the trouble-free o eration of the
roducts of Reha & Medi Hoffmann GmbH. Reha & Medi Hoffmann GmbH does not assume
any warranty or liability for direct or indirect damage resulting from unauthorised modica-
tions to the roduct or failure to observe these instructions for use.
The roducts of Reha & Medi Hoffmann GmbH may only be used in conjunction with equi -
ment o tions a roved by the manufacturer as s ecied in the instructions for use.
Any combination of the roduct with other roducts, in articular with medical roducts, as
well as any technical modication to the roduct is generally not ermitted. Exce tions re-
quire the written a roval of the manufacturer.
Des ite careful checking, errors in this document cannot be com letely ruled out. We reser-
ve the right to make technical or content-related changes at any time without rior notice.
Documents in rinted form are not subject to a change service.
5
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
1.3 Definition of groups of persons
For reasons of better readability, the simultaneous use of the language forms male, female
and diverse (m/f/d) is dis ensed with.
Manufacturer
determines all measures to ensure safe and ro er handling and use and is res onsible for
instructing the o erator in this res ect.
Operator
is any natural or legal erson res onsible for the o eration of the healthcare facility in which
The Mobilizer Norbert is a lied by its em loyees.
User
is medical and nursing staff who use the roduct for mobilisation after instruction by the
o erator. As well as maintenance ersonnel with basic training in mechanical and mecha-
tronic systems who are res onsible for troubleshooting. Users are able to recognise, assess
and, if ossible, avoid ossible hazards during use.
Patient
is a - in medizinischer Behandlung bendliche Person
- Persons in care
- mentally and / or hysically im aired ersons in need of care.
medical professionals (staff)
These are, among others, doctors, nurses, caregivers, hysiothera ists / occu ational the-
ra ists. Trainee healthcare rofessionals must be su ervised during use in addition to in-
struction.
Lay people and third parties
Lay ersons are ersons instructed in cleaning work by healthcare rofessionals. Third ar-
ties" are also understood to include, for exam le, relatives of the atient.
This instruction manual has been re ared for users and o erators!
Instructions for use Mobilizer Norbert
6Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
2. Description and purpose
The Mobilizer Norbert is a medically used roduct that su orts nursing staff in the thera y
and mobilisation of atients and is used for ositioning and trans orting atients, as well
as for facilitating the work of nursing staff in hos itals, clinics and care facilities.
The Mobilizer Norbert can be adjusted to a lying and sitting osition. The inde endent
height adjustment can be used in any lying or sitting osition. De ending on the selected
equi ment o tion, the osition settings are made manually with a um lever or electromo-
tively in battery o eration by means of a hand switch.
This model has a three- art, at lying surface which, when adjusted, results in a wide seat,
a high backrest and a leg rest. The leg rest is lowered or raised synchronously with the
inclination of the backrest. A atented length com ensation system, in conjunction with the
integrated seat tilt, minimises the shearing forces on the atient's body that are otherwise
common with couch-seat adjustment. The seat and backrest have comfortable viscoelastic
adding that relieves ressure and hel s revent ressure sores. The osition of the moul-
ded neck cushion in the head area is adjustable.
There are added armrests on both sides of the seat. Both armrests raise automatically
when adjusted to the sitting osition, but can also be swivelled u wards, facilitating a sea-
ted lateral transfer of the atient. To su ort both feet, there is a footrest that can be adjus-
ted to the length of the lower leg.
If it is not needed, it can be stowed behind the adding of the leg rest. Mobilizer Norbert
has four large, swivelling castors that ensure easy manoeuvrability. The central brake unit
can be used to x one directional castor as well as to o erate the arking brakes.
The safe working load is 250 kg.
Any use of the Mobilizer deviating from this ur ose is excluded from ossible liability.
7
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
2.1 Indication
De ending on the severity of the res ective functional or structural damage, tting with a
Mobilizer Norbert:
Signicant im airment of standing and walking, for exam le:
• Com lete/incom lete hemi legia (hemi aresis) and, if necessary, with involvement of
the trunk muscles as a result of a brain disease (for exam le, stroke, brain tumour).
• Com lete/incom lete aralysis of the arms and legs (tetra legia/ aresis) and, if neces-
sary, with involvement of the trunk muscles as a result of a disease of the brain (for ex-
am le, multi le sclerosis, brain injury), the s inal cord (for exam le, oliomyelitis, ara-
legia due to trauma or tumour) or the eri heral nervous system/muscular diseases (for
exam le, Guillain-Barré syndrome, muscular dystro hies).
