1 About This Document
This manual contains important information
on the safe and appropriate assembly, trans-
port, commissioning, operation, mainte-
nance, disassembly and simple troubleshoot-
ing of the CS351/CC-CS351 Compact
System.
The description of the software used in the
Compact System is not a part of these in-
structions. For any information on software
and operation which you may require, please
see the online help of the operating program
for BS350 as well as the system documenta-
tion on the enclosed USB system stick.
Read these instructions completely, espe-
cially chapter “General safety instructions”
on page 58 before working with the Compact
System.
Scope of the documentation
This documentation is applicable for the
CS351 and CC-CS351 Compact Systems.
Tightening operations requiring documenta-
tion according to VDI/VDE 2862 Category A
can be performed using tightening systems
which consist of the ErgoSpin hand-held nu-
trunner and the CS351E... Compact System.
Tightening operations requiring documenta-
tion according to VDI/VDE 2862 Category B
can be performed using CC tightening sys-
tems which consist of the CC-ErgoSpin
hand-held nutrunner and the CS351E... or
CC-CS351E-D Compact System.
The CS351... Compact System allows con-
necting the system to field buses.
Related documents
Please also observe the generally applicable,
legal or otherwise binding regulations of Eu-
ropean or national legislation and the rules for
the prevention of accidents and for environ-
mental protection applicable in your country.
CS351_zweispaltig - D.book Seite 57 Dienstag, 16. Juli 2013 12:00 12

58 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
General safety instructions
2 General safety
instructions
The Compact System has been manufac-
tured according to the accepted rules of cur-
rent technology. There is, however, still a dan-
ger of personal injury or damage to
equipment if the following general safety in-
structions and the warnings before the steps
contained in these instructions are not com-
plied with.
• Read these instructions completely and
thoroughly before working with the Com-
pact System.
• Keep these instructions in a location
where they are accessible to all users at all
times.
• Always include the operating instructions
when you pass the Compact System on to
third parties.
Intended use
The product described in this documentation
is part of the control and power electronics
for Rexroth tightening systems and is in-
tended for the industrial application of tight-
ening processes exclusively in connection
with further products. Only use the product
with the corresponding connecting cables.
The product is intended for industrial use and
not for private use.
Observe the operating conditions and perfor-
mance limits specified in the technical data.
Intended use includes having read and un-
derstood these instructions, especially chap-
ter 2 “General safety instructions”.
Only use the Compact System CS351 in
conjunction with a Rexroth ErgoSpin/CC-Er-
goSpin hand-held nutrunner or tightening
spindles to tighten and loosen bolts and nuts.
Only use the Compact System CC-CS351 in
conjunction with a Rexroth CC-ErgoSpin
hand-held nutrunner or tightening spindles to
tighten and loosen bolts and nuts.
The integrated logic is not permitted for
safety-relevant applications. Safety-relevant
applications are all applications that may re-
sult in personal injury or property damage.
Improper use
Any use of the Compact System other than
described in section “Intended use” is con-
sidered as improper.
NOTE
The Compact System CS351/CC-
CS351 is not designed to be directly
connected to the public low-voltage
power supply, but is only intended for use
in industrial environments (emission
class A).
CS351_zweispaltig - D.book Seite 58 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 59 /108
General safety instructions
ENGLISH
Personnel qualification
Assembly, commissioning and operation, dis-
assembly, service (including maintenance
and repair) require basic electrical and me-
chanical knowledge, as well as knowledge of
the appropriate technical terms. In order to
ensure operating safety, these activities may
therefore only be carried out by qualified
technical personnel or an instructed person
under the direction and supervision of quali-
fied personnel.
Qualified personnel are those who are able to
assess the tasks they are commissioned to
perform, identify possible risks and take the
appropriate safety measures due to their pro-
fessional training, knowledge, and experi-
ence as well as their knowledge of the appli-
cable regulations. Qualified personnel must
observe the rules relevant to the subject area.
Safety instructions in this document
In this manual, there are safety instructions
before the steps whenever there is a danger
of personal injury or damage to the equip-
ment. The hazard avoidance measures de-
scribed must be observed.
