Riello UPS CSS SENTINEL TOWER CAM 3 User manual

- 1 -
INTRODUCTION
Congratulations on purchasing a CSS Sentinel Tower product and welcome to Riello UPS! To use the support service offered
by Riello UPS, visit the site www.riello-ups.com
Our Company is a specialist in the design, development and manufacturing of uninterruptible power supplies (UPS).
The CPS described in this manual is a high quality product which has been carefully designed and built in order to guarantee
the highest levels of performance.
This device can be installed by anyone on the condition that they have READ THIS INSTALLTION AND USER MANUAL
CAREFULLY.
The CPS and the Battery Cabinet generate DANGEROUS internal electrical voltages. All maintenance operations must
be carried out by suitably qualified operators.
This manual contains detailed instructions for using and installing the CPS and any additional Battery Cabinet.
For information on how to use and maximise the performance of your device, please retain this manual and read it
carefully before operating the equipment.
ENVIRONMENTAL PROTECTION
In the development of its products, the company devotes abundant resources to analysing the environmental aspects.
All our products pursue the objectives defined in the environmental management system developed by the company in
compliance with applicable standards.
No hazardous materials such as CFCs, HCFCs or asbestos are used in this product.
When evaluating packaging, the choice of material has been made favouring recyclable materials.
For correct disposal, please separate and identify the type of material of which the packaging is made according to the table
below. Dispose of all material in compliance with applicable standards in the country in which the product is used.
DESCRIPTION MATERIAL
Box Cardboard
Packaging corner Cardboard
Protective bag Polythene
Accessories bag Polythene
Pallet Heat-treated pine
DISPOSING OF THE PRODUCT
The CPS and the Battery Cabinet contain electronic internal material that (in case of dismiss / disposal) are considered TOXIC
and HAZARDOUS WASTE, such as electronic circuit boards and batteries. Treat these materials according to the laws
applicable referring to qualified service personnel. Their proper disposal contributes to respect the environment and human
health.
© The reproduction of any part of this manual, in whole or in part, is forbidden without the prior consent of the manufacturer.
In order to make improvements, the manufacturer reserves the right to modify the product described at any moment and without notice.

- 2 -
CONTENTS
PRESENTATION 5
CPS VIEWS 6
FRONT VIEW 6
REAR VIEW 7
DISPLAY PANEL VIEW 8
BATTERY CABINET (OPTIONAL) 9
BATTERIES 9
INSTALLATION 10
INITIAL CONTENT CHECK 10
REMOVAL FROM THE PALLET 11
INSTALLATION ENVIRONMENT 13
PLACEMENT 13
POWER CONNECTION 14
INSTRUCTIONS FOR CONNECTION 14
INTERNAL PROTECTION 15
EXTERNAL PROTECTIVE DEVICES 16
CONNECTION CABLES CROSS SECTION DETAILS 16
CONNECTIONS 17
OTHER INSTALLATION MODES 17
BATTERY CABINET INSTALLATION 18
CPS –BATTERY CABINET CONNECTION 18
CONFIGURING THE RATED BATTERY CAPACITY 18
USE 19
SWITCHING ON FOR THE FIRST TIME 19
SWITCHING ON FROM THE MAINS 19
SWITCHING ON FROM THE BATTERY 19
SWITCHING OFF THE CPS 19
INTERNAL CLOCK SETTING 19
DISPLAY PANEL MESSAGES 20
CPS STATUS MESSAGES 20
MEASUREMENT DISPLAY AREA 21
OPERATING MODE CONFIGURATION 22
POSSIBLE SETTINGS 22

