Rehamedi Ottfried User manual

www.rehamedi.de

Mobilizer Ottfried

Instructions for use

Mobilizer Ottfried

Table of contents Information on the

instructions for use

Manufacturer

Reha & Medi Hoffmann GmbH

Debyestraße 5

04329 Lei zig

Germany

Tel. +49 341 / 39284960

[email protected]

SRN: DE-MF-000007034

www.rehamedi.de

Version: 6

Date of issue: 02.05.2023

Language: English

Validity range: Mobilizer Ottfried

Article number: 7020408-01

1. foreword and general information ....................3

1.1 Co yright..........................................................4

1.2 Disclaimer.........................................................4

1.3 Denition of grou s of ersons ........................5

2. Descri tion and ur ose..................................6

2.1 Indication..........................................................7

2.2 Contraindication ...............................................7

3. Permissible o erating conditions/ lace of use 8

4. Dimensions.......................................................8

5. Safety instructions............................................9

5.1 Ex lanation of symbols and notes ...................9

5.2 Basic safety information...................................9

5.3 O erational ca ability.....................................11

5.4 Products with battery .....................................12

5.5 Product life .....................................................12

6. Height adjustment ..........................................13

7. Backrest adjustment ......................................13

8. Tilt adjustment................................................13

9. Hand control...................................................14

10. Main switch ....................................................14

11. Transfer...........................................................15

11.1 Horizontal transfer..........................................15

11.2 Sitting transfer ................................................15

12. Armrests .........................................................16

13. Footste .........................................................16

14. Driving and braking ........................................17

15. Battery change ...............................................18

16. Product care note...........................................19

17. Re rocessing..................................................19

18. Re-use ............................................................19

19. Equi ment o tions .........................................20

19.1 Headrest, xing ..............................................20

19.2 Table with u holstery......................................20

19.3 Locking the armrests in lace .........................20

19.4 Side bar ...........................................................20

19.5 Stra s .............................................................21

19.6 Infusion stand.................................................21

19.7 Battery............................................................21

20. Warranty .........................................................22

21. Dis osal..........................................................22

22. Technical data ................................................22

22.1 IP rotection classes & tem erature ranges .23

22.2 The ty e late.................................................24

1. foreword and general information

Dear customer,

Thank you for choosing a roduct from Reha & Medi Hoffmann GmbH. These instructions

for use rovide you with all the im ortant information and notes on the Mobilizer Ottfried. It

is also intended to make it easier for you to get to know the roduct and to rovide instruc-

tions for its ro er use and safe o eration.

Please read these instructions carefully and completely before starting up and using

your Mobilizer Ottfried. Keep them handy for future reference.

All directions are indicated looking from the back of the roduct in the direction of travel, as

shown in Fig. 1.

If, des ite careful study, further information is required, lease do not hesitate to contact us.

You will nd our contact details at the beginning of these instructions for use.

You can find all documents in digital form online at www.rehamedi.de.

Fig. 1: Basis for direction/page references

LEFT RIGHT

DIRECTION OF TRAVEL

Instructions for use Mobilizer Ottfried

1.1 Copyright

These o erating instructions, including all their arts and illustrations, are rotected by co-

yright. The rights to translation, re rinting, extraction of ictorial re resentations as well as

re roduction and storage in data rocessing systems are reserved, even if only excer ts are

used. The use in lectures or ublication in media, in articular in ublications, also in ex-

tracts, requires the rior written consent of Reha & Medi Hoffmann GmbH.

1.2 Disclaimer

Understanding, observing and com lying with these instructions for use is absolutely es-

sential for atient safety and the safety of users as well as the trouble-free o eration of the

roducts of Reha & Medi Hoffmann GmbH. Reha & Medi Hoffmann GmbH does not assume

any warranty or liability for direct or indirect damage resulting from unauthorised modica-

tions to the roduct or failure to observe these instructions for use.

The roducts of Reha & Medi Hoffmann GmbH may only be used in conjunction with equi -

ment o tions a roved by the manufacturer as s ecied in the instructions for use.

Any combination of the roduct with other roducts, in articular with medical roducts, as

well as any technical modication to the roduct is generally not ermitted. Exce tions re-

quire the written a roval of the manufacturer.

Des ite careful checking, errors in this document cannot be com letely ruled out. We reser-

ve the right to make technical or content-related changes at any time without rior notice.

Documents in rinted form are not subject to a change service.

1.3 Definition of groups of persons

For reasons of better readability, the simultaneous use of the language forms male, female

and diverse (m/f/d) is dis ensed with.

Manufacturer

determines all measures to ensure safe and ro er handling and use and is res onsible for

instructing the o erator in this res ect.

Operator

is any natural or legal erson res onsible for the o eration of the healthcare facility in which

The Mobilizer Ottfried is a lied by its em loyees.

User

is medical and nursing staff who use the roduct for mobilisation after instruction by the

o erator. As well as maintenance ersonnel with basic training in mechanical and mecha-

tronic systems who are res onsible for troubleshooting. Users are able to recognise, assess

and, if ossible, avoid ossible hazards during use.

Patient

is a - erson undergoing medical treatment

- erson in care

- cared for mentally and / or hysically im aired erson.

medical professionals (staff)

These are, among others, doctors, nurses, caregivers, hysiothera ists / occu ational the-

ra ists. Trainee healthcare rofessionals must be su ervised during use in addition to in-

struction.

Lay people and third parties

Lay ersons are ersons instructed in cleaning work by healthcare rofessionals. Third ar-

ties" also includes, for exam le, relatives of the atient.

These instructions for use have been re ared for users and o erators!

Instructions for use Mobilizer Ottfried

2. Description and purpose

The Mobilizer Ottfried is a universal thera y device for erforming atient mobilisation from

a lying to a sitting osition.

The sitting/lying surface is mounted on a com act chassis with four swivelling castors and

is easy to manoeuvre. Both directional and total locking of the wheels can be controlled

centrally by foot control. There are added armrests on both sides which raise and lower

synchronously with the backrest. In addition, the armrests can be swivelled in any osition

to ensure barrier-free lateral transfer of the atient in any lying or sitting osition.

Every safe and sensible osition between head-down, horizontal, sitting can be adjusted by

means of a hand switch or control buttons on the roduct, as can the height adjustment.

The height-adjustable footrest ensures adjustment to the atient's height.

When the atient is lying on his back, a movement sequence from lying to any, also inclined,

sitting osition is ossible. The leg su ort moves synchronously with the inclination of the

backrest. The built-in length com ensation reduces shearing forces when adjusting the

couch to the seat. If required, the atient can be stabilised in the knee and hi joint area,

the torso and the head by means of safety belts.

The adding in the seat and back area has a ressure-relieving effect due to a viscoelastic

com onent in the adding foam and contributes to decubitus ro hylaxis. The moulded

neck cushion in the head area is adjustable in height and rovides lateral su ort for the

head. All u holstery covers are removable, wi eable and anti-microbial.

2.1 Indication

De ending on the severity of the res ective functional or structural damage, tting with a

Mobilizer Ottfried may be indicated:

Signicant im airment of standing and walking, for exam le:

• Com lete/incom lete hemi legia (hemi aresis) and, if necessary, with involvement of

the trunk muscles as a result of a brain disease (for exam le, stroke, brain tumour).

• Com lete/incom lete aralysis of the arms and legs (tetra legia/ aresis) and, if neces-

sary, with involvement of the trunk muscles as a result of a disease of the brain (for ex-

am le, multi le sclerosis, brain injury), the s inal cord (for exam le, oliomyelitis, ara-

legia due to trauma or tumour) or the eri heral nervous system/muscular diseases (for

exam le, Guillain-Barré syndrome, muscular dystro hies).

• Com lete/incom lete aralysis of the legs ( ara legia/ aresis) and, if necessary, with

involvement of the trunk musculature as a result of a disease of the s inal cord (for ex-

am le, ara legia in the case of traumatic/inammatory/tumorous thoracic and lumbar

marrow lesion) or disease of the eri heral nervous system/muscular diseases (for ex-

am le, olyneuro athy, muscular dystro hies).

