Rice Lake EVOLUTION Synergy 380 User manual

380/380X/381
Synergy Series
Battery Powered Digital Weight Indicators
Technical Manual
380 Synergy Series Digital Weight Indicator
380X Synergy Series Digital Weight Indicator
381 Synergy Series Digital Weight Indicator
PN 201481 Rev GAugust 15, 2023

© Rice Lake Weighing Systems. All rights reserved.
Rice Lake Weighing Systems® is a registered trademark of
Rice Lake Weighing Systems.
All other brand or product names within this publication are trademarks or
registered trademarks of their respective companies.
All information contained within this publication is, to the best of our knowledge, complete and
accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make
changes to the technology, features, specifications and design of the equipment without notice.
The most current version of this publication, software, firmware and all other product
updates can be found on our website:
www.ricelake.com

Revision History
© Rice Lake Weighing Systems ● All Rights Reserved 3
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
Revision History
This section tracks and describes manual revisions for awareness of major updates.
Revision Date Description
D August 10, 2022 Revision history established; clarified configuration section and general formatting updates.
E November 3, 2022 Added cord grip diameter ranges.
F April 19, 2023 Added the 381 indicator models to the manual.
G August 15, 2023 Added the 380X indicator model to the manual
Table i. Revision Letter History

Contents
380/380x/381 Synergy Indicator
4 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 Operating Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 380/380X Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 381 Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4 Mounting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5 Open Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5.1 380/380X Front Plate Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.5.2 381 Back Cover Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.6 Cord Grip Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.6.1 380 Cord Grip Connections (PN 202711) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.6.2 380X Cord Grip Connections (PN 214337) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.6.3 381-2D-AA Cord Grip Connections (PN 215695) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.6.4 381-2D-NiMH Cord Grip Connections (PN 215696) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.7 380/380X Cable Shield Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.8 CPU Board Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.8.1 Load Cell Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.8.2 380/380X RS-232 Serial Communications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.9 Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.9.1 380-2D Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.9.2 380X-2D Power Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.9.3 381-2D-AA Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.9.4 381-2D-NiMH Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.10 Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.10.1 380/380X Front Plate Reattachment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.10.2 381 Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.11 380/380X Parts Kit Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.12 Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.0 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.1 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2 LCD Annunciators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3 General Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3.1 Numeric Value Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.3.2 Alphanumeric Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.4 Weigh Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.1 Zero Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.2 Print Ticket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.3 Toggle Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.4 Toggle Gross/Net Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.5 Acquire Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.6 Remove Tare Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4.7 Preset Tare (Keyed Tare) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Contents
© Rice Lake Weighing Systems ● All Rights Reserved 5
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com/training
or obtained by calling 715-234-9171 and asking for the training department.
3.5 User Mode Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.1 Display a Stored Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.2 Clear a Stored Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.3 View Legally Relevant Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.4 Display Accumulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.5.5 Print Accumulator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.5.6 Clear Accumulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3.6 Reset (Default) Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.0 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.1 Seal the Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.1.1 Close the CAL Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.1.2 Seal the 380/380X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.1.3 Seal the 381 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.2 Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3 Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3.1 Setup – Configuration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.3.2 Setup – Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.3.3 Setup – Calibration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.3.4 Setup – Communication Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.3.5 Setup – Program Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.3.6 Setup – Print Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.3.7 Setup – Stream Format Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.4 Accumulator Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5 Tare Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.6 Audit Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.0 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1 Front Panel Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.1 Span Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.2 Linear Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2 Alternative Zero Calibrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2.1 Last Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2.2 Temporary Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2.3 Rezero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.3 EDP Command Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.0 Revolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.1 Connecting to the Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.2 Saving and Transferring Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.2.1 Saving Indicator Data to a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.2.2 Downloading Configuration Data from PC to Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.0 EDP Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.1 Key Press Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.2 Reporting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.3 Reset Configuration Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.4 Parameter Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.5 USB Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.6 EDP Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.7 Stream Setting Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