• Com lete/incom lete aralysis of the legs ( ara legia/ aresis) and, if necessary, with
involvement of the trunk musculature as a result of a disease of the s inal cord (for ex-
am le, ara legia in the case of traumatic/inammatory/tumorous thoracic and lumbar
marrow lesion) or disease of the eri heral nervous system/muscular diseases (for ex-
am le, olyneuro athy, muscular dystro hies).
• For assuming a standing osition, for exam le in re aration for gait training and/or for
achieving ositive effects of an u right body osition (for exam le with regard to circula-
tion regulation/bone metabolism/bowel eristalsis/urinary drainage and/or for reventing
ressure sores, thrombosis or joint contractures, romoting head control and arm func-
tion and im roving s atial erce tion), if the clinical icture and the s atial conditions
make it necessary for the assistant/carer to change the location of the aid within the
home.
2.2 Contraindication
Selected contraindications to the use of Mobilizer Norbert as a standing aid:
• Non-stabilised fractures, acute hase of a ara legic injury
• Sym toms of the failure of autonomous vascular regulation also in other neurological
and/or internal diseases.
• Cardiac emergency - acute, severe im airment of cardiovascular function.
• Surgical wounds - Patients with fresh wounds after surgical rocedures, such as a ster-
notomy after cardiac surgery, after lastic surgery to cover sacral or leg decubiti, should
not be raised, or only after a doctor's orders.
• The atient's body weight must not exceed 250 kg.
The Mobilizer Norbert must not be used if a atient has failed the examination of a rofes-
sional with medical com etence.
3. Permissible operating conditions/place of use
The Mobilizer Norbert is intended for indoor use. If it is necessary to drive over ste s or
thresholds, these must be slo ed or a ram must be created. The ram s or an inclined
lane may have a maximum gradient of seven degrees. The o erating tem erature range is
+5°C to +40°C.
Instructions for use Mobilizer Norbert
8Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
. Dimensions All dimensions in millimetres
Fig. 3: Mobilizer Norbert in sitting position
Fig. 2: Mobilizer Norbert in rest position
ATTENTION!
The osition adjustments may only be made on a horizontal surface. Use in o-
tentially ex losive atmos heres is not ermitted.
!
9
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
5. Safety instructions
5.1 Explanation of symbols and notes
For the safety of atients, for ersonal safety as well as to avoid damage to ro erty, the
meaning of the following symbol and note ex lanations must be observed. These are divi-
ded into hazard levels. If several levels of severity occur, the warning for the highest level is
always used.
Safety and warning notices on the mobilizer
Safety and warning notices in the form of ictograms and stickers are attached to the Mo-
bilizer and to any equi ment su lied. These must not be changed or removed. Defective
or damaged notices must be re laced immediately. The manufacturer must be contacted
for this ur ose.
5.2 Basic safety information
The Mobilizer has been designed and roduced in accordance with the state of the art and
its recognised safety rules.
Nevertheless, risks of injury to staff, atients and third arties or damage to the Mobilizer or
other ro erty cannot be ruled out if the Mobilizer:
• is not used according to the intended use,
• is o erated in a technically unsound condition or
• is o erated by untrained or uninstructed ersonnel.
ATTENTION!
Indicates a hazard. Failure to observe and avoid the situation may result in injury.
!
ATTENTION!
All safety instructions and warnings as well as the recommendations for action
in these o erating instructions must be read!
These must be followed without fail! Failure to do so may result in ersonal injury
and/or damage to or malfunction of the Mobilizer!
!
Pictogramm Meaning
Follow the instructions for use!
Mandatory instructions for the safe use of the Mobilizer are included.
250 kg
Observe the maximum atient weight!
Non-observance can lead to injury to atients, medical staff and third
arties or to damage to ro erty.
=
Instructions for use Mobilizer Norbert
10 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
Occupational safety in general
ATTENTION!
General and national accident revention regulations must be observed.
The o erating ersonnel must be instructed accordingly. Safety and warning
notices on the Mobilizer must not be changed or removed.
Damaged notices must be re laced immediately and can be obtained from the
manufacturer.
!
Qualification of the staff
ATTENTION!
Only demonstrably instructed users are allowed to use the Mobilizer.
�a ly,
�clean,
�maintain and service as a recaution.
!
Commissioning
ATTENTION!
Before the Mobilizer is ut into o eration, the medical staff must be instructed
in its use on the basis of the instructions for use. The otential hazards that may
occur des ite ro er o eration of the Mobilizer must be ointed out in detail.
