Reverie R600 User manual

R600™ Power Base
Owner’s Manual and Reference Guide
REV: 2018-08-10
Manual Part No. LIT-MAN-DT
Copyright © 2018. All Rights Reserved.
Ascion LLC.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
2
CONGRATULATIONS ON YOUR PURCHASE
OF A REVERIE POWER BASE!
Please take a moment to follow the below steps to ensure the correct set-up (or pairing) of your
Reverie remote and Reverie NightstandTM app with your power base.
Step 1: Download the Reverie NightstandTM app from the App store for any of your Apple devices, or
from the Google Play store for any Android devices.
Step 2: Fully charge your remote before use.*
Step 3: Contact our customer service at 1-800-973-8374 or [email protected] if you
need any additional assistance.
* Remote will arrive with minimal charge, we recommend fully charging the remote battery before use.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
3
R600™ Power Base
Table of Contents
Safety Precautions ..............................................................................................4
Parts List ...........................................................................................................9
Assembly Instructions .......................................................................................10
App User Guide ................................................................................................13
Wireless Remote Control ..................................................................................16
Remote Control Operation Guide .....................................................................17
Bluetooth® Pairing (Replacement Remote Control) .........................................19
Troubleshooting ................................................................................................22
Warranty............................................................................................................25
Warranty Information: Please see warranty details at the end of this manual.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
4
Safety Precautions
SAFETY PRECAUTIONS
WARNING! IMPORTANT SAFETY INSTRUCTIONS.
PLEASE READ THESE INSTRUCTIONS
THOROUGHLY BEFORE USING THIS PRODUCT.
SAVE THESE INSTRUCTIONS!
When using an electrical furnishing basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS FURNISHING)
DANGER: To reduce the risk of electric shock:
Always unplug this furnishing from the electrical outlet before cleaning.
WARNING:
To reduce the risk of burns, re, electric shock, or injury to persons:
• Unplug from outlet before putting on or taking off parts.
• Close supervision is necessary when this furnishing is used by or near children, invalids or
disabled persons.
• Use this furnishing only for its intended use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
• Never operate this furnishing if it has a damaged cord or plug, or if it is not working properly,
dropped or damaged, or dropped into the water. Return the furnishing to a service center for
examination and repair.
• Keep the cord away from heated surfaces.
• Never operate the furnishing with the air openings blocked. Keep the air openings free of lint,
hair and the like.
• Never drop or insert any object into any opening.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
• To disconnect, turn all controls to the off position, then remove plug from outlet.
• Do not place remote in water or near areas of intense heat.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
5
Safety Precautions
WARNING: Risk of Injury:
Keep children away from extended foot support (or other similar parts).
WARNING: Risk of electric shock:
Connect this furnishing to a properly grounded outlet only.
See Grounding instructions.
GROUNDING INSTRUCTIONS:
This product must be grounded. If it should malfunction or breakdown, grounding provides a path
of least resistance for electric current to reduce the risk of electric shock. This product is equipped
with a cord having an equipment-grounding conductor and a grounding plug. The plug must be
plugged into an appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
DANGER:
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualied electrician or serviceman if you are in doubt as to whether the product is
properly grounded.
Do not modify the plug provided with the product. If it will not t the outlet, have a proper outlet
installed by a qualied electrician.
SAVE THESE INSTRUCTIONS!

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
6
Safety Precautions
This product is for use on a standard 120-volt circuit, and has a grounding plug that looks
like the plug illustrated in photo A (see Figure). A temporary adapter that looks like the
adapter illustrated in photo B and C can be used to connect this plug to a 2-pole receptacle
as shown in photo B if a properly grounded outlet is not available. The temporary adapter
should be used only until a properly grounded outlet (photo A) can be installed by a
qualied electrician. The green colored rigid ear, lug or the like extending from the adapter
must be connected to a permanent ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place by a metal screw.
This product is for use on a circuit having a standard rating of 120 volts and is factory equipped
with a specic electric cord and plug to permit connection to a proper electric circuit. Make sure
that the product is connected to an outlet having the same conguration as the plug. No adapter
should be used with this product. If the product must be reconnected for use on a different type of
electric circuit, the reconnection should be made by qualied service personnel.
