REMKO EFS Series User manual

Operating and
installation instructions
Read the instructions prior to performing any task!
REMKO EFS series
FC 3.10
Fresh water station controller
0282-2021-03 Edition 1, en_GB
Instructions for users and specialists

Translation of the original
Read these operating instructions carefully before commis-
sioning / using this device!
These instructions are an integral part of the system and must
always be kept near or on the device.
Subject to modifications; No liability accepted for errors or mis-
prints!

Table of contents
1 Safety and usage instructions............................................................................................................. 5
1.1 General safety notes....................................................................................................................... 5
1.2 Identification of notes...................................................................................................................... 5
1.3 Personnel qualifications.................................................................................................................. 5
1.4 Dangers of failure to observe the safety notes................................................................................ 5
1.5 Safety-conscious working............................................................................................................... 5
1.6 Safety instructions for the operator................................................................................................. 6
1.7 Safety notes for installation and inspection tasks........................................................................... 6
1.8 Unauthorised modification and changes......................................................................................... 6
1.9 Intended use................................................................................................................................... 7
1.10 Safety-conscious working............................................................................................................. 7
1.11 Warranty........................................................................................................................................ 7
1.12 Transportation and packaging....................................................................................................... 7
1.13 Environmental protection and recycling........................................................................................ 7
2 Technical data........................................................................................................................................ 8
2.1 Unit data.......................................................................................................................................... 8
2.2 Cable specification.......................................................................................................................... 9
3 Unit construction and operation........................................................................................................ 10
3.1 Housing and buttons..................................................................................................................... 10
3.2 Display........................................................................................................................................... 11
4 Assembly and installation.................................................................................................................. 12
4.1 Mounting the controller.................................................................................................................. 12
4.2 Electrical wiring............................................................................................................................. 14
5 Commissioning................................................................................................................................... 15
5.1 Commissioning.............................................................................................................................. 15
5.2 Menu settings................................................................................................................................ 18
5.3 Status............................................................................................................................................ 20
5.4 Hot water....................................................................................................................................... 22
5.5 Functions....................................................................................................................................... 23
5.6 Basic settings................................................................................................................................ 23
5.7 Internet module............................................................................................................................. 25
5.8 USB............................................................................................................................................... 25
5.9 Automatic/manual mode............................................................................................................... 27
5.10 Operator code............................................................................................................................. 28
5.11 Expanded settings....................................................................................................................... 28
6 Controller parameters......................................................................................................................... 29
7Function description........................................................................................................................... 35
7.1 Circulation..................................................................................................................................... 35
7.2 Return flow stratification (RF stratification)................................................................................... 38
7.3 Sliding TWW regulation................................................................................................................. 39
7.4 Comfort function............................................................................................................................ 39
7.5 Disinfection.................................................................................................................................... 40
7.6 Fault relay..................................................................................................................................... 41
7.7 Parallel relay................................................................................................................................. 42
7.8 Hygiene flushing............................................................................................................................ 42
7.9 Buffer tank *)................................................................................................................................. 43
3

7.10 Reheating *)................................................................................................................................ 43
8 Cascade controller installation.......................................................................................................... 44
8.1 General......................................................................................................................................... 44
8.2 Installation..................................................................................................................................... 44
8.3 Initial commissioning of the cascade controller............................................................................. 48
8.4 Expansion of an individual controller to the cascade network....................................................... 49
8.5 Cascade menu settings................................................................................................................. 50
8.6 Cascade on client submenu.......................................................................................................... 52
8.7 Submenus on the server............................................................................................................... 53
8.8 Functions in the cascade network................................................................................................. 54
9 Troubleshooting.................................................................................................................................. 57
9.1 Fault messages............................................................................................................................. 57
9.2 Troubleshooting............................................................................................................................ 58
9.3 Check flow probe VFS 2-40.......................................................................................................... 59
9.4 FlowSonic flow rate probe............................................................................................................. 61
10 Index..................................................................................................................................................... 62
REMKO EFS series
4