- 3 -
ADDITIONAL FUNCTIONS 22
EXTERNAL BATTERY CAPACITY CONFIGURATION 22
MANUAL BYPASS 23
MAINTENANCE BYPASS (SWMB) 23
PROGRAMMABLE AUXILIARY SOCKETS (ENERGYSHARE) 23
REMOTE COMMANDS TERMINAL BOARD AND R.E.P.O. 24
AUTORESTART 24
REDUNDANT AUXILIARY POWER ADAPTER FOR AUTOMATIC BYPASS 24
EXTERNAL TEMPERATURE PROBE 24
SOFTWARE 25
MONITORING AND CONTROL SOFTWARE 25
CONFIGURATION SOFTWARE 25
CPS CONFIGURATION 26
COMMUNICATION PORTS 28
CONFIGURATION FOR OUTPUT SIGNALS (FACTORY DEFAULT) 28
COMMUNICATION SLOT 28
TROUBLESHOOTING 29
STATUS /ALARM CODES 33
TECHNICAL DATA 35
MECHANICAL DIMENSION 36

- 4 -

- 5 -
PRESENTATION
The CSS SENTINEL TOWER developed by Riello UPS utilises ON-LINE double conversion technology, classified as VFI-SS-
111 according to standard IEC EN 62040-3.
The CSS SENTINEL TOWER consists of transformerless CPS units with single phase input and output available in versions
3000 and 5000 VA/W.
CPS are equipment designed especially for use in buildings subject to fire safety regulations, their main objective is to supply
safety lighting systems in case of power failure, but they are also used to supply:
 electric circuits supplying automatic fire extinguishing systems;
 paging systems and signaling security systems;
 fume extraction equipment;
 carbon monoxide alarm systems;
 special security systems in relation to specific properties, for example high risk areas.
CPS view and CPS with side-by-side BATTERY CABINET

- 6 -
CPS VIEWS
FRONT VIEW
All models
Display panel
Removable front panel
Ventilation grill

- 7 -
REAR VIEW
All models
Battery expansion connector
Remote commands terminal
Cooling fan
EnergyShare sockets (10A max) and overcurrent
protection
Parallel card (optional) Mains input switch (SWIN)
Slot for optional accessory communication
cards and contacts cards Manual bypass switch (SWMB)
USB communication port Output switch (SWOUT)
Dry contact outputs Terminals cover panel

- 8 -
DISPLAY PANEL VIEW
“ON” button Input phase indicator
“SEL1” button Measurement display area
“SEL2” button Timer
“STAND-BY” button Battery charge indicator
Regular operation Configuration area
Mains operation Maintenance request
Battery operation Load level indicator
Load powered by bypass Parallel mode indicator
Stand-by / alarm EnergyShare

- 9 -
BATTERY CABINET (OPTIONAL)
The BATTERY CABINET, with the same dimensions and aesthetic appearance of the CPS, is an optional accessory.
The BATTERY CABINET contains batteries which allow the operating time of the uninterruptible power supplies to be increased
during extended blackouts. The number of batteries contained can vary according to the type of CPS for which the BATTERY
CABINET is intended. It is therefore necessary to take great care to ensure that the battery voltage of the BATTERY CABINET
is the same as the voltage permitted by the CPS.
Several BATTERY CABINETS can be connected in series to achieve a longer extended runtime.
Front view Rear view
Internal battery fuse holder isolator
Battery expansion connector
BATTERIES
EN 50171 norm requires the batteries to be compliant to EN60896-2 and to have 10 years estimated service life at an ambient
temperature of 20°C.

- 10 -
INSTALLATION
INITIAL CONTENT CHECK
After opening the packaging, it is first necessary to check the contents.
The CPS package must contain:
CPS Safety manual + Quick start guide + Download card
USB cable Warning labels against backfeed
After opening the packaging, it is first necessary to check the contents.
The Battery Cabinet (optional) package must contain:
BATTERY CABINET Safety manual + Quick start guide
Fuses Connection cable CPS - Battery Cabinet

