Ricoh GR-C1 Series Manual

1
GR-C1 Training
Slide 1
D117/D118
Service Training
GR-C1
Version 1.0
This training course provides service technician training for the GR-C1 series
copiers.

2
GR-C1 Training
Slide 2
D117/D118
Service Training
Product Overview
This section provides an overview of the machine, and the options that can be
installed.

3
GR-C1 Training
Slide 3
MT-C4
60-90 ppm
Al-C1.5
40-50 ppm
R-C5.5
28-33 ppm
PR-C1
25ppm
A3 MFP
A3 MFP A4 MFP
A4 MFP
V-C3
60-75 ppm
AP-C2.5
45-55 ppm
AT-C2.5
30-35 ppm
Di-C1.5
20–25 ppm
A3 MFP
A3 MFP A4 MFP
A4 MFP
Black and White Full Color
K-C3.1
15-21 ppm
２
Rn-MF1
28ppm
S-C4.5
20ppm
Panache-MF2
20ppm
PE-MF2
20ppm
Sh-MF1
45-55ppm
Z-C1
30-40ppm GR
GR- -C1 C1
A4
A4 color color
desktop
desktop
Desktop
Desktop
Floor
Floor Desktop
Desktop
Floor
Floor
Position in the Product Lineup
The GR-C1 fills this empty slot in the product lineup.
It is a successor to the S-series and K-series black-and white copiers, to try to
get customers to change over to color.
PE-MF2 is user maintenance, but GR-C1 is maintained by techicians.

4
GR-C1 Training
Slide 4
What Models are there in the Series?
GR-C1 SPF (D117): Aficio MP C305SPF
30 cpm (full color/black-and-white)
Contains a fax unit as standard equipment
GR-C1 SP (D118): Aficio MP C305SP
30 cpm (full color/black-and-white)
Fax is available as an option
ARDF: Standard for all models except the EU and China
versions of D118
All models contain a duplex unit and a bypass tray as
standard equipment.
All models contain scanner and printer kits as standard
equipment
A hard disk is not included (an optional hard disk is
available).
The GW+ controller is used.
SPF: Scanner, Printer, Fax
SP: Scanner, Printer

5
GR-C1 Training
Slide 5
Appearance
In addition to the above, up to two optional paper tray units can
be installed below the main unit.
One-bin tray: This is the first time that a one-bin tray has been
offered as an option for an A4 desktop MFP series.
There are no optional or built-in finishers.
ARDF
Standard (except
EU and China
versions of the
Standard model)
One paper tray is
standard
Optional one-bin
tray
Duplex and bypass are
standard
Color LCD Touch
panel
For Europe standard model, the ARDF or a platen cover are available as
options.
One-bin tray: This is the first time that a one-bin tray has been offered as an
option for an A4 desktop MFP series.

6
GR-C1 Training
Slide 6
Machine Layout
Toner Bottles
Image Transfer
Belt Unit (ITB)
Fusing Unit
Duplex Path
Paper Transfer
Roller (PTR)
ID Sensor
ITB Cleaning
Unit
PDCU
(Photoconductor and
Development Unit)
Laser Units and
Polygon Mirrors
Just a quick look – more detail later.

7
GR-C1 Training
Slide 7
Operation Panel - 1
A 4.3” color touch panel is included.
A home button is added. You can return to the home
screen from anywhere.
Three function keys are available, to which you can assign
your own designated functions.
An SD/USB slot is built-into the right side of the panel as
standard equipment (not an optional unit).
Home Button
Function
Keys
SD/USB Slot
Touch Panel
SP5074 can be used to customize the application that appears when the Home
button is pressed.
Function keys:
¾Nothing is assigned when the machine leaves the factory.
¾If the browser unit is installed, a URL can be assigned to a function key.

8
GR-C1 Training
Slide 8
Operation Panel - 2
Status key: When the error lamp lights, press this key. The machine
displays a list that shows the status of all jobs
Energy saver key: There is no operation panel power button, only this
energy saver button. Press this once, and the machine goes to the energy
saver mode.
To cut the power, turn of the main switch; the machine goes into the safe
shutdown process.
Energy saver lamp: Blinks slowly when the machine is in energy saver
mode. Stays off when the machine is in normal operation mode (full
power).
Stop key: For the GW+ controller, this button can be used to stop all types
of jobs, including printer, fax, etc.
With the old GW controller, this button can only be used to stop copy jobs.
Energy Saver
Key and Lamp
Status Key and
Error Lamp
No additional notes

9
GR-C1 Training
Slide 9
Operation Panel - 3
The angle of the operation panel can be changed.
No additional notes

10
GR-C1 Training
Slide 10
Options: Original Feed
S-C5NewPlaten cover (D607):
Platen Cover PN1010
D118 Europe/China: The
customer must buy one
of these.
S-C5NewARDF (D606): DF1030
Also used with these
new models: NoteSimilar to:
These are only options for the RE and China versions of the D118. All other
models have an ARDF as standard equipment.

