Rice Lake 880 Performance Series User manual

880 Performance™ Series
Controller/Indicator
Panel Mount Size 5.5
Software Version 3
Technical Manual
PN 158387 Rev DJuly 15, 2019

An ISO 9001 registered company
© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Contents
© Rice Lake Weighing Systems ● All Rights Reserved i
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.1 Weigh Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.2 Configuration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3.3 User Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Front Panel Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.5 Menu Structures and Parameter Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5.1 Navigating Through Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5.2 Edit Parameter Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5.3 Alphanumeric Entry Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5.4 Numeric Values Editing Procedure (880Plus Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.6 Indicator Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.1 Toggle Gross/Net Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.2 Toggle Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.3 Zero Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.4 Acquire Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.5 Remove Stored Tare Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.6 Preset Tare (Keyed Tare) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.7 Print Ticket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.8 Front Panel User Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.9 Displaying Audit Trail Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.6.10 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.6.11 Display or Edit Setpoint Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.6.12 Turn Setpoint On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.6.13 Set Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.6.14 Display Accumulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.15 Clear the Accumulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6.16 Display Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 Unpacking and Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2 Panel Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.1 Mounting the Controller Assembly Remotely. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2.2 Controller Box Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2.3 Remove Backplate of Controller Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2.4 Display Board Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2.5 Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.3 Universal Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.3.1 Remove Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.3.2 Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.4 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.4.1 Load Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.4.2 Power Connections – 880 Panel Mount. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.4.3 DC Cable Grounding in 880 Universal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.4.4 Universal Mount Enclosure Ground Bonds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.4.5 Serial Communications – Port 1 (COM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.4.6 USB Device Communications – Port 2 (USBCOM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

880 Performance Series Controller/Indicator
ii Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
2.5 USB Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.6 Ethernet Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.7 CPU Board (175109 - Blue) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.8 Audit Trail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.9 Digital I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.10 Legal for Trade Sealing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.10.1 880 Panel Mount Sealing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2.10.2 880 Universal Mount Sealing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.11 Option Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.12 Battery Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.13 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.0 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.1 Configuration Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.2 User Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.2.1 Audit Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.2.2 Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.2.3 Scale Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
3.2.4 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3.2.5 Calibration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3.2.6 Feature Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.2.7 Region Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.2.8 Ports Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3.2.9 Com Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3.2.10 Ethernet Communications Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.2.11 USB Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
3.2.12 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
3.2.13 Setpoints Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
3.2.14 Digital Input Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
3.2.15 Analog Output Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
3.2.16 Version Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.1 Front Panel Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.1.1 Five-point linearization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.1.2 Rezero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.2 LAST – Calibrating Zero Without Removing Test Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.3 TEMP – Establishing a Temporary Zero for Calibrating a Loaded Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.4 Adjusting Final Calibration (Trimming) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.5 Gravity Compensation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.6 EDP Command Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
4.7 Revolution® Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.0 Using Revolution®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.1 Connecting to the Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
5.2 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.2.1 New Configuration File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.2.2 Open an Existing Configuration File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.2.3 Saving a Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
5.3 Updating the Indicator CPU or Display Module Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5.4 Revolution Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Contents
© Rice Lake Weighing Systems ● All Rights Reserved iii
Contents
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
6.0 EDP Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6.1 The EDP Command Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6.1.1 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6.1.2 Reporting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.1.3 The RESETCONFIGURATION Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.1.4 Parameter Setting Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.1.5 Scales Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.1.6 Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
6.1.7 Calibration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
6.1.8 Ports COM Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
6.1.9 Ports – Field Bus Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
6.1.10 Ports – Ethernet Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
6.1.11 Ports – USBCOM Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1.12 Stream Tokens Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1.13 Feature Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1.14 Regulatory Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.1.15 Time and Date Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.1.16 Passwords Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.1.17 Keypad Lock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.1.18 Setpoints Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
6.1.19 Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6.1.20 Digital I/O Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6.1.21 Analog Out Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6.1.22 Weigh Mode Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.1.23 Digital I/O Control Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.1.24 ERROR Commands Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.1.25 Batching Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.1.26 Database Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
7.0 Print Formatting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
7.1 Print Formatting Tokens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
7.2 Default Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
7.3 Customizing Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
7.3.1 Using the EDP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
7.3.2 Using the Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
7.3.3 Using Revolution® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
8.0 Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8.1 Batch and Continuous Setpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8.2 Batch Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
8.2.1 Batching Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.3 Batching Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
9.0 Ethernet and USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9.1 Ethernet Server/Client Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9.1.1 Ethernet Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9.1.2 Ethernet Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
9.1.3 Direct Connection from Computer to 880 Ethernet Server Without a Network (Ad-Hoc). . . . . . . . . . . . . . . . . . . . . . 94
9.1.4 Computer Connection to 880 Ethernet Server Through a Network Switch or Router . . . . . . . . . . . . . . . . . . . . . . . . 94