Safety instructions are set out as follows:
•Safety sign (warning triangle): alerts the
user to the risk
•Signal word: identifies the degree of haz-
ard
•Type of risk: identifies the type or source
of the risk
•Consequences: describes what occurs
when the safety instructions are not ob-
served
•Precautions: states how the hazard can
be avoided
The signal words have the following mean-
ings:
SIGNAL WORD
Type of RISK!
Consequences
Precautions
This warning symbol cautions
against dangers to your health.
Observe all safety instructions
that follow this symbol to avoid
possible injuries or death.
This warning symbol cautions
against dangers to your health
caused by electric voltages or
currents. Observe all safety in-
structions that follow this symbol
to avoid possible injuries or
death.
DANGER
DANGER indicates an imminently hazard-
ous situation which, if not avoided, will
certainly result in death or serious injury.
WARNING
WARNING indicates a potentially hazard-
ous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazard-
ous situation which, if not avoided, could
result in minor or moderate injury or dam-
age to equipment.
CS351_zweispaltig - D.book Seite 59 Dienstag, 16. Juli 2013 12:00 12

60 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
General safety instructions
Adhere to the following instructions
General instructions
Observe the regulations for accident preven-
tion and environmental protection for the
country where the product is used and at the
workplace.
Exclusively use Rexroth products in good
technical order and condition.
• Check the product for visible defects, for
example cracks in the housing or missing
screws and seals.
Do not change or modify the Compact Sys-
tem.
Only use the product within the performance
range provided in the technical data.
Persons who assemble, operate, disassem-
ble or maintain Rexroth products must not
consume any alcohol, drugs or pharmaceuti-
cals that may affect their ability to respond.
Do not expose the Compact System to any
mechanical loads under any circumstances.
Never use the product as a handle or step.
Do not place any objects on it.
Observe the local, system-specific regula-
tions and requirements; proper use of tools,
lifting, and transport equipment; as well as
the relevant standards, provisions, and acci-
dent prevention regulations.
During assembly
Make sure the relevant system component is
not under pressure or voltage before assem-
bling the product or when connecting and
disconnecting plugs. Protect the system
against being switched on.
Lay cables and lines in accordance with the
permissible bending radiuses so that they
cannot be damaged and no one can trip over
them.
Before commissioning, make sure that all the
connection gaskets and plugs are installed
correctly to ensure that they are leakproof
and fluids and foreign bodies are prevented
from penetrating the product.
During commissioning
Let the product acclimate itself for several
hours before commissioning, otherwise wa-
ter may condense in the housing. Condensed
water might damage the compact system
when switched on.
Make sure that all electrical connections are
either used or covered. Commission the
product only if it is installed completely.
During operation
Only allow persons who are authorized by the
operator to access the system's direct oper-
ating area. This is also valid when the system
is standing still.
In case of an emergency, fault or any other
anomalies, switch the system off and protect
it against being switched on again.
NOTE
NOTE indicates a situation which, if not
avoided, could result in minor or moder-
ate damage to equipment.
If this information is not ob-
served, the operating procedure
may be impaired.
CS351_zweispaltig - D.book Seite 60 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 61 /108
General safety instructions
ENGLISH
Only operate the Compact System in
grounded networks. Operation in non-
grounded networks (IT network) is not per-
mitted, as clearance and creepage distances
in the system may be overloaded.
Here, protective grounding is the permissible
protective measure in accordance with
EN 50178. The inlet cable to the Compact
System must have a PE wire.
Make sure that there is potential equalization
between the workpiece and tightening spin-
dle, as well as its carrier plate, so that poten-
tial equalization is ensured for all system com-
ponents.
Protect the system from short circuits in the
connector cables with a fuse provided by the
customer.
After switching the device off, wait 10 sec-
onds before turning it back on.
Observe the discharging time (at least 90
seconds after separating the system from the
network) before working on the power supply
connections.
During cleaning
Cover all openings with the appropriate pro-
tective equipment in order to prevent deter-
gents from penetrating the system.
Never use solvents or aggressive detergents.
Only clean the product using a slightly damp,
lint-free cloth. Only use water to do this and,
if necessary, a mild detergent.
Do not use a high-pressure cleaner for clean-
ing.
During maintenance and repair
Perform the prescribed maintenance work at
the intervals specified in the instruction man-
ual.
Make sure that no lines, connectors or com-
ponents are disconnected as long as the sys-
tem is under pressure and voltage. Protect
the system against being switched on.
