Rice Lake 250-10-4 Series User manual

151863
Bariatric Handrail Scale w/ Seat
250-10-4 Series
Software Revision 11439
Operation Instructions

Contents
1.0 Introduction.................................................................................................................................. 1
2.0 Safety ........................................................................................................................................... 2
2.1 Safety Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.2 Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3.0 Scale Assembly ........................................................................................................................... 3
3.1 Unpacking Your Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Repacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.3 Setting Up Your Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.4 Inserting Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.5 AC Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.0 Scale Operation ........................................................................................................................... 6
4.1 Weighing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Hold/Release Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.3 Preset Tare. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.4 Toggle Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.5 Using the Body Mass Index (BMI) Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.0 RS-232 Communication............................................................................................................... 9
5.1 Pushbutton Keypad Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.2 USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.0 Troubleshooting and Testing ..................................................................................................... 10
7.0 Maintenance .............................................................................................................................. 11
7.1 Basic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8.0 Digital Bariatric Scale Handrail Specifications........................................................................ 12
For More Information ............................................................................................................................. 13
Digital Bariatric Handrail Scale Limited Warranty................................................................................ 14
Technical training seminars are available through Rice Lake Weighing Systems.
Course descriptions and dates can be viewed at www.ricelake.com or obtained
by calling 715-234-9171 and asking for the training department
©2012 Rice Lake Weighing Systems. All rights reserved. Specifications subject to change without notice.
Rice Lake Weighing Systems is an ISO 9001 registered company.
Software revision 11439, November 2012

ii Bariatric Handrail Scale Operation Instructions
Rice Lake continually offers web-based video training on a growing selection
of product-related topics at no cost. Visit www.ricelake.com/webinars.

1
1.0 Introduction
The Rice Lake Digital Bariatric Handrail Scale with fold down seat is designed for weighing bariatrics and
ensures sound, accurate weighing information. A non-skid platform paired with side rails assists persons who
need extra support and safety. The fold down chair allows patients to sit down while being weighed. The scale is
set up to use motion sensing technology, to determine the actual weight of a moving patient. The weight is
displayed on the indicator and can be displayed in pounds or kilograms and has a 1000 lb capacity.
This manual can be viewed and downloaded from the Rice Lake Weighing Systems
web site at www.ricelake.com/health. Technical information on this product and other
medical products are available on the Rice Lake Weighing Systems web site.
Rice Lake Weighing Systems is an ISO 9001 registered company.
Figure 1-1. Digital Bariatric Handrail Scale with Fold Down Chair (250-10-4)
Internet

2Bariatric Handrail Scale Operation Instructions
2.0 Safety
There are certain precautions that should be taken to prevent personal injury to the user and damage to your
scale.
2.1 Safety Signals
Safety Signal Definitions:
Indicates an imminently hazardous situation that, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation that, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation that, if not avoided, may result in minor or
moderate injury.
Indicates information about procedures that, if not observed, could result in damage to
equipment.
2.2 Safety Precautions
Do not operate or work on this equipment unless you have read and understand
instructions in the manual. Failure to follow the instructions or heed the warnings could
result in injury or death. Contact any Rice Lake Weighing Systems dealer for replacement
manuals. Proper care is your responsibility.
Before attempting to operate this unit, make sure every individual who operates or works
with this unit has read and understands the following safety information. Please follow
these instructions carefully.
• Do not drop the scale or subject it to violent shocks.
• For accurate weighing, the scale must be placed on a flat, stable surface.
• Do not transport the scale while someone is standing on it.
• Weight exceeding the maximum capacity (1000 lb/453 kg) may damage your scale.
• Operating at voltages and frequencies other than specified could damage the equipment.
• If the LO Bat indicator activates, for accurate weighing, replace the batteries or connect the scale to an AC
power source as soon as possible.
• To avoid cross contamination, the scale should be cleaned regularly.
• Avoid contact with excessive moisture.
• Do not allow minors (children) or inexperienced persons to operate this scale.
• Do not jump up and down on the scale.
• Do not use in the presence of flammable materials.
• Do not make alterations or modifications to the scale.
• People with disabilities, or who are physically frail, should always be assisted by another person when
using this scale.
• Do not use the scale on slippery surfaces, such as a wet floor.
• Do not use this scale when your body/feet are wet, such as after taking a bath.
DANGER
Warning
Caution
Important
Warning