- 11 -
REMOVAL FROM THE PALLET
This chapter describes the operations to remove the product from the pallet and prepare it for installation.
1. Cut the straps and open the cardboard box.
2. Remove the packaging and the accessory box located
above the product.
3. Remove the cardboard box by sliding it
upwards and remove the corner supports.
4. Remove the protective sack.
5. Remove the 4 fixing brackets from the pallet; each bracket is fixed to the pallet by 2 screws.
FRONT VIEW REAR VIEW

- 12 -
6. Move the brackets upwards and rotate for releasing them from the retaining bushing.
Follow the instructions below to remove the fixing brackets without releasing the front panel (*).
7. Remove the 4 fixing screws of the
frontal wooden beam of the pallet.
8. Remove the end wooden support,
and ensure that the product is held
stable during this process .
9. Guide the product towards the front of
the pallet with caution; the pallet will
begin to tilt down acting as a ramp;
continue to move the product down off
the pallet.
(*) If it will be difficult to remove the brackets, unhook the front panel pulling it from the edges; the front panel is hooked with a
system of pins and springs, tools are not needed.

- 13 -
INSTALLATION ENVIRONMENT
The CPS and the Battery Cabinet must be installed in ventilated, clean environments which are sheltered from bad weather.
The ambient temperature and relative humidity must not exceed the maximum values shown in the "TECHNICAL DATA” table.
Avoid installation in locations exposed to direct sunlight or hot air.
The recommended operating temperature for the product with the batteries is between 20 and 25°C.
Warning: an ambient temperature increase of 10 degrees will half the batteries expected life.
The CPS of category C2 if installed in a residential environment may cause radio interference, in which case
the user may be required to take additional measures.
For three-phase installation, this equipment complies with IEC 61000-3-12 provided that the short-circuit power
Ssc is greater than or equal to 2.94MW (7.4kA) at the interface point between the user's supply and the public
system. It is responsibility of the installer or the user to ensure that the equipment is connected to a supply with
the adequate short-circuit power Ssc (if required, consult the distribution network operator).
If the supply doesn’t meet the above requirements or if the requirements listed above are difficult to obtain, a
single-phase installation is suggested.
PLACEMENT
When installing the equipment, the following points should be considered:
 the wheels are to be used exclusively for fine positioning, and thus for small distances only.
 the plastic parts and the front panel are not to be used for gripping or pushing.
 enough space should be left in front of the equipment for it to be turned on/off and maintenance operations to be
performed on it (1.5 m)
 the rear part should be set at least 30 cm from the wall, to enable the air blown by the ventilation fans to flow away
correctly and to allow access to the disconnector switches
 no objects should be left on its top surface
 check that the room containing the batteries is ventilated in compliance with EN 50272-2 paragraph 8.2

- 14 -
POWER CONNECTION
ATTENTION: BEFORE PROCEDING WITH THE FOLLOWING OPERATIONS, MAKE SURE THAT THE CPS
IS COMPLETELY OFF AND DISCONNECTED FROM THE MAINS AND ANY LOAD.
ALL OPERATIONS DESCRIBED IN THIS SECTION MUST BE PERFORMED BY QUALIFIED PERSONNEL
ONLY. Our Company assumes no liability for damages caused by incorrect connections or operations
not contained in this manual.
The CPS and the Battery Cabinet contains HAZARDOUS electrical voltages inside them, even when the
input and/or battery switches are off. The internal parts are protected by safety panels which can be
removed by trained personnel only. All installation and maintenance or operations involving access
inside the CPS or Battery Cabinet require the use of tools and may ONLY be performed by trained
personnel.
To carry out the following operations, the CPS must be disconnected from the mains power supply,
switched off, and with all the equipment switches and fuse holders open. Check that there are no Battery
Cabinets connected to the CPS, if this is the case open all their fuse holders.
INSTRUCTIONS FOR CONNECTION
Follow the instruction below to access the terminals of the CPS and made the electrical connections:
1. Remove the terminals cover in the back of the CPS,
placed below the disconnector switches (see "CPS
VIEWS")
2. Pierce the rubber grommets to allow the wires to
pass through, otherwise remove the pre-cut slots
(located in the bottom part of the terminal cover)
using cutters.
3. We recommend using double-insulated multi-core
cables to be connected, respectively, to the “INPUT”
and “OUTPUT”.
4. For the cross section and the cable stripping, refer
to the paragraph "CONNECTION CABLES CROSS
SECTION DETAILS
5. The wires should be stripped and inserted into the
terminals (for the length of the stripping, refer to the
paragraph “CONNECTION CABLES CROSS SECTION
DETAILS”).
NOTE: To remove the wire, insert a flat blade
screwdriver into the clamp slot above the wire inlet.
6. Fix the cables to the ties block in the back of the
CPS.
7. When the installation is complete, close the
terminals cover and secure with the screws
Option with cable glands (not supplied):
Cable glands (not supplied) can be used to secure the cables, using the pre-cut holes in the terminal cover; refer to the example
images below. To remove the pre-cut disks use a suitable pair of cutters.