• For assuming a standing osition, for exam le in re aration for gait training and/or for

achieving ositive effects of an u right body osition (for exam le with regard to circula-

tion regulation/bone metabolism/bowel eristalsis/urinary drainage and/or for reventing

ressure sores, thrombosis or joint contractures, romoting head control and arm func-

tion and im roving s atial erce tion), if the clinical icture and the s atial conditions

make it necessary for the assistant/carer to change the location of the aid within the

home.

2.2 Contraindication

Ausgewählte Kontraindikationen zur Benutzung des Mobilizer Ottfried:

• Non-stabilised fractures, acute hase of a ara legic injury

• Sym toms of the failure of autonomous vascular regulation also in other neurological

and/or internal diseases.

• Cardiac emergency - acute, severe im airment of cardiovascular function.

• Surgical wounds - Patients with fresh wounds after surgical rocedures, such as a ster-

notomy after cardiac surgery, after lastic surgery to cover sacral or leg decubiti, should

not be raised, or only after a doctor's orders.

• The atient's body weight must not exceed 250 kg.

The Mobilizer Ottfried must not be used if a atient has failed the examination of a rofes-

sional with medical com etence.

Instructions for use Mobilizer Ottfried

3. Permissible operating conditions/place of use

The Mobilizer Ottfried is intended for indoor use. If it is necessary to negotiate ste s or

thresholds, these must be slo ed or a ram must be created. The ram s or an inclined

lane may have a maximum gradient of seven degrees. The o erating tem erature range is

+5°C to +40°C.

ATTENTION!

The osition adjustments may only be made on a horizontal surface. Use in o-

tentially ex losive atmos heres is not ermitted.

. Dimensions

All dimensions in millimetres

Fig. 3: Mobilizer Ottfried in sitting position

Fig. 2: Mobilizer Ottfried in rest position

5. Safety instructions

5.1 Explanation of symbols and notes

For the safety of atients, for ersonal safety as well as to avoid damage to ro erty, the

meaning of the following symbol and note ex lanations must be observed. These are divi-

ded into hazard levels. If several levels of severity occur, the warning for the highest level is

always used.

Safety and warning notices on the Mobilizer Ottfried

Safety and warning notices in the form of ictograms and stickers are attached to the Mo-

bilizer Ottfried and to any equi ment su lied with it. These must not be changed or remo-

ved. Defective or damaged notices must be re laced immediately. The manufacturer must

be contacted for this ur ose.

5.2 Basic safety information

The Mobilizer Ottfried has been designed and roduced in accordance with the state of the

art and its recognised safety rules. Nevertheless, risks of injury to staff, atients and third

arties or damage to the Mobilizer Ottfried or other ro erty cannot be ruled out if the Mo-

bilizer Ottfried:

• is not used according to the intended use,

• is o erated in a technically unsound condition or

• is o erated by untrained or uninstructed ersonnel.

ATTENTION!

Indicates a hazard. Failure to observe and avoid the situation may result in injury.

ATTENTION!

All safety instructions and warnings as well as the recommendations for action

in these instructions for use must be read! These must be followed without fail!

Failure to do so may result in ersonal injury and/or damage to or malfunction

of the Mobilizer Ottfried!

Pictogramm Meaning

Follow the instructions for use!

Instructions for the safe use of the Mobilizer Ottfried are included and

must be followed.

250 kg

Observe the maximum atient weight!

Non-observance can lead to injury to atients, medical staff and third

arties or to damage to ro erty.

Instructions for use Mobilizer Ottfried

Occupational safety in general

ATTENTION!

General and national accident revention regulations must be observed. The

o erating ersonnel must be instructed accordingly. Safety and warning notices

on the Mobilizer must not be changed or removed. Damaged notices must be

re laced immediately and can be obtained from the manufacturer.

Qualification of the staff

ATTENTION!

Only demonstrably instructed users are allowed to use the Mobilizer.

�a ly,

�clean,

�Maintain and service as a recaution.

Commissioning

ATTENTION!

Before the Mobilizer is ut into o eration, the medical staff must be instructed

in its use on the basis of the instructions for use. The otential hazards that may

occur des ite ro er o eration of the Mobilizer must be ointed out in detail.