1 Safety and
usage instructions
1.1 General safety notes
Carefully read the operating manual before com-
missioning the units for the first time. It contains
useful tips and notes such as hazard warnings to
prevent personal injury and material damage.
Failure to follow the directions in this manual not
only presents a danger to people, the environment
and the system itself, but will void any claims for
liability.
Keep this operating manual and the refrigerant
data sheet near to the units.
1.2 Identification of notes
This section provides an overview of all important
safety aspects for proper protection of people and
safe and fault-free operation.The instructions and
safety notes contained within this manual must be
observed in order to prevent accidents, personal
injury and material damage.
Notes attached directly to the units must be
observed in their entirety and be kept in a fully
legible condition.
Safety notes in this manual are indicated by sym-
bols. Safety notes are introduced with signal words
which help to highlight the magnitude of the danger
in question.
DANGER!
Contact with live parts poses an immediate
danger of death due to electric shock. Damage
to the insulation or individual components may
pose a danger of death.
DANGER!
This combination of symbol and signal word
warns of a situation in which there is immediate
danger, which if not avoided may be fatal or
cause serious injury.
WARNING!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may be fatal or cause
serious injury.
CAUTION!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may cause injury or mate-
rial and environmental damage.
NOTICE!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may cause material and
environmental damage.
This symbol highlights useful tips and recom-
mendations as well as information for efficient
and fault-free operation.
1.3 Personnel qualifications
Personnel responsible for commissioning, opera-
tion, maintenance, inspection and installation must
be able to demonstrate that they hold a qualifica-
tion which proves their ability to undertake the
work.
1.4 Dangers of failure to observe
the safety notes
Failure to observe the safety notes may pose a risk
to people, the environment and the units. Failure to
observe the safety notes may void any claims for
damages.
In particular, failure to observe the safety notes
may pose the following risks:
nThe failure of important unit functions.
nThe failure of prescribed methods of mainte-
nance and repair.
nDanger to people on account of electrical and
mechanical effects.
1.5 Safety-conscious working
The safety notes contained in this manual, the
existing national regulations concerning accident
prevention as well as any internal company
working, operating and safety regulations must be
observed.
5

1.6 Safety instructions for the oper-
ator
The operational safety of the units and compo-
nents is only assured providing they are used as
intended and in a fully assembled state.
nThe units and components may only be set up,
installed and maintained by qualified per-
sonnel.
nThe existing regulations concerning accident
prevention must be adhered to.
nDo not operate units or components with
obvious defects or signs of damage.
nContact with equipment parts or components
can lead to burns or injury.
nEnsure that electrical energy does not pose a
risk.
nRegulations of the VDE and the local energy
supply company must be adhered to.
NOTICE!
Material damage due to mineral oils!
Mineral oil products permanently damage
EPDM seal elements; the sealing properties
may therefore be lost. We do not take responsi-
bility or provide warranty replacements for
damage caused by seals that are damaged in
this way.
–It is essential that you prevent EPDM from
coming into contact with mineral oil sub-
stances.
–Use a lubricant that is free of mineral oil and
has a silicone or polyalkylene basis, such
as Unisilkon L250L and Syntheso Glep 1
made by Klüber, or a silicon spray.
1.7 Safety notes for installation and
inspection tasks
nThe operator must ensure that all inspection
and installation work is carried out by author-
ised and qualified personnel who have thor-
oughly read the operating manual.
nWorks on the pump/system may only be car-
ried out whilst at a standstill as a matter of prin-
ciple.
nAppropriate hazard prevention measures must
be taken to prevent risks to people when per-
forming installation, repair, maintenance or
cleaning work on the units.
nThe setup, connection and operation of the
units and its components must be undertaken
in accordance with the usage and operating
conditions stipulated in this manual and comply
with all applicable regional regulations.
nRegional regulations and laws as well as the
Water Ecology Act must be observed.
nThe power supply should be adapted to the
requirements of the units.
nThe units and components must be kept at an
adequate distance from flammable, explosive,
combustible, abrasive and dirty areas or
atmospheres.
nSafety devices may not be modified or
bypassed.
NOTICE!
Malfunction!
The fresh water module must be integrated into
the equipotential bonding system of the elec-
trical installation. If this is not ensured by the
pipe network, set up an approved potential
equalisation connection to the main potential
connection.
1.8 Unauthorised modification and
changes
The operational safety of the fresh water module
that was delivered is guaranteed only with
intended use in accordance with section 1.8 of the
operating instructions. Under no circumstances
should the threshold values specified in the data-
sheet be exceeded.
Modifications or changes to units and components
are not permitted and may cause malfunctions.
Safety devices may not be modified or bypassed.
Original replacement parts and accessories
authorised by the manufacturer ensure safety. The
use of other parts may invalidate liability for
resulting consequences.
REMKO EFS series
6