880 Performance Series Controller/Indicator
iv Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
9.1.5 Connection to a Remote Host - Demand Print to an Ethernet Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.1.6 Connecting to a Remote Host - Stream weight data to an Ethernet Remote Display . . . . . . . . . . . . . . . . . . . . . . . . 96
9.1.7 Connecting to a Remote Host, Stream/Demand Data to Remote Ethernet-to-RS-232 Device Server . . . . . . . . . . . 96
9.2 USB Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
9.2.1 Using a USB Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
9.2.2 USB Memory storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
10.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.1 Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.1.1 Displayed Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.2 Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
10.3 Using the HARDWARE Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
10.4 ERROR Commands Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
10.5 TARE and ZERO Key Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
10.6 Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.6.1 Stream Serial Data Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.6.2 Print Output Serial Data Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
10.6.3 RS-485 Data Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
10.7 Custom Stream Formatting – Input/Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.8 Stream Formatting Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.8.1 Toledo 8142 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.8.2 Cardinal 738 Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.8.3 Weightronix WI 120 Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.9 ASCII Character Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
10.10 Digital Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
10.10.1 Sample Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
10.10.2 Digital Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
10.11 Analog Output Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
11.0 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
12.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 1
1.0 Introduction
This manual is intended for use by service technicians responsible for installing and servicing 880 digital weight indicators.
This manual applies to indicators using Version 3 of the 880 firmware and because the 880 board design has
changed, there are new part numbers which now has 5.5'' boards and associated new part numbers. Please be
advised, past generation boards and parts are not interchangeable with the new boards. Information contained
within this manual is exclusively for units with CPU board, PN 175109 (blue in color), see Section 2.13 on
page 31 for drawing and replacement part information.
Manuals and additional resources are available from the Rice Lake Weighing Systems website at www.ricelake.com
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Safety
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
Indicates information about procedures that, if not observed, could result in damage to equipment or corruption
to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
Failure to heed could result in serious injury or death.
Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by
qualified service personnel only.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without the enclosure completely assembled.
Do not use for purposes other than weight taking.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not exceed the rated specification of the unit.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not submerge.
Before opening the unit, ensure the power cord is disconnected from the outlet.
IMPORTANT
DANGER
WARNING
CAUTION
IMPORTANT
WARNING

880 Performance Series Controller/Indicator
2 Visit our website www.RiceLake.com
1.2 Overview
The 880 is a programmable single-channel digital weight indicator, available in a panel mount or universal enclosure.
The front panel bezel can be sealed to a NEMA Type 4X/IP69K rating. The front panel consists of a six-button keypad and a
six-digit, 14-segment LED display. The Universal front panel includes a numeric key pad.
Features include:
• LED display, 0.56'' (14 mm), six-digit, 14-segment
• RS-232 or RS-485 serial port
• USB device port connects directly to a PC
• Ethernet TCP/IP polled or continuous
• AC or DC models
• Built-in DIN-rail clips on controller box (panel mount)
• Display and controller can be separated up to 250' (panel mount)
• Hardware slot for one option card
• Operator functions through menu key for audit trail, preset tare, accumulator, time & date and setpoints
• Audit trail tracking for configuration and calibration changes; password protection for user and configuration changes
• 20 setpoints with latched batch engine or unlatched outputs
• Four onboard digital I/O channels
• Programmable ticket formats up to 1,000 characters for header text, gross, net, accumulator and setpoints
• Local/remote operation
• Multi-range or multi-interval weighing
• Filter settings for light, medium and heavy noise
Options/Accessories:
• Metrological hardware sealing kit
• Adapter plate for converting 310 A and 520 panel mounts
• Panel mount kit for universal enclosure
Network Cards:
• 179158 Ind Opt, EtherCat Model 880 Indicator
• 179159 Ind Opt, Ethernet/IP Model 880 Indicator
• 179160 Ind Opt, Profinet Model 880 Indicator
• 179161 Ind Opt, Modbus TCP Model 880 Indicator
• 179162 Ind Opt, Devicenet Model 880 Indicator
• 179163 Ind Opt, Profibus Model 880 Indicator