DANGER
Insufficient emergency OFF equip-
ment!
Danger to life through electrical or me-
chanical forces
The user is responsible for determin-
ing the necessity of an emergency
OFF, its implementation, and the risk
analysis! Make sure the emergency
OFF equipment is accessible and ef-
fective. Release of the emergency
OFF equipment may not result in an
uncontrolled system restart!
Check the function of the emergency
OFF equipment before switching the
system on.
CS351_zweispaltig - D.book Seite 61 Dienstag, 16. Juli 2013 12:00 12

62 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Scope of delivery
Disposal
Dispose of the product in accordance with
the currently applicable national regulations
in your country.
Batteries must not be disposed in the general
waste but the end user is obliged by law to
return used batteries. Used batteries may
contain contaminants which might be harmful
for the environment or for your personal
health if not correctly stored or disposed of.
Batteries, however, consist of different re-
sources and must be separately collected
and recycled.
Our batteries can be returned after use either
• at commercial waste management compa-
nies for used batteries
• at treatment facilities for used devices ac-
cording to the electric and electronics de-
vice act
• or free of charge at our distribution agen-
cies or at the Murrhardt site
The symbol with the crossed out waste con-
tainer means that batteries must not be dis-
posed of in the general waste but must be
collected and recycled separately.
3 Scope of delivery
The delivery contents include:
• 1 CS351 or CC-CS351 Compact System
• 1 power supply connection cable (in acc.
with the EU regulations), length 2 m
• 1 hardware operating instructions for the
Compact System
• 1 suspension strip
• Preassembled dummy panels on all slots
CS351_zweispaltig - D.book Seite 62 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 63 /108
Product description
ENGLISH
4 Product description
Performance description
The Compact System combines a servo am-
plifier, power supply, display, controller, and
slots for optional interface cards.
The system is a comprehensive solution for
use with ErgoSpin or CC-ErgoSpin hand-
held nutrunners or tightening spindles.
Compact System variants for hand-held nut-
runners include:
• CS351E-D with LC display.
• CS351E-D IL with LC display and inte-
grated logic compliant with IEC 61131-3.
• CS351E-G with large color TFT display
(VGA 640x480) with integrated touch-
screen.
• CS351E-G IL with large color TFT display
(VGA 640x480) with integrated touch-
screen and integrated logic compliant with
IEC 61131-3.
• CS351E-G+ with large color TFT display
(VGA 640x480) with integrated touch-
screen, integrated logic compliant with IEC
61131-3., and integrated computer unit
• CS351E-D NK with LC display for
connection to the modular system 350
(SB356, BT356).
A Compact System variant for hand-held nu-
trunners is:
• CC-CS351E-D with LC display.
Compact System variants for tightening spin-
dles include:
• CS351S-D with LC display.
• CS351S-D IL with LC display and inte-
grated logic compliant with IEC 61131-3.
• CS351S-G with large color TFT display
(VGA 640x480) with integrated touch-
screen.
• CS351S-G IL with large color TFT display
(VGA 640x480) with integrated touch-
screen and integrated logic compliant with
IEC 61131-3.
• CS351S-G+ with large color TFT display
(VGA 640x480) with integrated touch-
screen, integrated logic compliant with IEC
61131-3., and integrated computer unit
• CS351S-D NK with LC display for connec-
tion to the modular system 350 (SB356,
BT356)
In normal operating state, the front panel is
covered.
The front cover can be opened or removed to
connect external devices.
CS351_zweispaltig - D.book Seite 63 Dienstag, 16. Juli 2013 12:00 12

64 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
Device description
Fig. 1: Compact System view
Legend relating to Fig. 1:
1Name plate
2Front cover lock
3 Cable duct strip
4Side cable ducts
5 Affixed pressure compensation membrane
(do not remove)
6 Safety warning (only visible when the front
cover is open)
7 Type label
Safety warning
It warns against the high electrical voltages in
the Compact System during operation and
provides maintenance information (see “Dis-
assembly and replacement” on page 101).