380/380x/381 Synergy Indicator
6 Visit our website www.RiceLake.com
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars
7.8 Feature Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.9 Print Format Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.10 Weigh Mode Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
8.0 Print Formatting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.1 Print Formatting Tokens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
8.2 Customizing Print Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
8.3 Non-Human Readable Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.0 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.1 Maintenance Checkpoints. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.2 Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
9.4 Board Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.5 Updating Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.5.1 With Revolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.5.2 Without Revolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
10.0 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
10.1 Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
10.2 ZZ EDP Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
10.3 Continuous Data (Stream) Output Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
10.3.1 Rice Lake Weighing Systems Stream Format (RLWS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
10.3.2 Cardinal Stream Format (crdnal) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
10.3.3 Avery Weigh-Tronix Stream Format (wtrnix) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
10.3.4 Mettler Toledo Stream Format (toledo) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
10.4 Conversion Factors for Secondary Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
10.5 Digital Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
10.5.1 Digital Rolling Average Filter (AVGONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
10.5.2 Regulatory Mode Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
10.6 ASCII Character Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
10.7 Front Panel Display Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
11.0 Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
12.0 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Introduction
© Rice Lake Weighing Systems ● All Rights Reserved 7
1.0 Introduction
This manual is intended for use by service technicians responsible for installing and servicing 380/380X/381 digital weight
indicators.
Configuration and calibration of the indicator can be accomplished using the Revolution® configuration utility or the indicator
front panel keys. See Section 4.0 on page 37 and Section 5.0 on page 47 for information about configuration and calibration.
Manuals and additional resources are available from Rice Lake Weighing Systems at www.ricelake.com/manuals
Warranty information can be found on the website at www.ricelake.com/warranties
1.1 Safety
Safety Definitions:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. Includes
hazards that are exposed when guards are removed.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in serious injury or death. Includes
hazards that are exposed when guards are removed.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, could result in minor or moderate injury.
IMPORTANT: Indicates information about procedures that, if not observed, could result in damage to equipment or
corruption to and loss of data.
General Safety
Do not operate or work on this equipment unless this manual has been read and all instructions are understood.
Failure to follow the instructions or heed the warnings could result in injury or death. Contact any Rice Lake
Weighing Systems dealer for replacement manuals.
WARNING
Failure to heed could result in serious injury or death.
Some procedures described in this manual require work inside the indicator enclosure. These procedures are to be performed by
qualified service personnel only.
Ensure the power source is disconnected from the outlet before opening the unit.
Do not allow minors (children) or inexperienced persons to operate this unit.
Do not operate without the enclosure completely assembled.
Do not use for purposes other than weight taking.
Do not place fingers into slots or possible pinch points.
Do not use this product if any of the components are cracked.
Do not exceed the rated specification of the unit.
Only connect unit to equipment certified to IEC 60950, IEC 62368, IEC 61010 or similar.
Do not make alterations or modifications to the unit.
Do not remove or obscure warning labels.
Do not use solvents or aggressive substances to clean the indicator.
Do not submerge.

380/380x/381 Synergy Indicator
8 Visit our website www.RiceLake.com
1.2 Options
The 380/380X/381 Synergy indicator includes several factory installed options. Some features in this manual are not available
in all models.
Synergy Series Models
Stainless Steel Model
• 380-2D (PN 202711) ― Universal alkaline C-cell battery powered (Adapter sold separately)
• 380X-2D (PN 214337) ― Universal washdown rechargeable lithium ion battery powered (AC internal power supply)
Plastic Models
• 381-2D-AA (PN 215695) ― Universal alkaline AA-cell battery powered (Adapter included)
• 381-2D-NiMh (PN 215696) ― Universal rechargeable nickel metal hydride battery powered (Charger included)
Available Options
• RTC Option (PN 204258) ― Adds date and time functionality to the indicator; time is backed by an independent battery.
1.3 Operating Modes
Weigh Mode
Weigh mode is the default mode of the indicator. The indicator displays gross or net weights as required, using the annunciators
to indicate scale status and the type of weight value displayed.
User Mode
User mode is accessible by pressing and holding for five seconds on the front panel while in weigh mode. The indicator
displays the audit, accumulator, tare and version menus when in user mode.
Setup Mode
Setup mode is accessible by pressing momentarily on the front panel during power up. Most of the procedures
described in this manual, including calibration, require the indicator to be in setup mode.
See Section 4.0 on page 37 for the procedure to enter setup mode and the parameters available.
1.4 FCC Compliance
United States
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Canada
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la Class A prescites dans le Règlement sur le brouillage radioélectrique edicté par le ministère des
Communications du Canada.
ZERO
ZERO