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 3
1.3 Operating Modes
The three modes of operation for the 880 are described in the following sections.
1.3.1 Weigh Mode
In this mode, the indicator displays gross or net weights to indicate the type of weight value displayed and annunciators to
indicate scale status.
1.3.2 Configuration Mode
Many of the procedures described in this manual, require the indicator to be in configuration mode, see Section 3.0 on page 35.
The 880 has an Audit Trail that tracks changes to configuration and calibration, allowing the setup switch to be bypassed with
Jumper J4 on the CPU board. If Audit Trail is enabled, configuration mode can be accessed through the user setup mode.
1.3.3 User Setup Mode
User setup mode, accessed by pressing , allows the following configuration steps:
• View the audit trail
• Set time and date
• View or clear accumulator value
• Change setpoint values
• View current tare value
• Enter configuration mode (if audit trail is enabled)
See Section 1.6.8 on page 8 for more information about entering user setup mode.
MENU

880 Performance Series Controller/Indicator
4 Visit our website www.RiceLake.com
1.4 Front Panel Display
The front panel consists of a six-button keypad and a six-digit, 14-segment LED display. The Universal front panel includes a
numeric key pad.
The numeric display consists of six 14-segment LED digits. If a negative number is displayed, the first digit is used to display -,
reducing the number of available digits to five.
The symbols on the keys in Figure 1-1 (representing up, down, enter, left, right) describe the key functions when in
configuration mode. The keys are used to navigate through menus, select digits within numeric values, and increment/
decrement values, see Section 3.2 on page 36 for information about using the front panel keys in configuration mode.
Figure 1-1. 880 Front Panel Display (Universal Model Shown)
Item No. Function
1 Sets the current gross weight to zero; used to navigate to other menus or to select another digit when editing a value
2 Sends an on-demand print format to a communications port, provided the conditions for standstill are met; if enabled in configuration,
Print may displayed while the unit is printing; used to navigate to other menus or select another digit when editing a value
3 Performs several predetermined tare functions dependent on the mode of operation selected in the TAREFN; acts as enter for numeric or
parameter entry
4 Toggles displayed weight between gross and net mode; if a tare value has been entered or acquired, the net value is the gross weight
minus the tare; gross mode is indicated by the Gross/Brutto annunciator; net mode is indicated by the Net annunciator; used to navigate
to different menus or to select another digit when editing a value
5 Allows access to the user setup menu; also acts as the cancel key when editing parameter values, or Exit key when in the configuration
or user setup menus
6 Switches the weight display to an alternate unit, defined in the format menu, see Section 3.2.4 on page 40; units available: lb, kg, oz,
metric ton, ton, gram; used to navigate to different menus or to select another digit when editing a value
7 Clears a numeric entry from the LCD (not available with the panel mount)
8 Inserts a decimal point where necessary (not available with the panel mount)
9 The Numeric Keypad can be used to enter values; values may also be entered by scrolling through values with the arrow keys
(not available with the panel mount)
10 R1, Rs, R3
11 Scale is at standstill or within the specified motion band; some operations, including Zero, Tare and Printing, can only be completed LED
is lit
Table 1-1. Key Functions
MENU
TARE
UNITS
ZERO
PRINT
GROSS
NET
B/N
Gross
Brutto
Net
lb
kg
T
PT
R1 R2 R3
10 1
2
3
4
5
6
7
8
9
11
12
13 15
16
14