- 15 -
INTERNAL PROTECTION
Within the cabinet there are fuses (not accessible) in order to protect the rectifier input stage, the output stage of the inverter
and the batteries. The table below shows the values of the internal protection fuses.
NOTE: the CPS internal bypass line is not protected by fuses. We recommend installing an external protection device as
defined in the chapter “EXTERNAL PROTECTION DEVICES”.
Internal protective devices
Model Input fuses Battery fuses Output fuses
3 kVA 2 x 25A GF (6.3x32) 80A aR 2 x 25A GF (6.3x32)
5 kVA 2 x 25A GF (6.3x32) 80A aR 2 x 25A GF (6.3x32)
WARNING: To insulate the CPS from the D.C. supply, disconnect all of the Battery Cabinets (if present).
SHORT CIRCUIT
If a fault occurs on the load, the CPS protects itself by limiting the value and the duration of the current supplied (short circuit
current). The short circuit current value is related to the CPS operating status at the time of the fault, these can either be (in
the "TECHNICAL DATA” table the protection characteristics and timings are described):
 CPS in NORMAL OPERATION with the Bypass Line available: the load is switched instantaneously to the bypass
line: the input line is connected to the output without any internal protection.
 CPS in BATTERY OPERATION or in NORMAL OPERATION but with no Bypass Line available: the CPS protects
itself by providing a higher current than the nominal one (see paragraph “TECHNICAL DATA”) and turns itself off after
this time has elapsed.
NOTE FOR SELECTIVITY: if the load is made up of more than one device, to avoid the opening of the protective devices
upstream of the CPS due to a failure of a single piece of equipment, it is recommended to protect each output line with a
suitably rated thermal or magnetothermal protection device. The maximum value for the protective device of each single line
must be lower than the current threshold of the protection upstream of the CPS and lower than the current supplied by the CPS
with the inverter on.
BACKFEED
The CPS has internal protection against backfeed, however the label supplied with the CPS must be affixed to all disconnectors
installed within the electrical system upstream of the CPS.

- 16 -
EXTERNAL PROTECTIVE DEVICES
LINE PROTECTION: MAGNETOTHERMAL OR FUSE
Within the CPS there are protection devices for output and internal faults.
You must protect the input line (and the separate bypass line if present) with the appropriate protection devices. These devices
must comply with the regulations of the country where the CPS is installed.
In order to set up the power line, install a magnetothermal switch upstream from the CPS with intervention curve C or D
(breaking capacity ≥6kA) or gR type fuse. Please follow the indications in the table below:
Automatic external protective devices
Model Mains single-phase input (1P+N)
3 kVA 20A (Max 40A)
5 kVA 32A (Max 40A)
SAFETY DEVICES: DIFFERENTIAL
The CPS can cause a D.C. current in the PE conductor.
An RCD located upstream is suggested: its trip current should be the sum of CPS + Load leakage current, with a
suitable margin to prevent unwanted interventions.
Only a RCD Type B is allowed.
CONNECTION CABLES CROSS SECTION DETAILS
To determine the minimum cross section of the input and output cables, see the table below:
Cross section of cables (sqmm) *
Model
INPUT OUTPUT
N L N L
3 kVA 10 4 (10 max) 4 (10 max)
5 kVA 10 6 (10 max) 6 (10 max)
* The cross sections indicated in the table refer to a maximum length of 10 meters.
The cross sections refer to bare cables (without terminals).
Note: the length of the cable stripping must be equal to 15mm