3
4
4
2
1
5
6
7
CS351_zweispaltig - D.book Seite 64 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 65 /108
Product description
ENGLISH
Interface overview
Controller and servo amplifier of the Com-
pact System feature the following available
electrical interfaces (see Fig. 2; the interface
components depend on the particular CS
variant):
Outside the front cover:
• 1 USB device interface for CS351 control-
ler (X3U3),
specification compatible with 2.0
(with screwed-on cover)
• 1 power supply connection interface (X1N)
• CS351E: interface for hand-held nutrunner
(XDS1)
• CS351S: interface for tightening spindle
(XDS2)
• 1 power switch (Q0)
Inside the front cover:
• 1 motor OFF interface (XDN1)
• 2 USB host interfaces for CS351 control-
ler (X3U1, X3U2), specification 2.0
• 1 slot (A) for the use of standard type A
modules
Slot A is without function in CC-CS351; in-
serted modules will not be detected
• 2 slots (B1, B2) for the use of standard
type B modules
Slot B2 is not applicable in CS351E-G+
and CS351S-G+ due to the integrated
computer unit.
• 1 restart/reset button (reset)
• 1 RS232 interface for CS351 controller
(X3C1),
• 1 Ethernet interface (X7E1) for CS351
controller
• 1 mass storage slot (X6C1)
• Only in CS351E-D (IL) / CS351S-D (IL):
– DVI interface to connect an external
monitor (DVI-D single link,
XDVI)
– USB host interface (X3U4)
• Only in CS351E-D NK/ CS351S-D NK:
– Interfaces for connection to the system
bus 350 (XDAC1, XDAC2)
The external interfaces of the integrated com-
puter unit (variants) CS351E-G+, CS351S-
G+) are arranged inside the front cover be-
low slots B1/B2 (see Fig. 3):
• Slot for a Micro-SD memory card
(X6MSD2)
• Status bar (St1, St2), St2 is orange in nor-
mal operation mode
• Reset button of the integrated computer
unit (reboot)
• RS232 interface of the computer unit
(X3C2)
• 1 DVI interface to connect an external mon-
itor (DVI digital, XDVI2)
• 3 USB interfaces (X3U6, X3U7, X3U8) to
connect a mouse, keyboard, USB stick
• 1 Ethernet interface (X7E4) to the built-in
Ethernet switch (connected to computer
unit and CS351 controller)
• 1 Ethernet interface (X7E5) for integrated
computer unit
NOTE
Damage through the use of non-
original parts!
Damages to the compact system
Only use interface modules from
Rexroth (manufacturer ID “Rexroth”).
CS351_zweispaltig - D.book Seite 65 Dienstag, 16. Juli 2013 12:00 12

66 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
Fig. 2: Available interfaces of the Compact System (interface components depending on CS
variant)
Fig. 3: Interfaces of the integrated computer unit (below slots B1/B2)
X3U3
XDS1
QO
X1N
XDAC1 XDAC2
XDS2
St2
St1
X6MSD2 X3U6 X3U7 X3U8
X3C2 XDVI2 X7E4 X7E5
Reboot
CS351_zweispaltig - D.book Seite 66 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 67 /108
Product description
ENGLISH
Table 1: Interface combinations
CS351S-
D
CS351S-
D IL
CS351S-
G
CS351S-
G IL
CS351S-
G+
CS351S-
D NK –
CS351E-
D
CS351E-
D IL
CS351E-
G
CS351E-
G IL
CS351E-
G+
CS351E-
D NK
CC-
CS351E-
D
Inside the front cover
XDN1 XXXXXXX
X3U1,
X3U2
XXXXXXX
Slot A XXXXX––
Slot B1 XXXXXXX
Slot B2 XXXX–XX
X3C1 XXXXXXX
X7E1 XXXXXXX
X6C1 XXXXXXX
XDVI XX––––X
X3U4 XX––––X
XDAC1,
XDAC2
–––––X–
X6MSD2 ––––X––
X3C2 ––––X––
XDVI2 ––––X––
X3U6 –
X3U8
––––X––
X7E4,
X7E5
––––X––
Outside the front cover
X1N XXXXXXX
X3U3 XXXXXXX
XDS1 CS351E-
D
CS351E-
D IL
CS351E-
G
CS351E-
G IL
CS351E-
G+
CS351E-
D NK
CC-
CS351E-
D
XDS2 CS351S-
D
CS351S-
D IL
CS351S-
G
CS351S-
G IL
CS351S-
G+
CS351S-
D NK
–
X: Interface present
–: Interface not present or without function
Variant
Inter-
face
CS351_zweispaltig - D.book Seite 67 Dienstag, 16. Juli 2013 12:00 12

68 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
4.1 External interfaces
X1N power supply connection interface
The compact system is delivered with an EU
power supply connection and power plug
with screw terminals. The power supply con-
nection cable can be unscrewed at the con-
nection plug and assembled as desired.