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 5
1.5 Menu Structures and Parameter Descriptions
The front panel keys are used to navigate through the menus in configuration mode, see Figure 1-2.
• and move left and right (horizontally) in a menu level
• and move up and down (vertically) to different menu levels
• serves as an enter key for selecting parameter values within the menus
1.5.1 Navigating Through Levels
Figure 1-2. Configuration Mode Menu Navigation
To select a parameter, press or to scroll left or right until the desired menu group appears on the display,
then press to move down to the sub-menu or parameter to be edited. When moving through the menu parameters,
the current selected value appears first on the display.
12 Indicates that the current gross weight reading is within ±0.25 display divisions of the acquired zero, or is within the center of zero band;
a display division is the resolution of the displayed weight value, or the smallest incremental increase or decrease that can be displayed
or printed
13 Gross weight mode (or Brutto in OIML mode)
14 Net weight mode
lb/kg LED – the lb and kg annunciators indicate the units associated with the displayed value. If the displayed value is pounds, lb will be
lit. If the displayed value is kilograms, kg will be lit;
primary or secondary – if the other units value is neither lb or kg, then lb will be lit for the units assigned as primary, and kg will be lit for
the units assigned as secondary;
lb/tn, t, oz, g, or none – alternate conversions that can be displayed include short tons (tn), metric tons (t), ounces (oz), grams (g), or
NONE (no units); if the displayed units is one of these alternate conversions, and the other unit value is lb, then kg will be lit;
tn, t, oz, g, or none – alternate conversions that can be displayed include short tons (tn), metric tons (t), ounces (oz), grams (g), or NONE
(no units); if the displayed units is one of these alternate conversions, and the other unit value is kg, then lb will be lit
16 T LED – indicates that a tare has been acquired and stored by the system;
PT LED – indicates that a preset tare weight has been keyed in or entered via the EDP serial port
Item No. Function
Table 1-1. Key Functions (Continued)
UNITS
PRINT
ZERO
GROSS
NET
B/N
TARE
Level 1
Parameter
Default value
Level 2
Parameter
Value Value Value
Level 1
Parameter
Level 2
Parameter
When moving through values below the first menu level, press to return to the level
above. Press or to move to the next parameter on that level.
UNITS
PRINT
GROSS
NET
B/N

880 Performance Series Controller/Indicator
6 Visit our website www.RiceLake.com
1.5.2 Edit Parameter Values
To change a parameter value, scroll left or right to view the values for that parameter. When the desired value appears on the
display, press to select the value and move back up one level. To edit numerical values, use the navigation keys to
select the digit and to increment or decrement the value. Alternatively, use the numeric keypad (universal enclosure only), to
enter the digits. The decimal point will begin flashing if a decimal value is allowed. Use the navigation keys, to move the decimal
point left or right. Press when done.
1.5.3 Alphanumeric Entry Procedure
Use the following scheme for alphanumeric entry when using the five-button keypad.
Figure 1-3. Editing Procedure for Numeric Values
1.5.4 Numeric Values Editing Procedure (880Plus Only)
When using the numeric keypad option, the method for editing numeric values relies on the numbers which are embossed on
the keypad (as opposed to using the arrows).
Figure 1-4. Numeric Keypad
1. Using the numeric keypad, insert the required value.
• Press to clear the currently selected digit
• Press to enter a decimal point
2. Press to save the value entered and return to the level above.
When editing fractional numeric values, the decimal point must be positioned in accordance with the primary units
formatting, otherwise the keyed number may be rejected by the software.
TARE
TARE
Display first 6
characters of format
Display and edit
active character and
ASCII value
Delete active
character
Scroll right in format string.
Scroll left in format string.
Increment ASCII value of active character
Decrement ASCII value
of active character.
Press to insert a space
before the active character.
Press to accept the changes
and return to the level above.
Level 2
Parameter
Level 1
Parameter
Level 2
Parameter
Level 1
Parameter
Press to accept the changes
and return to the level above.
TARE
Note

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 7
1.6 Indicator Operations
Basic 880 operations are summarized below.
1.6.1 Toggle Gross/Net Mode
1. Press to toggle the display mode between gross and net.
Net mode is available when a tare value has been entered or acquired (Net = Gross minus Tare). If tare has not been
entered or acquired, the display remains in gross mode. The LEDs next to Gross or Net indicate the current mode.
1.6.2 Toggle Units
Press to switch between primary and secondary units. The current units LED will be lit.
1.6.3 Zero Scale
1. In gross mode, remove all weight from the scale and wait for the LED to light.
2. Press . The LED lights to indicate the scale is zeroed.
The scale must be stable and within the configured zero range for the scale to be zeroed. If the scale cannot be
zeroed, No zero is displayed.
1.6.4 Acquire Tare
1. Place a container on the scale and wait for the LED to light.
2. Press to acquire the tare weight of the container. The Net weight is displayed and the T LED lights to show
the tare value was entered.
1.6.5 Remove Stored Tare Value
1. Remove all weight from the scale and wait for the LED to light. The display should read zero and the
LED should be lit.
2. Press to zero the scale if needed.
3. Press (or in OIML mode). Display shifts to gross weight and the Gross LED is lit.
If keyed tares are allowed, press to open the keyed tare prompt. To clear tare, press again.
GROSS
NET
B/N
Note
UNITS
ZERO
0
Note
TARE
0
ZERO
TARE
ZERO
Note
TARE
TARE

880 Performance Series Controller/Indicator
8 Visit our website www.RiceLake.com
1.6.6 Preset Tare (Keyed Tare)
Tare mode must be set to keyed or both for the preset tare feature to function.
1. With the scale empty and zero weight on the display, press . 000000 displays with the focused digit flashing.
2. Edit the value using the keypad on the 880Plus, see Section 1.5.4 on page 6 or use the following method for the panel
mount.
• Press or to select the digit
• Press or to increment or decrement the value
• Press to move to the decimal point entry
• Press or to adjust the decimal point placement
• Press when the value is correct
The display will change to the Net mode and the PT LED lights to show the preset tare was entered.
Entering a keyed tare of zero will remove the stored tare value.
1.6.7 Print Ticket
1. Wait for the LED to light.
2. Press to send data to the configured communications port.
1.6.8 Front Panel User Setup
Press to enter user setup mode. Use User Setup to:
• View audit trail information
• Enter configuration mode if audit trail is enabled
• View or set time and date
• View or clear the accumulator
• Change setpoint values and enable/disable setpoints
• View the current tare value
1.6.9 Displaying Audit Trail Information
The Audit Trail Configuration and Calibration counters can be viewed through the User Menu.
1. Press . Audit is displayed.
2. Press to display the Legally Relevant Firmware version.
3. Press to display Calib.
4. Press to view the Calibration Counter.
5. Press to return to Calib.
6. Press to display CFG.
7. Press to view the Configuration Counter.
8. Press to return to CFG.
9. Press to return to the weigh mode.
Note
TARE
TARE
TARE
Note
PRINT
MENU
MENU
MENU
MENU
MENU

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 9
1.6.10 Setpoints
Setpoints must be enabled in the configuration mode to be accessible in the user setup mode.
Breaking the seal to enter the configuration mode will void a Legal for Trade unit.
To enter the configuration mode:
1. Remove the large fillister head screw from the back of the enclosure.
2. Insert a non-conductive tool into the access hole and press the setup switch. Scale displays.
3. Press or until Setpts is displayed.
4. Press . SP CFG is displayed.
5. Press . Press or to desired setpoint number.
6. Press to enter setpoint settings.
7. Select the type by pressing or to desired setting, then press to set the value. For complete list of choices, see
Section 3.2.13 on page 53.
8. When all settings have been made, press to return to weighing mode.
Setpoints are now accessible from the front panel menu.
1.6.11 Display or Edit Setpoint Value
1. Press . Audit is displayed.
2. Press or until Setpts is displayed.
3. Press and the first available setpoint number is displayed.
4. Press or to toggle through each setpoint that is operator accessible.
5. Press . Value is displayed.
6. Press again to display or edit the value.
7. Edit the value using the keypad on the 880Plus, see Section 1.5.4 on page 6 or use the following method for the panel
mount.
• Press or to increment or decrement the value of the flashing digit
• Press or to select the digit to edit
• Press to move to the decimal point entry
• Press or to adjust the decimal point placement
8. Press to accept the displayed value.
9. Repeat the above steps to set Preact, if enabled.
10. When all settings have been made, press to return to weigh mode.
Setpoint Value and Preact Value may be accessible from the front panel in weigh mode.
Some indicator configurations may not allow setpoint values to be changed through the front panel or may require a
password to display or change the setpoint value.
IMPORTANT
MENU
Note
MENU
TARE
TARE
MENU
Note

880 Performance Series Controller/Indicator
10 Visit our website www.RiceLake.com
1.6.12 Turn Setpoint On or Off
Turn a setpoint off at the front panel.
1. Press . Audit is displayed.
2. Press or until Setpts is displayed.
3. Press and the first available setpoint number is displayed.
4. Press or to toggle through each setpoint that is operator accessible.
5. Press , then press or to Enable.
6. Press , then press or to turn setpoint On/Off.
7. Press to accept the setting.
8. Press to return to weigh mode.
Some indicator configurations may not allow setpoints to be turned off through the front panel or may require a
password to turn the setpoint on and off.
1.6.13 Set Time and Date
1. Press . Audit is displayed.
2. Press or until T&D is displayed.
3. Press . Time is displayed.
4. Press to enter time.
5. Edit value using the keypad on the unit, see Section 1.5.4 on page 6 or use the following method for the panel mount:
• Press or to select the digit
• Press or to increment or decrement the value
6. Press when the value is correct. Date is displayed.
7. Press to enter date.
8. Edit the value using the keypad on the 880Plus in the specified format MMDDYY, DDMMYY, or YYMMDD. Press or
to select the digit. Press or to increment or decrement the value.
9. Press when the value is correct. Time is displayed.
10. Press to return to weighing mode.
MENU
TARE
MENU
Note
MENU
TARE
TARE
MENU

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 11
1.6.14 Display Accumulator
Enable the accumulator before use in either weigh mode or setpoint operations. Once enabled, weight (net weight if a tare is in
the system) is accumulated whenever a print operation is performed using the key, digital input, setpoint PSHACC
operation or KPRINT serial command. The scale must return to below the threshold value (except for the setpoint PSHACC
operation) before the next accumulation.
1. Press to enter the user setup mode, Audit is displayed.
2. Press or until Accum is displayed.
Accum is only displayed if the accumulator is enabled, see Section 3.2.3 on page 38.
3. Press . View is displayed.
4. Press to view the current accumulator value.
5. While the accumulator value is displayed, press to print the value.
The format of the print output can be configured using the accumulator print format, see Section 7.0 on page 85.
1.6.15 Clear the Accumulator
1. Press to enter the user setup mode. Audit is displayed.
2. Press or until Accum is displayed.
3. Press , then press or until CLR Y is displayed.
4. Press to clear the accumulator. Clear will display briefly and display returns to CLR Y.
5. Press to return to the weigh mode.
The pxrint key only performs one accumulation, and only if the weight is above the accumulator threshold. Weight
must return to below the accumulator threshold value before another accumulation is allowed.
Accumulator threshold is configured in the setup menu, see Section 3.2.2 on page 37.
1.6.16 Display Tare
When a stored Tare value is displayed, the Gross and Net LEDs will be off and will be lit. To display a stored tare:
1. Press .
2. Press to tare and press to view the current tare value.
3. Press twice to return to weigh mode.
If there is not a tare in the system, the value displayed will be zero and the Gross and Net LED will be turned off, see
Section 10.5 on page 101 for more information pertaining to the regulatory mode of operation.
PRINT
MENU
Note
PRINT
Note
MENU
TARE
MENU
Note
0
MENU
MENU