11
GR-C1 Training
Slide 11
Options: Paper Feed and Finishing
Also used with these
new models:
NewOne-bin tray (D574):
BN1010
Up to two of these can
be installed below the
main unit
NewOne-tray paper feed unit
(D573): PB1050
NoteSimilar to:
No additional notes

12
GR-C1 Training
Slide 12
Options: Fax
For the Remote Fax
feature (new function)
This unit will not be
released at the same
time as the GR-C1.
NewD657: Fax Connection
Unit Type D
AT-C3, AP-C3, S-C5D645: Handset Type
C5502
Also used with these
new models:
Option for D118,
standard for D117
NewD649: Fax Option Type
C305
NoteSimilar to:
No additional notes

13
GR-C1 Training
Slide 13
Options: Controller
NewD656: HDD Option Type
C305
OR-C1, AL-C2, AT-C3D377: File Format
Converter Type E
NewD656: VM Card Type T
AT-C3NewD658: Camera Direct Print
Card Type K
AT-C3NewD656: SD card for NetWare
printing Type J
Not supported for
China/Taiwan
OR-C1, AL-C2, AT-C3D377: IEEE 802.11a/g
Interface Unit Type J
OR-C1, AL-C2, AT-C3
OR-C1, AL-C2, AT-C3
OR-C1, AL-C2, AT-C3
OR-C1, AL-C2, AT-C3
Also used with these
new models:
NewD656: Browser Unit Type H
G874: Gigabit Ethernet
Board Type A
D377: IEEE 802.11g
Interface Unit Type K
Not supported for
China/Taiwan
B679: IEEE 1284 Interface
Board Type A
New type, uses USB
Not supported for
China/Taiwan
N/ANewD566: Bluetooth Interface
Unit Type D
NoteSimilar to:
PostScript3 is standard.
There is no IPDS.

14
GR-C1 Training
Slide 14
Options: Other
OR-C1, AL-C2, AT-C3
OR-C1, AL-C2, AT-C3
Also used with these
new models:
HDD is not requiredB829: Copy Data
Security Unit Type F
B870: Optional Counter
Interface Unit Type A
NoteSimilar to:
No additional notes

15
GR-C1 Training
Slide 15
Controller Options
Memory Upgrade Options
There are no memory upgrades.
Also no fax memory upgrade option.

16
GR-C1 Training
Slide 16
Controller Options
Fax Unit
In this fax unit, the FCU and MBU boards have
been combined. Because of this, the data backup
procedure has been changed.
The FCU contains the ROM, SRAM and NCU
circuits.
Options for fax:
Handset (for the USA): This is a new model.
There is no optional memory.
There is no optional extra G3 interface unit.
Fax Connection Unit: This is needed for the
Remote Fax function.
No additional notes

17
GR-C1 Training
Slide 17
Slots
Slot A is used for one of
the following: IEEE1284,
IEEE802.11a/g g (Wireless
LAN), File Format
Converter, Gigabit
Ethernet
Slot B is used for the
Bluetooth unit or the
external USB keyboard.
SD card slots [1, 2]: See
the next few slides.
Caution: Do not remove
the Bluetooth unit while
the machine power is on.
The SD Card slots are discussed in more detail on the next few slides.
The Bluetooth interface unit and the Wireless LAN interface unit cannot be used
simultaneously.

18
GR-C1 Training
Slide 18
SD Card Slots (1)
Slot 1 (upper slot) can be used for the following:
Empty when shipped
Use when installing the following options
»VMcard
» PictBridge
» Browser unit
» SD card for Netware printing
There is no App2Me for this model.

19
GR-C1 Training
Slide 19
SD Card Slots (2)
Slot 2 (lower slot)
Empty when shipped
Use this slot for service procedures, such as
firmware update and NVRAM backup.
No additional notes

20
GR-C1 Training
Slide 20
SD Card Slots (3)
Operation panel SD card slot
Use this for SMC data export (SP5992). The
service slot does not support this function.
PDF direct print from SD card
SMC data export is a feature that was added for the GW+ controller.