A connection cable for the American market
is available, but must be ordered separately.
Fig. 4: Connection assignment of the power
supply connection plug
NOTE
Damage through the use of non-
original parts!
Damages to the compact system
Only use power supply connection
cables from Rexroth.
Rexroth provides suitable cables in its
product range. Please also observe
the local regulations.
12
PE 3
Table 2: X1N pin assignment
Pin Signal Description/
function
Voltage/
current
1 L1 L1 power supply
connection
230 VAC/5 A,
120VAC/10A
2 N Power supply
connection
neutral
230 VAC/5 A,
120VAC/10A
3n.c. -
PE PE Leading PE wire PE potential
CS351_zweispaltig - D.book Seite 68 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 69 /108
Product description
ENGLISH
XDS1 interface for hand-held nutrunner
The ErgoSpin/CC-ErgoSpin hand-held nut-
runner is connected to the Compact System
via a spindle connection cable that is con-
nected to the 11-pin connection socket. The
power supply for the motor, logic supply, and
transmission of interface signals is provided
via this cable.
Fig. 5: Socket, 11-pin, female
(view from front side)
XDS2 interface for tightening spindle
The tightening spindle is connected to the
Compact System via a spindle connecting
cable that is connected to the 14-pin socket.
The power supply for the motor and the trans-
mission of the interface signals is provided
via this cable.
Fig. 6: 14-pin socket, female
(front view)
Table 3: XDS1 assignment
Pin Signal Description/function
1 CANL Serial spindle data CAN low
2 CANH Serial spindle data CAN high
3 VEE 24 V spindle power supply
4 GND Reference potential logic
5 HS Start switch for motor contac-
tor
(motor breaker)
6 B Serial interface B
7 O Serial interface A
UU MotorphaseU
VV MotorphaseV
WW MotorphaseW
PE Protective conductor (project-
ing)
V1
2
3
4
5
6
7
PE
UW
Table 4: XDS2
Pin Signal Description/function
PE Protective conductor (project-
ing)
A U Motor phase U
B V Motor phase V
C W Motor phase W
1 VTR Driver power supply
2 CANL Serial spindle data CAN low
3 CHB Incremental encoder channel 2
4 GND Reference potential logic
5 INDX Index impulse
6 VEE 24 V spindle power supply
7 MKTF Motor ID and motor
temperature error
8 HS Start switch for motor contactor
(motor breaker)
9 CANH Serial spindle data CAN high
10 CHA Incremental encoder channel 1
89
10
7
6
543
2
1
C
B
O
CS351_zweispaltig - D.book Seite 69 Dienstag, 16. Juli 2013 12:00 12

70 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
Motor OFF interface XDN1
Two independent motor OFF circuits are
available:
• Motor OFF circuit 1 (NH1) is implemented
via a contactor installed in the Compact
System. This separates the motor from the
servo amplifier (motor is braked).
• Motor OFF circuit 2 (NH2) prevents the
development of a motor rotating field (mo-
tor is not braked).
Both connections are bridged in the delivery
state.
Fig. 7: Delivery state with bridged motor OFF
circuits (NH1 and NH2)
Fig. 8: XDN1
Boundary conditions:
• The maximum cable length for the motor
OFF circuit is 30 m.
• Always design the motor OFF circuits sep-
arately and with potential-free contacts. Do
not mix up the motor OFF circuits under
any circumstances.
• Both motor OFF interfaces must be led
back. If only one is used, the other one
must be provided with a wire jumper.
• If you are only using one motor OFF con-
nection option, we recommend implement-
ing the motor OFF function via motor OFF
circuit NH1 (see Fig. 9, page 72).
CAUTION
Risk of damage to persons and
property!