Unauthorized modications could void the electrical portion of your warranty. Failure to use a
properly grounded outlet for this product or modication of the plug will compromise this important
grounding safety feature and may result in electrical shock, electrical re, or faulty operation of the
product.
FOR BEST RESULTS, YOUR POWER BASE SHOULD BE PLUGGED INTO A SURGE
PROTECTOR (not included).
WARRANTY PRECAUTION:
Do not open control box, motors or wireless remote controls (with the exception of the battery
compartment if equipped). The warranty is void if these units are tampered with. Any repair or
replacement of power base parts must be performed by an authorized technician.
IN-HOME USE AND HOSPITAL DISCLAIMER:
Your power base is strictly designed for in-home use only. It is NOT designed for hospital use
and is NOT designed to meet hospital standards. Do not use this base with TENT TYPE oxygen
therapy equipment or near explosive gases.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
7
Safety Precautions
WARNING!
DO NOT USE NEAR PEOPLE USING OR WEARING MEDICAL DEVICES. FOR HOUSEHOLD /
RESIDENTIAL USE ONLY. DO NOT USE OUTDOORS.
This product conforms to UL STD 962
IMPORTANT SAFETY FEATURES:
Use this furnishing only for its intended use as described in these instructions. Do not use attachments not
recommended by the manufacturer.
If there is an overload weight condition on the head or foot mechanism, the control unit will automatically stop
all functions. Once the excess weight is removed the control unit will automatically allow all functions to resume
operation after 30 seconds.
As with any product that produces a vibrating motion, it is possible that some pacemakers may interpret this
motion as a false sense of movement and/or exercise. This may or may not affect your pacemaker. If you have any
concerns, please consult your physician. For more information please contact customer service by calling 800-973-
8374.
USER-SERVICEABLE PARTS:
This product is specically designed to have no maintenance by you, the user. Therefore, you are encouraged not to
open any motors, alter the wiring, adjust, modify or change the structure of the product, as it will void the warranty.
POWER RATINGS:
INPUT: AC 120V - 60Hz, 1Amp
OUTPUT: DC 32-36V (4.2A)
The input transformer voltage is AC120V 60HZ, and the output voltage is DC36V (4.2A). When there is a short-
circuit, a fuse on the transformer will be blown in order to protect the electrical equipment. Should the above situation
occur, the customer should seek professional assistance by calling a licensed electrician or by contacting customer
service at 800-973-8374.
SMALL CHILDREN AND PETS WARNING:
After your Reverie Power Base has been unboxed, immediately dispose of packaging as it can smother small
children and pets. To avoid injury, children and pets should not be allowed to play on or under the power base.
Children should not operate this product without adult supervision. Close supervision is necessary when this
furnishing is used by, or near children, invalids, or disabled persons.
SAVE THESE INSTRUCTIONS:
Your Reverie Power Base has been designed to provide you with the reliable
operation and durability you expect. This product has been inspected and tested prior to shipment.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
8
Safety Precautions
RADIO FREQUENCY IS 433.92 MHZ
FCC COMPLIANCE
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is
permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure
requirements and void the user’s authority to operate the device.
PRODUCT RATINGS
The lift motor in your Reverie Power Base is NOT designed for continuous use. Reliable operation and full life
expectancy will be attained as long as the lift motor does not operate more than two (2) minutes over an eighteen (18)
minute period, or approximately 10% duty cycle. Any attempt to circumvent or exceed this rating will shorten the life
expectancy of this product and may void the warranty. The recommended weight restrictions for your Reverie Power
Base is up to 850 lbs. total weight, including people and the mattress for all sizes of power bases. Lift speed will vary
due to weight and mattress conguration, as well as the mattress type. The weight must be evenly distributed across
the power base. This Product is not designed to support or lift 850 lbs of total weight in the head or foot sections of
your Reverie power base alone, or in any unevenly distributed fashion. Some mattresses are not designed for Power
Bases because they do not bend or ex well when adjusted. When using such a mattress with your Reverie Power
Base the weight limits set forth herein do not apply, as the bending of the mattress requires signicant force and puts
signicant strain on the motors and the Power Base itself.
Note: Exceeding the recommended weight restrictions could damage your power base and void your
warranty and using a mattress on top of your power base that is not designed for adjustability may also
void your warranty.