The Mobilizer may only be o erated in accordance with its intended ur ose
and only within its erformance limits.
In the event of malfunctions or defects that could im air safety, the Mobilizer
must be taken out of o eration immediately and the fault must be rectied im-
mediately. Authorised technicians or the manufacturer must be informed.
Never use the Mobilizer with defective technical safety devices.
Before utting the Mobilizer and its accessories into o eration, a visual ins ec-
tion must be carried out. For this ur ose, all cables must be checked for exter-
nal damage, connecting elements for tightness and the resence of the rotec-
tive measures.
!
ATTENTION!
Mobilizer Norbert is not suitable as a climbing aid, nor is it ermitted to sit
down on the backrest or foot end. An im ermissible load can cause the Mobi-
lizer Norbert to ti over.
!
11
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
5.3 Operational capability
Before and during the use of Mobilizer Ottfried and its accessories, further instructions listed
below must be observed:
• Care must be taken to ensure that the adjustment rocesses take lace without collision,
continuously and almost noiselessly.
• The function of the brake system must be checked according to item "13 Driving and bra-
king".
• Com liance with hygiene requirements must be ensured. The ads must be checked for
damage that could affect their disinfectability.
• Ensure that the connecting and fastening elements function correctly.
• The smooth functioning of all o erating elements must be checked.
• The a liance may only be o erated by ersons who are familiar with these o erating in-
structions. These instructions must be ke t accessible to all o erators. If they are lost, they
must be obtained from the manufacturer.
• Before each transfer and when the atient sits down or stands u , the arking brake must
be activated to revent the Mobilizer Ottfried from rolling away unintentionally.
• The o erator must ensure that the erson on the Mobilizer Ottfried is suitably secured
against falling out.
• The o erator must ensure that no one can mani ulate the Mobilizer Ottfried or be injured by
moving arts during adjustment. The atient's arms should be in the atient's la or on the
armrests. The feet are to be laced securely on the footrest or the oor.
• Avoid direct and rolonged skin contact with Mobilizer Ottfried for more than 1 hour by using
a suitable ad.
• The Mobilizer Ottfried and the individual com onents are sometimes subjected to high
stresses over the course of their useful life or in the event of im ro er handling. Any kind of
cracks or scratches can be indications that the com onent in question will suddenly fail,
which can lead to accidents with a risk of injury.
• Rattling noises or wobbling are an indication of defects!
• Technical modications are not ermitted. Only original arts from the manufacturer may be
used for re airs. A combination with other medical devices may only be carried out after
written a roval by all manufacturers or distributors involved.
• Re airs, maintenance and adjustment work may only be carried out by ersons who have
sufcient s ecialist knowledge. The EU Medical Device Regulation (MDR 2017/745) must be
observed.
• Regular roduct maintenance of the Mobilizer Ottfried is recommended in order to reserve
its value.
• The linear actuators and the su ly cables must be free of external damage.
• Only the batteries intended for this ur ose may be used to o erate Mobilizer Ottfried!
5. Products mechanical adjustment
If your Mobilizer Norbert is equi ed with a hydromechanical adjustment via um lever,
the following additional safety instructions a ly:
• The gas s rings and the hydraulic drive must be free of external damage. No oil may leak
from the manual lifting device.
• Check that all o erating elements function smoothly. The Bowden cable must not be da-
maged.
5.5 Products with battery
Products with rechargeable batteries may only be o erated with the rechargeable batteries
su lied or other rechargeable batteries a roved by the manufacturer. The rechargeable bat-
teries may only be charged in the charging station rovided, including the mains ada ter.
Batteries
These are 24 V rechargeable batteries. Contact between the two contacts is almost im os-
sible due to the design. Do not touch the contacts, otherwise there is a risk of re or electric
shock. As a recaution, avoid wearing metallic jewellery, as touching the electrical contacts
can cause a short circuit in the battery and thus ose a risk of ex losion.
Charging station
The external charging station for the batteries must be o erated se arately and must not be
connected to the roduct for mains o eration. The charging station may only be o erated out-
side the atient environment. The charging station and the mains ada ter with su ly cable
must be checked for external damage. The mains ada ter is subject to the relevant regulations
for mains- owered devices.
