Reinecker MANO User manual

Gebrauchsanweisung
User manual
Modo de empleo
DEENES

Before initial use
Insert the rechargeable battery into the case
• Take MANO out of the plastic bag
• Open the folding stand until it locks in place
• Slide open the battery cover pushing in the direction
of the arrow 1
• Remove the battery cover
• Take the rechargeable battery out of the packaging
• Insert the rechargeable battery into the case, making sure
the contacts are properly positioned
• According to the illustration, slide the battery cover plate
back into the case (Make sure that the holes on the
battery cover fit squarely over the pins on the case)
• Press the battery cover plate against the battery. Push in
the direction of the arrow 2 until it locks in place
Quick reference guide
• Push the yellow button: switch MANO on/off
• Push the zoom button: change the color modes
• Push the zoom button upwards/downwards: zoom in/out
• Push the snapshot button in live image: save an image
• Press the snapshot button upwards:
switch from freeze frame to live image
• Press the snapshot button downwards:
the next image will be shown
• Keep snapshot pressed: scroll zoomed image
EN

1
2
Stativbügel
folding stand
placa del soporte
Abdeckplatte
cover plate
cubierta
de la batería
Vor Inbetriebnahme/Before initial use/
Antes de usar
Skizzen:/Illustrations:/Ilustraciones:/
Kurzanleitung/Quick reference guide/
Guía de referencia rápida
Schnappschuss
snapshot
foto
Ein/Aus
on/off
Encender/apagar
Zoom
zoom
Zoom/enfoque

Accessories ................................................................... 28
Notes before operating the device ................................ 28
1. Start-up ...................................................................... 29
2. Description of the controls......................................... 29
2.1 Yellow “on/off” button ............................................. 30
2.2 “Zoom” Button with 4 functions ............................... 30
2.2.1 Zoom plus = Increase Magnification .................... 30
2.2.2 Zoom minus = Decrease Magnification................ 30
2.2.3 Changing color modes ......................................... 30
2.2.4 Turn on/off the light .............................................. 30
2.3 Snapshot/Live image Button .................................. 31
2.3.1 Saving an image .................................................. 31
2.3.2 Changing to Live picture ...................................... 31
2.3.3 Retrieving saved pictures ..................................... 31
2.3.4 Image scroll function ............................................ 31
2.4 Freeze frame function ............................................. 32
3. Application ................................................................. 33
3.1 Reading with stand .................................................. 33
3.2 Handheld reading .................................................... 33
3.3 Writing ..................................................................... 34
4. Battery operation ....................................................... 34
4.1 Recharging the battery ............................................ 34
4.2 Rechargeable battery display .................................. 35
Content

4.3 Display of rechargeable battery flashes .................. 35
5. Power Supply ........................................................... 35
5.1 Included adapters .................................................... 35
5.2 Connecting the adapter to the power supply .......... 36
5.3 Connecting MANO to the power supply .................. 36
6. Standby function........................................................ 37
7. Automatic switch-off .................................................. 37
8. Saving the settings .................................................... 37
9. Notes for changing the rechargeable battery ............ 37
9.1 Changing of the rechargeable battery .................... 38
9.2 Non-liability in case of using wrong
rechargeable battery ............................................... 39
9.3 Disposal of the rechargeable battery ...................... 39
9.4 Protective circuit of the rechargeable batteries ....... 39
10. Protective bag ......................................................... 40
11. Hand strap ............................................................... 40
12. Notes for handling ................................................... 41
13. Cleaning of the device............................................. 42
14. CE and FCC notes for
electro-magnetic compatibility (EMV) ...................... 42
15. Technical data ......................................................... 43
16. Warranty Information .............................................. 43
EN

MANO is an electronic magnifier that magnifies text and
images.
You can use it at home or take it with you when you go
shopping or on a visit.
Accessories
The following equipment is included in the packaging:
• a power supply with four country-specific adapters
(country-specific top parts guarantee a world-wide
application)
• a hand strap
• a protective bag
• a manual in three languages:
German, English, Spanish
• a microfibre tissue for cleaning the display
Notes before operating the device
!Please note!
Read the manual carefully before switching on the device.
Keep the manual in a safe spot for further reference.
If you need to return your MANO for service, pack it in its
original packaging and return it to your retailer, indicating
the problem you are having.
The manufacturer is not liable for malfunctions or
damages caused by inappropriate usage.
28

1. Start-up
Please insert the pre-charged battery as described in the
quick start guide on the front cover page.
MANO can be switched on by pressing the yellow „on/off“
button.
2. Description of the controls
29
EN
live image
snapshot
image selection
on/off
Plug
for AC adapter
zoom plus
color mode
zoom minus
front
left side right side