For best performance, you should enter and exit the Power Base while it is in the at or fully lowered position.
DO NOT SIT ON THE HEAD OR FOOT SECTIONS WHILE IN THE RAISED POSITION.
INTENDED USAGE
The electric power base should be installed with the head board brackets and/or the head of the frame
positioned close to a wall.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
9
Parts List for Reverie
R600TM Power Base
Note: Before discarding any packing materials, check the power base carton and verify the
following items in the parts list are included:
PARTS LIST
A. Wireless Remote Control (1x)
B. Mattress Retainer Bracket (2x)
C. 3-in-1 Tapered Wooden Leg (4x)
D. Inner Headboard Bracket (2x)
E. Outer Headboard Bracket (2x)
F. Retainer Bar Bolt (4x)
G. Headboard Bolt (4x)
H. Headboard Bracket Bolt (8x)
I. Retainer Bar Plate (4x)
J. 5/16 Inch Washer (16x)
K. 5/16 Inch Locking Nut (8x)
L. Allen Key (1x)
M. Wrench (1x)
A. C.B.
E.
H.G. I.
D. F.
J.
M.
K. L.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
10
Frame Assembly Instructions
IMPORTANT UNPACKING INSTRUCTIONS
To avoid damage to the power base, always
open the carton while the power base is
laying in the FLAT position on the oor.
OPEN FLAT
STEP 1
STEP 3
STEP 4
STEP 5
STEP 6
STEP 2
Carefully lift the power base unit out of the
shipping carton, keeping the unit top side down.
For safety reasons, this should be performed
by 2 people. Be sure to use a protective layer
under the power base to prevent damage to
your hard oors.
Untie and extend the power cord from the frame.
Remove the plastic packaging from the power
base.
Carefully rotate the power base over to the
topside-up position.
Plug the power cord into a grounded electrical
outlet.
Assembling power base legs: Open the
accessories box, take out the 4 legs,
and thread them in a clockwise direction into
the threaded holes in the frame.
NOTE: Tighten the legs securely to the frame.
Leave no space between the leg and frame.
NOTE: An electrical surge protection unit is
recommended (not included)
WARNING:
POWER CORDS MUST NOT INTERFERE
WITH ANY POWER BASE MECHANISMS.
ATTENTION! Improper handling
DO NOT
lean the power base
against the installed
legs to ip it over.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
11
Frame Assembly Instructions
STEP 7
STEP 8
Return the base to the at position and proceed
to assemble the Mattress Retainer Brackets.
NOTE: If the power base is to be set
up without a headboard, simply install a
mattress on the frame. Installation is now
complete. If a headboard is to be installed,
proceed to step 9.
Use the Retainer Bolts (F) and Retainer
Bar Plate (I) to fasten the Mattress Retainer
Bracket (B) to the power base.
NOTE: Use only a manual screwdriver to
install the retainer bolts. DO NOT use a
power screwdriver to tighten the bolts. DO
NOT over tighten the mattress retainer
hardware.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
12
Frame Assembly Instructions
Headboard Bracket Installation
(OPTIONAL)
STEP 10
Place your mattress on top of your power base.
Typical Power Base is now complete. If the
power base is equipped with a programmable
setting or options, refer to the Remote Control
Guide for more information.
1. Use the hand control to raise the head of
the base in order to gain access to the
power base.
2. Bolt the Inner Headboard Bracket (D) to
the headboard mount tube located on the
steel frame crossbar using the Headboard
Bracket Bolts (H), the 5/16” Washer (J),
and the 5/16” Lock Nut (K). Make sure the
bracket orientation is correct as indicated.
4. Ensure the headboard bracket is
assembled a distance of 1.5 (38.1 mm)
to 2 inches (50.8 mm) between the edge
of the power base and the headboard
bracket assemblies.
3. Place the open side of the Outer
Headboard Bracket (E) onto the exposed
square tube of the Headboard Bracket (D).
This will create a tight t between (D) and
(E). Place a Headboard Bracket Bolt (H)
with a 5/16 Inch Washer (J) through the
Outer Headboard Bracket (E) and into the
Inner Headboard Bracket (D). Use a 5/16
Inch Washer (J) and 5/16 Inch Locking
Nut (K) and hand tighten to allow for
adjustment. Repeat same procedure for
opposing side of the power base.