Fig. 4: Operating the foot
le er for height adjust-
ment
6. Height adjustment
6.1 Hydromechanical height adjustment
(factory-fitted equipment option)
The hydromechanical height adjustment allows the setting of the
o timal working height for the staff in any sitting or lying ositi-
on. By ressing down one of the foot levers located on either
side between the front and rear wheels (see Fig. 3), the entire
seat-back unit including armrests and footrest is raised. Lowe-
ring in turn is effected by lifting the foot lever. The height adjust-
ment is factory-tted and cannot be retrotted.
Instructions for use Mobilizer Norbert
12 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
ATTENTION!
Risk of destruction of the electric motors and re hazard when using unauthori-
sed batteries and charging stations! Recharging batteries is only ermitted with
the charging station su lied by the manufacturer.
!
6.2 Electromotive height adjustment
(factory-fitted equipment option)
The electromotive height adjustment (see g. 4) allows the set-
ting of the o timum working height for the staff in any sitting or
lying osition. It is o erated by means of a hand switch. Fig. 5: Electromoti e
height adjustment
Fig. 6:
Backrest adjustment
7. Backrest adjustment
By tilting the backrest, Mobilizer Norbert can be adjusted from a
at lying surface to a sitting osition (see Fig. 5). Synchronously
with the inclination of the backrest, the leg rest is also lowered
or raised. By ulling u the release bar, the backrest can be ad-
justed between the reclining and sitting osition.
The Mobilizer Norbert is characterised by a reduction of the
shearing forces that are otherwise common when adjusting the
backrest. De ending on the inclination of the backrest, the seat
cushion is moved longitudinally and adjusted at the front.
13
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
* Electromotive height adjustment
equipment option
8. Hand control*
1 - Raise backrest
2 - Lowering the backrest
3 - Raise height adjustment
4 - Lower height adjustment
5 - Kick u wards
6 - Footste down
The tilt of the backrest and seat, as well as the adjustment of
the seat height, is carried out by means of two electric mo-
tors. O eration is via a hand control with three rows of but-
tons (see Fig. 6). The u er row of buttons controls the tilt of
the backrest, the middle row controls the height adjustment
and the lower row controls the height of the footrest. Fig. 7: Hand switch
9. Main switch*
Behind the backrest is the main switch, with
which all drives of the Mobilizer can be switched
off by ressing the switch button. The Mobilizer
can be switched on again by turning the switch
knob clockwise according to the symbols on the
switch knob.
Fig. 8: Main switch
Power+
o t.
Fig. 9: Permissible patient positioning Fig. 10: Inadmissible patient positioning
10. Transfer
Patients can be transferred sideways into and out of Mobilizer Norbert while sitting or lying
down. Patients whose mobility allows it are also able to get out forwards or sit in the stan-
ding-u osition. In rinci le, Mobilizer Norbert must be braked every time the atient is
transferred or sits in or gets out of the chair.
10.1 Horizontal transfer
Before transferring the atient lying down, lower the backrest to the at lying osition and
the footrest to the lowest ste . Patients are to be laced on the Mobilizer Norbert in such a
way that their greater trochanter (large rolling hill) is ositioned above the rear end of the
seat cushion. In this osition, the u er art of the atient's head must not rotrude above
the head cushion. Moving the atient towards the head end or foot end is not ermitted (see
Fig. 9 and Fig. 10). The backrest must be raised to achieve a semi-sitting osition and the
footrest adjusted to the atient's lower leg length according to cha ter 13.
ATTENTION!
In the lying osition, the atient's body weight must be evenly distributed. The
atient's centre of gravity must be on the seat cushion (a lies es ecially to
am utees). Lifting the legs can cause the Mobilizer to ti over.
!
10.2 Sitting transfer
Alternatively, the armrests can be swivelled u wards to allow comfortable lateral transfers
in sitting ositions. If atients are transferred to Mobilizer Norbert in a sitting osition, they
should only be ositioned on the seat in such a way that the lower art of the back rests
against the backrest and the atient can assume an u right sitting osition.
To get out forward, the seat of Mobilizer Norbert is tilted forward as far as it will go and the
footrest is stowed under the calf ad. In this osition, an attendant can hel the atient out
of Mobilizer Norbert with minimal effort while observing kinaesthetic rinci les.
Instructions for use Mobilizer Norbert
1 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
15
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
Fig. 11: Armrest swi elled
upwards
11. Armrests
The armrests rovide su ort for the atient without limiting
the seat width. They lower automatically to the level of the seat
cushion when adjusted to the couch, facilitating the rone la-
teral transfer of atients. For seated transfer or lateral sitting, it
is ossible to swivel the armrests u wards individually (see
Fig. 11).
