D096
1
RicohCo.Ltd.http://www.ricoh.com/
Slide 1
D096
Service Training
Introduction
Uploaded November 17th, 2009

D096
2
RicohCo.Ltd.http://www.ricoh.com/
Slide 2
Introduction
Product Concept
Low cost
Simple operation
Appearance
New Blue Internal Exit Tray
Compared to B245
Faster printing speed
» B245: 15cpm
» D096: 19cpm
Faster warm-up
» B245: Less than 15 seconds
» D096: Less than 10 seconds
Languages added (for EU model)
» Turkish
» Catalan
.

D096
3
RicohCo.Ltd.http://www.ricoh.com/
Slide 3
D096
Service Training
1) Product Outline
.

D096
4
RicohCo.Ltd.http://www.ricoh.com/
Slide 4
The Machine
This is the machine
you will study in this
training course. Note
the following:
Paper tray
Bypass tray
» On right side of
machine
– See next slide
Operation panel
ADF (optional)
.

D096
5
RicohCo.Ltd.http://www.ricoh.com/
Slide 5
Bypass Tray
By-pass Tray
.

D096
6
RicohCo.Ltd.http://www.ricoh.com/
Slide 6
Operation Panel
Start
Error
Load Paper
Add Toner Display Selection Scroll Clear/
Stop
Main Power
Indicator
Operation
Switch
# key
Escape
Lighter/
Darker
Sort Number
Keys
OK
Original
Type
Clear
Modes
User Tools/
Counter
.

D096
7
RicohCo.Ltd.http://www.ricoh.com/
Slide 7
External
Part Names
Paper Tray
Front Cover
Operation Panel
Main Power Indicator
Main Power Switch
Internal Tray
Internal Tray
Exposure Glass
Platen Cover/
ADF (optional)
Operation Switch
"Operation Switch" refers to the Operation Panel Power Switch.

D096
8
RicohCo.Ltd.http://www.ricoh.com/
Slide 8
Optional Units
Platen Cover
B406
» See following slide
ADF
B813
» See following slide
Accessibility Handle, Type-A
B272
.

D096
9
RicohCo.Ltd.http://www.ricoh.com/
Slide 9
Platen Cover & ADF (Optional)
Platen Cover - B406
ADF (Automatic Document Feeder) - B813
Main Unit - D096
.

D096
10
RicohCo.Ltd.http://www.ricoh.com/
Slide 10
D096
Service Training
2) Specifications
.

D096
11
RicohCo.Ltd.http://www.ricoh.com/
Slide 11
Specifications
Configuration
Desktop
Copy process
Dry electrostatic transfer system
Zoom
50% to 200% in 1% steps
Power Consumption
Full system
» Less than 1.28 kW
Reduced Electrical Consumption via Lower Power mode
» Less than 1 W.
See Energy Saver Modes for more details.
Print speed
19cpm (platen mode)
18cpm (ADF)
Warm-up
Less than 20 seconds
.

D096
12
RicohCo.Ltd.http://www.ricoh.com/
Slide 12
D096
Service Training
3) Installation
.

D096
13
RicohCo.Ltd.http://www.ricoh.com/
Slide 13
Install the Copier
Procedure: Copier Installation (see service manual)
Developer Initialization must be performed via SP-2214-1
After installing machine & all options, and making all test
copies, record value of total counter.
» This is very important, because this value will be used for billing
with Meter Click contracts.
» Also, inform customer of value along with reason why counter
does not start from zero.
– Do not set to zero.
.

D096
14
RicohCo.Ltd.http://www.ricoh.com/
Slide 14
Putting in Developer
Make only a small cut in top corner of bag for better control when pouring.
Make sure not to spill developer on the gears.
If you have to turn the gears to distribute developer evenly, make sure to do so
very slowly and as little as possible. Otherwise developer may spill.
After pouring in developer, initialize it with SP-2214-1.
.

D096
15
RicohCo.Ltd.http://www.ricoh.com/
Slide 15
Installation Options
Regarding Platen Cover and ADF - only one of these
options can be installed at a time.
Platen Cover Installation (see service manual)
ADF Installation (see service manual)
.

D096
16
RicohCo.Ltd.http://www.ricoh.com/
Slide 16
D096
Service Training
4) Machine Overview
.

D096
17
RicohCo.Ltd.http://www.ricoh.com/
Slide 17
Mechanical Components Layout
2nd Mirror Exposure
Lamp
1st Mirror
3rd Mirror
Exposure Glass
Lens Block
SBU
Scanner
HP Sensor
Scanner
Motor
Exit Sensor
Exit Roller
Hot Roller
Toner Supply Bottle Holder
OPC Drum
Image Density Sensor
Registration Sensor
By-pass Feed Roller
By-pass Tray
Laser Unit
Polygon
Mirror
Motor
WTL
Development Roller
Paper End Sensor Paper Feed Roller Friction Pad
Pressure Roller
Registration Roller
.

D096
18
RicohCo.Ltd.http://www.ricoh.com/
Slide 18
Paper Path
ADF Original Feed
Paper feed
from Tray 1
Paper feed from
By-pass Tray
.

D096
19
RicohCo.Ltd.http://www.ricoh.com/
Slide 19
Main motor drives
fusing unit, PCU and
development unit.
PCU
Scanner Motor
Hot Roller
Development roller
OPC Drum
Drive Layout
Fusing Unit
Development Unit
.

D096
20
RicohCo.Ltd.http://www.ricoh.com/
Slide 20
Copy Process
Development
Laser exposure
Drum charge
Cleaning
Image transfer
Paper separation
.