The Mobilizer may only be o erated in accordance with its intended use and

only within its erformance limits.

In the event of malfunctions or defects that could im air safety, the Mobilizer

must be taken out of o eration immediately and the fault must be rectied im-

mediately. Authorised technicians or the manufacturer must be informed.

Never use the Mobilizer with defective technical safety devices.

Before utting the Mobilizer and its accessories into o eration, a visual ins ec-

tion must be carried out. For this ur ose, all cables must be checked for exter-

nal damage, connecting elements for tightness and the resence of the rotec-

tive measures.

ATTENTION!

Mobilizer Ottfried is not suitable as a climbing aid, nor is it ermitted to sit

down on the backrest or foot end. An im ermissible load can cause the Mobi-

lizer Ottfried to ti over.

5.3 Operational capability

Before and during the use of Mobilizer Ottfried and its accessories, further instructions listed

below must be observed:

• Care must be taken to ensure that the adjustment rocesses take lace without collision,

continuously and almost noiselessly.

• The function of the brake system must be checked according to item "13 Driving and bra-

king".

• Com liance with hygiene requirements must be ensured. The ads must be checked for

damage that could affect their disinfectability.

• Ensure that the connecting and fastening elements function correctly.

• The smooth functioning of all o erating elements must be checked.

• The a liance may only be o erated by ersons who are familiar with these o erating in-

structions. These instructions must be ke t accessible to all o erators. If they are lost, they

must be obtained from the manufacturer.

• Before each transfer and when the atient sits down or stands u , the arking brake must

be activated to revent the Mobilizer Ottfried from rolling away unintentionally.

• The o erator must ensure that the erson on the Mobilizer Ottfried is suitably secured

against falling out.

• The o erator must ensure that no one can mani ulate the Mobilizer Ottfried or be injured by

moving arts during adjustment. The atient's arms should be in the atient's la or on the

armrests. The feet are to be laced securely on the footrest or the oor.

• Avoid direct and rolonged skin contact with Mobilizer Ottfried for more than 1 hour by using

a suitable ad.

• The Mobilizer Ottfried and the individual com onents are sometimes subjected to high

stresses over the course of their useful life or in the event of im ro er handling. Any kind of

cracks or scratches can be indications that the com onent in question will suddenly fail,

which can lead to accidents with a risk of injury.

• Rattling noises or wobbling are an indication of defects!

• Technical modications are not ermitted. Only original arts from the manufacturer may be

used for re airs. A combination with other medical devices may only be carried out after

written a roval by all manufacturers or distributors involved.

• Re airs, maintenance and adjustment work may only be carried out by ersons who have

sufcient s ecialist knowledge. The EU Medical Device Regulation (MDR 2017/745) must be

observed.

• Regular roduct maintenance of the Mobilizer Ottfried is recommended in order to reserve

its value.

• The linear actuators and the su ly cables must be free of external damage.

• Only the batteries intended for this ur ose may be used to o erate Mobilizer Ottfried!

Instructions for use Mobilizer Ottfried

5. Products with battery

Products with rechargeable batteries may only be o erated with the rechargeable batteries

su lied or other rechargeable batteries a roved by the manufacturer. The rechargeable bat-

teries may only be charged in the charging station rovided, including the mains ada ter.

Batteries

These are 24 V rechargeable batteries. Contact between the two contacts is almost im os-

sible due to the design. Do not touch the contacts, otherwise there is a risk of re or electric

shock. As a recaution, avoid wearing metallic jewellery, as touching the electrical contacts

can cause a short circuit in the battery and thus ose a risk of ex losion.

charging station

The external charging station for the batteries must be o erated se arately and must not be

connected to the roduct for mains o eration. The charging station may only be o erated out-

side the atient environment. The charging station and the mains ada ter with su ly cable

must be checked for external damage. The mains ada ter is subject to the relevant regulations

for mains- owered devices.