Fig. 12: Locking the arm-
rest in place
Locking the armrests
According to the sco e of equi ment, the armrests can be lo-
cked in any osition by means of a locking lever (Fig. 12).
12. Footstep
The atient's feet must be ositioned centrally arallel on the
foot ste (see g. 10). The atient's feet must not rotrude
beyond the footrest. The symmetrical arrangement of the feet
on the foot ste ensures o timal function and revents the
risk of ti ing over due to uneven load distribution. For a ly-
ing transfer or if the foot ste is not needed, it can be folded
under the calf ad. To do this, lift the calf ad, fold in the fully
extended foot ste and then ut the calf ad down again.
Fig. 13: Positioning the
feet on the foot step
Fig. 14: Electric footrest
adjustment
12.1 with electric footrest adjustment
The footrest can be continuously adjusted to the length of the
atient's lower leg. To do this, ress the buttons on both
sides underneath the seat cushion (see Fig. 11) to raise or
lower the footrest.
12.2 with manual footrest adjustment
The footrest can be adjusted to the atient's lower leg length in three ste s. O erate the
release lever below the calf ad (see g. 12 and 13) to raise or lower the footrest. The re-
lease lever audibly engages in one of the three ositions.
Fig. 15: Folding in the footstep Fig. 16: Release le er
ATTENTION!
The foot ste may only be folded in in the extended osition to avoid damage
to the calf ad.
!
Fig. 14: Brake le er
13. Driving and braking
With the foot control lever at the rear of the
frame, both the directional and the total locking
of the castors are o erated centrally. For driving
straight ahead, the directional castor at the front
right can be locked by lifting the central brake
lever.
Pushing down the central brake lever (Fig. 15)
locks the rear brake rollers and the directional
roller (all-wheel brake). The central, horizontal
osition of the central brake lever causes free-
wheeling and free ivoting of all wheels.
ATTENTION!
To revent unintentional rolling away, the arked Mobilizer Norbert must al-
ways be braked.
!
Instructions for use Mobilizer Norbert
16 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
17
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
* Electromotive height adjustment equipment
option
1 . Battery change*
The Mobilizer Norbert's backrest and seat height are adjus-
ted by electric motor in battery mode. An LED indicator light
in the battery monitor shows the current charge status:
• lights u green: sufcient charge - battery full
• ashes orange when a button is ressed, a short signal
tone sounds: charge is running low - recharge battery
• lights u ermanently orange, a re eating signal tone
sounds: low charge - be sure to charge the battery before
using the Mobilizer.
The battery is freely accessible behind the backrest. To change the battery, the backrest
should be ositioned vertically. The battery is ulled out of the lug-in cou ling with a
slight jerk to the left and removed.
ATTENTION!
The weight of the battery is u to 5 kg, de ending on the ty e of battery. When
removing the battery, make sure that it does not fall down when detaching it.
!
Fig. 16:
Remo ing the battery
Fig. 17:
Inserting the battery
Fig. 18: Charging station with
wall bracket
The battery is freely accessible behind the backrest. To change the batteries, the back-
rest should be moved to a vertical osition and the arking brake a lied. To release
the battery, ull it to the left with a slight jerk and then lift it off the backrest (see Fig. 16).
To insert the charged battery, roceed in reverse order. To charge the battery, insert it
into the charging station. The battery is inserted into the charging station in the same
way as on the battery holder on the Mobilizer Norbert (see Fig. 17). Please also observe
the general safety instructions (cha ter 5). The charging station should referably be
mounted vertically on a wall (see Fig. 18) so that the battery is inserted into the charging
station from above for charging.
INFORMATION
De ending on the battery ty e, the battery must be re laced regularly. If
the battery erformance dro s noticeably, contact your customer advisor
or the manufacturer.
Power+
o t.
Fig. 15: Battery control
light
Instructions for use Mobilizer Norbert
18 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
neck cushion Fixing headrest
Chest stra
calf belt
La belt
Positioning
cushion
Leg stra
Positioning
cushion
Table with
u holstery
Chest stra
Fig. 19: Recommended equipment
15. Equipment options
15.1 Headrest, fixing
This headrest is tted in lace of the standard neck ad and has an additional stra to se-
cure the head over the atient's forehead (see Fig. 22).