The emergency OFF interface is no sub-
stitute for an emergency stop facility. It
does not offer functional safety according
to
EN ISO 13849. The user is responsible
for determining the necessity of an emer-
gency OFF, its implementation, and the
risk analysis!
Make sure the emergency OFF equip-
ment is accessible and effective. Re-
lease of the emergency OFF equip-
ment may not result in an
uncontrolled system restart!
NH1
NH2
Table 5: XDN1 assignment
Pin Signal as-
signment
Description/
function
Voltage/
current
1 VEE NH1 Motor OFF 1
supply voltage
24 V/0.3 A
2 NH1 Motor OFF 1 re-
turn (motor con-
tactor)
24 V/0.1A
3 VEE NH2 Motor OFF 2
supply voltage
24 V/0.3 A
4 NH2 Motor OFF 2 re-
turn (end step)
24 V/0.1A
XDN1
1234
CS351_zweispaltig - D.book Seite 70 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 71 /108
Product description
ENGLISH
The maximum torque at the
bolted connections of the termi-
nals at XDN1 must not exceed
0.3 Nm.
CAUTION
Risk of damage to persons and
property!
The user is obliged to maintain the
system-specific requirements for an
emergency OFF system.
When using external power supply
contactors in superior emergency
OFF circuits, observe the restarting
time of 10 seconds for single switch-
ing and 30 seconds for repeated
switching.
Check that the emergency OFF cir-
cuit is functioning correctly before
commissioning the tightening system.
Observe the local, system-specific
regulations and requirements; proper
use of tools, lifting, and transport
equipment; as well as the relevant
standards, provisions, and accident
prevention regulations.
CAUTION
Risk of damage to persons and prop-
erty!
Dangerous shock currents due to insuffi-
cient PE wire connections!
Protective conductor connections
may not be affected by mechanical,
chemical, or electrochemical influ-
ences. The connection must be per-
manent.
NOTE
The voltage circuits on terminal XDN1
are safely isolated from the power
supply circuits (safe isolation in accor-
dance with EN50178). The require-
ments for safe isolation of electric cir-
cuits must be observed if using the
connection options on this terminal.
CS351_zweispaltig - D.book Seite 71 Dienstag, 16. Juli 2013 12:00 12

72 /108 Bosch Rexroth AG CS351/CC-CS351 | 3 609 929 B45/2013-06
Product description
Motor OFF protective circuit
1. Cut-out via the internal motor contactors
After a cut-out via the motor contactor, the
motor phases are electromechanically iso-
lated from the power supply.
Fig. 9: Motor OFF circuit 1 (NH1) connection to the Compact System
Motor Off switch directly connected to the
contacts for motor OFF
If the S1 motor breaker switch is actuated,
the motor of the hand-held nutrunner/tighten-
ing spindle will be decelerated by the servo
amplifier and the internal contactor in the
compact system will be opened. This tighten-
ing job abort leads to an error message in the
controller. The error message is automatically
acknowledges once switch S1 is closed
again. Now you can restart the system.
XDN1
1234
S1
Einsatz
Motor-Stopp-Schalter
1 mm
2
VEE NH1
NH1
NH1
CS351_zweispaltig - D.book Seite 72 Dienstag, 16. Juli 2013 12:00 12

3 609 929 B45/2013-06 | CS351/CC-CS351 Bosch Rexroth AG 73 /108
Product description
ENGLISH
2. Cut-out via the end step
In addition, the motor OFF can be switched
via the end step or along with the cut-out via
the motor contactors (double protection).
Fig. 10: Motor OFF circuit 2 (NH2) connection to the Compact System
Use of the ErgoSpin/CC-ErgoSpin hand-held nutrunner as a stationary tightening
spindle (valid for “ 1. Cut-out via the internal motor contactors” and “ 2. Cut-out via
the end step”)
If the ErgoSpin/CC-ErgoSpin hand-held nut-
runner is used as a stationary tightening spin-
dle, the start switch must be continually actu-
ated.
Fig. 11: Start switch lock on the ErgoSpin
hand-held nutrunner
1Velcro tape (see ErgoSpin accessories)
XDN1
1234
S1
Einsatz
Motor-Stopp-Schalter
1 mm
2
VEE NH2
NH2
1
CS351_zweispaltig - D.book Seite 73 Dienstag, 16. Juli 2013 12:00 12