5. Firmly tighten the Headboard Bolts (G) to the
end of the headboard bracket assembly.
6. Measure the distance of the center to center
mounting holes in the headboard.
7. Measure the distance of the center to center
mounting holes in the headboard bracket
assemblies.
8. If the headboard brackets require adjustments,
loosen the bolts that are holding the outer
headboard brackets and move them to the
necessary distance. Reinstall the bolts and
rmly tighten.
STEP 9 (optional accessory)
NOTE: It is important to position the
bottom of the headboard cross member
a maximum distance of 3 inches (76.2
mm) between the headboard and the top
of the mattress. Do not exceed 3 inches
(76.2 mm).
D
K
J
E
D
H
J
J
K
JH
G

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
13
How to Download the App
Software
STEP 1
STEP 2
STEP 3
STEP 4
Please use your iOS or Android mobile device
to log into the APP STORE or GOOGLE PLAY
STORE.
Type “Reverie Nightstand” in the search column.
Select the reverie app.
Click install to download the app.
NOTE: Once the App is installed, when
you open the app the Bluetooth module will
connect to your device automatically.
NOTE: Make sure the Reverie Nightstand
App is the last app open on your phone
before locking (putting your phone in sleep
mode)
Reverie Nightstand
App User Guide

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
14
Home Screen
• Key features, functions and settings are accessible
from the home screen.
- Settings, Preset List, Comfort Settings, Routines,
Bluetooth, Nightlight, Home Tab, Position Tab,
Massage Tab, and Alarm Tab.
• Reverie Presets – Zero Gravity, Anti-Snore, and Flat
are right at your ngertips.
• Comfort Setting – Press “New +” to program a unique
head, foot and/or massage combination.
• Routines – Press “New +” to program a set of saved or
new comfort settings into a series of timed positions.
Position Control
• Control your head and foot elevation.
• Select the part of the bed you would like to elevate or
lower (head or foot).
- Use your nger to slide the blue dot
along the curve to your desired elevation.
- Or press and hold the plus or minus
symbol to adjust elevation.
• Your position readout on a scale of 1-100 will appear
at the top of the screen and next to the head or foot
position.
App User Guide
Massage
• Control your massage intensity and duration.
• Full body – Turns on the full body function.
• Wave – Select number of alternating pulses at the
head and foot of the bed.
• Head and Foot control – Select massage intensity in
the head and foot sections of the bed.
- Use your nger to slide the blue button to your
desired intensity.
- Or press and hold the plus or minus symbol to
adjust intensity.
• Timer – Select your desired massage duration.
• Stop – Turns the massage off.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
15
Alarm
• Create an alarm setting to raise and/or massage you
awake.
• Press “New +” to create a new alarm setting.
- Set time: Scroll to select the hour, minute and day.
- Repeat: Select the days of the week you would
like the alarm to activate.
- Bed control: Select nothing or select a new or
existing comfort setting or routine.
- Snooze: Enable snooze.
Settings
• Customize your app in settings.
• User Prole – Dene your user prole to get
recommendations on custom settings for you.
• Bluetooth – Shows the bed your app is connected to.
Shows nearby beds that you can connect to in order of
proximity.
• Help – Contact info for technical support.
• Mattress Congurator – Recongure your Reverie
Dream or Dream Supreme mattress with these
rmness guides.
• Factory Reset – Reset your app to original settings.
• Logout – Logout or create a new user.
App User Guide

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
16
Wireless Remote Control
DISPLAY SCREEN
A. RAISE & LOWER HEAD SECTION
OF THE BASE
B. RAISE & LOWER FOOT SECTION
OF THE BASE
C. TILT UP/DOWN
D. ZERO GRAVITY
E. ANTI - SNORE
F. RETURN TO FLAT
G. CUSTOM PRESET 1
H. LED LIGHTS ON/OFF
I. CUSTOM PRESET 2
J. MASSAGE
K. HEAD MASSAGE INTENSITY
L. WAVE PATTERN PRESET
M. STOP MASSAGE
N. FOOT MASSAGE INTENSITY
O. MICRO USB CHARGING PORT

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
17
Remote Control Operation Guide
OPERATING INSTRUCTIONS:
HEAD AND FOOT ADJUSTMENTS (A,B)
• Adjusts the head and foot sections to the de-
sired positions.