1.9 Intended use
The fresh water controller, subsequently referred to
as the controller, is an independent, mounted elec-
tronic temperature controller for assembly and
installation. Integration in a pump group is possible
if the technical data of the controller is complied
with. The maintenance-free controller is provided
exclusively for controlling and monitoring a
REMKO fresh water station. Use only REMKO
accessories in conjunction with the controller.
Any different or additional use is a non-intended
use. The manufacturer/supplier assumes no lia-
bility for damages arising from a non-intended use.
The user bears the sole risk in such cases.
Intended use also includes working in accordance
with the operating and installation instructions and
complying with the maintenance requirements.
The threshold values specified in the technical
data must not be exceeded.
1.10 Safety-conscious working
The safety notes contained in this manual, the
existing national regulations concerning accident
prevention as well as any internal company
working, operating and safety regulations must be
observed.
1.11 Warranty
For warranty claims to be considered, it is essential
that the ordering party or its representative com-
plete and return the "certificate of warranty" to
REMKO GmbH & Co. KG at the time when the
units are purchased and commissioned.
The warranty conditions are detailed in the "Gen-
eral business and delivery conditions". Further-
more, only the parties to a contract can conclude
special agreements beyond these conditions. In
this case, contact your contractual partner in the
first instance.
1.12 Transportation and pack-
aging
The units are shipped in sturdy transport pack-
aging or within the heat pump housing. Immedi-
ately check the units on delivery and make a note
of any damage or missing parts on the delivery
note. Inform the forwarding agent and contractual
partner. Claims under guarantee made at a later
date will not be accepted.
WARNING!
Plastic films and bags etc. are dangerous
toys for children!
Why:
- Leave packaging material are not around.
- Packaging material may not be accessible to
children!
1.13 Environmental protection and
recycling
Disposing of packaging
All products are packed for transport in environ-
mentally friendly materials. Make a valuable contri-
bution to reducing waste and sustaining raw mate-
rials. Only dispose of packaging at approved
collection points.
Disposing of the units and their components
For the manufacture of the units and components,
only recyclable materials have been used. Help
protect the environment by ensuring that the units
or components (for example batteries) are not dis-
posed of in household waste, but only in accord-
ance with local regulations and in an environmen-
tally safe manner, e.g. using authorised disposal
and recycling specialists or council collection
points.
7

2 Technical data
2.1 Unit data
Series FC 3.10
General
Rated voltage (system voltage) V / Hz 115... 230V~ / 50/60 Hz
Energy consumption W < 2.5
Private consumption stand-by W < 1
Max. current consumption including out-
puts A < 4.2
Outputs
Outputs R1, R2
Type
Switching current
Voltage
Relays
1 (1) A
115... 230V~ / 50/60 Hz
Output R3
Type
Switching current
Voltage
Relays
2 (2) A
115... 230V~ / 50/60 Hz
Complete
Switching current
Voltage
4 (4) A
115... 230V~ / 50/60 Hz
Signal inputs
Temperature
Number
Designation
4
S1..S4, probe 1..4
Medium flow rate
Number
Type
Channels per probe
Voltage
Current (max.)
2
VFS / US
2 (V and T)
5VDC ±5%
20 mA
PWM
Number
Frequency
Voltage
2
75 Hz
10 V
REMKO EFS series
8

Unit data (continued)
Series FC 3.10
Signal outputs
PWM
Number
Frequency
Voltage
Current (max.)
2
200 Hz
10 V
10 mA
Modbus
Number of connections
Type
2
RJ9
Internal bus
Number of connections
Type
1
RJ12
Operating conditions
Enclosure class
Protection class
Ambient temperature
IP 20, DIN 40050 [without front panel: IP 20]
I
0 ...50 °C for free wall mounting
Physical values
Dimensions L x W x H mm 164 x 112 x 55
Weight g 390
Housing temperature °C max. 90
2.2 Cable specification
Mains cable
Mains power supply type
Outer diameter of jacket
Single wire cross section (rigid)
finely-stranded (with wire end sleeves)
H05 VV-... (NYM…)
6.5 mm to 10 mm
≤ 2.5 mm2
≤ 1.5 mm2
Diameter of the internal strain relief mm 6.5 to 10
Signal cable
Length of probe cable m ≤ 100 m, including extension
Extension cable for probe configuration
Cross-section per conductor
Wires twisted in pairs for length > 10 m
0.75 mm2 for length < 50m
1.5 mm2 for length > 50 m
9