5.5 Product life

The ex ected technical roduct life is set by the manufacturer at 10 years, rovided the

intended use and safety instructions are observed. Daily use rovides for 10 a lications

on 5 consecutive days followed by 2 rest days. It is recommended to limit one a lication

to 15 minutes.

ATTENTION!

Risk of destruction of the electric motors and re hazard when using unauthori-

sed batteries and charging stations! Recharging batteries is only ermitted with

the charging station su lied by the manufacturer.

6. Height adjustment

The Mobilizer Ottfried is equi ed with a

height adjustment that works inde endently of

the lying or sitting osition. It is o erated by

means of a hand switch (see Fig. 4).

Fig. 4: Height ad ustment

7. Backrest adjustment

By tilting the backrest, Mobilizer Ottfried can be adjusted

from a at lying surface to a sitting osition. The leg rest

is lowered or raised synchronously with the inclination of

the backrest.

The Mobilizer Ottfried is characterised by a reduction of

the shearing forces that are otherwise common when ad-

justing the backrest. De ending on the inclination of the

backrest, the seat cushion is shifted longitudinally and

adjusted (tilted) at the front. This gives the atient a sta-

ble sitting osition without shifting during sitting u .

Fig. 5: Backrest ad ustment

8. Tilt adjustment

The Mobilizer Ottfried has a seat tilt adjustment. This can

be adjusted inde endently of the seat height and back-

rest angle. The seat and reclining surface can be tilted u

to 9° forwards and 10° backwards com ared to the nor-

mal osition. This makes it ossible to stand u with the

seat surface slightly tilted forwards and the backrest er-

endicular to the oor as well as to lie down with the

head in a straight osition. For comfortable adjustment of

the normal osition, a sto osition is inserted which

sto s the adjustment when the hand control button is

ressed when the normal osition is reached.

Fig. 6: Seat inclination

Instructions for use Mobilizer Ottfried

9. Hand control

The tilt of the backrest and seat, the adjustment of the

seat height, as well as the o eration of the lower leg

length (height of the foot ste ) is carried out by means of

two electric motors. The o eration is done via a hand

control with four rows of buttons (see g. 7).

1 - Raise backrest

2 - Lowering the backrest

3 - Raise height adjustment

4 - Lower height adjustment

5 - Seat tilt forward

6 - Seat inclination to the rear

7 - Kick u wards

8 - Footste down

The tilt of the backrest and seat, as well as the adjust-

ment of the seat height, is carried out by means of two

electric motors. O eration is via a hand control with four

rows of buttons. Fig. 7: Hand switch

10. Main switch

Behind the backrest is the main switch, with

which all drives of the Mobilizer are switched off

by ressing the knob. The Mobilizer can be swit-

ched on again by turning the knob clockwise

according to the symbolism on the knob.

Fig. 8: Main switch

Fig. 9: Permissible patient positioning Fig. 10: Inadmissible patient positioning

11. Transfer

Patients can be transferred sideways into and out of the Mobilizer Ottfried while sitting or

lying down. Patients whose mobility allows it are also able to get out forwards or sit in the

standing-u osition. In rinci le, the Mobilizer Ottfried must be braked every time the a-

tient is transferred or sits in or gets out of the chair.

11.1 Horizontal transfer

Before transferring the atient lying down, lower the backrest to the at lying osition and

the footrest to the lowest ste . Patients are to be laced on the Mobilizer Ottfried in such a

way that their greater trochanter (large rolling hill) is ositioned above the rear end of the

seat cushion. In this osition, the to of the atient's head must not rotrude above the

head cushion. Moving the atient towards the head end or foot end is not ermitted (see

Fig. 9 and Fig. 10). The backrest must be raised to achieve a semi-sitting osition and the

footrest adjusted to the atient's lower leg length according to cha ter 13.

ATTENTION!

In the lying osition, the atient's body weight must be evenly distributed. The

atient's centre of gravity must be on the seat cushion (a lies es ecially to

am utees). Lifting the legs can cause the Mobilizer to ti over.

11.2 Sitting transfer

Alternatively, the armrests can be swivelled u wards to allow comfortable lateral transfers

in sitting ositions. If atients are transferred to Mobilizer Ottfried in a sitting osition, they

should only be ositioned on the seat in such a way that the lower art of the back rests

against the backrest and the atient can assume an u right sitting osition.