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 9
2.0 Installation
This section describes procedures for connecting power, load cells and data communication cables to a 380/380X/381 Synergy
Series indicator. An assembly drawing and parts list are included for the service technician.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to state and
local regulations.
ATTENTION: Risque d’explosion si la batterie est remplacée par un type incorrect. Mattre au rebus les batteries usagées
selon les règlements d'état et locaux.
Specified optional power adapters are the only external power sources allowed to be used for the 380/380X/381 Synergy Series
indicators.
• 380-2D ― (PN 206433)
• 380X-2D ― Built in power supply. No optional external source.
• 381-2D-AA ― (PN 215734)
• 381-2D-NiMh ― (PN 185064) The 381-2D-NiMh cannot be powered on with the adapter connected
IMPORTANT: Leaving the charger attached to the 381-2D-NiMh while not plugged in will discharge the battery even if the
indicator is powered off.
The 381-2D-NiMh loses its IP rating when the charger is attached.
WARNING: Failure to heed the following statements could result in serious injury or death.
• Procedures requiring work inside the product enclosure must be performed by qualified service personnel only.
• Use a grounding wrist strap to protect components from electrostatic discharge (ESD) damage when working inside the
product enclosure.
• The power outlet must be near the equipment and must be easily accessible.
2.1 Unpacking
Immediately after unpacking, visually inspect the 380/ 380X/ 381 to ensure all components are included and undamaged. The
380/ 380X shipping carton contains the indicator, this manual and a parts kit (Section 2.11 on page 22). The 381 shipping carton
contains a power adapter, the stand and a quick start guide. If parts were damaged in shipment, notify Rice Lake Weighing
Systems and the shipper immediately.
2.2 380/380X Product Dimensions
Figure 2-1. 380 Product Diagram
WARNING
AVERTISSEMENT
Risk of electrical shock.
Risque de choc.
Disconnect power before servicing.
Débranchez l’alimentation avant l’entretien.
A B C D E F
9.50 in (241 mm) 6.00 in (152 mm) 8.57 in (218 mm) 11.58 in (294 mm) 4.53 in (115 mm) 3.53 in (90 mm)
Table 2-1. 380/380X Product Dimensions
A
B
C
D


TARE
T
PRINT
ZERO GROSS
NET
B/N
UNITS
E
F

380/380x/381 Synergy Indicator
10 Visit our website www.RiceLake.com
2.3 381 Product Dimensions
Figure 2-2. 381 Product Diagram
2.4 Mounting Instructions
All 380/ 380X /381 Synergy Series indicators include a universal mount stand. The 380/ 380X/381 universal mount stand has 4
holes. The stand can be mounted on a wall, tabletop or a flat surface. The instructions below are to be used as an example for
all models. Holes in the 380/380X universal mount stand are configured differently than the 381. The 381 universal mount stand
supports additional mounting options.
NOTE: The universal mount stand comes attached to the 380/380X. Rice Lake Weighing Systems recommends removing
the indicator from the stand prior to mounting.
Figure 2-3. Mounting the Indicator
1. Using the mount as a template, mark the screw locations.
2. Drill holes for the screws.
3. Secure the universal mount using the appropriate length 1/4 in or M6 hardware (not included).
4. Reattach the 380/ 380X /381 to the universal mount stand.
NOTE: The 380/380X parts kit includes rubber grommets to insert into the four screw holes of the universal mount stand for
a non-mounted application.
A B C D E F
6.77 in (172 mm) 3.82 in (97 mm) 5.06 in (129 mm) 8.50 in (216 mm) 3.17 in (81 mm) 1.77 in (45 mm)
Table 2-2. 381 Product Dimensions


A
B
D
E
F
C

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 11
2.5 Open Enclosure
This section includes information on opening the 380/ 380X/ 381 enclosures.
2.5.1 380/380X Front Plate Removal
Remove the front plate of the 380/ 380X to connect cables and to gain access to the 380/ 380X board.
WARNING: Before opening the unit, ensure batteries are removed and the optional power cord is disconnected from the
power outlet.
1. Place the indicator face-up on an anti-static work mat.
2. Unscrew the screws holding the front plate to the enclosure.
NOTE: Screws are held in place with retaining washers and cannot be entirely removed.
3. Lift the front plate away from the enclosure and disconnect the ground wire from the front plate.
Figure 2-4. Removing the Front Plate
380/380X Torque Ratings
Refer to Table 2-3 throughout installation and use of product to maintain proper torque ratings for 380/ 380X components.
Component Torque Rating
Front Plate Screw 10 in-lb (1.1 N-m)
Cord Grip Nut (to enclosure) 33 in-lb (3.7 N-m)
Cord Grip Dome Nut (around cable) 22 in-lb (2.5 N-m)
Screw at Antenna Hole 10 in-lb (1.1 N-m)
Grounding wire 10 in-lb (1.1 N-m)
Standoff Nuts 4 in-lb (0.45 N-m)
Table 2-3. Component Torque Ratings