3 Unit construction and
operation
3.1 Housing and buttons
1
2
3
Fig. 1: Front view of the controller
1: Display with hydraulic diagram
2: Buttons
3: USB service interface (beneath the cover)
Buttons / key combination
Key Description
Back: jumps back to the next
highest level or back to the
system overview
Up: navigate up in the menu,
increase setting value
Down: navigate down in the
menu, decrease setting value
Confirm: Opens the main
menu, jumps to the next
lowest level, confirms set
values, activates functions
Key combination
Stand-by on Back and Confirm: Press
and hold keys
Stand-by off Back: Press and hold key for
approx. 5 seconds
Factory settings Confirm: Press and hold key
for approx. 30 seconds
Software update
Up and down: Press and
hold key for approx. 5 sec-
onds (USB stick connected
with firmware version)
REMKO EFS series
10

3.2 Display
Overview
1 2 3 4
8765
Fig. 2: Display
1: Time with weekday
2: Inlet temperature (T-VL)
3: Medium flow rate (VFS V)
4: Remaining disinfection time
5: Primary pump speed (PWM 1)
6: Cold water temperature (T-KW)
7: Hot water temperature (T-WW)
8: Circulation pump speed (PWM 2)
Symbols
Symbol Description
3-way valve with flow direction
Checkbox (activated/deactivated)
Disinfection active
Fault message
Manual mode
Pump
Storage tank
Thermometer
Heat exchangers
Water extraction point
Sliding TWW regulation active
USB recording active
11

4 Assembly and installation
4.1 Mounting the controller
The following section only describes the installation of the controller.
When installing external components (valves etc.), follow the instructions provided by the relevant manufac-
turer.
Do not bring the controller into operation if there is visible damage
DANGER!
Danger of death due to electric shock!
- Disconnect the controller from the power supply before opening the housing.
- Ensure that the power supply cannot be switched on inadvertently when the housing is open.
2
1
4
3
5
67
89
1: Temperature probes S1-S4 (Pt1000)
2: Flow probe (VFS/US)
3: Outputs PWM
4: Modbus RS485
5: RS232
6: Outputs 230V
7: Power supply
8: Seating of the jumper
9: Fuse
REMKO EFS series
12

Inputs EFS 20.1
Terminal Individual operation / cascade operation
S1, ^Inlet temperature, primary (T-VL)
S2, ^Optional: Storage tank temperature (T-SP), ext. Circulation temperature, ext. Return flow strat-
ification temperature (EFS 20.1)
S3, ^Optional: Storage tank temperature (T-SP), ext. Circulation temperature, ext. Return flow strat-
ification temperature (EFS 35.1 and EFS 50.1)
S4, ^Cold water temperature, secondary (T-KW)
VFS/US1 Hot water temperature (T-WW) and medium flow rate, secondary
Inputs EFS 35.1 and 50.1
Terminal Individual operation / cascade operation
S1, ^Inlet temperature, primary (T-VL)
S2, ^Hot water temperature, secondary (T-WW)
S3, ^Optional: Storage tank temperature (T-SP), ext. Circulation temperature, ext. Return flow strat-
ification temperature (EFS 35.1 and EFS 50.1)
S4, ^Cold water temperature, secondary (T-KW)
VFS/US1 Medium flow rate, secondary
Outputs
Terminal Individual operation Cascade operation
R1 Optional: Alarm relay, fault relay, reheating,
return flow stratification Cascade valve/zone valve
R2 Optional: Return flow stratification, alarm
relay, fault relay, reheating
Return flow stratification (optional, on server
1)
R3 Primary/secondary pump Primary/secondary pump
PWM 1 Primary pump Primary pump
PWM 2 Secondary pump (circulation) Secondary pump (circulation on client)
13