880 Performance Series Controller/Indicator
12 Visit our website www.RiceLake.com
2.0 Installation
This section describes procedures for connecting power, load cells, digital I/O and data communications cables to the 880
indicator. Instructions for replacement of the circuit boards are included, along with assembly drawings and parts lists for the
service technician.
Use anti-static protection for grounding and to protect components from electrostatic discharge
(ESD) when working inside the indicator enclosure.
Procedures requiring work inside the indicator must be performed by qualified service personnel only.
The supply cord serves as the power disconnect for the 880. Ensure the power cord is unplugged prior to opening the enclosure.
2.1 Unpacking and Assembly
Immediately after unpacking, visually inspect the 880 to ensure all components are included and undamaged. The shipping
carton should contain the controller, display, CD, parts kit, see Table 2-10 on page 32 and manuals. If any parts were damaged
in shipment, notify Rice Lake Weighing Systems and the shipper immediately.
2.2 Panel Mount Installation
The controller can be mounted to the display DIN rail or mounted remotely up to 250 ft away from display.
Figure 2-1. 880 Panel Mount Dimensions
Use the DIN rail mount plate as a template, see Figure 2-2 on page 13, to drill the mounting holes in the panel for the stainless
steel panel mount enclosure.
WARNING
Note
5.50
5.15 (13.1 cm)
4.57 (11.6 cm)
.58
1.5 cm
3.38
(8.6 cm)
3.88
(9.9 cm)

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 13
1. Mark panel for installation using the DIN rail mount plate and drill the five holes required for mounting.
Figure 2-2. Pattern for Cutting Holes
2. Install the gasket on the display assembly. It must be seated correctly on display before mounting to ensure tight seal.
3. Align the display assembly to the front and the DIN rail mount plate to the back of the panel with holes cut, see Step 1.
4. Secure display and mounting plate to the panel using the four 6-32 Kep nuts (PN 14621) provided. Torque to 8 in-lb.
Figure 2-3. Mounting Display Assembly
5. Connect the cable assembly to the controller assembly.
6. Hook the controller assembly to the top DIN rail assembly as shown in Figure 2-4 on page 14.
4.25"
3.38"
4.00"
2.25"
1.13"
6.00"
0.88"
0.88"
5/32 " Ø
7/8 " Ø
Use DIN Rail Mount Plate as a template for drilling
mounting holes in panel.
This is not a template. Drawing
is for reference only.
IMPORTANT
Panel for mounting indicator (Ref)
Din Rail Mounting Plate
Display Assembly
6-32 Kep Nuts
Ensure gasket is seated properly on display assembly before mounting.
Note
Back of panel
Front of panel

880 Performance Series Controller/Indicator
14 Visit our website www.RiceLake.com
7. Snap the bottom spring loaded latch to the bottom DIN rail so it is secure.
Figure 2-4. Install Controller Assembly
2.2.1 Mounting the Controller Assembly Remotely
A 6-pin connector (PN 153883) is required to mount the controller assembly remotely, see Figure 2-5 for terminal location and
Table 2-1 for pin assignments.
Controller assembly can be mounted remotely on a standard 35 mm DIN rail, up to 250' from display.
Figure 2-5. Mount Controller Assembly Remotely
Connect to this terminal when mounting the display remotely (from the Controller Assembly).
Pin Function
1 +6V
2 GND
3 -TX
4 +TX
5 -RX
6 +RX
Table 2-1. Pin Assignments
Insert screwdriver into tab to open
Display cable harness
Note
J1 J2 J3 J4 J5 J6
AC POWER
N L
Connect to this
terminal when
mounting the display
remotely (from the
Controller Assembly).
Note
Note