380/380x/381 Synergy Indicator
12 Visit our website www.RiceLake.com
2.5.2 381 Back Cover Removal
Remove the back cover of the 381 to connect cables and to gain access to the 381 board.
WARNING: Before opening the unit, ensure power cord is disconnected from the power outlet.
1. Place the indicator face-down on an anti-static work mat.
2. Remove the screws holding the back cover to the enclosure with a 3mm hex key (PN 216647).
3. Lift the back cover away from the enclosure.
Figure 2-5. Removing the Back Cover
381 Torque Ratings
Refer to Table 2-4 throughout installation and use of product to maintain proper torque ratings for 381 components.
Component Torque Rating
Back Cover Screw 13 in-lb (1.5 N-m)
Cord Grip Nut (to enclosure) 33 in-lb (3.7 N-m)
Cord Grip Dome Nut (around cable) 22 in-lb (2.5 N-m)
Standoff Nuts 4 in-lb (0.45 N-m)
Table 2-4. Component Torque Ratings

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 13
2.6 Cord Grip Connections
Each of the models in the 380/ 380X /381 Synergy Series indicator line utilizes a different cord grip configuration. Cable plugs for
the 380/ 380X are included in the parts kit and must be installed in open cord grips to prevent moisture from entering the
enclosure. Depending on the application, install cables as required. Cord grip plugs for the 381 are already installed. The
recommended cable strip length is 0.25 in (7 mm) for all 380/ 380X /381 connectors.
WARNING: Only connect unit to equipment certified to IEC 60950, IEC 62368, IEC 61010 or similar.
IMPORTANT: Do not have open/bare wires outside of the enclosure. Make sure no stripped portion of cable is on the
outside of the cord grips.
IMPORTANT: Properly seal cord grips to prevent moisture damage inside of the enclosure. Cable plugs must be installed in
unused cord grips. Cord grip dome nuts, around a cable or a plug, must be torqued to 22 in-lb. The cord grip nut against the
enclosure must be torqued to 33 in-lb.
Cable Diameter Ranges
Refer to Table 2-5 for minimum and maximum cable sizes for use with cord grips.
Table 2-5. Allowable Cable Diameter Ranges
2.6.1 380 Cord Grip Connections (PN 202711)
The 380 provides four cord grips at the bottom of the enclosure for cabling into the indicator. One of the cord grips is used for
the load cell and the other three are used to accommodate the serial connection and other future connections. See Figure 2-6
for the recommended assignments for the 380 cord grips.
Figure 2-6. Recommended Cord Grip Assignments
Cord Grip Diameter Range
PG7 (PN 58983) 0.098 - 0.256 in (2.5 - 6.5mm)
PG9 (PN 15626) 0.138 - 0.315 in (3.5 - 8mm)
PG11 (PN 68600) 0.197 - 0.394 in (5 - 10 mm)
Batteries
Cord grips for
communication cables
Power Jack
Cord grip for
load cell cable
Breather Vent

380/380x/381 Synergy Indicator
14 Visit our website www.RiceLake.com
2.6.2 380X Cord Grip Connections (PN 214337)
The 380X provides four cord grips at the bottom of the enclosure for cabling into the indicator. See Figure 2-7 for the
recommended assignments for the 380X cord grips.
Figure 2-7. Recommended Cord Grip Assignments
2.6.3 381-2D-AA Cord Grip Connections (PN 215695)
The 381-2D-AA provides one cord grip, a power jack and an RJ-11 jack at the bottom of the enclosure for cabling into the
indicator. The cord grip is used for the load cell and the other connections are for power and serial connection. See Figure 2-8
for the recommended assignments for the 381-2D-AA connections.
Figure 2-8. Recommended Connection Assignments
Cord grips for
communication cables
Cord Grip for Power
Cord grip for
load cell cable
Breather Vent
Cord grip for
load cell cable
Power Jack
RJ-11 Jack
Battery Door