• Zero Clearance feature allows for the founda-
tion to be placed on the oor without legs and
able to adjust all sections [head/foot/pillow] in a
complete motion range without any of the me-
chanical parts under the bed touching the oor.
Basically allows you to use your adjustable bed
without legs if desired.
TILT (C)
• Includes a remote-controlled adjustable tilt back-
wards and forwards.
ZERO GRAVITY (D)
• Allows your legs to be lifted to a position slightly
above the chest, which enables blood ow to
easily circulate back to the heart, thus reducing
stress and fatigue.
ANTI SNORE (E)
• Raises the HEAD slightly for easier breathing.
POWER BASE “FLAT” BUTTON (F)
• Levels the power base to the at position when
the button is pressed and held for at least 3
seconds.
PROGRAMMABLE MEMORY POSITIONS (G,I)
You can store 2 personalized memory positions.
• To Set a Memory Position: When in desired po-
sition, press and hold Memory button for more
than 5 seconds until the LED light ashes 3
times to signal Memory position is stored.
• To recall a Memory Position: Press 1 of the 2
presets.
AMBIENT LIGHTING ON/OFF (H)
• Toggle the lightbulb button for on/off functions.
HEAD AND FOOT MASSAGE CONTROLS (K,N)
• Turns on the corresponding massage unit
(starting at intensity 5 of 10)
• Slowly increases or decreases massage inten-
sity. To increase massage intensity, press (+)
button. To decrease massage intensity, press (-)
button.
WAVE MASSAGE PATTERN (L)
• Turns on both head and foot massage motors to
the wave 1 preset.
MASSAGE STOP BUTTON (M)
• Press to stop all massage features.
CHARGING PORT (O)
• To charge remote, plug in the wall charger and
connect to the micro usb port.
• Unplug and plug-in the remote again if you do
not see a charging symbol on the screen.
• Flashing LED on remote indicates Low Power
status.
NOTE: Any control button on the remote
will interrupt and stop the FLAT, ZERO-G,
Anti-Snore and Memory presets 1-2.
NOTE:
All screens will timeout after 5 seconds,
15 seconds if screen is auto-refreshing
NOTE: The lowest setting will turn off the
corresponding massage unit.
NOTE: The massage feature is designed
to automatically shut off after 30 minutes of
continuous use.

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
18
Remote Control Operation Guide
ADDITIONAL REMOTE
FEATURES:
• This power base uses a Bluetooth® remote
control system.
• The included remote is already paired with
your power base, so should be operational
right out of the box. Please test some of the
features to ensure functionality.
• Only replacement remote controls require
pairing instruction on following pages.
If you nd that your remote is not paired
with the bed, please follow those Bluetooth
pairing instructions.
NOTICE:
The changes or modications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
SAFETY:
• If there is an overload weight condition on
the head or foot mechanism, the control unit
will automatically stop all functions.
• The buttons are back-lit, when a button is
pressed, to aid the visibility of the remote in
low light environments.
• Customers can control the remote without
facing the receiver (best transmission range
is within 30 feet or 10 meters)
• The remote is equipped with a
lithium-ion battery that can be recharged
anytime with the included Micro USB wall
charger adapter.
• Please fully charge your remote before
operating for the rst time.
• When remote is fully charged, the charging
symbol will disappear.
• The input transformer voltage is AC 120V
60 HZ, the output voltage is DC 36V 4.2A.
When there is a short circuit, a fuse on the
transformer will be blown in order to protect
the electrical equipment.
NOTE: This power base may have minor
intermittent performance due to RF
Interference. This is a normal operation of
the power base and is not a defect.
ATTENTION: When the above situation
occurs, the customer MUST seek
professional assistance.
REMOTE LOCKOUT FEATURE (D,M)
• We created the remote lockout feature to help
owners prevent unintended use of the base.
• At the same time, press and hold the
ZERO G and STOP buttons for 3 seconds.
The white LED will ash twice to indicate
activation. Pressing any buttons on the
remote while in lockout mode will result in
no movement from the power base.