4.2 Electrical wiring
DANGER!
Danger to life and limb due to electric
shock!
Ensure that the following conditions are met
when carrying out the works described in this
section:
- During installation, all cables to the controller
must be disconnected from the mains and
cannot be inadvertently connected to the mains!
- The earth conductors (PE) from the power
supply, pump cables and valve cables are con-
nected to the terminal block earth conductors.
- All cables are located so that people cannot
step on them or trip over them.
- The cables fulfil the requirements specified in
the “Technical data” section.
- The local power supply matches the data on
the name plate of the controller.
- The power supply cable is to be connected to
the mains as follows:
-- with a plug to a wall socket or
-- via an isolating device for full isolation in fixed
locations.
- The power supply cable is located according
to the legal and local regulations of the respon-
sible electricity supply company.
NOTICE!
Danger of damage and malfunction!
–Only connect components that do not over-
load the inputs and outputs of the controller;
for more information, see the name plate
and “Technical data” section.
NOTICE!
Danger of damage and malfunction!
–When using a circulation pump, the current
consumption of the pump connected to the
controller must always be observed and the
current consumption matched to the con-
troller. In some cases the circulation pump
must be supplied directly via the power
supply. The speed is also controlled via the
PWM signal.
Important information
nThe polarity of signal inputs/outputs 1 – 4 is not
fixed during connection.
nOnly temperature probes of type Pt1000 are
permitted.
nProbe cables must be located at least 100 mm
away from power supply cables.
nUse shielded probe cables if inductive sources
are present, e.g. high-voltage cables, radio
transmitters, microwave units.
REMKO EFS series
14

5 Commissioning
5.1 Commissioning
DANGER!
Contact with live parts poses an immediate
danger of death due to electric shock. Damage
to the insulation or individual components may
pose a danger of death.
If the controller is connected for the first time, the
message “Please carry out initial commis-
sioning” appears on the main screen. When con-
firming with “Yes”, the commissioning menu
appears in which the desired basic settings can be
made intuitively.
If the power supply is interrupted after the initial
commissioning, you can press “NO” on the display
for the initial commissioning. It is not necessary to
carry out the initial commissioning again.
Select the parameters desired for this using the
“” and “ ” keys and confirm with the “ ”
key to go into the submenu.
Navigate to the next parameter using the “ ”
and “ ” keys in the submenu and confirm with
the “ ” key.
After selecting and confirming the desired parame-
ters, press the “ ” key in order to adjusted the
next commissioning parameter in the main menu.
C O M M I S S I O N I N G
L a n g u a g e
C o n t r o l l e r m o d e
D a t e
T i m e
Language
Setting the desired menu language.
L A N G U A G E
D e u t s c h ( D E )
P o l s k i ( P L )
E n g l i s h ( E N G )
F r a n ç a i s ( F R )
Controller type
Setting the available controller type. The individual
controller menu item should be selected if you
would only like to bring one fresh water station into
operation. If you switch on several fresh water sta-
tions (stations 2 to 4) hydraulically in parallel, these
controllers are designated as cascading. The con-
trollers are connected to each other via a BUS line
and are designated as “Client” or “Server”.
C O N T R O L L E R M O D E
S i n g l e c o n t r o l l e r
C l i e n t ( I D 1 )
S e r v e r 1 ( I D 2 )
S e r v e r 2 ( I D 3 )
15

Date
Setting the current date. First the day, then the
month and finally the year.
S E T D A T E
17 – 03 – 2020
D a y
Time
Setting the current time. First the hour, then the
minutes.
S E T T I M E
09 : 16
H o u r
Automatic summer/winter time
Activate/deactivate automatic summer/winter time
adjustment. This point is activated when delivered.
Scan Modbus
The fresh water stations which are operating in
cascade mode are identified via the Scan Modbus
menu item.
The point indicates which controller type is cur-
rently being searched for.
S C A N M O D B U S S T A T U S
S e r v e r 1 O K
S e r v e r 2
- - -
S e r v e r 3
- - -
I O - M O D U L
- - -
M B 3 . 1 0
- - -
Nominal temperature
Setting the desired target temperature for the hot
water.
N O M I N A L T E M P E R A T U R E
60 °C
6 0 ° C
M I N : 3 5 M A X : 7 5
Functions
Activation/deactivation of the functions as well as
other, associated settings. All functions except
overtemperature protection are deactivated
when delivered and after resetting to factory set-
tings. Detailed information is shown in the “Func-
tions” chapter.
The following functions are available:
nCirculation
nReturn flow stratification
nSliding TWW regulation
nComfort function
nDisinfection
nFault relay
nParallel relay
nHygiene flushing
nBuffer tank
nReheating
End with logging
Save commissioning with production of a log. To
do this, an external storage device (USB stick)
must be inserted into the service interface/USB
port. This interface is first accessible when the
front panel is removed from the controller.
REMKO EFS series
16