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 15
2.6.4 381-2D-NiMH Cord Grip Connections (PN 215696)
The 381-2D-NiMH provides two cord grips and two other connections at the bottom of the enclosure for cabling into the
indicator. One of the cord grips is used for the load cell and the other three connections are used to accommodate the serial
connection, the battery charger and other future connections. See Figure 2-9 for the recommended assignments for the 381-
2D-NiMH connections.
WARNING: Only connect unit to equipment certified to IEC 60950, IEC 62368, IEC 61010 or similar.
IMPORTANT: Removal of the RJ-11 cover and the charger cap invalidate the IP rating of the unit.
Figure 2-9. Recommended Connection Assignments
Cord grip for
load cell cable
Battery charger
connector
RJ-11 Serial
connection
cover
Cord grip for
optional
connectivity

380/380x/381 Synergy Indicator
16 Visit our website www.RiceLake.com
2.7 380/380X Cable Shield Grounding
All cables routed through the cord grips on the 380/ 380X must be shield grounded against the grounding rail in the enclosure.
• Use M4 screws provided in the parts kit to install shielding clamps on the grounding rail at the back of the enclosure
• Install only the necessary amount of shielding clamps for the cord grips to be used
• Remove the insulated jackets and shielding per the following instructions
Shielding Procedure
1. Install the shielding clamps on the grounding rail using the clamp screws. Finger tighten the screws at this time.
2. Route the cables through the cord grips and the shielding clamps to determine the cable lengths required to reach the
appropriate cable connectors.
3. Mark cables to remove the insulated jacket as described below for Foil Shielded Cables and Braid Shielded Cables.
Foil Shielded Cables
Figure 2-10. Foil Shielded Cable
1. Strip the insulated jacket and foil 1/2 in (15 mm) past the shielding clamp.
2. Strip another 1/2 in of the insulated jacket, leaving the foil shielding exposed.
3. Fold the foil shielding back on the cable where the cable passes through the clamp.
4. Ensure the silver (conductive) side of the foil is turned outward.
5. Wrap the shield wire around the cable, ensuring it contacts the foil where the cable passes through the clamp.
6. Torque the shielding clamp screw to 10 in-lb (1.1 N-m), ensuring the clamp is around the cable and contacting the
shield wire.
Braid Shielded Cables
Figure 2-11. Braid Shielded Cable
1. Strip the insulated jacket and braided shielding from a point just past the shielding clamp.
2. Strip another 1/2 in (15 mm) of the insulated jacket, leaving the braid exposed where the cable passes through the
clamp.
3. Torque the shielding clamp screw to 10 in-lb (1.1 N-m), ensuring the clamp is contacting the braided shielding of the
cable.
NOTE: The recommended cable strip length is 0.25 in (7 mm) for all 380/380X/381 connectors.
Length of foil before
folding back on
cable insulation
Silver side out
Cut insulated jacket here
for foil shielded cables
Shield wire
Braid
Cut insulated
jacket here

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 17
2.8 CPU Board Connections
Figure 2-12. CPU Board Connections
2.8.1 Load Cell Cable
To attach the cable from a load cell or junction box, route cable to the YC3 connector. See Table 2-6 for wiring the load cell cable
from the load cell or junction box to connector.
NOTE: For a 4-wire installation leave pins 3 and 4 empty on the connector.
NOTE: For a 6-wire installation set SW2 to all positions “off”, for 4-wire installation set all positions to “on.”
2.8.2 380/380X RS-232 Serial Communications
The CN10 connector is intended to provide a connection point for the RS-232 serial communications. One RS-232 port is
available. See Table 2-7 for the pin assignments for the CN10 connector.
NOTE: This connection is available on the outside of the 381 enclosure via an RJ-11 connector and optional
cable (PN 215273). The serial connection can be made directly to the CN10 connector if the RJ-11 connection is not wanted.
Connector Pin Function
YC3 1 +SIG
2 –SIG
3 +SEN
4 –SEN
5 +EXC
6 –EXC
Table 2-6. YC3 Pin Assignments (Load Cell)
Connector Pin RS-232
CN10 1 TX1
2 RX1
3 GND
4 N/A
5 N/A
Table 2-7. CN10 Pin Assignments (RS-232)
+SIG
-SIG
+SEN
MICRO-USB
-SEN
+EXC
-EXC
YC3
SW2
RTC
CN2
CN1
CN4
JP3
CN3
CN10
COM1 - RS-232
COM1
CAL
N/A
N/A
GND
+Vin
CN9
SENSE
N/A N/A
GND
RX
TX
ON
OFF
1 2