To get out forward, the seat of Mobilizer Ottfried is tilted forward as far as it will go and the

footrest is stowed under the calf ad. In this osition, an attendant can hel the atient out

of Mobilizer Ottfried with minimal effort while observing kinaesthetic rinci les.

Instructions for use Mobilizer Ottfried

Fig. 11: Armrest swivelled upwards

Fig. 12: Locking the armrest in place

12. Armrests

The armrests rovide su ort for the atient

without limiting the seat width. They lower

automatically to the level of the seat cushion

when adjusted to the couch, facilitating the

rone lateral transfer of atients. For seated

transfer or lateral sitting, it is ossible to swi-

vel the armrests u wards individually (see

Fig. 11).

Locking the armrests

According to the sco e of equi ment, the

armrests can be locked in any osition by

means of a locking lever (Fig. 12).

13. Footstep

The osition of the footrest can be adjusted to

the length of the lower leg. The release levers

on either side of the calf ad release the ad-

justment. When the release levers are res-

sed, the footrest is brought into the desired

osition (see Fig. 13). Releasing the release

levers then gradually locks the footrest in

lace. For a lying transfer or if the foot ste is

not needed, it can be folded under the calf

ad. To do this, lift the calf ad, fold in the fully

extended foot ste and then ut the calf ad

back down.

Fig. 13: Operating the footstep

Fig. 14: Brake lever

1 . Driving and braking

With the foot control lever at the rear of the

frame, both the directional and the total locking

of the castors are o erated centrally. For driving

straight ahead, the directional castor at the front

right can be locked by lifting the central brake

lever.

Pushing down the central brake lever (Fig. 15)

locks the rear brake rollers and the directional

roller (all-wheel brake). The central, horizontal

osition of the central brake lever causes free-

wheeling and free ivoting of all wheels.

ATTENTION!

To revent unintentional rolling away, the arked Mobilizer Ottfried must al-

ways be braked.

Instructions for use Mobilizer Ottfried

15. Battery change

All functions of the Mobilizer Ottfried are owered by a rech-

argeable battery. An LED indicator light on the battery holder

(see Fig. 18) shows the current charge status:

• green: sufcient charge - battery full

• yellow, a short bee sounds when a button is ressed:

charge is running low, recharge the battery.

• red, a re eating signal tone sounds: low charge - be sure

to charge the battery before using Mobilizer Ottfried.

Fig. 15:

Battery control light

ATTENTION!

The weight of the battery is u to 5 kg, de ending on the ty e of battery. When

removing the battery, make sure that it does not fall down when detaching it.

Fig. 16:

Removing the battery

Fig. 17:

Inserting the battery

Fig. 18: Charging station with

wall bracket

The battery is freely accessible behind the backrest. To change the batteries, the backrest

should be moved to a vertical osition and the arking brake a lied. To release the battery,

ull it to the left with a slight jerk and then lift it off the backrest (see Fig. 16). To insert the

charged battery, roceed in reverse order. To charge the battery, insert it into the charging

station. The battery is inserted into the charging station in the same way as on the battery

holder on the Mobilizer Ottfried (see Fig. 17). Please also observe the general safety instruc-

tions (cha ter 5). Preferably, the charging station should be mounted vertically on a wall

(see Fig. 18) so that the battery is inserted into the charging station from above for charging.

INFORMATION

De ending on the battery ty e, the battery must be re laced regularly. If

the battery erformance dro s noticeably, contact your customer advisor

or the manufacturer.

16. Product care note

The Mobilizer Ottfried is maintenance-free. To maintain the value and serviceability, rofes-

sional roduct care of the Mobilizer Ottfried is recommended within 24 months. Instructions

for roduct care and a manual for checking the safety of the device are available from the

manufacturer. Due to the owder coating and chrome- lated com onents, Mobilizer Ott-

fried has corrosion rotection. Damage to the lacquer must be re aired immediately to

maintain its value and safety.

