MITSUBISHI 8-BIT SINGLE-CHIP MICROCOMPUTER
740 FAMILY / 7200 SERIES
7220
Group
User’s Manual

keep safety first in your circuit designs !
●Mitsubishi Electric Corporation puts the maximum effort into making semiconductor
products better and more reliable, but there is always the possibility that trouble
may occur with them. Trouble with semiconductors may lead to personal injury,
fire or property damage. Remember to give due consideration to safety when
making your circuit designs, with appropriate measures such as (i) placement
of substitutive, auxiliary circuits, (ii) use of non-flammable material or (iii) prevention
against any malfunction or mishap.
Notes regarding these materials
●These materials are intended as a reference to assist our customers in the
selection of the Mitsubishi semiconductor product best suited to the customer’s
application; they do not convey any license under any intellectual property rights,
or any other rights, belonging to Mitsubishi Electric Corporation or a third party.
●Mitsubishi Electric Corporation assumes no responsibility for any damage, or
infringement of any third-party’s rights, originating in the use of any product
data, diagrams, charts or circuit application examples contained in these materials.
●All information contained in these materials, including product data, diagrams
and charts, represent information on products at the time of publication of these
materials, and are subject to change by Mitsubishi Electric Corporation without
notice due to product improvements or other reasons. It is therefore recommended
that customers contact Mitsubishi Electric Corporation or an authorized Mitsubishi
Semiconductor product distributor for the latest product information before
purchasing a product listed herein.
●Mitsubishi Electric Corporation semiconductors are not designed or manufactured
for use in a device or system that is used under circumstances in which human
life is potentially at stake. Please contact Mitsubishi Electric Corporation or an
authorized Mitsubishi Semiconductor product distributor when considering the
use of a product contained herein for any specific purposes, such as apparatus
or systems for transportation, vehicular, medical, aerospace, nuclear, or undersea
repeater use.
●The prior written approval of Mitsubishi Electric Corporation is necessary to
reprint or reproduce in whole or in part these materials.
●If these products or technologies are subject to the Japanese export control
restrictions, they must be exported under a license from the Japanese government
and cannot be imported into a country other than the approved destination.
Any diversion or reexport contrary to the export control laws and regulations of
JAPAN and/or the country of destination is prohibited.
●Please contact Mitsubishi Electric Corporation or an authorized Mitsubishi
Semiconductor product distributor for further details on these materials or the
products contained therein.

Preface
This manual describes the hardware of the Mitsubishi
CMOS 8-bit microcomputers 7220 group.
After reading this manual, the user should have a
through knowledge of the functions and features of
7220 group, and should be able to fully utilize the
product. The manual starts with specifications and
ends with application examples.
For details of software, refer to the “SERIES 740
<SOFTWARE> USER’S MANUAL.”
For details of development support tools, refer to the
“DEVELOPMENT SUPPORT TOOLS FOR
MICROCOMPUTERS” data book.

i
BEFORE USING THIS MANUAL
This user’s manual consists of the following chapters. Refer to the chapter appropriate to your conditions,
such as hardware design or software development. The M37221M6-XXXSP/FP is used as a general example
in describing the functions of the 7220 group, unless other wise noted.
1. Organization
● CHAPTER 1 HARDWARE
This chapter describes features of the microcomputer, pin configuration, pin description, functional
block diagram.
●CHAPTER 2 FUNCTIONAL DESCRIPTION
This chapter describes operation of each peripheral function.
●CHAPTER 3 ELECTRIC CHARACTERISTICS
This chapter describes electric characteristics and standard characteristics.
●CHAPTER 4 M37220M3-XXXSP/FP
This chapter describes differences between the M37220M3-XXXSP/FP and M37221M6-XXXSP/FP.
●CHAPTER 5 APPLICATION
This chapter describes usage and application examples of peripheral functions, based mainly on
setting examples of related registers.
●CHAPTER 6 APPENDIX
This chapter includes precautions for systems development using the microcomputer, a list of control
registers, the mask ROM confirmation forms (mask ROM version) and mark specification forms which
are to be submitted when ordering.

ii
2. Register diagram
The figure of each register structure describes its functions, contents at reset, end attributes as follows:
Values immediately after reset release
Bit attributes
(Note 1)
(Note 2)
Bits
2: Bit attributes••••••The attributes of control register bits are classified into 3 types : read-only, write-only
and read and write. In the figure, these attributes are represented as follows :
: Bit in which nothing is assigned
Notes 1: Values immediately after reset release
0••••••“0” after reset release
1••••••“1” after reset release
?••••••Indeterminate after reset release
••••••Read enabled
••••••Read disabled
R••••••Read ••••••Write enabled
••••••Write disabled
••••••“0” can be set by software, but “1”
cannot be set.
W••••••Write
b7b6 b5b4b3 b2b1b0 CPU mode register (CPUM) (CM) [Address FB 16]
B After reset RW
CPU Mode Register
0, 1
2
3
to
5
0
1
Name Functions
Fix these bits to “0.”
Fix these bits to “1.”
1
Stack page selection
bit (CM2)
1
0: 0 page
1: 1 page
100
6, 7 Indeterminate
111
RW
RW
RW
RW
R
—W —
✽

7220 Group User’s Manual i
