Renishaw UCC dynamic mapping tool User manual
General information
© 2017 ‐ 2021 Renishaw plc. All rights reserved.
ORIGINAL LANGUAGE VERSION
This document may not be copied or reproduced in whole or in part, or transferred to any other media or language by any means, without the
prior written permission of Renishaw.
Disclaimer
WHILE CONSIDERABLE EFFORT WAS MADE TO VERIFY THE ACCURACY OF THIS DOCUMENT AT PUBLICATION, ALL WARRANTIES,
CONDITIONS, REPRESENTATIONS AND LIABILITY, HOWSOEVER ARISING, ARE EXCLUDED TO THE EXTENT PERMITTED BY LAW.
RENISHAW RESERVES THE RIGHT TO MAKE CHANGES TO THIS DOCUMENT AND TO THE EQUIPMENT, AND/OR SOFTWARE AND THE
SPECIFICATION DESCRIBED HEREIN WITHOUT OBLIGATION TO PROVIDE NOTICE OF SUCH CHANGES.
Trade marks
RENISHAW®, the probe symbol and REVO®are registered trade marks of Renishaw plc.
Renishaw product names, designations and the mark ‘apply innovation' are trade marks of Renishaw plc or its subsidiaries.
Other brand, product or company names are trade marks of their respective owners.
WEEE
The use of this symbol on Renishaw products and / or accompanying documentation indicates that the product should not be mixed with
general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for
waste electrical and electronic equipment (WEEE) to enable reuse or recycling. Correct disposal of this product will help to save valuable
resources and prevent potential negative effects on the environment. For more information, please contact your local waste disposal service
or Renishaw distributor.
Warranty
Unless you and Renishaw have agreed and signed a separate written agreement, the equipment and/or software are sold subject to the
Renishaw Standard Terms and Conditions supplied with such equipment and/or software, or available on request from your local Renishaw
office.
Renishaw warrants its equipment and software for a limited period (as set out in the Standard Terms and Conditions), provided that they are
installed and used exactly as defined in associated Renishaw documentation. You should consult these Standard Terms and Conditions to find
out the full details of your warranty.
Equipment and/or software purchased by you from a third-party supplier is subject to separate terms and conditions supplied with such
equipment and/or software. You should contact your third-party supplier for details.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
2
Care of equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with
care.
Changes to Renishaw products
Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to
Renishaw equipment previously sold.
Company registration details
Renishaw plc. Registered in England and Wales. Company no: 1106260. Registered office: New Mills, Wotton-under-Edge, Gloucestershire,
GL12 8JR, UK.
Packaging
To aid end user recycling and disposal the materials used in the different components of the packaging are stated here:
Packaging component Material 94/62/EC code 94/62/EC number
Outer box Polypropylene PP 5
Packing foam Low density polyethylene LDPE 4
Outer box Corrugated fibreboard PAP 20
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
3
Product compliance
EU declaration of conformity
Contact Renishaw plc or visit www.renishaw.com/EUCMM for the full EU declaration.
UK declaration of conformity
Contact Renishaw plc or visit www.renishaw.com/UKCMM for the full UK declaration.
EMC conformity
This equipment must be installed and used in accordance with this installation guide. This product is intended for industrial use only and
should not be used in a residential area or connected to a low voltage power supply network which supplies buildings used for residential
purposes.
FCC (USA only)
Information to user (47 CFR 15.105)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case you will be required to correct the interference at your own expense.
Information to user (47 CFR 15.21)
The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or authorised representative could void the
user's authority to operate the equipment.
Equipment label (47 CFR 15.19)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
4
ICES-001 (Canada only)
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme ICES‐001 du Canada.
REACH regulation
Information required by Article 33﴾1﴿ of Regulation ﴾EC﴿ No. 1907/2006 ﴾“REACH”﴿ relating to products containing substances of very high
concern (SVHCs) is available at:
www.renishaw.com/REACH
China RoHS
Contact Renishaw plc or visit www.renishaw.com/ChinaRoHSCMM for the full China RoHS tabulation.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
5
Safety
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
There are no user serviceable parts inside the equipment.
Power is supplied to the UCC dynamic mapping tool electronics via the USB connection to the PC.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
6
Environmental conditions
The following environmental conditions comply with those defined in BS EN61010-1:2001:
Indoor use IP40 (no protection against water)
Altitude Up to 2000 m
Operating temperature +5 °C to +55 °C
Storage temperature ‐25 °C to +70 °C
Relative humidity 80 % maximum for temperatures up to +31 °C.
Linear decrease to 50 % at +50 °C
Pollution degree 2
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
7
Introduction
The UCC dynamic mapping tool (DMT) enables laser error mapping to be run dynamically on a CMM. This speeds up the process of data
gathering and allows more data to be collected, ultimately giving a higher quality error map in a shorter time.
The DMT can only be used from UCCsuite 5.1 or later.
The DMT is compatible with the XL80 only.
Software setup
Error mapping is carried out through UCCassist-2 using the sequence player.
Prior to the error mapping runs, the XL80 is powered up and connected to the PC via its USB connection.
The DMT should be connected as per the instructions in this user guide prior to the first ‘Run Configuration' stage of the error mapping
sequence.
The software recognises that the DMT is connected and the ‘Run Configuration' window displays an additional settings section called ‘Trigger
Lead Capture'. These control how the system behaves during data capture when using the DMT.
The setting options are 'Move speed', 'Acceleration' and 'Capture speed'. Suitable settings will depend on the type of machine. For example,
acceleration may be reduced for heavy machines.
During data collection the machine will move continually and capture data in both the positive and negative direction.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
8
UCC T5 / UCC S5 and SPA3
The DMT 'Y' adaptor cable PICS connector must be connected to the PICS connection on the SPA3.
CAUTION: If using a PH20, ensure the orange cable is unplugged (this does not apply to REVO).
NOTE: For simplicity, only connectors relevant to the use of DMT are shown.
UCC dynamic mapping tool user's guide
www.renishaw.com
Issued 12 2021
12
UCC T3 PLUS / UCC S3 and SPA3
The DMT 'Y' adaptor cable PICS connector must be connected to the PICS connection on the UCC.
CAUTION: Ensure the scanning connector is unplugged if using a UCC S3 and scanning probe.
NOTE: For simplicity, only connectors relevant to the use of DMT are shown.