Activating Remote Lockout
• Same method, press and hold the ZERO
G and STOP buttons at the same time for
3 seconds. The white LED will ash twice
to indicate deactivation. The remote and
power base will work normally.
Deactivating Remote Lockout

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
19
Bluetooth® Pairing
Replacement Remote Control
CONNECTING TO ONE BED
(does not include KING or SPLIT KING bed sizes)
KING only
SPLIT KING only
STEP 1
STEP 2A
STEP 2
STEP 2B
STEP 3B
STEP 2
STEP 3
STEP 4
STEP 1
Select KING
If the remote detects only 2 control boxes then
the remote will automatically connect to both
control boxes on your bed.
Select SPLIT KING
When you choose SPLIT KING, will be asked if
want to connect to both sides of bed? Select
YES or NO
Select YES
If the remote detects only 2 control boxes then
the remote will automatically connect to both
sides of your bed.
If the remote detects more than 2 control boxes,
there should now be a list of available control
boxes that you can connect to. (this usually
means you have more than one bed in your
house) Scroll using any of the up/down buttons
H/T/F. Select the 2 desired control boxes by
single-pressing the lightbulb button. You will
then be taken back to the home screen.
Select NO
There should now be a list of available control
boxes that you can connect to. Select the
desired side of the bed you want to connect to
by single-pressing the lightbulb button. You will
then be taken back to the home screen.
Hold Lightbulb button for 3 seconds to start
searching.
The remote will only detect one control box
and automatically connect. Connection is now
complete and will be taken back to the home
screen.
[Remote only detects 1 bed]
Select Other
The screen now asks if you are connecting to
only 1 bed. Select YES
There should now be a list of available control
boxes that you can connect to. Scroll using any
of the up/down buttons H/T/F. Select desired
control box by single-pressing the lightbulb
button. Once the single bed is selected, you will
then be taken back to the home screen.
[Remote detects multiple control boxes, this
usually means you have more than one bed in
your house]
Hold Lightbulb button for 3 seconds to start
searching.
If the remote detects more than 2 control
boxes, there should now be a list of available
control boxes that you can connect to. (this
usually means you have more than one bed in
your house) Scroll using any of the up/down
buttons H/T/F. Select the 2 desired control
boxes by single-pressing the lightbulb button.
STEP 3A
STEP 4A

CUSTOMER SERVICE: 800-973-8374
CUSTOMERSER[email protected]
20
CONNECTING TO TWO
SEPARATE BEDS
STEP 1
STEP 3
STEP 4
STEP 2
The screen now asks if you are connecting to
only 1 bed. Select NO.
There should now be a list of available control
boxes that you can connect to, select the beds
you wish to connect to [remote can show up
to 20 beds] Select any two beds you wish to
connect by single-pressing the lightbulb button.
After selecting 2 beds, the remote will send the
user to the home screen.
Our remote and Bluetooth technology allows for
pairing/connecting two remotes with each side
of the bed so each remote can control both
sides of bed.
Pair/Connect one remote with both sides of the
bed, then wait for that remote to enter sleep
mode and pair/connect the other remote with
both sides of bed.
If two remotes are connected to one bed, in
order to actively use one of the remotes to
control the bed you must make sure the other
remote is in sleep mode. Waking up other
remote will result in a disconnection from the
control unit and the remote will show “No Bed
Paired”.
Hold Lightbulb button for 3 seconds to start
searching.
Select Other
NOTE: If it cannot detect any beds then
will say NO BED FOUND.
NOTE:
Please remember to recycle all electronics.
NOTE:
This applies to the king bed situation,
where two remotes are connected to both
sides of the bed.
FOR PAIRING TWO REMOTES TO
EACH SIDE OF THE BED
[for KING, SPLIT KING or two beds]
Bluetooth® Pairing
Replacement Remote Control
IMPORTANT NOTE:
• To comply with the FCC RF exposure
compliance requirements, no change to
the antenna or the device is permitted.
Any change to the antenna or the device
could result in the device exceeding the
RF exposure requirements and void user’s
authority to operate the device.
THIS DEVICE COMPLIES WITH
PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY
NOT CAUSE HARMFUL
INTERFERENCE (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED
OPERATION.