End without logging
Ends commissioning without saving onto an external USB stick.
The settings made during commissioning can be changed again at any time in the corresponding submenus.
The controller is ready for use after carrying out commissioning.
Parameter Meaning Adjustment range Factory setting
Language Selection of the menu lan-
guage
German Deutsch
Polish
English
French
Spanish
Italian
Controller type Setting the controller type Individual controller, Individual controller
Client
Server 1
Server 2
Server 3
I/O module
Deactivated
Date Setting the date --- ---
Time Setting the time --- ---
Auto.
Summer/winter time
Activate automatic time
changeover
Yes, no Yes
Scan Modbus Identification of the stations --- ---
Nominal temperature Setting the hot water target
temperature 35 ... 75 °C 60 °C
Functions Functions submenu --- ---
End with logging Save with logging --- ---
End without logging Save without logging --- ---
17

5.2 Menu settings
The FC3.10 controller menu opens when pressing the ( ) button. The menu bar includes several sub-
menus in which various settings can be edited or viewed. The available menu items of the first three “levels”
are shown in the form of a menu tree and are explained in detail in the following chapter.
MENU
Status
Measurement/result
Messages
Service
Controller
Hot water
Nominal temperature
Minimum temperature *)
Maximum temperature *)
Functions
Circulation
RF stratification
Sliding TWW regulation
Comfort function
Disinfection
Fault relay
Parallel relay
Hygiene flushing/
Blockage protection
Buffer tank *)
Reheating *)
Basic settings
Language
Date
Time
Date/time sync.
Automatic summer/winter time
Commissioning *)
Software update
Display
REMKO EFS series
18

Menu settings (continued)
MENU
Internet module
Registration
DHCP
IP address
Network mask
Gateway address
DNS address
Information
USB
Remove data carrier
Load settings
Save settings
Save alarm process
Save parameter process
Log interval
Type of logging
Format data carrier
Features
Automatic/manual mode
Automatic mode
Probe simulation
Relay 1
Relay 2
Relay 3
PWM 1
PWM 2
Operator code Factory code (9856)
Expanded settings *) Minimum speed *)
*) Settings only visible with installer code (see “Operator code” chapter).
19

5.3 Status
Submenus are assigned the “status” menu item
which makes it possible to check all measure-
ments/results, temperatures and medium flow
rates on the probes, relay statuses, operating
times, heat content, dispensing volumes and an
overview of the error messages. Furthermore, the
current firmware can be read under the “Controller”
point.
S T A T U S
M e a s u r e d / b a l a n c e va l u e s
R e p o r t s
S e r v i c e
C o n t r o l l e r
Measurement and result
This menu item includes information about all cur-
rent measurement values of the probes, their min-
imum and maximum measurement value and the
statuses of the relays (R1, R2, R3). The minimum
and maximum measurement values can be reset
by pressing the “Confirm” button.
S E N S O R S 1 / 2
ACT. MIN: MAX:
S e n s o r S 1 ° C 79.4 78.9 80.6
S e n s o r S 2 ° C -- 0.0 0.0
S e n s o r S 3 ° C 157.1 156.7 158.8
S e n s o r S 4 ° C 9.8 8.2 13.4
Furthermore, the current operating times, switch
cycles, heat content and dispensing volumes are
recorded and can be viewed in the respective sub-
menu. An example is shown in the following figure.
W O R K T I M E S
R e l a y 1 0 D 0 7 H 0 1 M
R e l a y 2 0 D 0 0 H 0 0 M
R e l a y 3 0 D 0 0 H 0 0 M
P u m p 1 0 D 0 7 H 0 0 M
P u m p 2 0 D 0 0 H 0 0 M
The heat content and the dispensing volumes are
shown in the following time periods:
nCurrent
nDay
nWeek
nMonth
nComplete
nTotal since
There is also the option of resetting the data of the
time periods via the “Confirm” key.
REMKO EFS series
20
