Rhima RG 9 User manual

Operator’s Manual
RG 9 & RG 9 HR Washer
Australia Tel: [phone] | New Zealand Tel: [phone] | Singapore Tel: [phone]

INSTRUCTION MANUAL FOR DISHWASHERS
●The appliance must be connected to water and electrical supplies by qualified
tradespersons only and according to local regulations.
●The appliance must be used by adults only. Do not let children play with, or operate
this machine.
●Only persons trained to use this dishwasher are permitted to operate it.
●This appliance has been designed to wash food preparation and eating utensils. It has
NOT been designed to wash objects soiled with petrol, paint, remnants of steel or iron,
corrosive chemical products such as acids, alkalis, or solvents or any item that cannot be
immersed in water.
●Do not open the appliance door or lift hood while the appliance is operating. The
appliance has a safety device which stops operation if the door or hood is accidentally
opened.
●After using the appliance, isolate the electric and water supply.
●Do not attempt to repair the appliance. Repairs made by unqualified persons may cause
further damage and will void warranty.
●Repairs and servicing of this appliance must be carried out by Rhima personnel only.
GENERAL INSTRUCTIONS
It is important to keep this instruction manual near the appliance for
future consultation.
If the appliance is sold or transferred to another user, make sure this
manual remains with the appliance so that the new owner is informed
about the warnings and operation of the appliance. These instructions
are given for safety reasons and they must be read carefully before
installing or using the appliance.
IMPORTANT CUSTOMER INFORMATION
●To request a service, detergents or rinse additive contact your local Rhima Service centre
below:
Australia: 1300 347 944
New Zealand: 0800 902 054
Singapore: [phone]
2

3
ELECTRICAL INSTALLATION
The Australian installation shall be in accordance with The Plumbing Code of Australia (PCA).
This appliance should be connected to a hot water supply (Max 65°C ) for in accordance
with Australian Standard AS/NZS 3500.1. for optimum performance.
The water supply pressure should be a minimum 200 kPa at all times and flow rate should
be at least 10 litres per minute. A static pressure higher than 600 kPa (73.5 psi) requires a
pressure reducing valve upstream of the supply line. If water pressure is below 150 kPa,
the use of a rinse booster pump is recommended.
This appliance is designed to drain to a tundish. Waste connection to a spigot is not
recommended and may cause draining issues.
The drainpipe should withstand 70°C (158°F) in continuous duty conditions.
The grey water drain hose must have a fixed watertight seal above the tundish in
accordance with the Australian Standard AS/NZS 3500.2.
A DIAGRAM SHOWING THE CORRECT METHOD OF WASTE INSTALLATION IN ACCORDANCE
WITH THE AUSTRALIAN STANDARD AS/NZS 3500.2 IS BELOW
PLUMBING INSTALLATION
WMTS-101
WM-022203
This appliance is intended to be connected to a 3 x 20.3 Amps electrical supply and must
be earthed.

4
DETECTION AND DISPLAY OF ALARMS AND FAULTS
Granule cleaning and collection

5
Rack preparation
Photo 1
Photo 2

6

7

8

9
Alarms
MAINTENANCE

10
SOLUTION
TYPE OF FAULTFAULT CODE
DELLIFTONRELIOB1B
Open the water supply tap and verify a
proper water supply flow. Contact the
Rhima Service Department.
Contact the Rhima Service Department.ERULIAFROSNESRELIOB2B
Contact the Rhima Service Department.DETAEHTONRELIOB3B
Contact the Rhima Service Department.GNISNIRNIERULIAF4B
Contact the Rhima Service Department.ERUTAREPMETREVOREL
IOB5B
DELLIFTONKNAT-HSAW1E Open the water supply tap. Contact the
Rhima Service Department.
Contact the Rhima Service Department.ERULIAFROSNESKNAT-HSAW2E
Contact the Rhima Service Department.DETAEHTONKNAT-HSAW3E
Contact the Rhima Service Department.ERUTAREPMETREVOKNAT-HSAW5E
Contact the Rhima Service Department.
YALERLAMREHTPMUPHSAW7E
Contact the Rhima Service Department.ROTATION MOTOR THERMAL RELAY7Z
Granule cleaning and collection

11
TROUBLESHOOTING
eruCsesuaCelbissoPmelborPfoepyT
The appliance does
not draw water
p.atretawehtnepOd.esolcsipatretawehT
Solenoid-valve filter blocked Contact the Rhima Service Department.
Faulty pressure switch. Contact the Rhima Service Department.
Granules: Insufficient
quantity --- Add or substitute granules up to the filter dispenser level.
Unsatisfactory
washing results
The washing nozzles are clogged or the washing
arms do not rotate.
Unscrew and clean the nozzles and the rotating
column, refit them correctly in their seats.
Unremoved grease or starch Detergent concentration too low.
Presence of foam. Use non-foaming detergent or use less of same
detergent.
The filter is too dirty. Remove the filter, clean it with a brush under
running water and refit in its seat.
Check tank temperature (which must be between
50°C and 60°C).
Contact the Rhima Service Department.
Length of washing cycle inadequate for type of
grime build-up.
Choose a longer cycle if possible, otherwise
repeat wash cycle.
Wash water too dirty. Empty water from the tub, clean filters; refill the
tub and correctly reposition the filters.
The objects are not
properly dried.
Insufficient rinse aid. Increase the amount of rinse aid. Contact the
Rhima Service Department.
The rack is not suitable for the objects. Use the suitable rack which gives the objects an
inclined position so that water can rinse away.
The washed items may have been sitting in the
wash chamber too long.
As soon as the cycle stops, remove the rack with
the objects so that they can dry more quickly in
the air.
Rinse temperature under 80°C. Contact the Rhima Service Department.
The rinse water is cold or not hot enough. Contact the Rhima Service Department.
Streaks and spots on
glasses and dishes
Too much rinse aid. Decrease the amount of rinse aid. Contact the
Rhima Service Department.
The water is too hard. Check the water hardness. Water should not be
harder than 2-8 °f.
During wash cycle
the machine stops
and draws water
Water from the previous day has not been
replaced. Empty the tub and refill it.
The tub water temperature is too high. Contact the Rhima Service Department.
Faulty pressure switch.
Machine will not
drain
Object stuck in drain pump*. Contact the Rhima Service Department.
Blocked drain. Check sink’s drain correctly.
If not contact licenced plumber.
* If drain pump is supplied.

Australia Tel: [phone]
New Zealand Tel: [phone]
Singapore Tel: [phone]
DETERGENTS
To request detergents or rinse additive contact your local Rhima Service centre
below:
Australia: 1300 347 944
New Zealand: 0800 902 054
Singapore: [phone]
Granules
9kg Bucket
For washing glass &
instrument washing
Version 1.0