- 17 -
CONNECTIONS
The first wire to be connected is the protective earth wire, which is to be inserted in the terminal marked
PE. During operation the CPS must be connected to the earthing system
Connect the cables to the terminals following the information provided on the label placed upon the CPS. In the images below
there are some notes in relation to the installation:
Models 3-5 kVA
NOTE
1. If an "external manual bypass" is not provided, make sure that there is a jumper between terminals 1 - 2 (Switch bypass).
2. The maximum cross section of the cables that may be inserted in the terminal board 1, 2, 3 & 4 are:
- 2.5 sqmm for bare cables
- 1.5 sqmm for cables with lugs.
The stripping length is 8 mm
WARNING! Pay attention to connect the input neutral (NIN) and output neutral (NOUT); incorrect connection could
cause a failure of the load when the Maintenance Bypass switch is closed.
OTHER INSTALLATION MODES
For more information regarding the parallel installation of the CPS, isolation transformers, accessories for maintenance Bypass
and others, consult the website www.riello-ups.com.

- 18 -
BATTERY CABINET INSTALLATION
ATTENTION:
REFER TO THE CPS SPECIFICATION LABEL TO CONFIRM THAT THE VOLTAGE FROM THE BATTERY
CABINET IS THE SAME AS THAT ALLOWED BY THE CPS.
CONFIRM THAT THE BATTERY CABINET IS EQUIPPED WITH A 50A gR FUSE TO PROTECT THE
BATTERY EXPANSION PORT OF THE CPS.
THE CONNECTION BETWEEN THE CPS AND THE BATTERY CABINET MUST BE MADE WITH THE
BATTERY CABINET FUSE HOLDER ISOLATOR OPEN.
CONNECT THE CABLE BETWEEN THE CPS AND THE BATTERY CABINET. CLOSE THE FUSE HOLDER
ISOLATORS ONLY IF THE CPS IS POWERRED ON OR IN STAND-BY CONDITION.
Battery Cabinets can be installed in series for extended runtimes. Connect the Battery Cabinets in series as shown in the figure
below:
CPS –BATTERY CABINET CONNECTION
ATTENTION:
The CPS is not equipped with devices for the disconnection of the external batteries. Verify that the Battery
Cabinets are fitted with a suitable fuse and/or fuse disconnector.
To prevent damage occurring to the batteries, the fuse holders must only be closed if the battery voltages between
the CPS and the Battery Cabinet are similar. Otherwise, recharge each battery unit following the procedure below:
CONFIGURING THE RATED BATTERY CAPACITY
Before installing one or more Battery Cabinets, the CPS must be configured in order to update the rated capacity value (total
Ah CPS's internal batteries + external batteries) using the dedicated configuration software.
The Battery Cabinet must only be installed while the CPS is switched off and disconnected from the mains power supply.
CAUTION:
The connection cables cannot be extended by the user.
The maximum length of the connecting cables between the CPS (without internal batteries) and the Battery
Cabinet is 3 meters.
After connecting the CPS to its Battery Cabinets, insert the fuses and close the Battery Cabinet battery fuse
holders (SWBATT). Do not open the SWBATT fuses whilst the CPS is on.
It is recommended that you do not connect more than 5 Battery Cabinets in cascade to a single CPS. To increase
capacity, we recommend installing a Battery Cabinet with higher battery capacity.
