RELACART Set 1x WAM-400 and 4x UB-200 System

Digital conference system, 4-channel mixer and 4 UHF mics, 823-832 + 863-865 MHz Art. No.: 13055223

GTIN:

The article is no longer in our assortment.

LogisticDescription:

The WAM-400 is a wireless, DSP-based conference system that subtly and automatically

carries out a number of functions in the background. Thus, it is also suitable for environments

without present technical personnel such as video conferencing, large meetings or public

sessions. Voice signals are detected intelligently, feedback and background noise thus

successfully prevented. The WAM-400 is very flexible thanks to numerous accessories

Features:

Digital conference system, 4-channel mixer and 4 UHF mics, 823-832 + 863-865 MHz

- Line input e.g. for multimedia applications from PC, laptop, MP3 players

- Rack installation, 1 U

Package contents

- 1 x microphone

RELACART WAM-400 4CH Digital UHF Automatic Mixer

Digital UHF automatic mixer with DSP for up to 4 microphones

- 4 digital input channels for matching wireless microphones, e.g. UB-200 and UD-200

- 2 license-free frequency ranges: 823-832 MHz (Duplex Gap) and 863-865 MHz

- Infrared interface for easy and error-free channel transfer to transmitters via infrared signal

- Precise and noise-free microphone selection that automatically adjusts to changes in

background room noise

- Eliminates acoustic feedback and background noise

- Automatic mixing technology activates only those microphones being addressed

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

- Number of open microphones adjustable

- Control algorithm adjusts gain automatically

- Auto mixing parameters adjustable

- 2 units can be linked for operation with 8 wireless microphones, link cables included

- User-friendly menu operation via LCD

- Last used microphone stays activated (switchable)

- Adjustable priority circuit for each microphone

- Automatic frequency scan (AFS) finds interface-free channels

- Lock function avoids accidental changing of settings

- Inputs e.g. for multimedia applications from PC, laptop, MP3 players

- Balanced and unbalanced outputs for PA or recording applications

- Two removable antennas (BNC connection)

- License-free and approved in large parts of the EU (please check Duplex Gap on a country-by-

country basis)

- Digital signal processor

- UHF 863 - 865 MHz License-free and approved in europe

- UHF 823 - 832 MHz License-free and approved in large parts of europe

- Operating range up to 60m

- The device can be connected via RS 232 to the PC

- (19") 48.3 cm rack installation 1 U

Package contents

- 1 x receiver, 1 x external mains adapter, 2 x antenna, 1 x jack cable, 1 x xLR cable, 1 x bNC

cable, 1 x user manual, 1 x declaration of conformity

RELACART UB-200 UHF-Boundary Microphone

UHF boundary microphone with PLL multifrequency transmitter

- Electret boundary microphone with UHF pilot tone technology (PLL)

- 2 license-free frequency ranges: 823-832 MHz (Duplex Gap) and 863-865 MHz

- Parallel operation of up to 9 transmitters is possible without any interference

- Suitable for the WAM-400 automatic mixer

- Infrared interface for easy and error-free synchronization with the receiver via infrared signal

- LCD for battery status, frequency and channel

- Durable metal diecast housing

- License-free and approved in large parts of the EU (please check Duplex Gap on a country-by-

country basis)

- Polar pattern: Semi-cardioid

- UHF 863 - 865 MHz License-free and approved in europe

- UHF 823 - 832 MHz License-free and approved in large parts of europe

- Operating range up to 60m

Package contents

- 1 x transmitter, 1 x declaration of conformity, 1 x battery

Technical specifications:

Type: Mixer

Weight: 4,90 kg

RELACART WAM-400 4CH Digital UHF Automatic Mixer

Type: Mixer

Power supply: 100-240 V AC, 50/60 Hz

12 V DC 1 A

Power consumption: 7,5 W

Power connection: Mains input via Coaxial power connector (M)

power supply cord with AC adapter (provided)

Number of channels: 4

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Frequency range: 65 - 16000 Hz

S/N ratio: >100 dB

DSP: Digital signal processor

Connections: Antenna via 2 x BNC (F) 8 V

Output: line via 1 x 3-pin XLR

Output: line via 1 x 6.3 mm plug (unbal.)

Output: line via 1 x stereo RCA

Input: line via 1 x stereo RCA

Link: 2 x Mini DIN 4-pin (W) mounting version

Link: 2 x DB-9 (F) mounting version

Frequency band: UHF 863 - 865 MHz; UHF 823 - 832 MHz

Frequency selection: 90 Switchable frequencys

In 10 groups with up to 10 preset frequencies

each

Modulation: FM

Frequency stability: ± 0,001 %

Range: Range up to 60m

Switching bandwidth: 11 MHz

Switch: On/off switch

Diversity: True diversity

Material: Metal

PC connect: Via RS 232

Housing design: (19") 48.3 cm rack installation 1 U

Dimensions: Width: 48,3 cm

Depth: 24,5 cm

Height: 4,45 cm

Weight: 2,88 kg

RELACART UB-200 UHF-Boundary Microphone

Type: Boundary microphone

Power supply: 3 V DC

Power connection: Battery/battery pack

Capsule type: Electret

Polar pattern: Semi-cardioid

Battery: 2 x Mignon (AA) (not included)

Frequency range: 50 - 17000 Hz

Frequency band: UHF 863 - 865 MHz; UHF 823 - 832 MHz

Frequency selection: Switchable frequencys

Modulation: FM

RF power output: 10 mW

Frequency stability: ± 0,0005 %

Range: Range up to 60m

Switching bandwidth: 11 MHz

Switch: On/off switch

Material: Metal

Dimensions: Width: 11 cm

Eurolite®, Futurelight®, PSSO®, Roadinger®, Alutruss®, Europalms® and Dimavery® are trademarks of Steinigke Showtechnic GmbH, Andreas-Bauer-Straße 5, DE-97297 Waldbüttelbrunn

Depth: 11,9 cm

Height: 4,1 cm

Weight: 510 g