15.2 Table with upholstery
The table has rounded crumbling edges and an insensitive sur-
face that can be disinfected by wi ing. It is laced on the arm-
rests at an a ro riate distance from the body. Under the table
there are locking levers on the right and left that audibly sna into
lace when light downward ressure is a lied (see Fig. 23). To
release the lock, the handles are moved u wards again. A mat-
ching cushion is available.
15.3 Locking the armrests in place
With the locking device for armrests (see g. 24) it is ossible to
x the armrests in any desired osition between arallel to the
seat surface u to com letely folded u wards.
15. Side bar
Side bars can be attached to both sides of the seat (see Fig. 25).
They offer the atient lateral su ort in the leg area and facilitate
the use of additional ositioning aids. The side bars can be lowe-
red for unhindered lateral transfer.
befestigen lösen
Fig. 20: Release le er
for table attachment
Fig. 21: Locking the
armrest in place
ATTENTION!
When using the forehead belt, never leave the atient unattended!
!
19
Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
15.5 Straps
A selection of different tethers is available (see Fig. 22). For all tethers, the tabs are ulled
through the retaining brackets rovided on the Mobilizer and the Velcro or belt fasteners
are closed. The thoracic belt is attached from the front with the foam ads facing the
atient's body, but as an alternative to the ad belt. The leg stra is to be a lied below
the kneeca ( atella).
Pressing the bar in the direction of the arrow releases the lock. The side
bars are tted at the factory, cannot be retrotted and cannot be com-
bined with ush handles. Pads for the side bars are additionally availa-
ble.
Fig. 22: Side bracket
15.6 Infusion stand
The infusion stand (see g. 26) is attached in one of the rear wheel so-
ckets. The cover ca is ulled out of the wheel socket and the holder of
the infusion stand is inserted into the socket. The infusion stand is then
attached using the star handle.
ATTENTION!
When using the Mobilizer, the infusion stand must be swivelled outwards. Con-
tact between the Mobilizer and the infusion stand during adjustment, es ecially
of the backrest, can damage arts of the stand or the Mobilizer. When trans or-
ting the Mobilizer, the infusion stand must be swivelled in. Otherwise, arts of
the stand may be damaged when assing through narrow laces, e.g. door
frames. Pushing, ulling and ushing on the infusion stand to trans ort or slow
down the Mobilizer will inevitably damage arts of the stand. Manoeuvring the
Mobilizer with the infusion stand is not ermitted.
!
15.7 Battery
An additional exchangeable battery allows the Mobilizer to be o erated continuously wi-
thout breaks in charging. For use, see section "15. Changing the battery".
Fig. 23: Infusion stand
Instructions for use Mobilizer Norbert
20 Co yright © Reha & Medi Hoffmann GmbH. All rights reserved!
16. Warranty
The warranty eriod for the Mobilizer Ottfried including the additional equi ment is 24
months from the date of delivery.
Excluded from warranty claims are:
• Wear arts (e.g. armrest ads, locking screws)
• Damage due to non-observance of these instructions for use
• Damage due to unauthorised modications to the Mobilizer Ottfried
• Damage due to unauthorised combination with other roducts
• Damage due to roduct maintenance, disinfection, re air or overhaul as a result of non-
com liance with the instructions available for this ur ose.
• Pads and stra s for atient restraint
• Circulation
17. Disposal
The trans ort ackaging is recyclable and must be recycled locally. The Mobilizer Ottfried
can be returned to the manufacturer free of charge for rofessional dis osal.
18. Product life
The ex ected technical roduct life is set by the manufacturer at 10 years, rovided the
intended use and safety instructions are observed. Daily use rovides for 10 a lications
on 5 consecutive days followed by 2 rest days. It is recommended to limit one a lication
to 15 minutes.
19. Technical data
Standard width:
Reclining height adjustable ................................................................................... 57 - 79 cm
Length of the lying surface..........................................................................................190 cm
Seat width .....................................................................................................................58 cm
Total width .....................................................................................................................74 cm
smooth running wheels ..........................................................................................Ø 150 mm
own weight ...............................................................................................................ca. 90 kg
Maximum ermissible atient weight...........................................................................250 kg
Widened version:
Seat width ................................................................................................................................66 cm
Total width................................................................................................................................ 81 cm
Exchangeable battery system 24 V / max. 5.5 Ah - de ending on battery ty e
Charging station ty e ZLA-142221, rotection class according to DIN EN 61140: rotection
class III / rotection by extra-low voltage (SELV), internal ower su ly, no mains connection
A lication ty e according to IEC 60601-1: no a lication art
Table of contents
Other rehamedi Medical Equipment manuals