380/380x/381 Synergy Indicator
18 Visit our website www.RiceLake.com
2.9 Power Connections
Power is connected to the power supply and the CPU board through the power harness.
2.9.1 380-2D Power Connections
The 380 Synergy Indicator is powered by 4 C-Cell Batteries or an optional 12 V adapter (PN 206433). When the adapter is
inserted into the power jack, indicator power is disconnected from the battery holders and batteries no longer drain. The Power
adapter does not charge the batteries.
NOTE: Optional power adapter (PN 206433) is the only external power source allowed to be used.
NOTE: Ensure that battery covers are screwed finger tight. If covers are not fully secured, the indicator will not function.
Figure 2-13. 380-2D Battery Cell Wiring
Connector Pin Wire Power
CN1 1 Red +Vin
2 Black GND
3 N/A N/A
4 N/A N/A
Table 2-8. CN1 Power Pin Assignments (Power Supply)
Black wire to CN1
Pin 2
Table 2-8
Red wire to CN1
Pin 1
Table 2-8
Black Jumper Wire
Black wire to GND
Red Wire to Pin

Installation
© Rice Lake Weighing Systems ● All Rights Reserved 19
2.9.2 380X-2D Power Connections
The 380X Synergy Indicator is powered by a rechargeable lithium-ion battery and a built in power supply. Power to the CPU
board is routed through the charger board.
Figure 2-14. Battery Cell Wiring
2.9.3 381-2D-AA Power Connections
The 381-2D-AA Synergy Indicator is powered by 4 AA Batteries or an optional 12 V adapter (PN 215734). When the adapter is
inserted into the power jack, indicator power is disconnected from the battery holders and batteries no longer drain. The power
adapter does not charge the batteries.
Figure 2-15. 381-2D-AA Battery Cell Wiring
Charger Board
CPU Board
Li-Ion Battery
J4
1
J2
J3
CN1
1
3
4
1
2
2 2
3
1
2
Power supply
(AC)
LN-V+V
Black wire power
supply -V Pin4 to
charger board J4 - Pin 1
Red Wire to charger
board J2 - Pin 1
Red wire power
supply +V Pin5 to
charger board J4 - Pin 2
Yellow Wire to
charger board
J2 - Pin 2
Black Wire to
charger board
J2 - Pin 3
Red Wire
charger board J3 - Pin 1 to
CPU Board CN1 - Pin 1
Black Wire
charger board J3 - Pin 2 to
CPU Board CN1 - Pin 2
Brown wire AC power to
power supply L - Pin 1
Blue wire AC power to
power supply N - Pin 2
Battery Pack
Black wire to CN1
Pin 2
Table 2-8 on page 18
Red wire to CN1
Pin 1
Table 2-8 on page 18
Red Jumper
Wire
Black wire
to GND
Red Wire to
+ on Battery
Pack
Note: Factory installed power
harness crimps to CN1 at PCB.
When battery is replaced,
connector must also be
replaced to reconnect all wires.

380/380x/381 Synergy Indicator
20 Visit our website www.RiceLake.com
2.9.4 381-2D-NiMH Power Connections
The 381-2D-NiMH Synergy Indicator is powered by a rechargable NiMH battery. The Power adapter (PN 185064) charges the
battery.
IMPORTANT: The 381-2D-NiMH must not be powered on while battery is charging.
Leaving the charger attached to the 381-2D-NiMh while not plugged in will discharge the battery even if the indicator is
powered off.
Figure 2-16. 381-2D-NiMH Battery Cell Wiring
NiMH Battery
CN1 2
14 3
White wire to
CN1 - Pin 2
Brown wire to
CN1 - Pin 1
Red Wire to
CN1 - Pin 1
Black wire to
CN1 - Pin 2
Black wire and
Blue Wire not
used
Note: Factory installed power
harness and battery both crimp to
CN1 at PCB. When battery is
replaced, connector must also be
replaced to reconnect all wires.