Bariatric Handrail Scale Operation Instructions - Scale Assembly 3
3.0 Scale Assembly
3.1 Unpacking Your Scale
Place the unopened box in an open area that has ample room for unpacking the scale.
Parts contained in the shipping box include:
• The scale
• This manual
• Six AA batteries
• 6 mm Allen Key
3.2 Repacking
If the Digital Bariatric Handrail Scale must be returned for modification, calibration or repair, it must be properly
packed with sufficient packing materials. Whenever possible, use original carton when shipping the scale back.
Damage caused by improper packaging is not covered by the warranty.
3.3 Setting Up Your Scale
Use the following steps to set up the Digital Bariatric Handrail Scale with seat.
1. Locate the manual from inside the box and set aside as it will provide instructions on the proper scale
removal and set up.
2. Move the scale into the area where the weighing process will occur. It’s recommended to place the scale
on a hard, level surface for the most accurate weighments. Thin carpeting is fine but not recommended.
3. Using two people, remove the scale out of the packaging material that it came in by lifting the scale out
of the box by the scale base.
DO NOT lift the scale out of the box by its handle as this can cause the hinges to break.
4. Gently set the scale platform down to the floor.
5. Loosen the handles and unfold and set upright (handles shown in Figure 3-1).
6. Tighten the two hinges on the scale by rotating the two handles. This will secure the handrail mounted
indicator.
Figure 3-1. Secure the Handrail by Tightening the Durable Hinges
7. Screw in all four legs.
8. Attach the wrap around rails.
9. Tighten the hex screw head using the enclosed 6 mm Allen key to stabilize the scale.
Important
Note

4Bariatric Handrail Scale Operation Instructions
Adjusting the Scale Feet
There must be adequate clearance between the scale base and the floor so screw each foot out counterclockwise
two full turns. This will ensure that there is enough clearance between the scale base and the floor.
Gently set the scale base down to the floor. There should be minimal clearance between the scale base and the
floor without having the scale base actually touching the floor. By not having clearance around the scale base
will cause inaccurate weighments.
It’s also important to make sure that the scale is completely level. Gently press down on all corners of the scale
base to ensure that there are no high spots or rocking of the scale base.
Unfold Platform Seat
The Digital Bariatric Handrail Scale comes with a fold down seat for those patients who need to be weighed
while seated. To unfold the seat, simply pull down on the seat bottom as shown in Figure 3-2.
Figure 3-2. Unfolding the Seat

Bariatric Handrail Scale Operation Instructions - Scale Assembly 5
3.4 Inserting Batteries
The six AA batteries that come with the scale offer an average of 25 hours of continuous use. To install the
batteries:
1. Open the battery chamber cover by loosening the thumbscrew.
2. Insert batteries into the battery chamber as shown in Figure 3-3.
Figure 3-3. Battery Chamber
3. Close the battery chamber.
If an external power supply or USB power supply is connected, the battery flag on the display is turned off.
When using battery or USB power supply, the backlight power is deducted to 60%.
3.5 AC Power Connections
Use the optional 120 VAC or 230 VAC adaptor when power is available. The AC power adaptor plugs into the
back of the indicator as shown in Figure 3-4. .
Figure 3-4. Power Connection
Connect the
optional AC
power source
here.

6Bariatric Handrail Scale Operation Instructions
4.0 Scale Operation
The Rice Lake Digital Bariatric Handrail Scale with seat display has various front panel keys as shown in
Figure 4-1.
Figure 4-1. Front Panel Display Keys
Key Descriptions
Table 4-1 describes each of the key functions.
Key Name Function
On/Off Switches the scale on or off.
Print
LB/KG
Print — A long key press will send data out from the RS-232 port.
LB/KG — A short key press allows the user to toggle between kilograms
and pounds providing that it’s enabled in configuration mode.
There is no toggling while in the BMI mode.
Zero Clears the weight off the scale and returns it to zero after three seconds.
It works only if the current weight is stable and zero up to 2% of full weight.
Hold
Release
Hold & Release — The first press holds the most current weight value shown
on the display.
A second press releases the weight value shown.
This key is not active while in BMI mode.
BMI Enables the user to access the BMI (Body Mass Index) function. This key
only works if there is a locked weight shown on the display and the BMI
function is turned on in the configuration mode.
TARE Used to subtract the weight off the scale, example: oxygen tank, other
equipment.
CLEAR Allows the user to return to normal weighing when the BMI value is being
displayed.
While in BMI mode, the height display causes the value to return to the
default of 190.0 cm, 5 ft, 7.5 in.
Table 4-1. Rice Lake Digital Bariatric Handrail Scale Key Functions
On/Off
LB/KG
Print
Zero
Hold
Release
BMI
TARE
T
CLEAR
