Rexing S1 Pro User manual

S1 Pro
User Manual
The information in this manual is subject to change without notice.
www.rexingusa.com

Notice
1
Menu Setup Operation: The menu is to be set up in non-video mode. If the
device is in video mode, proceed after stopping the video recording.
Memory card: A new card must be formatted to the device before use.
Continuous image recording for long periods of time may produce protected
files that are not subject to long-term protection (these files may not be
overwritten during loop recording) and storage fragments, which need to be
cleared regularly in order to save stable storage space.
Standard Voltage for On-board Charger: Standard input voltage is configured
at 12V. If a charge voltage greater than 12V is found, contact your dealer or
our service center to replace it with an applicable charger. An OEM charger
must be used.
Parking Monitor: Do not enable this function during driving. When it is enabled,
repeated start/stop recording may affect the integrity of your video.
Do not install the device within the range that could be impacted by airbag or
in a location that interferes with the driver’s view or other safe operation of the
vehicle. Make sure it is securely mounted.
The features described in the operation manual are available for all products
of the same type. Your model may have come with optional or additional
functions. Menu operations may vary. Please refer to the instructions that
apply to your actual product.
2.
3.
4.
5.
6.
1.

2
The battery (module or pack) must not be expose to an overheat
environment such as direct sunlight or flame.
Never remove, strike, or squeeze the battery or put it in fire. Stop
using the battery if it is ballooned, warped, leaking, or shows any
other visible signs of damage.
Warning
!

Thank you for choosing REXING! We hope you love your new products as
much as we do.
If you need assistance, or have any suggestions to improve it, please contact
us. You can reach us via
Our support team will respond you as soon as possible.
•https://www.facebook.com/rexingusa/
•https://www.instagram.com/rexingdashcam/
•https://www.rexingusa.com/support/registration/
3
Overview
Thank you for choosing REXING!
Check us out here.
Facebook Instagram Site Product Support
[email protected]
[phone]

What’s in the box?
S1 Pro
User Manual
The information in this manual is subject to change without notice.
www.rexingusa.com.
132 4
5678
1. Rexing S1 Pro Dash Camera
2. Rear Camera with Extension
Cable (20ft)
3. Free Smart Hardwire Kit
4. GPS Logger
5. 3M Adhesive Mount
6. USB Computer Cable
7. Cable Management Tool
8. Quick Start Guide
4

Table of Contents
Camera Overview
Installation
Basic Operations
Mobile Connection
GPS Player
Product Specifications
6
9
12
20
27
30
General Troubleshooting 31
Warranty and Support 32
5

Camera Overview
I. Visual Features
6
1. Menu/Mode Button
2. Record/Up Button
3. Power Button
4. Down/Toggle Button
5. OK Button
6. Power Cord Connection Port
7. Rearview Camera Connection Port
8. Reset Pinhole
GPS
Socket
USB 5V
Socket
Smart
Hardwire
Kit Socket
Rearview
Camera
Socket
IR light
Cabin Camera
Front Camera
6 7
8123 4 5
Note:
GPS is an optional feature, needs to connect to the included GPS Logger. The S1 Pro does not
support memory expansion.

1. In standby mode, press this button to start/stop the related menu
options such as recording mode, photography mode, playback mode.
2. In recording mode, press and hold the button for 3 second to enter
picture-taking and playback interface. Depress it again to exit.
Buttons
Buttons and Description
M Button
(Menu/Mode
Switch)
1. In standby mode, press this button to start/pause video recording.
2. Video Mode: Depress this button to start/stop audio recording.
3. The button is defined for page up in menu setup and playback mode.
4. During playback, press the button shortly to play fast rewind.
Record/Up/MIC
Button
1. Press this button to start the device. Depress it for 3 seconds to power
off the device.
2. In power-on state, press the button shortly to turn off/on screen
backlight.
Power Button
1. This button is defined for page down in menu setup and playback mode.
2. Press this button to switch between front/rear camera view and PIP
display.
3. During playback, press the button shortly to play fast forward.
4. In video mode, depress the button to switch the IR light to
OFF/ON/AUTO.
Down/Toggle
Button
Description
7

1. This button functions as a confirmation in each of the setups.
2. In video recording, press this button to start emergency recording.
3. Depress this button to switch Wi-Fi on/off.
4. In photography mode or playback mode, press the button to take a
picture or play back a file.
OK Button
Power charging port/USB data cable portUSB Port
Power cable connection port
Power Port
Rearview Camera Connection PortRearview Camera
Connection Port
If the system crashes, use a pin to reset the system.Reset Pinhole
8

1. Turn off the car’s engine.
2. Secure the dashcam to a place close to the original rearview mirror.
3. Plug the GPS module into the GPS port and secure the module to a position close
to A-pillar of the car. The antenna receiver side (the side without 3M adhesive)
faces the outside and the side with 3M adhesive faces down. It should be properly
secured.
4. Plug the charger into the car’s cigarette lighter. Connect the device to the cigarette
lighter through the car charger.
9
Installation
The charger extension cable can be wired along the edge of the windshield during
installation. The optional rearview camera should be mounted on the rear
windshield of the car. Pay attention to its orientation during installation. It can be
wired against or above the interior’s headliner. Plug the rearview camera
connector into its rear camera port of the device once the camera is securely
mounted. Adjust the position of the lens to make sure that it remains horizontal
with the ground. Start the engine to check the video operation of your device.
Note:
