RF Point DC4KEP User manual

SPECIFICATION RF Point Pte Ltd
Website: www.rf-point.com.sg
3.5 KW Portable
DC EV Charger
Model DC4KEP

Website: www.rf-point.com.sg
Specifications
Item
Description
Model
DC4KEP
Dimension (H x W x D)
330 x 164 x 110 mm
Weight
7.2 kg
Storage Temperature
-40 to 176 ° F (-40 to 80 ° C)
Operating Temperature
-22 to 131 ° F (-30 to 50 ° C)
Operating Humidity
5 % to 95%
Mounting
N.A, Portable
Enclosure Ratings
IP67 for indoor or outdoor & Dust Proof
Protection
Leakage Current and Ground Fault Protection, Lightning
Protection, Overvoltage Protection,
Undervoltage Protection, Overcurrent Protection,
Overtemperature Protection
Ground Fault Detection
Built-in type A RCD (residual-current device)
Warranty
2 years
Standards
EN/IEC 61851-1:2019
EN/IEC 61851-21-2:2021
IEC/IEC 62955:201
IEC/IEC 62196-2
Status Display
LED
Charging Cable Length
16.5 ft. (5 m )

Website: www.rf-point.com.sg 3
Input Wiring
Hardwired
Input Cord
L1, L2, L3, N (Neutral), and PE (Protective Earth)
AC Power Input Rating
220±20 %Va.c., 50/60 Hz, 32 A (Max )
Output Current Rating
Maximum 10A
Output Voltage Range
250-500VDC
Connector Type
Type 2
Charging Mode
Plug-and-Charge

Website: www.rf-point.com.sg
2Charging Operation
2.1 Plug-and-Charge Mode (Default )
When the charging station is on standby, plug in the connector to your EV, and
the LED will turn blue from purple.
The LED will be flashing green while charging.
When your EV is fully charged, the LED will be solid green, unplug the connector
and place it back into the holster.
If you need an emergency stop while charging, please press the RESET
BUTTON then unplug the connector.
1. without any operation.
2. Once you enable the RFID mode, the plug-and-charge mode will be
disabled, if you want to use the plug-and-charge mode, please contact us
When the charging station is on standby, plug in the connector to your EV, 6
LED Indicator

Website: www.rf-point.com.sg
Description
Led Indicator
Standby
Solid Purple
Connector Plug in
Solid Blue
Charging
Flashing Green
Fully Charged
Solid Green
RFID Card Setting
Solid Orange
Fault
Flashing RED
3Troubleshooting
LED Status
Problems
Solutions
The red light flashes slowly once
and quickly once, alternately
cycle.
Grounding Fault
1. Immediately turn off the
leakage/overcurrent protection switches in
the power distribution box.
2. Check whether the input cables
are grounded correctly.
3. After the fault is rectified, power
on the device again. If the fault persists,
contact us.
The red light flashes slowly twice
and quickly twice, alternately
cycle.
Output Overcurrent
1. Immediately turn off the
leakage/overcurrent protection switches in
the power distribution box.
2. Check whether there is low
impedance or short circuit between the
charger output line.
3. Ensure the charging current to
less than 35A.
4. After the fault is rectified, power
on the device again. If the fault persists,
contact us.

Website: www.rf-point.com.sg
The red light flashes slowly twice
and quickly for 4 times,
alternately cycle.
Over-heating
1. Check the charger installation
environment.
2. Check whether there are other
heating devices nearby.
3. Ensure that the ambient
temperature is below 50℃.
The red light flashes slowly for 3
times and quickly for 2 times,
alternately cycle.
Input Overvoltage
If the voltage exceeds 265Vac for a short
time,wait for the power gird to restore itself
to the normal voltage range. Contact local
power grid company if the voltage fault
persists.
The red light flashes slowly for 3
times and quickly for 3 times,
alternately cycle.
Input Undervoltage
If the voltage under 90Vac for a short
time,wait for the power gird to restore itself
to the normal voltage range. Contact local
power grid company if the voltage fault
persists.
The red light flashes slowly
twice and quickly once,
alternately cycle.
Relay Adhesion
Please contact us if the fault persists.
The red light flashes slowly for 2
times and quickly for 3 times,
alternately cycle.
Residual Current
Detected
1. Immediately turn off the
leakage/overcurrent protection switches in
the power distribution box.
2. Check whether the charger output
line is damaged or has low impedance to the
ground or short circuit.
3. After the fault is rectified, power
on the device again. If the fault persists,
contact us.
The red light flashes slowly for 3
times and quickly once,
alternately cycle.
L/N Connected
Reversely
1. Immediately turn off the
leakage/overcurrent protection switches in
the power distribution box.
2. Check whether the input L/N
cables are connected in correct sequence.
3. After the fault is rectified, power
on the device again. If the fault persists,
contact us.

Website: www.rf-point.com.sg
The red light flashes slowly
once and quickly twice,
alternately cycle.
CP Frequency Fault
1. Check whether the charging
connector is connected correctly and stably.
2. IF the fault persists, contact us.
The red light flashes slowly once
and quickly for 3 times,
alternately cycle.
CP Duty Cycle
Fault
The red light flashes slowly once
and quickly for 4 times,
alternately cycle.
CP Voltage Level
Fault
1
3
8 Safety Warning
For your own safety and the safety of others, and to prevent damage to the
device and vehicles upon which it is used, it is important for all users to read
and follow this manual and safety instructions during installation, operation,
and maintenance. Non-compliance may cause damage to the EV charger, and
may also lead to electric shock, fire, property damage, and personal injury.
Safety Instructions
This product should only be installed by a licensed electrician in accordance with all
local codes and ordinances.
Please turn off the power at the circuit breaker before installing or cleaning this
product.
Please do not install or use this product near flammable, explosive, rough or
combustible materials, chemicals or vapors.
Please do not use the product if the enclosure or the EV connector is frayed, broken,
otherwise damaged, or fails to operate.

Website: www.rf-point.com.sg
Please do not operate this product at a temperature beyond -30 to 55 ° C.
Please do not repair or refit without authorization, contact our support for
help.
Please do not disassemble safety signs, warning notices, labels, or markings.
Please do not spray water or other liquids directly onto the charging station
or the connector.
Do not immerse the charging connector in liquid.
Please do not forcibly fold or apply pressure to any part of this product or use
sharp objects to damage it.
Please do not subject this product to strong force or impact or pull, twist,
tangle, drag or step on it to prevent damage to itself or its components during
transportation.
Please read the safety instructions in the manual carefully when using our EV
charger to charge your electric vehicle.
Made in China