2.1 Yellow “on/off” button
The on/off button is unmistakably marked in yellow.
When you push the button for 3 seconds, MANO will be
switched on. To turn off MANO, briefly push the yellow
button.
2.2 “Zoom” Button with 4 functions
2.2.1 Zoom plus = Increase Magnification
By pushing the button upwards, you will increase the
magnification level
2.2.2 Zoom minus = Decrease Magnification
By pushing the button downwards, you will decrease the
magnification level
2.2.3 Changing color modes
By pushing the zoom button you may change the color
selection options on the TFT screen:
• Full color
• Semi-colors
• Positive mode: black-white
• Negative mode:
white-black, green-black, yellow-black, yellow-blue
2.2.4 Turn on/off the light
If you wish to turn off the light (for use with ATMs and
other machines which may cause glare), push the zoom
button for 2 seconds. To turn on the light, push the button
briefly once more.
30

2.3 Snapshot/Live image Button
You can change from freeze frame image to live image
with the “snapshot” button. Both text and images can be
saved and retrieved.
2.3.1 Saving an image
By pushing the snapshot button, you may save the image
currently on the TFT screen.
!Please note! You may save up to 3 pictures.
If 3 pictures are saved and you take another one, the first
one will be deleted
2.3.2 Changing to Live picture
By pushing the snapshot button upwards, you will switch
back to live viewing.
2.3.3 Retrieving saved pictures
By pushing the snapshot button downwards, you will
retrieve the saved pictures. Pushing the button multiple
times will advance to subsequent images.
2.3.4 Image scroll function
This function enables you to read saved images which
cannot be shown completely on the display after having
been enlarged. This may be used for telephone numbers,
email addresses, schedules, package inserts etc.
31
EN

Proceeding:
Choose a saved image. In case you cannot read the
font use the button zoom plus for enlargement. Should
the text not be legible due to this operation, permanently
press the snapshot button. Move MANO smoothly across
any reading material in any direction (to the left, right,
up and down). Now the text will be shown on the display
according to your movement.
2.4 Freeze frame function
The functions 2.3 including 2.3.4. have been pre-set by
the manufacturer.
However, if you prefer a simple freeze frame function
without scrolling capabilities, you may deactivate the
scrolling by pressing the snapshot and zoom buttons
simultaneously for 3 seconds. The scrolling function will
be deactivated.
By pressing the snapshot button, the live image will be
displayed as a frozen image on the TFT. This enables
you to take a picture of something which is not immedi-
ately in front of you (up to 15 cm or 6 inches away from
MANO.) Pressing the snapshot button one more time will
return you to the live reading mode.
32

3. Application
MANO may be used in 3 different ways:
3.1 Reading with stand
Expand the folding stand
until it locks in place
Place MANO on the
reading material. Move
MANO with the expanded
folding stand across the
reading material. Now
you can see your reading
material or your pictures
on the TFT screen.
The angle of the TFT
screen is about 20°. This enables an ergonomic seating
position and an optimal depiction
of contrast and brightness.
3.2 Handheld reading
Fold down the stand frame
and hold MANO at a
distance of 1 to 15 cm
(0.5“ to 6“) above the
reading material. Within that
range, a sharp image can be
displayed on the TFT screen.
33
EN

!Please note! Viewing of computer monitors
If you wish to use MANO to view screens such as ATM
machines, computers, or other electronic displays, you
may experience excessive glare due to the internal ligh-
ting on MANO. To avoid the glare, turn off the internal
light on MANO (see 2.2.4).
3.3 Writing
If you lift MANO
or open the folding
stand, you may
write short notes.
4. Battery operation
4.1 Recharging the battery
Switch off MANO.
Put DC plug of power supply in DC nut of MANO
Plug the small end of the power supply into the power
port on the MANO.
Plug the power supply into an electrical outlet.
The rechargeable battery will start charging.
Charging time is approximately 2.5 hours.
34

4.2 Rechargeable battery display
Upon turning MANO on, you will see the symbol of the
rechargeable battery on the TFT display. The charge
level will be indicated.
Charge level 100% = rechargeable battery is completely
charged
Charge level 50%=rechargeable battery is half charged
If the symbol of the rechargeable battery is flashing red,
the rechargeable battery needs to be charged.
4.3 Display of rechargeable battery flashes
If the rechargeable battery icon flashes, the rechargeable
battery needs to be charged immediately.
If you do not begin charging promptly, MANO will shut
itself down.
5. Power Supply
Included in the delivery are a 100-240 VAC power supply
and 4 primary adapters. They will enable you to connect
the power supply world-wide.
5.1 Included adapters
1 adapter for Europe (EU)
1 adapter for England (UK)
1 adapter for USA, South America, Japan etc. (US/J)
1 adapter for Australia (AUS)
35
EN