17. Reprocessing

Cleaning and disinfection

Before starting cleaning work, switch off the Mobilizer Ottfried by ressing the main switch

and a ly the central brake. It is recommended that the surfaces be wi ed down with a

dam cloth using household and commercially available, non-abrasive, neutral cleaning

agents. Disinfectants that are gentle on the material can be used for disinfection. The a -

lication instructions and ex osure times of the disinfectant used must be observed.

An overview of recommended disinfectants listed by the Robert Koch Institute are listed

under: htt s://rehamedi.de/service/#reinigen.

The ads are attached with Velcro and can therefore be removed without tools. The calf ad

can be swivelled u wards for easy cleaning and disinfection. The Mobilizer Ottfried is not

suitable for machine cleaning. Disinfectant list as

Download

18. Re-use

The Mobilizer Ottfried can be reused indenitely within its roduct life. For reuse, the usabi-

lity must be checked in accordance with oint 5.3 and re rocessing must be carried out

thoroughly in accordance with oint 18. If there are any irregularities, es ecially in oint 5.3,

a com rehensive safety check (STK) is necessary. This may result in service and re air

work, which must be agreed with the manufacturer. A safety checklist is available from the

manufacturer.

Instructions for use Mobilizer Ottfried

neck cushion Fixing headrest

Chest stra

calf belt

La belt

Positioning

cushion

Leg stra

Positioning

cushion

Table with

u holstery

Chest stra

Fig. 19: Recommended equipment

19. Equipment options

19.1 Headrest, fixing

This headrest is tted in lace of the standard neck ad and has an additional stra to se-

cure the head over the atient's forehead (see Fig. 22).

19.2 Table with upholstery

The table has rounded crumbling edges and an insensitive sur-

face that can be disinfected by wi ing. It is laced on the arm-

rests at an a ro riate distance from the body. Under the table

there are locking levers on the right and left that audibly sna into

lace when light downward ressure is a lied (see Fig. 23). To

release the lock, the handles are moved u wards again. A mat-

ching cushion is available.

19.3 Locking the armrests in place

With the locking device for armrests (see g. 24) it is ossible to

x the armrests in any desired osition between arallel to the

seat surface u to com letely folded u wards.

19. Side bar

Side bars can be attached to both sides of the seat (see Fig. 25).

They offer the atient lateral su ort in the leg area and facilitate

the use of additional ositioning aids. The side bars can be lowe-

red for unhindered lateral transfer.

befestigen lösen

Fig. 20: Release lever

for table attachment

Fig. 21: Locking the

armrest in place

ATTENTION!

When using the forehead belt, never leave the atient unattended!

Table of contents

Other rehamedi Medical Equipment manuals

rehamedi

rehamedi Norbert User manual

rehamedi

rehamedi Curalizer Arne User manual

rehamedi

rehamedi Medior User manual

Popular Medical Equipment manuals by other brands

GE HEALTHCARE

GE HEALTHCARE Logiq Book XP series Basic service manual

Osprey Medical

Osprey Medical DyeTect RRL Instructions for use

Atmos

Atmos A 161 operating instructions

Drive

Drive inspired BCWL-7210S instructions

Tuffcare

Tuffcare Rhino P420 Operation manual

Seca

Seca 531 instructions

Labomed

Labomed PRIMA WALL MOUNT User & installation manual

NorthEast Monitoring

NorthEast Monitoring DR181 HOOK-UP GUIDE

BRASSELER USA

BRASSELER USA EndoSync PLUS Instructions for use

BlackBox Biometrics

BlackBox Biometrics Blast Gauge quick start guide

DHP

DHP MAINSTAYS 6028149W quick start guide

Gima

Gima Sigma manual

Sissel

Sissel Heat Wave Instructions for use

bort medical

bort medical MalleoStabil quick guide

Sharper Image

Sharper Image 206994 user guide

Cristofoli

Cristofoli Autoclave Baby manual

TEXIBLE

TEXIBLE Wisbi user manual

GERLINK UTAMA MANDIRI

GERLINK UTAMA MANDIRI Gerlip HFNC 01 Manual book

rehamedi Ottfried User manual

Popular Medical Equipment manuals by other brands