5.2 Connecting the adapter to the power supply
When connecting the primary adapter, the power supply
must not be plugged into an electrical outlet. Choose the
primary adapter necessary for your region and connect it
to the power supply. Push both parts together until they
lock in place.
5.3 Connecting MANO to the power supply
After connecting the primary adapter, plug the power
supply into an electrical outlet. Switch on MANO. The
operating elements and the use are the same as for
battery operation. If you use MANO with while plugged
into an electrical supply, the power supply to the battery
is disconnected in order to preserve battery capacity.
36
primary adapter
Europe
power supply

6. Standby function
If MANO is left idle for 2 minutes of no use, the device
switches automatically to standby mode.
Simply moving the device turns it on again.
7. Automatic switch-off
If MANO remains in the standby mode for more than
5 minutes, the unit will shut off completely. MANO will
then have to be switched on by means of the main
on/off button.
8. Saving the settings
Upon turning off the device, MANO will save all data and
settings. They will be activated as soon as you switch the
device back on.
9. Notes for changing the rechargeable battery
You may only use the rechargeable battery specified
for MANO. A replacement can only be purchased from
Reinecker Reha-Technik GmbH or from one of its
contractual partners.
37
EN

9.1 Changing of the rechargeable battery
Switch off MANO and pull the DC plug of the power
supply out of the DC nut of MANO. Open the folding
stand. Push the cover plate of the rechargeable battery
softly out of its lock (1), take out the cover plate (2). Take
the rechargeable battery out of the bay (deepening of the
handle at the edge). Put the original rechargeable battery
into the bay (Beware of the positioning due to the con-
tacts). Put the cover plate with the fasteners in front of
the lock holders onto the rechargeable battery. Press on
the plate evenly and into the direction of the LEDs.
Push all the way until stop.
38
1
2
folding stand
cover plate

9.2 Non-liability in case of using wrong
rechargeable battery
!Please note!
You may only use the rechargeable battery specified for
MANO.
The usage of rechargeable batteries other than one
provide by Reinecker Reha-Technik GmbH or one of
its partners is specifically prohibited, as this may cause
severe damage to the device.
The MANO warranty is voided if any other rechargeable
battery is used.
Reinecker Reha-Technik is not liable for damage caused
by wrong or faulty rechargeable batteries as well as
inappropriate operation when using the rechargeable
battery, be it damage to property or persons.
9.3 Disposal of the rechargeable battery
Rechargeable batteries must be disposed of according
to the laws of the specific countries. They must not be
burned. Do not allow animals or children to play with the
battery.
9.4 Protective circuit of the rechargeable
batteries
Despite the protective circuit applied at the rechargeable
battery, it is prohibited to short-circuit the contacts of the
rechargeable battery with a metallic item.
This may cause the rechargeable battery to explode,
creating potential danger for anyone nearby.
39
EN

10. Protective bag
Please always use the protective bag for storing MANO.
The display and the case will thus be protected from
damage.
11. Hand strap
In the cardboard box a hand strap is included. It may be
attached to carry MANO on your wrist.
40

12. Notes for handling
!Please note!
• The pictures used in this manual only serve illustrative
purposes and may not be in accordance with the actual
positions. Content changes of this manual are subject to
change without advance notice.
• Do not expose MANO to extreme direct sunlight. For
instance, do not store it close to windows or heaters.
• Protect MANO from excessive heat and do not place
other objects on top of it.
• Keep all liquids away from MANO.
• Use MANO only in dry surroundings.
• Never open the case, as this may only be done by an
authorized speciality retailer.
• Operate MANO only with the indicated supply voltage.
• Protect MANO from mechanical damage which may be
caused by stroke, blow or fall.
• Do not expose MANO to magnetic fields.
• Do not alter MANO in any way.
• Send MANO only in its original packaging.
• Never use MANO with wet hands.
• Use the fabric bag for carrying in bags or other
containers.
41
ENEN

13. Cleaning of the device
For cleaning of the display, use the included microfibre
tissue or another dry and soft tissue. Do not use any
liquids for cleaning. Never clean the display or the case
with thinner, gasoline, alcohol, or other chemical means.
The case parts may be damaged.
14. CE and FCC notes for electro-magnetic
compatibility (EMV)
MANO is suited for use in all facilities, including all homes
and offices connected to the public power supply.
MANO is destined for operation in the indicated electro-
magnetic surrounding. The operator should make sure to
use it in a surrounding as described in this manual.
MANO uses HF energy exclusively for its own function.
Therefore transient emissions of high-frequency transi-
ents are limited. It is unlikely to disturb other devices in
operation nearby.
MANO has been verified according to the European regu-
lations of each country as well as to the FCC regulations.
It is guaranteed that the limits determined in the regulati-
ons will not be exceeded. However, one should consider
that common operation of MANO and other devices may
lead to interferences between MANO and other devices.
For this reason one should not locate the device within
proximity of another device. Keep a distance of 1 meter
(3 feet.)
42
